Eaton NZMB Series Manual

Electric current! Danger to life!
Only skilled or instructed persons may carry out the
following operations.
Lebensgefahr durch elektrischen Strom!
Nur Elektrofachkräfte und elektrotechnisch
unterwiesene Personen dürfen die im Folgenden
beschriebenen Arbeiten ausführen.
Tension électriquedangereuse !
Seules les personnes qualifiées et avertiesdoivent
exécuter les travaux ci-après.
¡Corriente eléctrica! ¡Peligro de muerte!
El trabajo a continuación descrito debe ser realizado
por personas cualificadas y advertidas.
Tensione elettrica: Pericolo di morte!
Solo persone abilitate e qualificate possono eseguire
le operazioni di seguito riportate.
触触电电危危险险！！
只允许专业人员和受过专业训练的人员进行
下列工作。
Электрический ток!Опасно для жизни!
Только специалисты или проинструктированные
лица могут выполнять следующие операции.
en
de
fr
es
it
zh
ru
Emergency On Call Service:Local representative (www.eaton.eu/aftersales)or [phone] (de,en) 1/9
Instruction Leaflet
Montageanweisung
Notice d’installation
Instrucciones de montaje
Istruzioni per il montaggio
安安装装说说明明
Инструкция по монтажу
11/15 IL01206006Z
(AWA1230-1916, AWA1230-2538)
NZMB(C)(N)(S)(H)(L)2(-4)-A(M)(S)…
NZMN(H)(L)2(-4)-VE(ME)…
(P)N2(-4)-…
NZMB(N)(H)(L)2-A(AF)…(-BT)-NA
NZMB(N)(H)(L)2-S…(-BT)-CNA
NZMN(H)(L)2-VE…(-BT)-NA
NZMN(H)(L)2-VEF…(-BT)-NA
NZMN(H)(L)2-SE…(-BT)-CNA
NZMN(H)2-ME...(-BT)-NA
N(S)2-…(-BT)-NA
Minimum Clearance space
for all models
Blowout direction in case
of a short-circuit
Ausblasrichtung
im Kurzschlussfall
Dégagement gazeux en
cas de court-circuit
Dirección de salida de los
gases en caso de cortocircuito
Direzione di estinzione in caso
di corto circuito
Направление продувки в
случае короткого замыкания
NZMB(C)2-A… ≦250 A
(P)N2(-4)-…
Blowout direction in case
of a short-circuit
Ausblasrichtung
im Kurzschlussfall
Dégagement gazeux en
cas de court-circuit
Dirección de salida de los
gases en caso de cortocircuito
Direzione di estinzione in caso
di corto circuito
Направление продувки в
случае короткого замыкания
90˚
90˚
90˚
90˚
ON
Trip
ON
Trip
35 mm (1.4”)
35 mm (1.4”)
f5 mm
(f0.2”)

ON
Trip
ON
Trip
a
f5 mm
(f0.2”)

a
mm inch
NZMB(C)2-A… 60 2.4
(P)N2(-4)-…351.4

2/9 Emergency On Call Service: Local representative (www.eaton.eu/aftersales)or [phone] (de, en)
11/15 IL01206006Z
Caution!
Theremoval or exchange of parts during mounting may become necessary.
Refer to installation instructions for proper assemblyand to maintain electrical clearances.
Vorsicht!
Für die Durchführung der beschriebenen Arbeiten kann das Entfernen oder der Austausch von Teilen
notwendig sein. Bitte alle Installations-Anweisungen beachten, um die erforderlichen Luft- und
Kriechstrecken nach demZusammenbau zu gewährleisten.
Attention !
L’enlèvementoù l’échangede certaines pièces pendant le montage est parfoisnécessaire.
Consultez l’instruction d’assemblagepour assurer une installation conforme auxnormes.
Atención!
Con el fin de llevar a cabo los trabajos descritos,puede ser necesario eliminar ocambiar alguna pieza.
Le rogamostenga en cuenta todas lasinstrucciones de instalación para asígarantizar laslíneas de fuga y
efluvio necesarias tras el montaje.
Attenzione!
Per l’esecuzione degli interventi descrittipotrebbe essere necessaria la rimozione o sostituzione di alcuni pezzi.
Attene rsi alle istruzioni d’installazione pergarantiredopo l’assemblaggio le viedi dispersione necessarie.
Осторожно!
При проведении описанных процедур может возникнуть необходимость демонтировать или заменить
детали.Для обеспечения надлежащих зазоров и вывода тока утечки,соблюдайте все инструкции по
монтажу.
UL/CSA models:
Follow diagrams below when making
connections using XKS screw
terminationsfor compressioncrimplugs:
–Always use terminal cover XKSA when
making connections with bare bus or
non-insulated crimplugs, or when two
wires perphase are connected.
To mount terminal cover XKSA, refer
to instruction sheet IL01206007Z
(AWA1230-2047).
ON
Trip
push
-NA
-CNA
(UL/CSA models)
Above 480 V, use of insulating plate Cat.No. IPXXX,
to be mounted under the breaker or switch, is
required.
en
de
fr
es
it
zh
ru
≧400 mm (≧ 16”)
10 mm (0.4”)
10 mm (0.4”)
22 mm (0.9”)
22 mm (0.9”)
22 mm (0.9”)
⌀8.5 mm
(⌀ 0.34”)
⌀8.5 mm
(⌀ 0.34”)
⌀8.5 mm
(⌀ 0.34”)
≦24 mm
(≦ 0.95”)
≦24 mm
(≦ 0.95”)
≦24 mm
(≦ 0.95”)
≦8 mm
(≦ 0.3”)
≦8 mm
(≦ 0.3”)
≦8 mm
(≦ 0.3”)
①②③
3pol M8 x 22
4pol
A = 95 mm2KS95-NZM7
A = 120 mm2KS120-NZM7
A = 150 mm2KS150-NZM7
A = 185 mm2NZM2-XKS185
A
n=Number of crimps
n=Anzahl der Pressungen
n = Nombre de sertissages
n=Número de compresiones
n=Numero delle crimpature
n = Числопрессований
n
2KS95-NZM7
2KS120-NZM7
2KS150-NZM7
2NZM2-XKS185
n
①②③
≧2 x 9 x 0.8 mm
≧2 x 0.35“ x0.03“
≧16 x 5mm
≧0.63“ x 0.2“
1x4 – 185 mm2
≦10 x 16 x 0.8 mm
≦10 x 0.63“ x 0.03“
≦20 x 5mm
≦0.8 x 0.2“
2x4 – 70 mm2
≦6 x 24 x0.5 mm
≦6 x 0.95“ x0.02“
1
ON
Z 2
ON
3
1
2
5 mm
14 Nm
(124 lb-in)
3
2
5 mm
2
ON
1

Emergency On Call Service:Local representative (www.eaton.eu/aftersales)or [phone] (de,en) 3/9
11/15 IL01206006Z
aBasic device – Grundgerät – Appareil de base –Aparato base – Apparecchio base – 基础设备 –Основное устройство
+Combination options – Kombinationsmöglichkeiten – Combinaisons possibles – Combinaciones posibles – Combinazioni possibili
组合方法 –Комбинационные возможности
*or–oder –ou–ó–oppure –或者 –или
aBasic device – Grundgerät – Appareil de base –Aparato base – Apparecchio base – 基础设备 –Основное устройство
+Combination options – Kombinationsmöglichkeiten – Combinaisons possibles – Combinaciones posibles – Combinazioni possibili
组合方法 –Комбинационные возможности
*or – oder –ou – ó – oppure –或者 –или
NZMB(C)2(-4)-A160(250)
XKSAEoder*XKP oder*XKSA
≦415 V ①+① ①
XKSAE oder*XKP oder*XKSA
≦525 V ①+① ①
XKSA
>525 V ①+① ①
NZM2(-4)-…300
XKSAEoder*XKP oder*XKSA
≦415 V ①+① ①
XKSAE oder*XKP oder*XKSA XKSAE oder*XKPoder*XKSA
≦525 V ①+① ① +
XKSA XKP oder*XKSA XKP oder*XKSA
≦690 V ①+①+①+
XKSAXKSA XKSA
>690 V ①+
f400 mm
(f16”)
f400 mm
(f16”)

4/9 Emergency On Call Service: Local representative (www.eaton.eu/aftersales)or [phone] (de, en)
11/15 IL01206006Z
Settings – Einstellung – Réglages –Parámetros– Regolazione – – Hастройка
NZMB(C)2-A… ≦300 A
(P)N2(-4)-…
NZMB(N)(H)(L)2-A(AF)…(-BT)-NA
NZMB(N)(H)(L)2-S…(-BT)-CNA
NZMN(H)(L)2-VE…(-BT)-NA
NZMN(H)(L)2-VEF…(-BT)-NA
NZMN(H)(L)2-SE…(-BT)-CNA
NZMN(H)2-ME...(-BT)-NA
N(S)2-…(-BT)-NA
UL/CSA = CU only, Ampacity per 75° C Table.
NZMB(C)(N)(H)(L)2(-4)-A(M)(S)…
NZM…2-A(AF)…-NA
NZM…2-S…-CNA
NZMB(C)(N)(H)(L)2(-4)-A(M)(S)…
NZM…2-A(AF)…-NA
NZM…2-S…-CNA Note: On certain models with
UL/CSA labeling the thermal
trip setting is fixed and only the
magnetic trip (instantaneous)
setting is adjustable.
Setting Iiwith DC = setting IiAC/1.35
Einstellwert Iibei DC = Einstellwert IiAC/1,35
Valeur de réglage Iiavec DC= valeur de réglage IiAC/1,35
Valor de respuesta Iicon DC =valore de respuesta IiAC/1,35
Valore di regolazione Iicon DC = valore di regolazione IiAC/1,35
Значение Iiпри постоянном токе = Iiпри переменном токе /1.35
✓+
XKSA
4
ON
Z 2
1.3 Nm
(11.5 lb-in)
1
ON
5 mm
2
22 mm
(0.87”)
22 mm
(0.87”)
F18 mm
(F0.7”)
F15 mm
(F0.59”)
1x 4 – 185 mm2≧2x9x 0.8mm
≧2x0.35“ x 0.03“
2 x 4 – 70 mm2
1 x AWG12 – 350 kcmil
Nm lb-in
14 > 10 mm2, > AWG8 123 AWG8
5≦10mm2,≦AWG8 44 AWG 8
1 2
Ii
Ir
1
2
F3 mm
ON
Trip
ON
Trip
Z 2
I >
Ir(A)
Thermal
Ii(A)
Magnetic
4
ii

Emergency On Call Service:Local representative (www.eaton.eu/aftersales)or [phone] (de,en) 5/9
11/15 IL01206006Z
NZMN(H)(L)2(-4)-VE(ME)…
-NA, -CNAUL/CSA Electronic Trip Circuit Breakers
Settings – Einstellung – Réglages – Parámetros – Regolazione – – Hастройка
NZM2-VE…-NA xx xx
NZM2-VEF…-NA –x xx
NZM2-SE…-CNA –– x–
I
r
[A], tr[s], Isd [A], tsd [ms]
Electronic Trip Circuit Breaker Adjustable settings
(In=Max. current rating)
Ir=Adjustable current setting (0.5– 1.0 x In) for Long Time Pick-up.
tr=Adjustable Long Time Pick-up Delay (2 – 20 sec.) factory set at 10 seconds.
Isd =Adjustable Short Time Pick-up (2 – 10 x Ir) factory set at 6 x Ir.
tsd = Short Time Pick-up Delay (0 – 1000 ms) factory set at 0 ms.
Note: Instantaneous Pick-up fixed at 12 x In.
Isd/n xIr Ir/n xIntr/s(6 xIr)tsd/ms
0,8
0,7 0,9
0,95
10 14
17
8
8
6
4
10
2
20
7
8
5
4
3
6
210
9
300
500
100
60
20
200
01000
750
0,6
0,5 1,0
Current Setting
Ir(C xIn)
Long Time Pick-up
Delay at 6xIr(sec)
Short Time Pick-up
(xIr) max = 8 xIr
Isd Irtrtsd
0,8
0,7 0,9
0,95
10 12
14
8
6
4
10
2
17
7
8
5
4
3
6
210
9
300
500
100
60
20
200
01000
750
0,6
0,5 1,0 20
Short Time Pick-up
Delay (millisec.)
1
1
2
F3 mm
ON
Trip
2
ON
Trip
Z 2
Isd
tsd
6 x Ir
t
r
tr= 20 s
tr= 2 s
Ir

6/9 Emergency On Call Service: Local representative (www.eaton.eu/aftersales)or [phone] (de, en)
11/15 IL01206006Z
M22-K10
M22-K01
M22-CK10
M22-CK01
Auxiliary Switches
HIA HINHIN -NA
-CNA
(UL/CSA)
Ith = Ie
aor –oder –ou – ó – oppure –或者 –или
Notes on mounting and wiring Auxiliary Switches for UL/CSA labeled models:
– M22-K(10)(01) have screw terminals.M22-CK(10)(01) have clamp terminals.
– Switch modules are snapped into place at the locations shown in the diagrams thatfollow.
–Switches will function as either „standard“ or „trip/alarm“contacts depending on their mounting location.
– Location „HIN“ refers to standard operation. Location „HIA“ refersto „trip/alarm“operation.
– Follow the numberingand wiring scheme provided above depending on the contact location and function. (N.O. or N.C.)
– Permissible contact configuration: 1HIAand/or2 HIN.
IEC
Ith = Ie
Note:
After mounting of the M22… switchis complete,check off the appropriate boxon theauxiliary switch
label provided on the side of the breaker or switch.
M22-K11
M22-CK20
M22-CK02
HIA
①①
HIN IEC
Ith = Ie
①or – oder – ou – ó – oppure – 或者 –или M22-CK11
①
M22-CK20
①
M22-CK02
4.14 4.12
4.13 4.11
①
1.14 1.12
1.13 1.11
①
1.24 1.22
1.23 1.21
①Ue(V) Ie(A)
600 AC 5 A
250 DC 1 A
Pilot Duty Ratings:
B 600, Q 300
Above 300 V AC
Same polarity
Ue(V) Ie(A)
AC-15115 4
2304
4002
5001
DC-13 24 3
42 1.7
60 1.2
1100.6
2200.3
4.14 4.12
4.13 4.11
4.14 4.24
4.13 4.23
4.22
4.21
4.12
4.11
1.14 1.44
1.13 1.43
…
1.42
1.41
1.12
1.11
…Ue(V) Ie(A)
AC-15115 4
2304
DC-13 24 3
42 1
60 0.8
110 0.5
2200.2
1
OFF
2
Z 2
3
a
or
oder
ou
ó
oppure
или
a4
HIA
HIN
HIN ￫PN2

Emergency On Call Service:Local representative (www.eaton.eu/aftersales)or [phone] (de,en) 7/9
11/15 IL01206006Z
M22-K10, M22-K01
(ScrewTerminals)
…K10: N. O. Contact
…K01: N. C. Contact
M22-CK10, M22-CK01
(Clamp Terminals)
M22-CK11, M22-CK20, M22-CK02
(Clamp Terminals)
5a
2
Z 2
0.8 Nm
(7 lb-in)
3
1
6 – 10 mm (0.24 - 0.4”)
2 x 0.75 – 2.5 mm2
2 x AWG 18 – AWG 14
UL/CSA=Cu only
5b
2 x 0.75 – 2.5 mm2
2 x AWG 18 – AWG 14
UL/CSA=Cu only 3
0.6 x 3.5
2
1
3
1
2
4
5c
a = 8 mm
(a = 0.3“)
1 x 0.5 – 1.5 mm2
1 x AWG20 – AWG16
2 x 0.5 – 0.75 mm2
2 x AWG20 – AWG18
a
6
ON
Trip
OFF
7
Z 2
1 Nm
(9 lb-in)

8/9 Emergency On Call Service: Local representative (www.eaton.eu/aftersales)or [phone] (de, en)
11/15 IL01206006Z
Dismounting –Demontage–Démontage – Desmontaje –Smontaggio–拆拆卸卸–Демонтаж
TEST 1
ON
Trip
ON
OFF
TEST 2
PN2-…(-AP)
ON
Trip
push to trip
tripped
3 mm
TEST 3
PN2-…
OFF
(= RESET)
HIA
HIN
HIN
2
3
1
3 mm

Emergency On Call Service:Local representative (www.eaton.eu/aftersales)or [phone] (de,en) 9/9
11/15 IL01206006Z
EatonIndustries GmbH, Hein-Moeller-Straße 7-11, 53115 Bonn, Germany
©2000 by Eaton IndustriesGmbH, www.eaton.eu/documentation All RightsReserved
11/15 IL01206006Z 10045159DHW
Printed in Germany (12/15)
Mounting – Montage – Montage–Montaje – Montaggio –安安装装–Монтаж
Wiringterminations circuit breaker type NZM…2…-NA (CNA)
Wiring terminations molded caseswitch typeN(S)2…-NA
Insulating plate, Cat. No. IPXXX
Mounting of insulating plate IPXXX, (shown shaded in the diagram)
is required on UL/CSA labeled models for all installations in which the
Line Voltage exceeds 480 V.
Mount as shown in diagram.
Connector Wire size WireMax.Tightening-
Type 75° CA-Rating Torque
NZM4-XKC 1 x AWG 12 – 350 kcmil Cu only 25014Nm (124 lb-in)
5 Nm (44 lb-in)
(AWG10)
NZM4-XKA 1 x AWG 6–350 kcmil Cu only 25030Nm (265 lb-in)
1) NZM4-XKS 1 x AWG 12 – 350 kcmil Cu only 25014Nm (124 lb-in)
2) Integrated
Auxiliary
Terminal
1 x AWG 12 – 18 Cu only 1.2 Nm (11 lb-in)
1) Connector Pads Type NZM2-XKS for Compression Crimp lugs supplied standard on all NZM2
circuit breakersand switches.
2) IntegratedAuxiliary Terminal on Barrel (Tunnel)Mechanical lug Connector Type NZM2-XKA only.
NZM...2...-NA
NZM...2...-CNA
N(S)2...-NA
> 480 V:
ON
Trip
Z 2
1.7 Nm
(15 lb-in)
4 x M4 x 85/20
3
2
2
1
NZM.2-4-...
NZM.2-...
70 mm (2.8”)
35 mm (1.4”)
145 mm (5.7”)
4 x M4 x 85/20
1.7 Nm (15 lb-in)
