Eaton FX6000 User manual

Intelligent Addressable Control Panel
FX6000 Installation and Operation Manual

2FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Contents
Contents
INTRODUCTION..............................................11
Project planning................................................11
SYSTEM DESIGN GUIDELINES .................................12
Guidelines ....................................................12
Loop lengths ..................................................12
Loop loading - total number of addresses............................12
Repeater Panels ...............................................12
Loop Loading System Verification ..................................13
COMPATIBLE EQUIPMENT .....................................13
Compatible callpoints ...........................................19
Compatible sounders and beacons .................................19
Base sounder. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Base sounder beacon ...........................................20
Visual Alarm Devices (VADs) ......................................21
Loop powered beacon...........................................21
Dedicated stand alone sounders...................................22
Interfaces.....................................................23
3 channel I/O devices ...........................................23
1 channel I/O device with mains rated switching ......................24
Zone monitor units .............................................25
4 way sounder circuit controller ...................................27
4-20mA interfaces ..............................................27
Micro interfaces................................................28
Technical input/output unit........................................29
Fan controller interfaces .........................................30
EQUIPMENT COMPATIBILITY ...................................31
Sensors ......................................................31
Call points ....................................................31
Sounders .....................................................31
Relay circuits ..................................................31
Relays/auto-dialers and auxiliary equipment ..........................32
Additional instructions for electromagnetic compatibility ................32

3FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Contents
SYSTEM OVERVIEW ..........................................33
Simple user interface ...........................................33
User configuration and maintenance facilities ........................33
Sophisticated sounder control facilities..............................33
Spur tolerant soft addressing .....................................34
Simple future expansion .........................................34
Integral power supply and battery..................................35
Optional printer ................................................35
Hinged lockable cover ...........................................35
TECHNICAL SPECIFICATION....................................36
Power supply (Approved EN54 pt 4) ................................36
Batteries .....................................................36
Inputs........................................................37
Outputs ......................................................37
Fault routing equipment .........................................37
Auxiliary relays.................................................38
Printer (Optional) ...............................................38
Mechanical specification .........................................39
Anti-tamper cover (Optional) ......................................39
Optional functions as per EN54 P2&4 ..............................40
Panel outputs..................................................40
Output fire alarm routing equipment................................40
Output to fire alarm protecting equipment ...........................40
Output to fault warning routing equipment ..........................41
Delays to outputs ..............................................41
Coincidence detection...........................................41
Alarm counter .................................................41
Optional auxiliary board VDS requirement. . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Optional functions as per EN54 P2&4 ..............................42
Optional Functions not approved to EN54 P2&4. . . . . . . . . . . . . . . . . . . . . . .44
CABLE & WIRING.............................................46

4FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Contents
INSTALLATION ...............................................48
Installation guide ...............................................48
Fixing details ..................................................49
Mounting the backbox...........................................49
Installing Cabling ...............................................49
External connections (Mains supply)................................50
Networking ...................................................51
Input/outputs ..................................................52
Panel inputs ...................................................52
Panel outputs..................................................52
Output fire alarm routing equipment................................53
Output to fault warning routing equipment...........................53
Auxiliary relay .................................................53
Auxiliary DC output .............................................53
MAINTENANCE ..............................................54
Daily inspection ................................................54
Weekly test ...................................................54
Quarterly .....................................................54
Annual test ...................................................54
Every 2-3 years ................................................54
Every 5 years..................................................54
Servicing .....................................................55
PANEL ASSEMBLY INFORMATION...............................56
Attaching the door ..............................................56
Installing a hinged cover .........................................57
Fitting printer paper roll ..........................................58
COMMISSIONING THE CONTROL PANEL SYSTEM .................59
Commissioning mode ...........................................59
Configuration ..................................................59
DB level check .................................................59
Sensor LED flashing ............................................59
Up/downloading using PC software ................................60

5FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Contents
Panel fault finding ..............................................61
PC COMMISSIONING SOFTWARE...............................62
Device input programming .......................................62
Non-Latching ..................................................63
Day / Night....................................................63
Cascading Delay ...............................................63
Allocate Zones/Devices ..........................................63
Sounder Trigger ................................................64
Delay Configuration .............................................64
MCP Override .................................................64
Allocation List .................................................64
Dependency detection ..........................................65
PANEL CONTROLS & INDICATORS ..............................66
Touch screen display ............................................68
Panel operation ................................................69
Public access level 1 ............................................70
Evacuate (Access level 2) ........................................71
Silence alarms .................................................71
Mute buzzer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Reset ........................................................72
Pre-alarms ....................................................73
Faults ........................................................73
Disabled devices ...............................................74
Enable/disable (Others menu) .....................................74
Print .........................................................76
Lamp test ....................................................76
Weekly test ...................................................77
Viewing events ................................................78
Check auto config ..............................................79
Replace device ................................................80
Test Device (Access Level 3)......................................81
Test zone .....................................................82
Sounder level test mode .........................................82
Global flashing LED On/Off .......................................83

6FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Contents
One man walk test .............................................84
Commission...................................................85
Load CDR from laptop...........................................85
Download CDR from laptop ......................................86
Auto learn ....................................................87
Erase log .....................................................88
System details .................................................89
Analogue level .................................................90
Printer settings ................................................91
Change panel number ...........................................92
Number of panels in network .....................................93
Screen cover ..................................................94
Programming I/O and sounders ...................................95
Sound settings.................................................96
Change date/time ..............................................97
Change text ...................................................98
Change zone text. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Change panel text .............................................100
Configure zones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Change user code .............................................102
Add zone ....................................................103
Delete zone ..................................................104
Add device...................................................105
Delete device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
Configure heat detectors........................................107
Network.....................................................108
Password protection ...........................................108
APPENDIX .................................................109
System wiring ................................................109
Detector base wiring (FXN720) ...................................110
Call point wiring (FXN501/FXN503) ................................111
Base sounder wiring (FXN538, FXN537)............................111
Loop powered beacon wiring (CAB382) ............................112
Wall sounder wiring (FXN538LPS, FXN539LPS) ......................112

7FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Contents
IP66 wall sounder wiring (FXN538LPSWP, FXN539LPSWP).............113
Base Sounder VAD (CASBB394) ..................................114
Wall Sounder VAD (CASB393)....................................115
IP66 Wall Sounder VAD (CASB393WP) .............................116
3 way input output unit (CIO351, CIO351S, CIO351SST)...............117
1 Channel mains rated I/O unit wiring (CMIO353) ....................118
Zone monitor unit wiring (CZMU352) ..............................119
Intrinsically safe zone monitor unit wiring (CZMU352-IS) ...............120
Shop monitor unit wiring (MSU840) ...............................121
Spur isolator wiring (CSI350).....................................122
4 Way sounder controller wiring (CSC354CPR).......................123
4-20mA interface wiring (CGI420, CIT420, CGI420R, CIT420R) ..........124
Micro zone monitor module wiring (JIU872).........................125
Micro input module wiring (MJIM) ................................126
Micro output module wiring (MJOM, MJOM-R, MJOM-S, MJOM-FC) ....127
Typical smoke management topology diagram .......................128
Grouped smoke management devices .............................128
EN54 Spec label positioning .....................................129
Battery disposal instructions .....................................129
CE marking ..................................................130
NOTES ....................................................131

8FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Contents
DOCUMENT UPDATE NOTES
S.No. Release / Change Notes Date
AFirst Release July 2019
BSecond Release December 2019
PROPRIETARY NOTICE
All data and information contained within this manual is of a proprietary nature.
Do not reproduce, transcribe, store in a retrieval system or translate into any
language, any part of this manual without the prior permission of ‘EATON‘. EATON
reserves the right to make changes to product specification without notice or liability.
Every care has been taken to ensure the accuracy of the information contained in
this manual, but no liability can be accepted for any errors or omission.
DISCLAIMER OF WARRANTIES AND LIMITATION OF LIABILITY
The information, recommendations, descriptions and safety notations in this
document are based on Eaton Corporation’s (“Eaton”) experience and judgment and
may not cover all contingencies. If further information is required, an Eaton sales
office should be consulted. Sale of the product shown in this literature is subject
to the terms and conditions outlined in appropriate Eaton selling policies or other
contractual agreement between Eaton and the purchaser.
THERE ARE NO UNDERSTANDINGS, AGREEMENTS, WARRANTIES, EXPRESSED
OR IMPLIED, INCLUDING WARRANTIES OF FITNESS FOR A PARTICULAR
PURPOSE OR MERCHANTABILITY, OTHER THAN THOSE SPECIFICALLY SET
OUT IN ANY EXISTING CONTRACT BETWEEN THE PARTIES. ANY SUCH
CONTRACT STATES THE ENTIRE OBLIGATION OF EATON. THE CONTENTS OF
THIS DOCUMENT SHALL NOT BECOME PART OF OR MODIFY ANY CONTRACT
BETWEEN THE PARTIES.
In no event will Eaton be responsible to the purchaser or user in contract, in tort
(including negligence), strict liability or other-wise for any special, indirect, incidental
or consequential damage or loss whatsoever, including but not limited to damage
or loss of use of equipment, plant or power system, cost of capital, loss of power,
additional expenses in the use of existing power facilities, or claims against the
purchaser or user by its customers resulting from the use of the information,
recommendations and descriptions contained herein. The information contained in
this manual is subject to change without notice.

9FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Contents
SUPPORT SERVICES
The goal of Eaton is to ensure your greatest possible satisfaction with the operation
of our products. We are dedicated to providing fast, friendly, and accurate assistance.
That is why we offer you so many ways to get the support you need. Whether it is
by phone, fax, or email, you can access Eaton’s support information 24 hours a day,
seven days a week. Our wide range of services is listed below. You should contact
your local distributor for product pricing, availability, ordering, expediting and repairs.
Website
Use the Eaton website to find product information. You can also find information on
local distributors or Eaton’s sales offices.
www.eaton.com
EatonCare Customer Support Center
Call the EatonCare Support Center if you need assistance with placing an order,
stock availability or proof of shipment, expediting an existing order, emergency
shipments, product price information, returns other than warranty returns, and
information on local distributors or sales offices.
Voice: 877-ETN-CARE (386-2273) (8:00 a.m. to 6:00 p.m. EST)
After-Hours Emergency: 800-543-7038 (6:00 p.m. to 8:00 a.m. EST)

10 FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Contents
Important Safety Information
Personnel who install, maintain or repair this equipment
must read the safety information below before
starting work.
Definitions and Symbols
WARNING
Indicates a potentially hazardous situation which, if
not avoided, can result in serious injury or death.
CAUTION
Indicates a potentially hazardous situation which, if
not avoided, can result in minor to moderate injury, or
serious damage to the product.
General Safety Precautions
NOTICE
The operating system of the control panel may be
revised as a result of enhancements to the system
software or hardware. Revisions to this manual will be
issued and supplied on request and should be logged
in the table supplied on the contents page.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY
AN INCORRECT TYPE DISPOSE OF THE USED
BATTERIES ACCORDING TO THE INSTRUCTIONS
(Appendix page 129).
This product must only be disposed of in
accordance with the WEEE directive.

11FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Introduction
Introduction
FX6000 provides all of the sophisticated features required of a leading edge analogue
addressable fire system along with the simple operation and neat installation
demanded by installers and building users.
The panel can be flush or surface mounted and the generously sized metal back box
allows ample facilities for rear or top cable entries. It is available in single two and
four loop versions, with or without an integral printer.
In addition both passive and fully functional repeater panels are available.
A comprehensive range of ancillary devices are available to operate with the panel,
including Optical, photo-thermal and heat sensors, base mounted and stand alone
sounders (including an IP67 version) a loop powered beacon and a wide
range of interfaces.
Each of the components has been specifically designed to operate as part of a
system, this provides an assurance that the panel, the sensors, the interfaces and
the ancillaries are all fully compatible with each other and that the full range of
system functionality is supported by each device.
Each loop of the control panel can accommodate up to 200 addresses, panels
are available in one, two or four loop format. Up to 126 panels can be networked
together to form a single system capable of operating with over 70,000 devices.
Project planning
The following is a typical program and timetable for an installation project, once the
initial order has been received:
1. Project meeting
Installer and user to be present; system specifications, schematic diagram and
proposed circuit drawing to be available. Installation & Commissioning Guide to
be provided.
2. Equipment fix
Typically two week’s notice is required for equipment to be delivered. Cable to be
installed and bases/back boxes to be fitted. Then fire sensors, call points,
alarm sounders, isolator units and interface units to be installed.
3. Address schedule
Schedule of sensor locations to be completed by installer and returned to enable
System programming.
4. Auto learn
Fire panel/repeater panels to be installed and terminated. System to be powered
up by installer and auto learn mode activated (see Auto Learn section). System to
be tested and verified by installer, prior to final commissioning.

12 FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
System design guidelines
5. Final commissioning
A minimum of two weeks notice is required from receipt of Address Schedule
and Commissioning request form for a Eaton Service Engineer to attend site and
implement/oversee the final commissioning procedures (see Commissioning
section), in conjunction with the installer.
System design guidelines
Guidelines
Systems should be installed to the relevant local standards and codes of practice,
for the UK this is BS5839 part 1. The panel meets all the relevant requirements
of BS5839 part 1: 2017. Installation planning is simplified by the fact that every
addressable device contains an integral short circuit isolator. Care must be taken to
ensure that local standards requirements regarding aspects such as loop coverage,
area covered by a single spur and cable specification are observed.
There may be certain applications in which deviations from the code may be
necessary and these must be listed on the commissioning certificate.
(See commissioning section)
Loop lengths
The maximum permitted loop length is 2 km measured from the near to the far
terminals on the panel motherboard PCB. There is no minimum limit to loop length.
Any wiring spurs off the loop must be included within the 2 km limit. On long loop
runs, the lengths of wiring rises and falls (between floors, down to manual call
points) must be included. Remember to include these especially when taking loop
lengths from plan drawings.
ote:N See loop loading system verification section below.
Loop loading - total number of addresses
The total number of addresses per loop is 200. this includes sensors, call points
and all other addressable items. When designing systems its recommended that
allowances are made for future expansion, Short circuit isolators are incorporated
into every panel loop device, including Smoke sensors, heat sensors, sounders,
callpoints and interfaces. Therefore, no further fault protection is required , in the
event of a single fault, none of the devices connected to the loop will fail to operate
as the fault will be isolated by the two adjacent devices. Spur connected devices
downstream of a cable fault will cease to function.
Repeater Panels
Each repeater unit requires one address and consumes no more current from the
loop than a smoke sensor. The repeater also requires a local mains supply and
incorporates battery backup.

13FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Compatible Equipment
Dimensions (mm) Product Codes
Description Length Width Height Model Reference Order Code
Addressable Control Panels
Addressable 2 Loop Control Panel 180 497 397 FX6000 FX60002
Addressable 2 Loop Control Panel
c/w Network Card 180 497 397 FX6000 FX60002NC
Addressable 2 Loop Control Panel
c/w Integral Printer 180 497 397 FX6000 FX60002P
Addressable 2 Loop Control Panel
c/w Integral Printer, Network Card 180 497 397 FX6000 FX60002PNC
Addressable 4 Loop Control Panel 180 497 397 FX6000 FX60004
Addressable 4 Loop Control Panel
c/w Network Card 180 497 397 FX6000 FX60004NC
Addressable 4 Loop Control Panel
c/w Integral Printer 180 497 397 FX6000 FX60004-P
Addressable 4 Loop Control Panel
c/w Integral Printer, Network Card 180 497 397 FX6000 FX60004PNC
Addressable Repeater Panels
Addressable Passive Repeater 92 332 270 FX6000PR FX6000PR
Addressable Passive Repeater c/w
Network Card 92 332 270 FX6000PRNC FX6000PRNC
Addressable Touch Screen Repeater 95 357 375 FTPR6000 FTPR6000
Addressable Detectors: Bases
Addressable Detector Base 104 104 22 FXN720 FXN720
Addressable Detectors: Point
Addressable Multi-Mode Heat
Sensor 100 100 44 FXN725 400003FIRE-0006X
Addressable Optical Smoke Sensor 100 100 34 FXN723 400002FIRE-0005X
Addressable Photo-Thermal Sensor 100 100 44 FXN722 400004FIRE-0007X
Addressable Detectors: Speciality
Addressable Reflective Beam
Detector 50-100m 120 130 210 MAB100R MAB100R
Loop Loading System Verification
Unless a loop loading calculation has already been carried out, please contact our
technical support department (01302 303350), before starting installation to verify
that a proposed loop loading arrangement is acceptable.
Compatible Equipment

14 FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Compatible Equipment
Dimensions (mm) Product Codes
Description Length Width Height Model Reference Order Code
Addressable Reflective Beam
Detector 5-50m 120 130 210 MAB50R MAB50R
Addressable Call Points
Addressable Manual Call Point 53 87 87 FXN501 FXN501
Addressable Manual Call Point
(Weatherproof) 53 87 87 FXN503 FXN503
Addressable Alarms and Beacons
Addressable Remote Indicator 49 87 87 MRIAD MRIAD
Addressable Beacon 53 95 95 FXN338BCN FXN338BCN
Addressable Ceiling VAD (Red
Plastic, Red Flash, Shallow Base) 37 93 93 CAB482CS 812037FULL-0214X
Addressable Wall VAD (Red Plastic,
Red Flash, Deep Base) 66 93 93 CAB482WD 812036FULL-0212X
Addressable Wall VAD (Red Plastic,
Red Flash, Shallow Base) 37 93 93 CAB482WS 812035FULL-0211X
Addressable Ceiling VAD (Red
Plastic, White Flash, Shallow Base) 37 93 93 CAB492CS 812050FULL-0269X
Addressable Wall VAD (Red Plastic,
White Flash, Deep Base) 66 93 93 CAB492WD 812034FULL-0210X
Addressable Wall VAD (Red Plastic,
White Flash, Shallow Base) 37 93 93 CAB492WS 812033FULL-0209X
Addressable Sounder Base 40 102 102 FXN538 FXN538
Addressable Sounder Base
(Australian Tone) 40 102 102 CAS380AU CAS380AU
Addressable Wall Sounder 96 105 105 FXN538LPS FXN538LPS
Addressable Wall Sounder
(Australian Tone) 96 105 105 CAS381AU CAS381AU
Addressable Wall Sounder
(Weatherproof, Australian Tone) 103 109 108 CAS381AU-WP CAS381AU-WP
Addressable Wall Sounder
(Weatherproof) 103 109 108 FXN538LPSWP FXN538LPSWP
Addressable Wall Sounder Beacon 95 105 105 FXN539LPS FXN539LPS
Addressable Wall Sounder Beacon
(Weatherproof) 105 108 108 FXN539LPSWP FXN539LPSWP
Addressable Wall Sounder VAD
(White Flash) 95 108 108 CASB393 CASB393
Addressable Wall Sounder VAD
(Open Class, Weatherproof) 105 110 110 CASB393WP CASB393WP

15FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Compatible Equipment
Dimensions (mm) Product Codes
Description Length Width Height Model Reference Order Code
Addressable Wall Sounder VAD
(Red Plastic, Red Flash) 92 106 147 CASB483 8500111FULL-0197X
Addressable Wall Sounder VAD (Red
Plastic, White Flash, Weatherproof) 100 111 151 CASB483WP 8500115FULL-0201X
Addressable Wall Sounder VAD
(Red Plastic, White Flash) 92 106 147 CASB493 8500110FULL-0199X
Addressable Wall Sounder VAD (Red
Plastic, Red Flash, Weatherproof) 100 111 151 CASB493WP 8500114FULL-0200X
Addressable Sounder Beacon Base 44 115 115 FXN537 FXN537
Addressable Sounder Beacon Base
(Bell Tone) 44 115 115 CASBB384-B CASBB384-B
Addressable Sounder VAD Base
(Open Class) 44 115 115 CASBB394 666129FULL-0198X
Addressable Interfaces
Addressable Door Release Module 60 180 130 CIOP-7273 CIOP-7273
Addressable 4-20mA Interface 57 147 88 CGI420 CGI420
Addressable 3 Channel I/O Unit
(Reset on Reset) 60 180 130 CIO351 CIO351
Addressable 3 Channel I/O Unit
(Reset on Silence) 60 180 130 CIO351S CIO351S
Addressable 3 Channel I/O Unit
(Triple Address) 60 180 130 CIO351SST CIO351SST
Addressable 4 Way Mimic Relay
Board (4 In, 4 Out) 88 252 180 CIOP4 CIOP4
Addressable 8 Way Mimic Relay
Board (4 In, 8 Out) 88 252 180 CIOP8 CIOP8
Addressable Micro Zone
Monitor Unit 18.5 35 65 JIU872 JIU872
Addressable 230V Relay I/O Unit 60 180 130 CMIO353 CMIO353
Addressable 4-Way Sounder
Controller 74 300 300 CSC354CPR CSC354CPR
Addressable Spur Isolator Unit 60 147 88 CSI350 CSI350
Addressable Zone Monitor Unit 60 147 88 CZMU352 CZMU352
Addressable Zone Monitor Unit
(Intrinsically Safe) 60 147 88 CZMU352-IS CZMU352-IS

16 FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Compatible Equipment
Dimensions (mm) Product Codes
Description Length Width Height Model Reference Order Code
Addressable Fan Controller (18
Channel, 19 " Rack Mount) 33 482 133 JFC18 JFC18
Addressable Fan Controller (6
Channel, Surface Mount) 43 161 126 JFC6 JFC6
Addressable Micro Single Channel
Input Unit 18.5 35 65 MJIM MJIM
Addressable Micro Single Channel
Output Unit 18.5 35 65 MJOM MJOM
Addressable Micro Single Channel
Output Unit (Fan Controller) 18.5 35 65 MJOM-FC MJOM-FC
Addressable Micro Single Channel
Output Unit (Reset on Reset) 18.5 35 65 MJOM-R MJOM-R
Addressable Micro Single Channel
Output Unit (Sounder) 18.5 35 65 MJOM-S MJOM-S
Addressable Shop Unit Monitor 57 147 88 MSU840 MSU840
Addressable Network and BMS
Single Mode Lon to Fibre
Optic Adapter 43 136 116 CFSFL01 CFSFL01
Dual Channel Lon to Fibre
Optic Adapter 43 136 116 CFSFL02 CFSFL02
Lon to RS232 Adapter
(connects panel network to PC) 135 116 36 EC0232 EC0232
Dual Channel LonWorks
BMS Interface 58 105 86 EC200 EC200
Dual Channel LonWorks
BMS Interface (for EC700) 58 105 86 EC200S EC200S
Addressable TCP/IP Interface 73 105 100 EC400 EC400
Addressable Lon Network Booster 73 110 106 EC540 EC540
Addressable BACnet Interface 73 110 106 EC650B EC650B
Addressable Modbus Interface 120 75 27 EC700 EC700
Addressable System Software
Graphical Visualisation Software -
10+ Panels c/w EC0232 interface N/A N/A N/A EFGVS11-PLUS EFGVS11-PLUS
Graphical Visualisation Software -
10+ Panels c/w TCP/IP interlink N/A N/A N/A EFGVS11-PLUS-TCPIP EFGVS11-PLUS-TCPIP
Graphical Visualisation Software -
Up to 2 Panels c/w EC0232 interface N/A N/A N/A EFGVS1-2 EFGVS1-2
Graphical Visualisation Software -
Up to 6 Panels c/w EC0232 interface N/A N/A N/A EFGVS3-6 EFGVS3-6

17FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Compatible Equipment
Dimensions (mm) Product Codes
Description Length Width Height Model Reference Order Code
Graphical Visualisation Software
- Up to 10 Panels c/w EC0232
interface
N/A N/A N/A EFGVS7-10 EFGVS7-10
Graphical Visualisation Software -
Up to 10 Panels c/w TCP/IP interlink N/A N/A N/A EFGVS7-10-TCPIP EFGVS7-10-TCPIP
Graphical Visualisation Software -
Designer, no panel connectivity N/A N/A N/A EFGVS-DESIGN EFGVS-DESIGN
Graphical Visualisation Software
- Premium Designer c/w EC0232
interface
N/A N/A N/A EFGVS-
PREMIUMDESGN
EFGVS-
PREMIUMDESGN
Sitemonitor/Webserver Software
c/w EC0232 interface N/A N/A N/A EF-SITEMONITOR EF-SITEMONITOR
Conventional Alarms and Beacons
Conventional Remote Indicator 30 87 87 FX251D FX251D
Conventional Remote Indicator
(Weatherpoof) 30 87 87 CIR301WP CIR301WP
Installation Accessories
Safety Power Supply (24V/1.5A) 175 300 22 SPS-2423 SPS-2423
Safety Power Supply (24V/2.5A) 175 300 22 SPS-2433 SPS-2433
Safety Power Supply (24V/4.5A) 175 300 22 SPS-2453 SPS-2453
Addressable Control Panel Spare Parts
Addressable Loop Splitter Unit 102 132 34 ZPCB2222 ZPCB2222
Addressable Loop Mimic LED PCB
(Master) 140 290 20 ZPCB2252-MML ZPCB2252-MML
Addressable Loop Mimic LED PCB
(Slave) 140 290 20 ZPCB2252-MSL ZPCB2252-MSL

18 FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Compatible Equipment
The range of compatible sensors for the control panel system consists
of the following:
Addressable Optical Detector, this is the
most commonly used detector and is most
suitable for detecting slow burning fires.
The status LED can be programmed to either
be permanently off under normal conditions
or to pulse in order to confirm that it is in
communication with the control panel.
Addressable Photo Thermal Detector, this is
the ideal detector for a multi-use environment
as it has an excellent response to smouldering
and fast burning fires. Photo/thermal detectors
can be programmed for thermal only operation
at certain times of day.
The status LED can be programmed to either
be permanently off under normal conditions
or to pulse in order to confirm that it is in
communication with the control panel.
Addressable Heat Sensor, this is suitable for
dusty environments or environments where
smoke is likely to be present under normal
operating conditions. The heat detectore can
be programmed to operate in A1R,BS or CS
mode of operation depending on the required
application and sensitivity requirements.
The status LED can be programmed to either
be permanently off under normal conditions
or to pulse in order to confirm that it is in
communication with the control panel.

19FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Compatible Equipment
Compatible callpoints
The range of purpose designed callpoints consists of a surface callpoint and a
surface weatherproof callpoint.
A range of accessories is available including a hinged protective cover, resettable
element kit and a flush bezel.
The status LED can be programmed to either be permanently off under normal
conditions or to pulse in order to confirm that it is in communication
with the control panel.
FXN501 FXN503
Compatible sounders and beacons
A wide range of loop powered sounders and beacons are available to operate with
the control panel, consisting of a combined sounder base with a maximum output of
95 dB(A), a standalone sounder with a maximum output of 100 dB(A) that is available
in standard or weatherproof versions and a stand alone loop powered beacon.
For applications where a discreet dedicated sounder is required, a cover plate is
available for the white base mounted sounder enabling it to be used as a stand alone
wall or ceiling mounted sounder.
All of these devices are fully programmable via the sophisticated multi-stage cause
and effect programming facilities.
All sounders have multiple selectable volume settings, the volume setting is
controlled by the panel and so can be altered without needing to access the sounder.

20 FX6000 INSTALLATION AND OPERATION MANUAL 25-14683-C December 2019 www.eaton.com
Compatible Equipment
Base sounder
The FXN538 has been designed specifically to complement the latest generation of
Eaton Fire Systems soft addressed detectors. It consists of a first fix bracket, and
a main body which clips onto the bracket incorporating the sounder and a detector
mounting base in a single composite assembly.
FXN538 FXN538 with Sensor fitted FXN538 with CASC fitted
After the body has been clicked into place and connected, a detector or front cover is
then added to complete a very simple quick and neat installation. The cover enables
the FXN538 to be used as a discreet stand alone wall or ceiling mounted device.
The sounder base design incorporates a mechanism that can be activated if required
to lock either the detector or the cover into place to prevent unauthorised removal.
Base sounder beacon
The FXN537 has been designed with the same fixing as the FXN538 so it can
accommodate either a detector or front cover being fitted.
