EASTMAN Kodak X-Omat 3000 RA PROCESSOR Setup guide

HEALTH IMAGING
© Eastman Kodak Company, 1999
{Diagnostics}{Production}{HealthImaging} Publication No. 5B6333
30SEP98
Supersedes 5B6333
NOV95
DIAGNOSTICS
for the
Kodak X-Omat 3000 RA PROCESSOR
Service Code: 3434

2 30SEP98 – 5B6333
PLEASE NOTE The information contained herein is based on the experience and knowledge relating to the
subject matter gained by Eastman Kodak Company prior to publication.
No patent license is granted by this information.
Eastman Kodak Company reserves the right to change this information without notice, and
makes no warranty, express or implied, with respect to this information. Kodak shall not be liable
for any loss or damage, including consequential or special damages, resulting from any use of
this information, even if loss or damage is caused by Kodak’s negligence or other fault.
This equipment includes parts and assemblies sensitive to damage from electrostatic
discharge. Use caution to prevent damage during all service procedures.
Description Page
Table of Contents
Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
All Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Fatal Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Non-Fatal Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Mechanical Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Transport Malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Artifacts and Wrong Film Densities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Wet Films . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Solution Levels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Internal Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Accessing the Internal Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
D1 Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
D2 Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
D3 Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Diagnostic Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
D1 Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
D2 Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
D3 Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Flowcharts for the Internal Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Printing Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Error Codes
5B6333 – 30SEP98 3
Section 1: Error Codes
Introduction
All Errors
Important
When you check an electrical component or BOARD, also check all the:
• connections and CABLES for the component or BOARD
• voltages from the POWER SUPPLY for the component or BOARD
Note
PROCESSORS with Serial No. 100500 and above have a 5000 BOARD with replaceable RELAYS K5001 through
K5006. RELAY K5006 is a spare RELAY that can be removed and used to replace RELAYS K5001 - K5005.
Fatal Errors
Overview The software on the 5000 MICROPROCESSOR BOARD controls and monitors the operation
of the PROCESSOR and continually checks for errors. When an error occurs, a description of
the error is displayed on the DISPLAY PANEL.
When 2 or more errors occur together, all the errors are displayed, but only 1 error is visible on
the DISPLAY PANEL at a time. The error with the highest priority is displayed first. You can
scroll through the list to view the other errors.
An error log on the 5000 BOARD records the last 100 errors that have occurred and the
number of times each error has occurred.
3 types of errors can occur:
• Fatal
• Non-Fatal
• Warning
Fatal and
Non-Fatal Errors Only qualified service personnel should repair both fatal and non-fatal errors
• Most fatal errors prevent optimum film processing.
• Most non-fatal errors do not prevent optimum film processing.
IMPORTANT:
When you service a PROCESSOR with a fatal or non-fatal error and you check an electrical
component or BOARD, also check all the:
• connections for the component or BOARD
• voltages from the POWER SUPPLY for the component or BOARD
Warning Errors Operators can repair warning errors. Normally, you can feed film into a PROCESSOR when a
warning error is displayed.
READY LED If any error prevents optimum film processing, the READY LED will de-energize. When the
LED de-energizes, you can feed film into the PROCESSOR but the image quality may not be
correct. Kodak recommends that you do not process film when the LED is de-energized.
Code Description Possible Malfunction Action
E001 Microcontroller error 5000 BOARD Install a new BOARD.

DIAGNOSTICS
4 30SEP98 – 5B6333
E002 Dryer over maximum
temperature
The maximum temperature
is 79 C (175 F).
Normally, the DRYER DC
OVER-TEMPERATURE
THERMOSTAT opens
beforetheDRYERreaches
this temperature.
DRYER THERMISTOR Check that the resistance at 25 C
(77 F) is approximately 10 KW.
SOLID STATE RELAY U3 that
controls the DRYER HEATER Check U3.
5000 BOARD Install a new BOARD.
E003 Loss of film accumulator
data link No communication with the 6000 BOARD De-energize and energize the PROCESSOR to automatically reset it.
BOOT PROM U6018 on the 6000
BOARD Install a new U6018.
6000 BOARD Install a new BOARD.
5000 BOARD Install a new BOARD.
E004 Inoperative transport See E041.
E005 Dryer over-temperature
thermostat open When this error occurs, the DRYER HEATER and BLOWER are disabled.
DRYER DC OVER-
TEMPERATURE THERMOSTAT Reset or install a new THERMOSTAT. If the THERMOSTAT opens again,
determine the cause of the over-
temperature condition. See E002.
E007 Developer thermistor
failure The DEVELOPER HEATER is disabled when this error occurs.
DEVELOPER THERMISTOR Install a new THERMISTOR.
E008 Fixer thermistor failure The FIXER HEATER is disabled when this error occurs.
FIXER THERMISTOR Install a new THERMISTOR.
E009 Dryer thermistor failure The DRYER HEATER is disabled when this error occurs.
DRYER THERMISTOR Install a new THERMISTOR.
E010 Analog-to-digital converter
failure All 3 HEATERS are disabled when this error occurs.
5000 BOARD Install a new BOARD.
Code Description Possible Malfunction Action

Error Codes
5B6333 – 30SEP98 5
E011 Developer Heater failure This error occurs when the 8000 CURRENT SENSE BOARD detects no
current through the DEVELOPER HEATER.
When the temperature of the
developer solution is too high, the
DEVELOPER HEATER
OVERTEMPERATURE
THERMOSTAT will open. The
THERMOSTAT will reset
automatically when the solution
cools.
Determine the cause for the high
developer temperature, and repair the
problem.
No continuity for the DEVELOPER
HEATER
The resistance should be
approximately 70 W.
Install a new HEATER.
SOLID STATE RELAY U1 that
controls the DEVELOPER
HEATER
Install a new U1.
The 5000 BOARD does not
energize the SOLID STATE
RELAY U1.
Check that LED DS4 on the 5000
BOARD is energized.If necessary,
install a new BOARD.
No AC power to the DEVELOPER
HEATER when both DS4 and DS9
are energized.
If the 5000 BOARD has removable
RELAYS, install a new RELAY K5004.
Otherwise, install a new 5000 BOARD.
8000 BOARD Install a new BOARD.
E012 This error occurs when the 8000 CURRENT SENSE BOARD detects no
current through the FIXER HEATER.
When the temperature of the fixer
solution is too high, the FIXER
HEATER OVERTEMPERATURE
THERMOSTAT will open. The
THERMOSTAT will reset
automatically when the solution
cools.
Determine the cause for the high fixer
temperature and repair the problem.
No continuity for the FIXER
HEATER
The resistance should be
approximately 70 W.
Install a new HEATER.
SOLID STATE RELAY U5 that
controls the FIXER HEATER Install a new U5.
The 5000 BOARD does not
energize the SOLID STATE
RELAY U5.
Check that the LED DS1 on the 5000
BOARD is energized. If necessary,
install a new BOARD.
No AC power to the FIXER
HEATER when both DS4 and DS9
are energized.
If the 5000 BOARD has removable
RELAYS, install a new RELAY K5004.
Otherwise, install a new 5000 BOARD.
8000 BOARD Install a new BOARD.
E013 Level Sensor circuit failure This error occurs when the circuit on the 5000 BOARD for the LEVEL
PROBE malfunctions. The following parts are disabled:
• DEVELOPER and FIXER REPLENISHMENT PUMPS
• RECIRCULATION PUMP
5000 BOARD Install a new BOARD.
Code Description Possible Malfunction Action

DIAGNOSTICS
6 30SEP98 – 5B6333
E014 Invalid program software E014 is displayed on the DEVELOPER TEMPERATURE DISPLAY. This
error disables all subsystems, except communications.
The main program software in the
EEPROM on the 5000 BOARD Download new software.
E015 Invalid bootstrap software The bootstrap software for the
PROM U5006 on the 5000 BOARD Install a new U5006.
E016 Invalid film accumulator
software This error does not disable any subsystems. The PROCESSOR will remain in the standby mode until the FILM DETECTOR SWITCHES actuate. These
SWITCHES provide information about the length of the film. Because the
6000 BOARD does not operate correctly, the PROCESSOR uses the
information from the SWITCHES to determine the replenishment rate.
The main program software in the
EEPROM on the 6000 BOARD Download new software.
Code Description Possible Malfunction Action

Error Codes
5B6333 – 30SEP98 7
Non-Fatal Errors
Code Description Possible Malfunction Action
E032 Developer tank fill error This error will occur if the:
• DEVELOPER TANK:
– does not fill in 4 minutes in normal operation.
– does not fill in 15 minutes in the Tank Fill Mode.
– is empty and the operator does not select the Tank Fill Mode.
• REPLENISHMENT TANK is empty.
• REPLENISHMENT HOSE has an obstruction.
• TANKS of the PROCESSOR are filled with water during the initial
installation.
The following parts will be disabled:
• DEVELOPER REPLENISHMENT PUMP
• RECIRCULATION PUMP
• Temperature control for the fixer and developer
To prevent the error from occurring during the initial installation:
• add 240 mL (8 fl oz) of developer to the DEVELOPER TANK before you
fill the PROCESSOR with water.
• energize the RECIRCULATION PUMP to move the developer and
remove any air bubbles. Use the diagnostics to energize the PUMP.
LEVEL PROBES Clean and check the PROBES.
The solution level in the
REPLENISHER TANK is low. Mix new developer solution.
Solution does not flow through the
HOSES between the
REPLENISHMENT TANK and the
REPLENISHMENT PUMP.
Check
• HOSE CLAMPS are tight
• HOSES:
– are round and opened
– have no obstructions or air
bubbles
The DEVELOPER DRAIN VALVE
is open. Close the VALVE.
SOLID STATE RELAY U2 that
controls the DEVELOPER
REPLENISHMENT PUMP
Check U2.
POPPET VALVES in the
DEVELOPER REPLENISHMENT
PUMP
Clean and check the VALVES.
DEVELOPER REPLENISHMENT
PUMP Check FUSE F1 and the REPLENISHMENT PUMP MOTOR B3.
The 5000 BOARD does not
energize the SOLID STATE
RELAY U2.
Check that the LED DS3 on the 5000
BOARD is illuminated. If necessary,
install a new BOARD.

DIAGNOSTICS
8 30SEP98 – 5B6333
Code Description Possible Malfunction Action
E033 Fixer tank fill error This error will occur if the:
• FIXER TANK:
– does not fill in 4 minutes in normal operation.
– does not fill in 15 minutes in the Tank Fill Mode.
– is empty and the operator does not select the Tank Fill Mode.
• REPLENISHMENT TANK is empty.
• REPLENISHMENT HOSE has an obstruction.
• TANKS of the PROCESSOR are filled with water during the initial
installation.
The following parts will be disabled:
• FIXER REPLENISHMENT PUMP
• RECIRCULATION PUMP
• Temperature control for the fixer and developer
To prevent the error from occurring during the initial installation:
• add 240 mL (8 fl oz) of fixer to the FIXER TANK before you fill the
PROCESSOR with water.
• energize the RECIRCULATION PUMP to move the fixer and remove any
air bubbles. Use the diagnostics to energize the PUMP.
LEVEL PROBES Clean and check the PROBES.
The solution level in the
REPLENISHER TANK is low. Mix new fixer solution.
Solution does not flow through the
HOSES between the
REPLENISHMENT TANK and the
REPLENISHMENT PUMP.
Check
• HOSE CLAMPS are tight
• HOSES:
– are round and opened
– have no obstructions or air
bubbles
The FIXER DRAIN VALVE is open. Close the VALVE.
SOLID STATE RELAY U2 that
controls the FIXER
REPLENISHMENT PUMP
Check U2.
POPPET VALVES in the FIXER
REPLENISHMENT PUMP Clean and check the VALVES.
FIXER REPLENISHMENT PUMP Check FUSE F1 and the
REPLENISHMENT PUMP MOTOR B4.
The 5000 BOARD does not
energize the SOLID STATE
RELAY U4.
Check that the LED DS2 on the 5000
BOARD is illuminated. If necessary,
install a new BOARD.

Error Codes
5B6333 – 30SEP98 9
Code Description Possible Malfunction Action
E038 Loss of developer cooling
ability Water does not enter the WASH TANK. Check • that water is supplied to the
PROCESSOR
– The water supply is turned on.
– The FILTER is clean.
• WASH WATER SOLENOID L1
– The operation is correct.
– The SCREEN has no
obstructions.
• DEVELOPER COOLING
SOLENOID L2
• QUICK DISCONNECT
The temperature of the water
entering the WASH TANK is too
hot.
Decrease the temperature of the water
supply. The wash water must be a
minimum of 5.5 C (10 F) below the
setpoint of the developer.
HEAT EXCHANGER in the WASH
TANK Remove any obstructions from the EXCHANGER.
The 5000 BOARD does not
energize SOLENOIDS L1 or L2 Check that the correct LED on the 5000 BOARD is energized:
• DS16 for L1
• DS15 for L2
Check for 24 V DC at TERMINALS 1
and 2 on the:
• WASH WATER SOLENOID L1
• DEVELOPER COOLING
SOLENOID L2
If necessary, install a new BOARD.
There is AC power at the
RECIRCULATION PUMP, but the
PUMP does not operate.
Check the RECIRCULATION PUMP
MOTOR B5. If necessary, install a new
PUMP.
No AC power to the
RECIRCULATION PUMP. If the 5000 BOARD has removable RELAYS, install a new RELAY K5003.
Otherwise, install a new 5000 BOARD.
The WASH TANK CLIP is not fully
seated or is not installed. Check that the CLIP is fully seated. If necessary, install the CLIP.

DIAGNOSTICS
10 30SEP98 – 5B6333
Code Description Possible Malfunction Action
E040 Loss of dryer heating ability A PANEL or DRYER RACK is not
installed. Install the part.
SOLID STATE RELAY U3 that
controls the DRYER HEATER Check U3.
RELAY K1 that enables the
DRYER HEATER Check K1.
No continuity for the DRYER
HEATER Check that the resistance at 25 C (77 F) is approximately 16 W
DRYER OVER-TEMPERATURE
THERMOSTAT Reset the THERMOSTAT. If the THERMOSTATopensagain,determine
the cause of the high temperature. If
you cannot determine the cause of the
problem, install a new THERMOSTAT.
No continuity for the DRYER
HEATER THERMAL CUTOFF Check that the DRYER BLOWER operates correctly. Install a new
CUTOFF.
5000 BOARD:
• The 5000 BOARD does not
energize the SOLID STATE
RELAY U3.
• The RELAY K5001
malfunctions.
If the LEDs DS5 and DS6 on the 5000
BOARD are energized: If the 5000
BOARD has removable RELAYS,
install a new RELAY K5001. Otherwise,
install a new BOARD.

Error Codes
5B6333 – 30SEP98 11
Code Description Possible Malfunction Action
E041 Loss of transport speed
control
Note
This error occurs when the
transport speed is adjusted
for 10 seconds and the
speed is not within 7.6 cm/
min (3 in./min) of the
setpoint
When the PROCESSOR operates normally:
• The supply voltage from the QUAD POWER SUPPLY to the + and -
TERMINALS of the DRIVE MOTOR CONTROLLER is 24 V DC.
• NOTE: Voltage can vary significantly from one PROCESSOR to another.
The control voltage at Test Point MOTDRV on the 5000 BOARD is
approximately:
– 1.0 V DC for the Extended Speed
– 1.9 V DC for the Standard Speed
– 2.6 V DC for the Rapid Speed
– 3.4 V DC for the K/RA Speed
• Feedback pulses from the DRIVE MOTOR CONTROLLER at Test Point
MOTFB on the 5000 BOARD indicate the speed of the DRIVE MOTOR.
If the transport operates slower than the set speed, the
MICROPROCESSOR increases the control voltage approximately 25 mV
every second at Test Point MOTDRV on the 5000 BOARD. When the
voltage reaches 5 V DC, the MICROPROCESSOR stops increasing the
voltage.
5000 BOARD If the control voltage is not correct at
Test Point MOTDRV on the 5000
BOARD, install a new BOARD.
DC DRIVE MOTOR B6 or DRIVE
MOTOR CONTROLLER If B6 operates, but no pulses occur at Test Point MOTFB on the 5000
BOARD.
7000 BOARD Close the COVERS and check that the
7000 BOARD supplies the MOTOR
CONTROLLER with 24 V DC
(CONNECTOR P/J7003, PINS 1 and
10), and 5 V DC (CONNECTOR P/
J7003, PINS 4 and 10).
E042 Loss of accessory data link Loose connections Check all connections between any
accessory and the PROCESSOR.
5000 BOARD Install a new BOARD.
2000 BOARD Install a new BOARD.
E045 Display data link error CABLES between the 3000 and
5000 BOARD Check the CABLES.

DIAGNOSTICS
12 30SEP98 – 5B6333
Warnings
Code Description Possible Malfunction Action
E128 Top Cover not in place When this error occurs:
• the following function is disabled:
– film transport
• the following parts are disabled:
– DRYER HEATER
– BLOWER
TOP COVER is open. Close the TOP COVER.
INTERLOCK SWITCH
S4 Check S4. If necessary, install a new S4.
7000 BOARD Install a new BOARD.
E129 Tanks currently being filled When this error occurs:
• the following function is disabled:
– film transport
• the following parts are disabled:
– RECIRCULATION PUMP
– 3 HEATERS
– DRYER BLOWER
None None. This message will clear automatically.
E130 Replenish pumps disabled None Use the KEYPAD to select either Automatic or
Flooded Replenishment to enable the PUMPS.
E132 Developer under set
temperature None None. This message will clear automatically when the developer reaches the setpoint
temperature.
E133 Developer over set
temperature None None. This message will clear automatically when the developer reaches the setpoint
temperature.
E134 Dryer under set
temperature None None. This message will clear automatically when the DRYER reaches the setpoint
temperature.
E137 Film accumulator LED
error 6000 BOARD • Check that no chemical deposits are on the PROTECTIVE COVER for the BOARD.
• De-energize and energize the PROCESSOR
to reset it.
• Check the BOARD. Use the internal
diagnostics.
• If necessary, install a new BOARD.
E141 Low developer tank level When this error ocurs:
• the RECIRCULATION PUMP is disabled.
• the temperature control for the fixer and developer is disabled
None This error will clear automatically when the
developer solution reaches the correct level.

Error Codes
5B6333 – 30SEP98 13
E142 Low fixer tank level When this error ocurs:
• the RECIRCULATION PUMP is disabled.
• the temperature control for the fixer and developer is disabled
None This error clears automatically when the fixer
solution reaches the correct level.
Code Description Possible Malfunction Action

DIAGNOSTICS
14 30SEP98 – 5B6333
Section 2: Mechanical Diagnostics
Transport Malfunction
Possible Cause Check
RACK and CROSSOVER
ASSEMBLIES RACK and CROSSOVER ASSEMBLIES:correct positionsseated correctly
• squareness
– SeetheAdjustmentsandReplacements,PublicationNo.5B6331,
RACKS and CROSSOVERS. Adjusting the Squareness of the
CROSSOVERS Adjusting the Squareness of the RACKS
• cleaned completely
– See the Preventive Maintenance, Publication No. 5B6746.
CROSSOVER TROUGHS
• correct positions
WASH RESERVOIR
• installed correctly
ROLLER ASSEMBLIES ROLLERS
• correct positions
• rotate freely
• GUDGEONS
– no damage
– If necessary, install new ROLLERS.
GEARS, SPROCKETS, and IDLERS
• engage correctly
• not broken or worn
BEARINGS
• no wear
SPRINGS and E-RINGS
• not broken or missing
RACK ASSEMBLY
• DRIVE CHAIN
– tension
DRYER AIR TUBE BAFFLES
• installed
Temperature setting of the DRYER lowest possible setting to provide the
best image quality
•
DRYER RACK and TOP EXIT RACK
• seated correctly
LOCKING TABS
• correct positions
DRIVE GEAR on the DRYER RACK
• no damage
TOP COVER TOP COVER
• closed

Mechanical Diagnostics
5B6333 – 30SEP98 15
Artifacts and Wrong Film Densities
Possible Cause Check
Replenishment system Replenishment rates
• correct setting
HOSES
• opened and round
• no obstructions
or air bubblesHOSE CLAMPS
• tight
REPLENISHMENT PUMP
• operation
• calibration
Replenishment chemicals
• Change any chemicals that are:
– not mixed correctly
– exhausted
– contaminated
Note
When you mix chemicals:
• Mix a maximum of a 2-week supply of the DEVELOPER
RELENISHER.
• Follow all directions for mixing chemicals and solutions.
• Use a SPLASH GUARD and DRIP TRAY when you remove the
FIXER RACK from the PROCESSOR to prevent contamination of the
developer.
DEVELOPER and FIXER TANKS
• DRAIN VALVES
– completely closed
Recirculation system DEVELOPER and RECIRCULATION HOSES
• ORIFICES
– no obstructions
DEVELOPER FILTER
• If necessary, install a new FILTER.
Movement of the solutions at the surface of the PROCESSOR TANKS
when you energize the PROCESSOR and the TANKS are full.
• If the solutions do not move, check that the:
– HOSES have no obstructions or air bubbles in the recirculation
system
– RECIRCULATION PUMP operates
– DEVELOPER FILTER is clean and in the correct position

DIAGNOSTICS
16 30SEP98 – 5B6333
RACK and CROSSOVER
ASSEMBLIES RACKS and CROSSOVERS • correct positions
• seated correctly
• cleaned completely
– See the Preventive Maintenance, Publication No. 5B6746.
CROSSOVER TROUGHS and EVAPORATION COVERS
• correct positions
• TROUGHS
– clean
• TROUGH DRAINS
– no obstructions
WASH RESERVOIR
• installed correctly
ROLLERS ROLLERS
• clean and not scratched
• correct positions
• rotate freely
• GUDGEONS
– no damage
– If necessary, install new ROLLERS.
DETECTOR ROLLERS
• clean
GEARS, SPROCKETS, and IDLERS
• engage correctly
• no wear
BEARINGS
• no wear
SPRINGS and E-RINGS
• not broken or missing
DEVELOPER and FIXER RACK ASSEMBLIES
• DRIVE CHAINS
– correct adjustment of the tension
Drying system DRYER AIR TUBES
• clean
– If necessary, use a BOTTLE BRUSH and water to clean the
TUBES and SLOTS in the TUBES.
• BAFFLES
– installed
Temperature setting of the DRYER
• lowest possible setting to provide the best image quality
• exhaust for the PROCESSOR
– meets the specifications
– See the Site Specifications, Publication No. 5B6329.
Wrong water temperature Temperature of the water
• 4 - 29 C (40 - 84 F)
Possible Cause Check

Mechanical Diagnostics
5B6333 – 30SEP98 17
Wash water Water flows through the WASH RACK Holes in the WASH RESERVOIR
• clean
COVERS and PANELS TOP COVER
• closed
ACCESS PANEL
• installed
WET SECTION COVER
• correct position
Ventilation system Exhaust for the PROCESSOR
• meets specifications
• See the Site Specifications, Publication No. 5B6329.
External EXHAUST HOSE
• connected to the AIR EXHAUST
Internal EXHAUST HOSE
• connected to the AIR EXHAUST
Possible Cause Check

DIAGNOSTICS
18 30SEP98 – 5B6333
Wet Films
Possible Cause Check
Film and chemicals are not
compatible. Film • compatible with the selected cycle
Replenishment system Replenishment rates
• correct setting
HOSES
• opened and round
• no obstructions or air bubbles
HOSE CLAMPS
• tight
REPLENISHMENT PUMP
• operation
• calibration
Replenishment chemicals
• Change any chemicals that are:
– not mixed correctly
– exhausted
– contaminated
Note
When you mix chemicals:
• Mix a maximum of a 2-week supply of the DEVELOPER
RELENISHER.
• Follow all directions for mixing chemicals and solutions.
• Use a SPLASH GUARD and DRIP TRAY when you remove the
FIXER RACK from the PROCESSOR to prevent contamination of the
developer.
REPLENISHMENT TANKS
• quantity of solution
DEVELOPER and FIXER TANKS
• DRAIN VALVES
– completely closed
Recirculation system Movement of the solutions at the surface of the PROCESSOR TANKS
when you energize the PROCESSOR and the TANKS are full.
• If the solutions do not move, check that the:
– HOSES have no obstructions or air bubbles in the recirculation
system
– RECIRCULATION PUMP operates
– DEVELOPER FILTER is clean and in the correct position

Mechanical Diagnostics
5B6333 – 30SEP98 19
Drying system DRYER AIR TUBES
• clean
– If necessary, use a BOTTLE BRUSH and water to clean the
TUBES and SLOTS in the TUBES.
• BAFFLES
– installed
DRYER
• lowest possible temperature to provide the best image quality
DRYER AIR EXHAUST
• no obstructions
• installed correctly
– See the Installation Instructions, Publication No. 5B9330.
DRYER HEATER
• operates correctly
DRYER RACK and TOP EXIT RACK
• seated correctly
Wash water Water flows through the WASH RACK
Holes in the CROSSOVER TROUGHS
• opened
– If necessary, clean the holes to prevent an overflow of the water
from the TROUGHS into the DEVELOPER and FIXER TANKS.
Possible Cause Check

DIAGNOSTICS
20 30SEP98 – 5B6333
Solution Levels
Possible Cause Check
Replenishment system Replenishment rates:
• correct setting
HOSES
• opened and round
• no obstructions or air bubbles
REPLENISHMENT PUMP
• operation
• calibration
REPLENISHMENT TANKS
• quantity of solution
POPPET VALVES
• clean
• no damage
DEVELOPER and FIXER TANKS
• DRAIN VALVES
– no leakage
CROSSOVER TROUGHS
• correct positions
• TROUGHS
– clean
• TROUGH DRAINS
– no obstructions
