Eaton SPD Series User manual

Instruction Manual IM01005019E - rev. 8 Effective March 2021
Eaton SPD Series
surge protective device
for integrated applications
For additional information on the new PX-SPD
go to www.eaton.com/pxspd

Effective March 2021
ii Eaton www.eaton.com
Eaton SPD Series
surge protective device for integrated applications
Instruction Manual IM01005019E - rev. 8
Table of Contents
1.0 Introduction ...................................................................... 1
1.1 Manual organization .............................................................. 1
1.2 Product overview ................................................................ 1
1.3 Safety precautions ............................................................... 1
1.4 Catalog numbering system ........................................................ 1
1.5 Equipment testing ............................................................... 2
2.0 Installation ....................................................................... 2
2.1 Preparation for Installation ......................................................... 2
2.2 Installation locations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.2.1 Direct bus mount applications................................................... 3
2.2.2 Connected through a circuit breaker applications .................................... 3
2.3 Installation procedures............................................................ 3
2.3.1 Direct bus mount applications................................................... 3
2.3.2 Connected through a circuit breaker applications .................................... 5
3.0 Operating features................................................................. 7
3.1 General........................................................................ 7
3.2 Displays and indicators ........................................................... 7
3.2.1 Basic feature package ......................................................... 7
3.2.2 Standard feature package ...................................................... 8
3.2.3 Standard With Surge Counter Feature Package ..................................... 8
3.2.4 Power Xpert SPD feature package ............................................... 8
4.0 Power Xpert overview .............................................................. 9
4.1 SPD main menu selections ........................................................ 9
4.1.1 SPD status .................................................................. 9
4.1.2 Event log ................................................................... 9
4.1.3 Settings .................................................................... 9
4.1.4 Identification................................................................. 9
5.0 Power Xpert SPD user setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.1 General....................................................................... 10
5.2 Setup using only the local display .................................................. 10
5.2.1 Configuration of the user's laptop to communicate to PX-SPD ........................ 11
5.3 Power Xpert SPD Network Connection. ............................................. 12
5.3.1 Establishing a secure connection ............................................... 13
5.3.2 Upgrading firmware.......................................................... 15
5.3.4 Modbus and BACnet access ................................................... 18
5.3.5 Sensitivity setting ........................................................... 18
5.3.6 How to reset the PX-SPD password ............................................. 18
5.3.7 End of life disposal .......................................................... 18
6.0 SPD display rotation .............................................................. 20
7.0 Remote display panel (RDP) option ................................................... 20
8.0 IEC approved models ............................................................. 20
9.0 Troubleshooting .................................................................. 21
10.0 Troubleshooting the Power Xpert SPD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
11.0 Specifications ................................................................... 23
12.0 Ordering guidelines .............................................................. 25
13.0 Warranty ...................................................................... 26
Appendix A Power Xpert SPD local display surge events menu map............................ 27
Appendix B Power Xpert SPD local display event log menu map............................... 27
Appendix C Power Xpert SPD local display settings menu map................................ 28
Appendix D Power Xpert SPD local display identification menu map............................ 29
Appendix E Power Xpert SPD local display test sequence .................................... 30
Appendix F Power Xpert SPD Modbus register map ........................................ 31
Appendix G Web user error codes ...................................................... 35
Appendix H BACnet map.............................................................. 36

Instruction Manual IM01005019E - rev.8
Effective March 2021
Eaton www.eaton.com 1
Eaton SPD Series
surge protective device for integrated applications
1.0 Introduction
1.1 Manual organization
This installation manual describes the safe installation, testing
and operation of the Eaton®SPD Series surge protective device
(SPD).
1.2 Product overview
The Eaton SPD Series protects critical electrical and electronic
equipment from damage by power surges. This is done by
shunting high energy lightning surges (and other transient
disturbances) away from the equipment being protected. It does
this in nanoseconds by providing a low impedance surge path to
ground while supporting power frequency voltage.
The Eaton SPD Series is designed to mount on panelboards,
switchgear, switchboards, busway, and motor control centers
(MCCs). It is available with surge current capacity ratings from
50 to 400kA.
The Eaton SPD Series is available in four feature packages
(Basic, Standard, Standard with Surge Counter, and Power Xpert
SPD), as described in Section 3, "Operating features." Each
model is available in delta, high leg delta, wye, single phase and
split phase wiring configurations.
All Eaton SPD Series models have been tested and certified
by Underwriter’s Laboratory (UL®), to comply with UL 1449, 4th
edition.
Eaton’s One-Port low-voltage surge protective device wye
models SPD120480Y2C, SPD160480Y2C, SPD200480Y2C
and Delta Models SPD120480D2C, SPD160480D2C,
SPD200480D2C meet the requirements of IEC 61643-11 / EN
61643-11, part 11: test class II, and are intended to be installed
in indoor applications with a degree of protection rated IP 00.
1.3 Safety precautions
WARNING
WARNING – SHOCK HAZARD – DO NOT OPEN. AVERTISSEMENT:
RISQUE DE DECHARGE ELECTRIQUE – NE PAS OUVRIR.
WARNING NO SERVICEABLE PARTS.
ATTENTION: AUCUNE PIÈCE REMPLACABLE OU RÉPARABLE
A LICENSED/QUALIFIED ELECTRICIAN MUST COMPLETE ALL
INSTRUCTIONS IN THIS MANUAL IN ACCORDANCE WITH THE
NATIONAL ELECTRIC CODE (NEC®), STATE, AND LOCAL CODES, OR
OTHER APPLICABLE COUNTRY CODES. ALL APPLICABLE LOCAL
ELECTRICAL CODES SUPERSEDE THESE INSTRUCTIONS.
CONDUCTING DIELECTRIC, MEGGAR, OR HI-POTENTIAL TESTING
WITH THE SPD INSTALLED WILL CAUSE INTERNAL DAMAGE TO THE
SPD. THE SPD WILL CAUSE THE TEST TO FAIL.
WARNING
IMPROPER INSTALLATION COULD CAUSE DEATH, INJURY AND
EQUIPMENT DAMAGE. FOLLOW ALL WARNINGS AND CAUTIONS.
COMPLETELY READ AND UNDERSTAND THE INFORMATION IN THIS
INSTRUCTION MANUAL BEFORE ATTEMPTING TO INSTALL OR OPER-
ATE THIS EQUIPMENT.
ARC FLASH DURING INSTALLATION COULD CAUSE INJURY OR DEATH.
USE APPROPRIATE SAFETY PRECAUTIONS, PPE AND EQUIPMENT FOR
ARC FLASH PROTECTION.
INSTALLING A PROTECTION DEVICE WHICH IS UNDER RATED FOR
THE ELECTRICAL SYSTEM VOLTAGE CAN CREATE A POTENTIALLY
HAZARDOUS CONDITION.
CHECK THE FACILITY’S GROUNDING SYSTEM. ALL GROUNDING,
BONDING AND EARTHING PRACTICES MUST MEET NEC, CEC AND
LOCAL APPROVED PRACTICES. A POOR GROUND, OR A GROUNDING /
BONDING VIOLATION WILL SERIOUSLY AFFECT THE SPD’S ABILITY TO
FUNCTION AS SPECIFIED.
FOR USE ON CIRCUITS DELIVERING UP TO 200,000 RMS AMPS.
CONVIENT Á DES CIRCUITS PRODUCISANT AU PLUS 200,000 A EFF.
ALWAYS VERIFY THAT NO VOLTAGE IS PRESENT BEFORE
PROCEEDING WITH THE TASK AND ALWAYS FOLLOW ALL SAFETY
PROCEDURES.
1.4 Catalog numbering system
Each Eaton SPD Series unit has a name plate that identifies
the parameters used for manufacture. These parameters are
expressed in letters and numbers to reflect the series, kA
rating, voltage code, feature package, and application.
Table 1. Catalog numbering system
SPD 250 480D 2 J
For example, a 480 volt delta (3-wire plus ground) for use in
an MCC application requires an SPD model SPD 250480D2J,
where:
SPD = SPD model,
250 = the kA rating (50 – 400 kA),
480D = the voltage,
2 = the feature package (Basic, Standard, Standard with Surge
Counter, or Power Xpert SPD),
J = the application suffix (such as direct bus mounted in a
panelboard or connected through a circuit breaker).
These numbers also appear as part of the product label attached
to the front left side of the SPD. See Figure 1.
kA rating
Application
Feature package
Voltage codeSeries

Effective March 2021
2 Eaton www.eaton.com
Eaton SPD Series
surge protective device for integrated applications
Instruction Manual IM01005019E - rev. 8
Figure 1. Product label
1.5 Equipment testing
WARNING
CONDUCTING DIELECTRIC, MEGGER, OR HI-POTENTIAL TESTING
WITH THE SPD INSTALLED WILL CAUSE INTERNAL DAMAGE TO THE
SPD. THE SPD WILL ALSO CAUSE THE TEST TO FAIL.
Every Eaton SPD Series unit is tested at the factory for dielec-
tric breakdown. No further SPD testing is required for installa-
tion.
If you desire to test distribution equipment by performing
dielectric, megger, or hi-potential tests, any installed SPD must
be disconnected from the power distribution system to prevent
damage to the unit.
Follow this procedure to safely disconnect the SPD:
1. Remove bus connected SPDs completely from the
installation prior to performing any form of hi-potential
testing.
2. Isolate SPDs connected via conductors as follows:
a. 3-wire delta SPDs: Turn off the circuit breaker to
isolate the SPD, if connected through a circuit breaker.
b. Wye connected SPDs: Turn off the circuit breaker and
remove the neutral connection.
3. Remove MCC units with SPDs from the MCC structure.
2.0 Installation
WARNING
INSTALLING AN SPD THAT IS IMPROPERLY RATED FOR THE ELECTRI-
CAL SYSTEM VOLTAGE COULD CREATE A POTENTIALLY HAZARDOUS
CONDITION, RESULTING IN INJURY OR EQUIPMENT DAMAGE.
2.1 Preparation for Installation
CAUTION
EATON SPD SERIES PRODUCTS MUST BE INSTALLED OR REPLACED
BY A QUALIFIED ELECTRICIAN TO AVOID INJURY OR EQUIPMENT
DAMAGE.
Before installing an Eaton SPD Series unit, do the following:
• Verify that the area is clear of any dirt, debris or clutter that
may hamper the installation process.
• Verify that there is enough space in the cabinet or MCC to
install the SPD. See Section 2.3, "Installation procedures" for
dimensions.
• Confirm that all tools and equipment needed for the installa-
tion are available.
• Confirm that the system voltage and wiring configuration is
the same as the SPD you are installing. Check the voltage
rating label on the front left side of the SPD. See Figure 1.
WARNING
TURN OFF THE POWER SUPPLY BEFORE WORKING IN ANY ELECTRI-
CAL CABINET OR ON ANY CIRCUIT BREAKER PANEL. FAILURE TO DO
SO COULD RESULT IN INJURY OR DEATH FROM ELECTRICAL SHOCK.
NOTICE
A POOR GROUND, OR GROUNDING/BONDING VIOLATIONS, COULD
PREVENT THE SPD FROM PERFORMING AS SPECIFIED.
DO NOT USE THE SPD TO CARRY OR PASS THROUGH GROUND TO
OTHER DEVICES OR LEADS. DAMAGE TO THE EQUIPMENT MAY
RESULT.
• Check the facility grounding system. All grounding, bonding,
and earthing must meet the NEC, CEC and any other national,
state and local electrical codes.
2.2 Installation locations
Eaton's SPD Series can be installed directly to the bus for
panelboard applications.
The SPD can also be connected through a circuit breaker for
installations in panelboards, switchboards, switchgear, MCC’s
and busway applications.
Follow these guidelines to determine the best location for
mounting this product.

Instruction Manual IM01005019E - rev.8
Effective March 2021
Eaton www.eaton.com 3
Eaton SPD Series
surge protective device for integrated applications
2.2.1 Direct bus mount applications
• Install the SPD on the load side of the main breaker. Connect
the SPD directly to the bus located as close as possible to
the main breaker.
2.2.2 Connected through a circuit breaker applications
• Install the SPD next to the first breaker after the incoming
main lugs or main breaker.
2.3 Installation procedures
2.3.1 Direct bus mount applications
1. Verify that the SPD you are about to install is rated for the
application voltage and system. See Table 9 in Section 12,
"Ordering guidelines".
2. Follow all national, state and local electrical codes when con-
necting the SPD.
3. Before mounting the SPD, first determine the bus bar con-
figuration. If the panelboard uses an offset B-Phase bus bar
configuration, no action is required. If the panelboard uses a
coplanar bus bar configuration, remove the bus bar extension
bushing from the back of the SPD and discard. See Figure 2.
Figure 2. Bus bar extension bushing
4. Mount the SPD to the support brackets (customer
supplied) using #10 fasteners and tighten to 4.1 N∙m
(36 in-lbs). See Figures 3 and 4 for mounting details.
Figure 3. Dimensions for 50-200kA units
Figure 4. Dimensions for 250-400kA units
3.04 [77,2]
2.02
[51,18]
2.02
[51,18]
4.40 [111,76]
MOUNTING 8.80 [223,52]
3.42 [86,93]
TERMINALS 8.74 [222,0]
9.50 [241,3]
4.66
[118,4]
5.40
[137,1] MTG
3.42
[86,9]
0.04 [1,0]
0.95 [24,1]
BUS
0.34 [8,5]
4X MTG
0.19 [4,8]
2.52 [64,0]
3.45 [87,7]
0.26
[6,7]
3.42
[86,9]
3X 0.221 [5,61]
BUS MOUNTING
4X #10-32 X .38 DP
BRASS TERMINALS
4X 0.218 [5,54]
MOUNTING
Ethernet Port
Power Xpert SPD Only
3.42 [86,9]3.04 [77,2]
TERMINALS 8.74 [222,0]
9.50 [241,3]
MOUNTING 8.80 [223,5]
MTG
3.42
[86,9]
4.66
[118,4]
5.40
[137,1]
4X 0.218 [5,54]
MOUNTING
4X #10-32 X .38 DP
BRASS TERMINALS
4X MTG
2.52 [63,9]
3.42
[86,9]
0.26
[6,7] 4.85 [123,1]
5.78 [146,8]
Ethernet Port
Power Xpert SPD Only

Effective March 2021
4 Eaton www.eaton.com
Eaton SPD Series
surge protective device for integrated applications
Instruction Manual IM01005019E - rev. 8
5. Install the bus mount fasteners and tighten to 4.1 N∙m
(36 in-lbs). See Figure 5.
Figure 5. Bus bar extension bushing
6. Select the correct wiring diagram for the SPD you are install-
ing. You must refer to this diagram while wiring the SPD.
See Figures 6, 7, 8, 9 and 10.
Figure 6. Wiring - single phase units (230 L)
Figure 7. Wiring - split phase units
Ethernet Port
Power Xpert
SPD Only
Figure 8. Wiring - 3-phase delta units
Figure 9. Wiring - 3-phase wye units
Figure 10. Wiring - high leg delta units
ote:N Please consult the factory for 240 delta high leg (4W+G) applica-
tions with high leg on the ‘C’ phase.

Instruction Manual IM01005019E - rev.8
Effective March 2021
Eaton www.eaton.com 5
Eaton SPD Series
surge protective device for integrated applications
7. Connect the system ground wire (green) to the SPD’s surge
ground connection using a ring terminal suitable for use
with a #10 fastener and a #10-32 x 3/8” fastener (customer
supplied). Tighten the surge ground connection to 4.1 N∙m
(36 in-lbs). If the system uses an isolated ground, connect
the isolated ground wire to surge ground. There are two
surge ground connection points provided on the SPD.
Connect only one of them. See Figure 11.
Figure 11. Ground connection
8. If equipped, connect the system neutral wire (grey or white)
to the SPD. Connect the system neutral wire to the SPD’s
neutral connection using a ring terminal suitable for use
with a #10 fastener and a #10-32 x 3/8" fastener (customer
supplied). Tighten the neutral connection to 4.1 N∙m
(36 in-lbs). There are two neutral connection points provided
on the SPD. Connect only one of them. See Figure 12.
Figure 12. Neutral connection
9. The SPD (Standard, Standard with Surge Counter and Power
Xpert models) also have an available connection for remote
monitoring of the form C relay contacts. See Figure 13.
This is a green connector located on the side of the SPD. To
make the connection, remove the green connector and install
the remote monitor leads (connector supports 12-24AWG
wire). Fasten the remote monitoring wires to the N.O., N.C
and COM connection points per the label on the front of
the SPD. Contacts are rated: 150 Vac at 0.46A or 30 Vdc at
1A. Follow all national, state and local electrical codes. With
wiring complete, plug the green connector into the SPD.
Figure 13. Form C connection
10. The Power Xpert SPD also has an available 10/100 Base T/Tx
RJ45 Cat5e(min) STP interface port with ethernet Modbus
TCP/IP and a HTML5 web interface for remote monitoring of
the SPD. See Figure 14.
Figure 14. STP interface port
11. Install the dead-front panel to complete the installation.
2.3.2 Connected through a circuit breaker applications
1. Verify that the SPD you are about to install is rated for the
application voltage and system. See Table 9 in Section 12,
"Ordering Guidelines".
2. Follow all national, state and local electrical codes when
connecting the SPD.
3. Mount the SPD to the support brackets (customer supplied)
using #10 x 2-3/4" fasteners and tighten to 4.1 N∙m
(36 in-lbs). For 50-200kA models, see Figure 3 for mounting
dimensions. For 250-400kA models, see Figure 4 for mount-
ing dimensions.
ote:N Mount the SPD as close as possible to the circuit breaker.
Ethernet Port
Power Xpert SPD Only

Effective March 2021
6 Eaton www.eaton.com
Eaton SPD Series
surge protective device for integrated applications
Instruction Manual IM01005019E - rev. 8
4. Determine the wire length required to connect to the
breaker and cut phase wires to the appropriate length. (To
maximize SPD performance, wire length should be as short
as possible).
ote:N For wire lengths longer than 4", phase wires should
be twisted once for each 4" of wire length to maximize SPD
performance.
5. Connect phase wire to circuit breaker. NEC requires that
conductors to a surge device be protected by an overcurrent
protection device. The cables on the SPD are #10 AWG,
therefore would require a 30A 3-pole breaker. See Figure 15,
and the wiring diagrams shown in Figures 6, 7, 8, 9 and 10.
Figure 15. Phase connections
6. Connect the system ground wire (green) to the SPD’s surge
ground connection using a ring terminal suitable for use
with a #10 fastener and #10-32 x 3/8" fastener (customer
supplied). Tighten the surge ground connection to 4.1 N∙m
(36 in-lbs). If the system uses an isolated ground, connect
the isolated ground wire to surge ground. There are two
surge ground connection points provided on the SPD.
Connect only one of them. See Figure 11.
7. If equipped, connect the system neutral wire (grey or white)
to the SPD. Connect the system neutral wire to the SPD’s
neutral connection using a ring terminal suit able for use
with a #10 fastener and a #10-32 x 3/8” fastener (customer
supplied). Tighten the neutral connection to 4.1 N∙m
(36 in-lbs). There are two neutral connection points provided
on the SPD. Connect only one of them. See Figure 12.
8. The SPD (Standard, Standard with Surge Counter and Power
Xpert models) also have a connection available for remote
monitoring of the form C relay contacts. See Figure 13. This
is a green connector located on the side of the SPD. To make
the connection, remove the green connector and install
the remote monitor leads (connector supports 12-24 AWG
wire). Fasten the remote monitoring wires to the N.O.,
N.C. and COM connection points per the label on the front
of the SPD. Contacts are rated: 150 Vac at 0.46A, 30Vdc at
1A. Follow all national, state and local electrical codes. With
wiring complete, plug the green connector into the SPD.
9. The final step of the SPD installation depends on the specific
application. The various applications are listed below by
catalog suffix.
a. Suffix 'B': This is the remote display panel (RDP) option.
The RDP option requires the addition of a factory supplied
RDP cable. See Section 7, "Remote display panel (RDP)
option" for cable catalog numbers.
1. Install the RDP using cutout and mounting dimensions
provided in Figure 16.
Figure 16. RDP cutout and mounting
2. Connect the RDP cable to the SPD. Use tie wraps
(already on the SPD) to secure the cable to the SPD.
See Figure 17. Cable can be routed as a right or left
dress.
Figure 17. RDP to SPD connection

Instruction Manual IM01005019E - rev.8
Effective March 2021
Eaton www.eaton.com 7
Eaton SPD Series
surge protective device for integrated applications
3.0 Operating features
3.1 General
The Eaton SPD Series comes in four feature packages: Basic,
Standard, Standard with Surge Counter, and Power Xpert SPD.
The operating specifics of each feature package are described
below.
The Eaton SPD Series requires no operator involvement, other
than to monitor the display panel to determine status of the
SPD.
After system power is applied, the SPD automatically begins
protecting downstream electrical equipment from voltage tran-
sients.
Some SPD units have a form C relay contact that allows for
the remote indication of SPD status. Form C contact wires are
connected via a three terminal connector. See Figure 13.
3.2 Displays and indicators
All of the Eaton SPD Series units (Basic, Standard, Standard
with Surge Counter, and Power Xpert SPD) use a display panel
to indicate system status. The display panel is slightly different
for each feature package.
The display in features 1, 2 and 3 have both green and red light
emitting diodes (LEDs) to indicate the status of protection on
each phase. Green indicates the phase is fully protected. Red
indicates a loss of protection. Wye, split phase and high-leg
delta units have an additional set of green/red LEDs to indicate
status of neutral/ground protection.
The display in feature 4 has green, yellow and red illuminating
LEDs to indicate the status of protection in phases A, B and C.
Systems with a neutral wire will show the status of protection in
N-G mode.
When an LED turns red, an audible alarm will sound on units
equipped with an audible alarm.
For features 1, 2 and 3 push the alarm silence button to silence
the alarm. For the Power Xpert SPD push any of the four push-
buttons on the display to silence the alarm.
Specific operating conditions displayed for each Eaton SPD
Series feature package are described below.
3.2.1 Basic feature package
The Basic feature package has the following features:
• Green LEDs: Illumination indicates the phase is fully
protected, and operating normally, with all protection active
and available. Green LEDs also indicate neutral to ground
protection on units with a neutral wire. Green LEDs do not
indicate on/off status of power.
• Red LEDs: Illumination indicates a loss of protection, and that
one or more protective devices are now inactive and unavail-
able for that phase. Red LEDs also indicate neutral to ground
protection on units with a neutral wire. Red LEDs do not
indicate on/off status of power.
Figure 19. Basic feature package display
3. Connect the RDP cable to the display. Use tie wraps
(already on the RDP) to secure the cable to the RDP.
See Figure 18.
Figure 18. RDP cable to display connection
b. Suffix 'C': This unit is intended for use in panelboard,
switchboard, and busway applications.
1. Ensure that the dead-front or door has the appro-
priate cut-out to accommodate the SPD display. See
Figure 3 or Figure 4.
2. Install dead-front or door and secure.
c. Suffix 'J': This unit is intended for MCC applications that
require a NEMA 12 enclosure rating.
1. Ensure that the MCC bucket door has the appropriate
cut-out to accommodate the SPD display. See Figure
3 or Figure 4.
2. Place an appropriate NEMA 12 rated gasket around
the display opening on the inside of the door.
3. Install the door and secure.

Effective March 2021
8 Eaton www.eaton.com
Eaton SPD Series
surge protective device for integrated applications
Instruction Manual IM01005019E - rev. 8
3.2.2 Standard feature package
The Standard feature package has the following features:
• All the features of the Basic feature package.
• One form C relay contact rated at 150 Vac at 0.46A, 30Vdc at
1A.
• Normal operating conditions. N.O. = OPEN. N.C =
CLOSED.
• Loss of protection on any phase or loss of power. N.O. =
CLOSED. N.C. = OPEN.
• Audible alarm with an alarm silence button.
• EMI/RFI filtering.
Figure 20. Standard feature package display
3.2.3 Standard with Surge Counter feature package
The Standard with Surge Counter feature package has the
following features:
• All the features of the Standard feature package.
• LCD screen that displays surge count.
• Reset button to RESET the Surge Counter to zero.
Figure 21. Standard with Surge Counter feature package
display
3.2.4 Power Xpert SPD feature package
All features of the Standard with Surge Counter feature package
including advanced monitoring and communication.
• Display upgraded to a 20x4 character liquid crystal display
(LCD)
• Power Xpert Gateway (PXG900) with firmware version 4.6.4
and higher are Modbus TCP supported and configurable with
the ability to receive email notifications. Modbus TCP/IP must
be enabled on the PX SPD prior to use.
• LCD main menu options include the following:
• SPD status - surge event logs
• Event logs – all events including phase protection percent-
age, phase loss, alarm status, power on/off, and low,
medium and high level surges.
• Settings - includes device setup, changing the password
and the option of giving the device a unique name.
• Identification - information on the device.
• One form C relay contact rated at 150Vac at 0.46A, 30Vdc
at 1A. Normal operating conditions. N.O. = OPEN. N.C =
CLOSED. Loss of protection on any phase or loss of power.
N.O. = CLOSED. N.C. = OPEN.
• Audible alarm with push any button to silence.
• EMI/RFI filtering.
• Remote monitoring via web UI, Modbus TCP/IP or BACnet/IP
protocols. Modbus, BACnet and HTTP are initially disabled for
cybersecurity purposes.
• Phase surge event counters.
• Time/date stamp event logs.
• Green LEDs: Illumination indicates the phase is fully
protected (100%), and operating normally, with all protection
active and available. Green LEDs also indicate neutral to
ground protection on units with a neutral wire. Green LEDs
do not indicate on/off status of power.
• Yellow LEDs: Illumination indicates a partial loss of protection
(>1% to 99%), and that one or more protective devices are
now inactive and unavailable for that phase.
• Red LEDs: Illumination indicates a total loss of protec-
tion(0%), and that one or more protective devices are now
inactive and unavailable for that phase. Red LEDs do not
indicate on/off status of power.
• LCD technology is readable above -20°C, however surge
protection is fully functional to -40°C.
Figure 22. Power Xpert SPD display

Instruction Manual IM01005019E - rev.8
Effective March 2021
Eaton www.eaton.com 9
Eaton SPD Series
surge protective device for integrated applications
4.1.2 Event log
Includes the follow sub-menu selections.
All events - Up to 40 events which includes surges, power up,
power loss, protection reduced (%), protection loss, and alarm
silence with time and date stamps of when the event occurred
are viewable to the user.
Low, med and high level surges - Up to the last 20 date
stamped events.
4.1.3 Settings
A valid User password must first be entered and confirmed
before a user can access the following selections.
Set date and time – set the current time and date for accurate
date and time stamped events. (Automatically synced when
connected to a network.) Temperature variations and other
factors can affect accuracy. Also, if the unit has been without
power for an extended period of time the date and time will
have to be re-entered.
Set device name – name the device to distinguish it from other
devices on your network. Device name can be up to 20 alpha
numeric characters.
Start display test – cycles through the LED states and then
turns on and off the LCD pixels.
Change password – changes the device password. Requires a
6-digit numeric password.
Clear surges & logs – Clears all surge counts and event logs
Sensitivity setting – Increase or decrease the low surge sensi-
tivity. It is not recommended for the user to modify this setting
without first contacting Eaton Customer Support at
1-800-809-2772 or email [email protected].
Communications – configure Modbus TCP, ethernet, and
IP, subnet mask, and gateway addresses. BACnet must be
configured through the web UI. See Appendix F for the Modbus
register map. See Appendix H for the BACnet register map.
4.1.4 Identification
This section contains information about the device itself. It
includes the following:
• Catalog number
• Style number
• Date code
• Firmware version
• PCB serial number
• Device name
• MAC address
• Customer support information
This information is necessary when contacting customer
support concerning the device.
4.0 Power Xpert local display overview
The Eaton Power Xpert SPD feature package includes a 20x4
LCD module which on power up displays the device’s home
screen which includes the following: catalog number, device
name (which is editable by the user), time, and firmware version.
Figure 23. Power Xpert SPD home screen
To enter the main menu from the home screen, push the enter
key. The following selections will then appear on the screen.
The less than symbol “<” represents the cursor location and will
appear to the right of the selected menu category. Press the
down arrow to scroll down through the selections or press the
up arrow to move up. Press the enter button to select a menu
item or press the back button to return to the previous menu
screen.
Figure 24. Power Xpert SPD main screen
4.1 SPD main menu selections
The main menu consists of four menu selections.
4.1.1 SPD status
Includes the following sub-menu selections.
Surge events – which contains a subset of menu selections that
includes events that occurred on each phase, the level of the
surge event (low, med, high) on each phase, the total number of
surges on each phase and the total surges and their level (low,
med, high)
Protection level – percentage of surge protection remaining in
the device per phase.
Alarm status – status of the alarm “Protected” or “Active Alarm
Replace SPD”.

Effective March 2021
10 Eaton www.eaton.com
Eaton SPD Series
surge protective device for integrated applications
Instruction Manual IM01005019E - rev. 8
5.0 Power Xpert SPD user setup
5.1 General
The Eaton Power Xpert SPD can be set up using just the local
display or with a laptop, Cat 5e cable and a web browser.
Modbus, BACnet, and HTTP are initially disabled to provide
cybersecurity protection. Modbus can be enabled through the
LCD module or the web UI. BACnet and HTTP can only be
enabled through the web UI. The PX-SPD must be rebooted
after enabling Modbus or BACnet communications.
5.2 Setup using only the local display
Once the SPD has been powered up the device’s home screen
will appear on the local display. See below. The home screen
shows the catalog number of the device, the device’s name, the
time and the firmware revision.
Figure 25. Power Xpert home screen
Setting up the date and time
To set the current date and time, press enter to go to the main
menu.
Figure 26. Power Xpert main menu
Now scroll down the menu to settings by pressing the down
arrow button. The cursor “<” is located to the right of the menu
category selection. Position the cursor to the right of settings<
by pressing the down button twice and then press enter.
Figure 27. Move cursor to settings
Next, enter a 6-digit password by pressing the up button to the
desired first number, if you go past the number press the down
button. Then press enter to go to the next digit. Repeat the
process until all 6 digits have been entered. After all 6 digits
have been entered press enter to continue.
Figure 28. Password screen
Next, select the date and time category by pressing enter.
Figure 29. Select date and time
Next press the enter button to edit the date and time or the back
button to exit and return to the previous screen.

Instruction Manual IM01005019E - rev.8
Effective March 2021
Eaton www.eaton.com 11
Eaton SPD Series
surge protective device for integrated applications
Figure 30. Setting date and time
Press up to enter the month, then press enter to move to the
date selection. Press up to enter the date, then press enter.
Next press up to scroll to the current year. Press enter to move
to hours and repeat the process for minutes and seconds.
Finally press enter to save the settings and then return to the
previous screen. (Time will initially be displayed in UTC time on
the web UI. This can be changed through the web UI.)
Figure 31. Saving the date and time
5.2.1 Configuration of the user's laptop to communicate
to PX-SPD
Follow these steps to enter the IP and Subnet Address on the
user's laptop or PC.
1. In Windows applications, navigate to Network and Sharing
Center.
2. Click on Change adapter settings.
3. Left click on Ethernet and then right click to open the
window shown below. Then click on properties.
4. Click on Internet Protocol Version 4 (TCP/IPv4).
5. Click on properties.
6. On the General tab, select Use the following IP address:
a. Enter 192.168.1.10 for the IP Address.
b. Enter 255.255.255.0 for the Subnet Mask.
c. Enter 192.168.1.1 for Default gateway.
7. Click on OK button and then exit out of all these open
windows.

Effective March 2021
12 Eaton www.eaton.com
Eaton SPD Series
surge protective device for integrated applications
Instruction Manual IM01005019E - rev. 8
5.3 Power Xpert SPD Network Connection.
Plug one end of a Cat5e ethernet cable into the SPD and the
other into a laptop PC which is connected to a network. The
device comes from the factory with the default IP address listed
below but can also be set up for dynamic IP (DHCP) or a user
defined Static IP address.
Default IP address is: 192.168.1.254
Default user: admin
Default password: Admin*1
Open Google Chrome, or Internet Explorer 11.x or higher and
enter the fixed IP address 192.168.1.254 and then hit the enter
key.
This window will open.
Click on Advanced.
Click on “Proceed to…” near the bottom of the window.
The login screen shown below will open. Enter the default user
name and password shown above and hit the enter key.
Figure 32. Power Xpert login screen
The change password window will open. Enter the default pass-
word and then enter a new 6 digit alpha-numeric password and
then click OK. Save password in a secure location to access the
Web UI. If lost, contact Eaton’s Application Engineers, at 1-800-
809-2772, or email [email protected].

Instruction Manual IM01005019E - rev.8
Effective March 2021
Eaton www.eaton.com 13
Eaton SPD Series
surge protective device for integrated applications
Figure 33. Password screen
Then it will return to the overview screen.
Password security: The Power Xpert SPD is shipped with
factory default user authentication credentials to allow for initial
installation and configuration. However, factory default authen-
tication credentials are often well known, easily discoverable
and present a significant security risk; therefore, the admin user
name and admin password should be changed at installation to
increase cybersecurity protection.
1. Limit access to the PX-SPD to reduce cybersecurity risk.
2. The maximum number of users that can be setup is six.
3. User names should be 5 characters in length or more.
4. Password expiration is configurable, the default is set to 90
days.
5. Up to three users can access the PX-SPD simultaneously.
Admin users assign a role to new users from one of four possi-
ble roles under the User Management tab through the web UI.
Table 2. User role privileges
Role Description IP Addr Modbus TO User/ Pass Factory Reset Reboot
Admin All privileges R/W R/W R/W R/W R/W
Engineer Product
configuration
R/W R/W
Operator Read only R R
Viewer Read only R R
R – Read access
W - Write access
IP Addr – IP Address configuration
Modbus TO – Modbus timeout value
User/Pass – Username and password setup
PX-SPD enforces complex passwords and session time-out
through User Management tab in the web UI.
There are 4 levels of Password Complexity, defined as follows:
• Password complexity level – 0
• It should be at least 6 characters long
• It should not match with user name, full name or existing
password
• Password complexity level – 1
• It should be at least 8 characters long
• It should not match with user name, full name or existing
password
• It should contain at least 1 alphabetic and 1 numeric
character
• Password complexity level – 2
• It should be at least 12 characters long
• It should not match with user name, full name or existing
password
• It should contain at least 1 alphabetic, 1 numeric character,
1 special character, and 1 upper case alphabetic character
• Password complexity level – 3
• It should be at least 16 characters long
• It should not match with user name, full name or existing
password
• It should contain at least 2 alphabetic characters, 1 numeric
character, 2 special characters, and 1 upper case alphabetic
character.
Admin Users: It is mandatory to provide password complexity
level when creating a new user.
The change password window will open. Enter the default pass-
word and then enter a new 6 digit alpha-numeric password and
then click OK. Save password in a secure location to access the
Web UI. If lost, contact Eaton’s Application Engineers, at 1-800-
809-2772, or email [email protected].
5.3.1 Establishing a secure connection
After initial login, the user will notice that the address bar on
the web browser shows that the connection is Not secure, see
example below.
To obtain a secure connection, click on the network tab, then
click on download certificate.
Figure 34. Download certificate
Download the certificate file, cert.cer. Open the cert.cer file.

Effective March 2021
14 Eaton www.eaton.com
Eaton SPD Series
surge protective device for integrated applications
Instruction Manual IM01005019E - rev. 8
The install certificate window will then open and then click on
Install Certificate button.
Figure 35. Install certificate
Then the Certificate Import Wizard will open. Select current
user and then click next.
Figure 36. Certificate Import Wizard
In the next window click on ‘Place all certificates in the follow-
ing store’. Then click the browse button and then the select
certificate store window will open. Next select ‘Trusted Root
Certification Authorities’ from the menu and then click OK.
Then select next.
Figure 37. Certificate storage location
Then select finish in the window.
Figure 38. Certificate download finish

Instruction Manual IM01005019E - rev.8
Effective March 2021
Eaton www.eaton.com 15
Eaton SPD Series
surge protective device for integrated applications
Then select yes when the security warning window pops up.
Figure 39. Security warning window
If the import is successful you will receive a pop up window
notification as shown below.
Figure 40. Import successful
Logout of the device, close the browser, reopen the browser
and then re-enter the device's IP address using secure login
beginning with https:// followed by the device’s IP address. Once
logged in, the address on the toolbar should show the locked
padlock symbol similar to the one shown below.
Figure 41. Successful secure login
5.3.2 Upgrading firmware
To update the firmware in the Power Xpert SPD, go to the Eaton
website at www.eaton.com/PXSPD and download the latest
version firmware to a laptop or PC.
Connect the laptop to the Power Xpert SPD via an ethernet
cable and login to the SPD. Once logged in, scroll to the toolbar
on the left and select Firmware from the menu.
Figure 42. Select the Firmware tab
The window below opens and then select "OPEN CODEPACK".
Figure 43. Select "OPEN CODEPACK"
A window will open to allow the user to browse their hard drive
to the place where they saved the downloaded firmware. Select
the *.xml file and click open. The End-User License Agreement
window will appear. Check the “I agree to the terms of the
License Agreement” and then click accept. The firmware
update window will open and then click "Select Processor". The
firmware/code pack evaluation window will open and then click
on the box to the left of PX-SPD_MAIN_PROCESSOR and then
click Ok. A status window will open and show the status of the
download.
Figure 44. Select PX-SPD_Main_Processor
Figure 45. Firmware Update complete
Once the download has been completed the device will return to
the login screen.

Effective March 2021
16 Eaton www.eaton.com
Eaton SPD Series
surge protective device for integrated applications
Instruction Manual IM01005019E - rev. 8
Login to the device and click on the General tab and verify the
SNTP server 1 has a green circle around it, as shown below.
This verifies the device has synced with the network and will
provide accurate time stamped events.
Figure 46. SNTP sync confirmed when circled in green.
5.3.3 Viewing surge logs
To view surge logs hover over the toolbar and then click on logs.
(Modbus must be enabled in order to view surge and general
logs.)
Figure 47. Log screen
Next click on list of logs in the upper left corner of the window.
Figure 48. Select list of logs
A dropdown will open displaying the options available to the
user. Select the log of interest.
Figure 49. Logs that are available to view
Low, Medium and High Surge Logs display specific phase
surges that occurred in a particular surge category. General Log
displays phase protection reduction percentage, phase protec-
tion loss, alarm silenced, power on/off. Audit-Power Log displays
when the device restarted after a power loss. Audit-Fw-Update
Log displays code update history. Audit-User Log displays when
Users logged in and out of the device. Once in the log, a list of
logging events and their time stamps are displayed. The user
has the option of scrolling down through the list or exporting the
logs to a *.csv file using the Export Log button in the upper right
corner of the screen. In addition, the user can clear logs in that
particular log if they choose to do so.
General settings
The user will be prompted before either of these actions. Click
the 'X' in the top right of the window to cancel this action.
Figure 50. General settings
Syncing the internal clock.
Figure 51. Sync the internal clock

Instruction Manual IM01005019E - rev.8
Effective March 2021
Eaton www.eaton.com 17
Eaton SPD Series
surge protective device for integrated applications
Select the appropriate timezone from the dropdown list to the
right of Timezone. GMT-05:00 represents Eastern Standard Time,
GMT-06:00 represents Central Time, etc. Date format, with four
different date formats to choose from, and the time format.
Figure 52. Select time format
Device Actions has two options for the Admin user. Reboot or
Reset Device. Reboot is a soft reset, the micro controller will
power down and power up. Reset is a hard reset which will
reset the device to factory defaults. Either action can only be
conducted by an Admin user.
Figure 53. Device actions
The user will be prompted before either of these actions. Click
the "X" in the top right of the window to cancel this action.
Figure 54. Reboot device alert
The Admin user can modify timeouts, number of concurrent
sessions and the number of failed login attempts.
Figure 55. Modifying timeouts
In the network window the following options are listed.
Figure 56. Network tab options
The user can select the IP allocation method between three
options and the IP address is also displayed here. The IP alloca-
tion method change does not take effect until the unit has been
rebooted. The reboot command is available under General tab,
Device Actions. (Do not select the Factory Reset command or
the device will return to the factory default value with a static IP
address.)
IP Allocation Methods available:
• Statically Hardcoded (192.168.1.254) Factory default
• DHCP Allocated (Network assigned)
• Taken from NV (stored IP address)
ote:N The User must reboot the device after performing any of these
changes.

Effective March 2021
18 Eaton www.eaton.com
Eaton SPD Series
surge protective device for integrated applications
Instruction Manual IM01005019E - rev. 8
Communication setting changes require a reboot of the micro
controller to enable it.
Figure 57. Method of IP allocation
IP configuration changes require a reboot of the device
To initiate a soft reset from the WebUI, go to the general tab and
click on the down arrow across from reboot or reset device as
shown below.
Figure 58. Select on down arrow
Figure 59. Click on reboot device
Click OK to verify that you want to continue with this operation.
The LEDs on the display will turn off, then back on again to indi-
cate that this command has been implemented.
Figure 60. Confirm reboot
A pop up window opens to confirm the reboot.
Figure 61. Click on reload
5.3.4 Modbus and BACnet access
The PX-SPD supports Modbus TCP and BACnet/IP using the
ethernet port, both are initially disabled. Using Modbus
commands, the PX-SPD can be used to read real time param-
eters, events and logs from the connected SPD. You will need
a Modbus TCP capable application such as ModScan which act
as the Modbus primary and the SPD is the Modbus secondary.
Refer to Appendix F Modbus register map for details on avail-
able registers and their properties. Refer to Appendix H for the
BACnet register map.
5.3.5 Sensitivity setting
Attention: Eaton does not recommend the customer modify
the sensitivity setting without first contacting Eaton Customer
Support at 1 800 809-2772 or email [email protected]. Increasing
the sensitivity setting will reduce the number of low level surge
counts.
5.3.6 How to reset the PX-SPD password
To reset the Power Xpert SPD password through the local
display, the user must first access the concealed menu.To
gain access to the concealed menu return to the home screen,
then press the following buttons in order within 5 seconds: up,
up, down, down, back, back, enter, enter. This will take you to
the concealed menu. Follow the screen prompts to reset the
password. When this password reset command is activated the
local display and Web UI passwords are reset to their default
values. The Power Xpert SPD local display prompts the user for
a 6 digit numeric password to be entered before being able to
enter the settings menu. The web UI user name and password
returns to default:
User name: admin
Password: Admin*1
5.3.7 End of life disposal
Before disposing of this device go to Device Actions and select
Reset Device to clear logs of any data.
