Chapter 1 1
1.
Introduction
Today’s retail environment needs and requires more powerful, reliable and flexible
POS system to guarantee best service and sound stocking-selling-storing
management. Fast checkout operations and seamless service are essential and
fundamental to meet customers’ satisfaction. EBN’s SolidPOS 60 series is born to
be the solutions for all concerns mentioned above.
EBN’s SolidPOS 60 series adopts compact and space-saving chassis design. Its
small footprint and angle-adjustable (45 degree) LCD display (2”, 5” and 8”
availible) give you the best flexibility to position your POS hardware to suit your
space arrangement. The front and concealed I/O panel offer excellent cable
management for a clean counter and to prevent accidental disconnection.
Fast and stable performances are most important issues for service business.
With Intel ULV Celeron M 1GHz w/o L2 Cache and Intel 852GM + ICH4 onboard,
SolidPOS 60 series could be at your service 24 X 7 and minimize maintenance
required.
Combined and equipped with all industry-standard I/O port, SolidPOS 60 series is
an all-in-one touch POS terminal with unlimited flexible compatibility and
extensibility to integrate with other accessories and devices. With one cash
drawer port, Gigabit Ethernet port, 4 USB 2.0 ports, one RS-232/422/485 port and
3 RS-232 ports equipped, SolidPOS 60 series can be expanded and connected
with all expanded devices required – 31 key keyboard, customer display, MSR ,
cash drawer and iButton…etc, to help user to conquer challenges from variable
business markets.
SolidPOS 60 series supports most popular Microsoft Windows series operation
system (Windows XP Home Edition, Windows XP Professional Edition, WEPOS
and Linux, making user spend less effort on technology and software- related
issues— so user can devote all energy making your business successful.

Chapter 1
2
Features:
Intel® low power consumption and high performance technology
Tool-free and modular design - easy upgrade and assembly/disassembly
4x USB 2.0,1 x RS-485/422/232, 3 x RS-232, Gigabit Ethernet port (RJ-45)
and cash drawer port (RJ-11) equipped
Peripherals (31 key keyboard, customer display, MSR, cash drawer and
iButton) expandable.
Microsoft Windows series operation system (Windows XP Home Edition,
Windows XP Professional Edition and WEPOS) and open-source Linux
operation system supported.

Chapter 2 3
2.
Unpacking the Box
Verify that the box contains the following items.
1 Device X 1
2 Driver and utility CD X 1
3 Power Adaptor X 1
4 Power Cord X 1
5 HDD screws

Chapter 3
4
3.
Hardware Setup
3.1. Quick Tour
Front View
LED Indicator
The Power indicator will glow green when power is on.
The HDD indicator will blink green when the HDD is accessed.
The LAN indicator will blink green when transferring data though the LAN.

Chapter 3 5
Back Panel I/O
Note: The I/O panel is covered by the front cover. For details about
removing the from cover, please see
Note: For details of I/O ports on the back panel, please refer to Chapter
7 – I/O Definition.

Chapter 3
6
3.2. HDD installation
1. Loosen the tool-free screw anticlockwise on the bottom of the device as shown
below.
2. Remove the back cover from the device by pulling back.
3. Loosen and remove two screws on the middle cover by #1 Phillips screwdriver.

Chapter 3 7
4. Pull the middle cover in the direction as shown below.
5. Bend the middle cover softly in the direction as shown below to remove it from
the device.
6. Install the four HDD screws as shown below.

Chapter 3
8
7. Connect the IDE cable to the HDD.
8. Connect the power cable to the HDD.
9. Install the HDD to the device.

Chapter 3 9
10. Tighten the five screws as shown below.
3.3. RAM installation
1. Align and insert the new RAM into the slot.
2. Push both ends of the RAM down until the ejectors snap into place.

Chapter 3
10
3.3. Turn on the Device
1. Connect the four pin connector of the power adapter into the DC 19V socket on
the I/O panel, and the other end into the grounded wall outlet properly.
2. Press and hold the power switch until the power indicator on the front panel
glow green.

Chapter 4 11
4.
Peripherals Installation
4.1. Customer Display Installation
1. Loosen the two tool-free screws anticlockwise on the bottom of the device as
shown below.
2. Remove the front covert assembly,
3. Disconnect the green speaker jack and the black multi function connector.
4. Loosen and remove four screws by #1 Phillips screwdriver as shown below.

Chapter 4
12
5. Remove the LCD panel assembly from the device.
6. Align the four screw holes of the customer display to the brown-yellow screw holes of
the LCD panel assembly, and then tighten screws by #1 Phillips screwdriver as shown
below.
7. Connect the RJ-45 connecter to the D-Sub 9 Cable, and the install the LCD panel
assembly to the device.

Chapter 4 13
8. Connect the RS-232 connector of the D-Sub 9 Cable to the COM port of the device.
10. Connect the speaker cable t and the multi function connecter to the device as
shown below.
4.2. Keyboard assembly Installation (Keyboard, MSR
and iButton)
1. Connect the PS2/COM5 connecter to the PS2/COM5 port of the device.

Chapter 4
14
2. Install the keyboard assembly to the device.
3. Tighten the two screws as shown below.
