Eaton HMIVU04CUNBE Manual

HMiVU Series Instruction Leaflet
Instruction Leaflet IL04801003E Effective March 2013
Contents
Description............................................ Page
Preface.................................................1
Safety Precautions................................1
Installation.............................................3
Wiring ...................................................4
Basic Inspection....................................4
Hardware Features ...............................7
Panel Cut-Out.......................................17
Specifications........................................19

HMiVU Series Instruction Leaflet
EATON CORPORATION www.eaton.com 1
Preface
Thank you for purchasing Eaton’s HMiVU
series operator interface. This quick start
guide will be helpful in the installation, wiring
and inspection of your Eaton operator
interface. Before using the product, please
read this quick start guide to ensure correct
use. You should thoroughly understand all
safety precautions before proceeding with the
installation, wiring and operation. Please
observe the following precautions:
Install the product in a clean and dry
location free from corrosive and
flammable gases or liquids.
Ensure that all wiring instructions and
recommendations are followed.
Ensure that the operator interface is
correctly connected to a ground. The
grounding method must comply with
the electrical standard for the country
of final installation (NFPA 70: National
Electrical Code, 2005 Ed).
Do not modify or remove wiring when
power is applied to the operator
interface.
Do not touch the power supply during
operation or it may cause electric
shock.
For the information on HMiSoft
installation and use, please refer to
the HMiSoft manual at
www.eaton.com/oi.
If you have any questions during operation,
please contact an authorized local distributor
or Eaton sales representative. The content of
this quick start guide may be revised without
notice. Please consult an authorized
distributor or download the most up to date
version at www.eaton.com/oi.
Safety Precautions
Carefully note and observe the following
safety precautions when receiving, inspecting,
installing, operating, maintaining and
troubleshooting. The following words,
DANGER, WARNING and STOP are used to
mark safety precautions when using Eaton’s
operator interface. Failure to observe these
precautions may void the warranty!
Installation
Do not install the product in a
location that is outside the stated
specification for the operator
interface. Failure to observe this
caution may result in an electric
shock or fire hazard as well as
damage to the unit.
Do not install the product in a
location where temperatures will
exceed specification for the
operator interface. Failure to
observe this caution may result in
abnormal operation or damage the
product.
Please note that this equipment
has obtained EMC registration for
commercial use. In the event that
it has been mistakenly sold or
purchased, please exchange it for
equipment certified for home use.
Do not use this product as an
alarm device for disaster early
warning systems nor as a system
emergency stop as it may result in
personal injury and equipment
damage.
Wiring
Connect the ground terminals to a
class-3 ground (Ground resistance
should not exceed 100Ω).
Improper grounding may result in
communication error, equipment
damage, and electric shock or fire.

HMiVU Series Instruction Leaflet
EATON CORPORATION www.eaton.com 2
Operation
HMiSoft Screen Editor software
is the only software authorized
for creation and editing of
applications to be run on
Eaton’s HMiand HMiVU series
hardware.
To avoid personal injury and
equipment damage, the HMi
applications should be designed
so that a communication loss
results in a system fail safe
state.
It is good practice to backup the
HMiapplication in the event that
the operator interface is
damaged, the application is lost
or inadvertently deleted.
Modify wiring during operation
may result in electric shock or
personal injury.
Using a sharp or pointed object
to activate screen controls may
result in damage to the
touchscreen and improper
operation.
Wiring Method
Observe voltage specifications.
Failure to do so observe this
caution may result in electric
shock or fire as well as damage
to the unit.
Remove the terminal block from
the operator interface before
wiring.
Insert only one wire into each
terminal on the terminal block.
Communication Wiring
Comply with communication
wiring and grounding
specifications for the network
being used.
All power cables should be
placed in separate conduits from
communication cables in order
to avoid noise and interference.
Maintenance and Inspection
Electrical shock and damage to
unit may result from contact with
any internal electronic
assemblies.
First remove power and then
disconnect the terminals to avoid
electrical shock and damage to
unit.
Accessing the unit’s internal
electric assemblies will void the
warranty. In addition, an electrical
charge with hazardous voltages
may reside in the operator
interface after power has been
removed for 10 minutes or longer
which may result in electrical
shock and damage to the unit.
Turn the power off before
changing backup battery and
check system settings after
changes are made. Note that the
application and all data will be
cleared after a battery change.
Obstruction of ventilation holes
during operation may result in
malfunction caused by
overheating.

HMiVU Series Instruction Leaflet
EATON CORPORATION www.eaton.com 3
Installation
Installation Notes
The panel thickness should be 5 mm
or less for proper mounting.
Installation Method:
Step 1:
Ensure the pre-installed waterproof gasket is
present and properly aligned.
Step 2:
Insert fasteners into the operator interface slots.
All should be finger tight initially.
Step 3:
Torque all fasteners to 6.17lb-inch (0.7N-M)
Over torque may cause damage to the operator
interface housing.
Step 4:
Maintain a minimum spacing of 60mm from the
back of the operator interface ventilation holes.
fastener
16
16.3
20.4
Units: mm
Units: mm

HMiVU Series Instruction Leaflet
EATON CORPORATION www.eaton.com 4
Wiring
•Please observe the following wiring notes.
Use shielded twisted-pair cables for
wiring.
Recommended wiring:
Type
Wire
Gauge
(AWG)
Stripped
length
Torque
Solid
28 ~ 12
7 ~ 8 mm
5 kg-cm
(4.3 lb-in)
Stranded
30 ~ 12
7 ~ 8 mm
5 kg-cm
(4.3 lb-in)
Power supply connector:
Basic Inspection
Item
Content
General
Inspection
Periodically inspect the
screws of the connection
between the operator
interface and device.
Tighten screws as
necessary as they may
loosen due to vibration and
varying temperatures.
Ensure that oil, water,
metallic particles or any
foreign objects do not fall
inside the operator interface
ventilation slots and holes,
as this may cause damage
to the unit.
Ensure the enclosure is free
from harmful dust, gases,
and liquids.
Inspection
before system
operation
(power not
applied)
Ensure that all wiring
terminals are correctly
insulated.
Visually check to ensure
that there are no lose
screws, metal shavings, and
conductive or flammable
materials that may fall into
the operator interface.
Inspection
before system
operation
(power is
applied)
Confirm power LED lights.
Confirm communication
with devices.

HMiVU Series Instruction Leaflet
EATON CORPORATION www.eaton.com 5
Pin Definition for
Communications
HMIVU04CUNBE
COM1 Port (Supports Flow Control)
PIN
MODE1
MODE2
MODE3
COM2
COM3
COM2
COM3
COM2
COM3
RS-232
RS-485
RS-485
RS-485
RS-232
RS-422
1
D+
TXD+
2
RXD
RXD
3
TXD
TXD
4
D+
D+
RXD+
5
GND
GND
GND
6
D-
TXD-
7
RTS
8
CTS
9
D-
D-
RXD-
Note: Blank = No Connection.
HMIVU06CUNB1 / HMIVU07CUNBE
COM1 Port (Supports Flow Control)
PIN
Contact
RS-232
1
2
RXD
3
TXD
4
5
GND
6
7
RTS
8
CTS
9
Note: Blank = No Connection.
COM2 and COM3 Port
PIN
MODE1
MODE2
MODE3
COM2
COM3
COM2
COM3
COM2
COM3
RS-232
RS-485
RS-485
RS-485
RS-232
RS-422
1
D+
TXD+
2
RXD
RXD
3
TXD
TXD
4
D+
D+
RXD+
5
GND
GND
GND
6
D-
TXD-
7
8
9
D-
D-
RXD-
Note1: Blank = No Connection.
Note2: HMIVU06CUNB/HMIVU07CUNBE models
do not support RS-422 flow control function.
HMIVU08CUNBE / HMIVU10WCUNBE
COM1 Port (Supports Flow Control)
PIN
Contact
RS-232
1
2
RXD
3
TXD
4
5
GND
6
7
RTS
8
CTS
9
Note: Blank = No Connection.

HMiVU Series Instruction Leaflet
EATON CORPORATION www.eaton.com 6
COM2 Port (Supports Flow Control)
PIN
MODE1
MODE2
MODE3
RS-232
RS-422
RS-485
1
TXD+
D+
2
RXD
3
TXD
4
RXD+
5
GND
GND
GND
6
TXD-
D-
7
RTS
8
CTS
9
RXD-
Note1: Blank = No Connection.
Note2: When COM2 port is used for RS-232 flow
control, i.e. RTS and CTS signals are used for
flow control, COM3 port will become disabled.
Note3: When COM2 port is used for RS-422 with flow
control, COM3 Port pins 1, 4, 6, and 9 are
used for the signals, RTS+, CTS+, RTS- and
CTS- as shown in brackets.
COM3 Port
PIN
MODE1
MODE2
MODE3
RS-232
RS-422
RS-485
1
TXD+
(RTS+)
D+
2
RXD
3
TXD
4
RXD+
(CTS+)
5
GND
GND
GND
6
TXD-
(RTS-)
D-
7
8
9
RXD-
(CTS-)
Note1: Blank = No Connection.
Note2: When COM2 port is used for RS-422 with
flow control, COM3 Port pins 1, 4, 6, and 9 are
used for the signals, RTS+, CTS+, RTS- and
CTS- as shown in brackets.
Ethernet Port
Ethernet Port
PIN
Contact
Ethernet
1
TX+
2
TX-
3
RX+
4
5
6
RX-
7
8
Note: Blank = No Connection.

HMiVU Series Instruction Leaflet
EATON CORPORATION www.eaton.com 7
Hardware Features
HMIVU04CUNBE(Front View)
A
Power LED Indicator (Lights in green when power is applied.)
B
Touch Screen / Display
B
A

HMiVU Series Instruction Leaflet
EATON CORPORATION www.eaton.com 8
HMIVU04CUNBE (Rear View)
A
USB Slave
D
Ethernet Port
B
USB Host
E
COM1(Note1)
C
System Button
F
Power Input Terminal
NOTE
1. Refer to the Pin Definition for Communications section for simultaneous use of COM1 and COM2.
C
B
A
E
F
D

HMiVU Series Instruction Leaflet
EATON CORPORATION www.eaton.com 9
HMIVU06CUNB1 (Front View)
A
Power LED Indicator (Lights in green when power is applied.)
B
Touch Screen / Display
A
B
