Eaton Sirios O-SLED Manual

Sirios LED Emergency Lighting
Instruction and Operation Manual

3
Table of Contents
Installation - Maintenance
General Information
1. Safety information
2. Scope of Operation
3. General product information
4. Order codes
Installation instructions
5. Step by step mounting instructions
6. Connections and wiring
7. Light Distribution
Operating Instructions
8. Mains Operation
9. Emergency Operation
10. Autotest Operation
11. Dimensions
SAFETY INSTRUCTIONS
ŸThe device shall only be used for its intended purpose and in undamaged and
awless condition
ŸOnly genuine Eaton spare parts may be used for replacement and repair
ŸObserve the national safety rules and regulations to prevent accidents as well as
the safety instructions included in these instruction leaet
.......................................................................... 5
.......................................................................... 5
.......................................................................... 5
.......................................................................... 6
.......................................................................... 7
.......................................................................... 7
.......................................................................... 6
.......................................................................... 4
.......................................................................... 7
.......................................................................... 7
.......................................................................... 5
.......................................................................... 6
Sirios-LED Emergency Lighting 1-05-250-Sirios LED Instruction Leaflet (R1) - June 2014 www.eaton.com

A
C
230VAC
B230VAC
D
G:
G:
Y:
Y:
OK
TEST
DK
SLO
HR
VC
EE
LT
Sirios LED Emergency Lighting - Installation / Maintenance
4Sirios-LED Emergency Lighting 1-05-250-Sirios LED Instruction Leaflet (R1) - June 2014 www.eaton.com

Sirios LED Emergency Lighting - General Information
1. Safety Information
Observe the national safety rules and regulations to
prevent accidents as well as the safety instructions
included in these instruction leaet.
2. Scope of Operation
Sirios LED is range of emergency lights with low
prole, designed and equipped with technical solutions
and accessories for a wide range of applications such
as ofces, restaurants, hotels, hospitals and general
commercial applications
The range of accessories includes a recessed base for
installation to walls and false ceilings and an IP65
weatherproof kit.
Sirios LED front view
Sirios LED emergency lights are suitable for both
antipanic and up to 30m viewing distance exit sign
applications.
3. General Product Information
0%
12h
IP42
0
+40 C
0
+5 C
1h 100%
12h
24h charge for
optimal operation
recyclable parts complying
with WEEE directive
designed for indoor use
(for outdoor applications
use IP65 kit)
temperature range
0 0
+5 C to +40 C
class II
Light Source:
24 white LED 1.5W
Materials:
White polycarbonate base
and reector
Clear polycarbonate
diffuser
Operation:
Maintained & Non-
Maintained (user
selectable)
Autonomy 1h up to 3h
Functional test integrated
into the diffuser
Inhibition and Rest Mode
Autotest & slave models
available
Installation:
Wall and Ceiling
Installation kit for
recessed wall and ceiling
Base for quick mounting
(accessory)
Panel, double-sided
printed for reporting
security (optional)
Protection Kit IP65 for
outdoor use
Applications:
Schools, universities,
public
administration,
commercial
environments
5
O-SLED
O-SLED-3H
O-SLED-AT
O-SLED-AT-3H
O-SLED-MAINS
Sirios LED 2hours self-contained
Sirios LED 3hours self-contained
Sirios LED 1hour Autotest
Sirios LED 3hours Autotest
Sirios LED Mains
Order code Description
Accessories
O-SLED-STRIPE
O-S-WB
O-S-RB
O-S-IP
171-000-032
171-000-035
Led stripe accessory for Sirios LED
Wall mounting base
Recessed base
Weatherproof base
Vertical metal base (O-MP41)
Horizontal metal base (O-PU41)
Order code Description
4. Order codes
Sirios LED order codes
Sirios-LED Emergency Lighting 1-05-250-Sirios LED Instruction Leaflet (R1) - June 2014 www.eaton.com

13
Sirios LED Emergency Lighting - Installation instructions
click
click
1 2
34
5
6 7
8
10
11
12
7. Light Distribution
By changing the
orientation of the LED
strip you can adjust and
choose the light
distribution of Sirios LED
5. Step by step Mounting Instructions
L1
L
N
230VAC !
6. Connections & wiring
Summary
Led
position
Application
Exit Sign Antipanic Escape Route
Open (Λ)
Closed (ΙΙ)
Best*
Good
Best**
Good
Good
Best***
* Better uniformity on sign
** Bigger covering area,
*** Longer distance in smaller heights, lower illuminance
diversity along the route path
Open
position
(Λ)
suggested
application
for Escape
Route, up
to 9,5m in
4m height
Closed
position
(II)
suggested
application
for Anti-
panic
6
B+ / A-
click
click
Sirios-LED Emergency Lighting 1-05-250-Sirios LED Instruction Leaflet (R1) - June 2014 www.eaton.com

Sirios LED Emergency Lighting - Operating instructions
EX500
B+ A-
1-2,5
SWITCH
9. Emergency Operation
Telecommand wiring
Inhibition wiring
TLU500
B+ A-
1-2,5
10. Autotest Operation
Telecommand operation
7
Sirios LED
11. Dimensions
121mm
359mm
168mm
336mm
56mm
384mm
192mm
171mm
361mm
59mm
358mm
60mm
357mm
159mm
153mm
Sirios recessed base
Sirios weatherproof base
8. Mains Operation
Maintained operation
Functional test, every week (7x24h)
Duration test, every 10 weeks (70x24h)
Autotest indications
Manual test
L
N
L1
S1
L
N
L1
S1 L1
S1
ECO operation
S2
MAX
ECO
S2
ONLY @ MAINS
{
C6
SB
SA
1-2,5
A- B+
SB
SA
Maintain:
A- B+
A- B+
G:
G:
Y:
Y:
OK
TEST
Sirios-LED Emergency Lighting 1-05-250-Sirios LED Instruction Leaflet (R1) - June 2014 www.eaton.com
Max = 50mA (100%)
Eco = 33mA (66%)

Eaton is a registered trademark.
All other trademarks are property
of their respective owners.
Cooper Univel S.A.
Thessalonikis 88
60100 Katerini, Greece
© 2014 Eaton
All Rights Reserved
Printed in EU
Publication No. 1-05-250 (R1)
May 2014
