EBN EZPPC70-2B-C1G User manual

User’s Manual
EZPPC70-2B-C1G
EZPOS70-2B-C1G

Copyrights
©2008 EBN Technology Corp. All rights reserved. The
information in this document is subject to change without
prior notice in order to improve reliability, design and
function and does not represent a commitment on the
part of the manufacturer.
This document contains proprietary information
protected by copyright. All rights are reserved. No
part of this manual may be reproduced by any
mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
All trademarks are property of their respective
owners
Liability Disclaimer
In no event will the manufacturer be liable for direct,
indirect, special, incidental, or consequential
damages arising out of the use or inability to use the
product or documentation, even if advised of the
possibility of such damages.
Regulatory Information
FCC Notices
i
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to
Part 15 of the Federal Communications Commission
(FCC) Rules. These limits are designed to provide
reasonable protection against harmful interference in
a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which
can be determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
• Increase the separation between the equipment
and the receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio or
television technician for help.
This device complies with Part 15 (A) of the FCC
Rules. Operation is subject to the following two
conditions:
1) this device may not cause harmful interference
and
2) this device must accept any interference received,
including interference that may cause undesired
operation.
NOTE: THE MANUFACTURER IS NOT
RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED
MODIFICATIONS TO THIS DEVICE. SUCH
MODIFICATIONS COULD VOID THE USER'S
AUTHORITY TO OPERATE THE DEVICE.
CE Notice
This device complies with EMC Directive
2004/108/EC issued by the Commission of the
European Community.
Copyrights

WEEE Notice
The WEEE mark applies only to countries within the
European Union (EU) and Norway.
This appliance is labeled in accordance with
European Directive 2002/96/EC concerning waste
electrical and electronic equipment (WEEE). The
Directive determines the framework for the return
and recycling of used appliances as applicable
throughout the European Union. This label is applied
to various products to indicate that the product is not
to be thrown away, but rather reclaimed upon end of
life per this Directive.
Contents
ii

Contents
Copyrights.................................................................................................i
Liability Disclaimer ...................................................................................i
Regulatory Information.............................................................................i
FCC Notices.......................................................................................................... i
CE Notice.............................................................................................................. i
WEEE Notice........................................................................................................ ii
Contents...................................................................................................iii
1. Features:...............................................................................................1
2. Unpacking the Box...............................................................................2
3. Hardware Setup....................................................................................3
3.1. Quick Tour .................................................................................................... 3
Front View...................................................................................................... 3
Front View...................................................................................................... 4
Back Panel I/O............................................................................................... 4
3.2. Peripherals Installation................................................................................ 5
Power Adapter ............................................................................................... 5
USB Mouse, USB Keyboard and USB ODD.................................................. 5
LAN Cable...................................................................................................... 5
Cash Drawer.................................................................................................. 5
D-Sub 9 Cable ............................................................................................... 6
MSR Installation............................................................................................. 6
3.3. Adjust View Angle (EZPOS Series only)..................................................... 8
3.4. Wall Mount Kit installation (EZPC Series only).......................................... 9
3.5. Turn on the Device..................................................................................... 10
4. Driver and Utility Installation ............................................................11
4.1. Before the installation.................................................................................11
4.2. Chipset Software Installation .....................................................................11
4.3. VGA Driver Installation .............................................................................. 13
4.4. LAN Driver Installation............................................................................... 15
4.5. Audio Driver Installation............................................................................ 16
4.6. Wireless LAN Driver Installation............................................................... 17
5. TouchKit Utility Quick Guide.............................................................19
5.1. Launch Touchscreen V7.3.COM................................................................ 19
5.2. User interface............................................................................................. 19
5.3. Serial Port Information .............................................................................. 20
5.4. Virtual Button Settings .............................................................................. 20
Virtual Button Option.................................................................................... 20
iii
Right Button Function .................................................................................. 21
Contents

Contents
iv
Right Button Automatic Mode....................................................................... 22
5.5. Feedback Sound ........................................................................................ 22
Feedback Sound Option .............................................................................. 22
Tone............................................................................................................. 23
Duration ....................................................................................................... 23
5.6. Screen Calibration ..................................................................................... 23
4 points, mode 1 .......................................................................................... 24
4 points, mode 2 .......................................................................................... 24
How to Use Event Selector.......................................................................... 25
6. I/O Definition.......................................................................................26
6.1. Power Connector ....................................................................................... 26
6.2. Serial Port................................................................................................... 26
6.3. COM............................................................................................................. 27
6.4. Cash Drawer............................................................................................... 27
7. Specification.......................................................................................29

1.
1. Features
Intel® low power consumption and high performance technology
Durable ultra-slim & robust die-casting aluminum chassis
4 x USB 2.0, 4 x RS-232, Gigabit Ethernet port (RJ-45), cash drawer port
(RJ-11) and 1 X parallel port equipped
Video Module (Optional)
Wireless LAN supported
Microsoft Windows series operation system (Windows XP Home Edition,
Windows XP Professional Edition and WEPOS) and open-source Linux
operation system supported.
Chapter 1 1

2.
2. Unpacking the Box
Verify that the box contains the following items.
1 Device X 1
2 Wall mount Kit x 1 (EZPPC series only)
3 Power Adaptor X 1
4 Power Cord X 1
5 Driver and utility CD X 1
6 Base Unit (EZPOS series only)
7 D-Sub 9 cable
Chapter 3 2

3.
3. Hardware Setup
3.1. Quick Tour
Front View
LED Indicator
The Power indicator will glow green when power is on.
The HDD indicator will blink green when the HDD is accessed.
The LAN indicator will blink green when transferring data though the LAN.
Chapter 3 3

Back View
Back Panel I/O
Note: For details of I/O ports on the back panel, please refer to Chapter
6 – I/O Definition..
Chapter 3
4

3.2. Peripherals Installation
Power Adapter
Connect the 4-pin output jack of the adapter to the DC 19V jack on the back panel
of the device.
USB Mouse, USB Keyboard and USB ODD
Connect your USB Mouse, USB Keyboard and USB ODD to USB ports on the
back panel of the device.
LAN Cable
Connect one end of RJ-45 LAN cable to the LAN port on the back panel of the
device, another end to your internet device.
Cash Drawer
Connect one end of RJ-11 cable to the Cash Drawer port on the back panel of the
Chapter 3 5

device, another end to your cash drawer.
D-Sub 9 Cable
1. Connect the female connector of the D-Sub 9 cable to the COM port on the
back panel of the device in the correct orient.
MSR Installation
1. Remove the two plastic covers from the device as shown below.
2. Loosen the six screws and open the chassis as shown below.
Chapter 3
6

3. Pass the MSR cable through the hole of the chassis as shown below.
4. Plug the MSR to the connector in the correct orient.
5. Tighten the four screws of the MSR assembly as shown below.
Chapter 3 7

6. Close the back panel and tighten the four screws on the back panel.
7. Finished.
3.3. Adjust View Angle (EZPOS Series only)
Adjust the device to the proper view angle.
Chapter 3
8

3.4. Wall Mount Kit installation (EZPC Series only)
1. Separate the wall mount kit.
2. Align the screw holes of the wall mount kit to the holes of the device and tighten the
four screws.
Chapter 3 9

3.5. Turn on the Device
1. Make sure all peripherals are connected properly.
2. Press and hold the power switch until the power indicator on the front panel
glow green.
Chapter 3
10

4.
4. Driver and Utility Installation
4.1. Before the installation
All installation procedures described below are based on Microsoft Windows XP.
1. Connect an external USB CDROM drive to the USB port and insert the
driver CD and turn on the device. The program autoruns and displays the
DRIVER BANK screen.
2. Click the proper product item.
4.2. Chipset Software Installation
1. Click INTEL Chipset Driver.
Chapter 4 11

2. Click Next.
3.1. Click Next.
3.2. Read the License Agreement carefully and click Yes.
4. Click Next.
Chapter 4
12

5.1. Select restart your computer right now or later.
5.2. Click Finish.
4.3. VGA Driver Installation
1. Click Graphic Driver.
2. Click VGA Driver for WIN2K/XP.
Chapter 4 13

3. Click Next.
3.1. After files extracted, click Next on the welcome screen.
4. Read the License Agreement carefully and click Yes, and then the installation
starts.
5.1. Select restart your computer right now or later.
5.2. Click Finish.
Chapter 4
14

4.4. LAN Driver Installation
1. Click RTL81x0 LAN Driver.
On the welcome screen, click Next.
Click Install to begin the installation.
3. Click Finish.
Chapter 4 15
