1. Introduction
1.1. Brief Introduction
E90-DTU (433C30) is a data transmission station that adopts extremely advanced ultra-narrow band modulation technology. On
the original basis, power amplifier (PA) and low noise amplifier (LNA) are built in, so that the maximum transmitting power reaches
0.5w and the receiving sensitivity is also improved to a certain extent. Compared with the products without power amplifier and low
noise amplifier, the overall communication stability isgreatly improved.
Different from the traditional data transmission station, E90-DTU (433C30) is specially developed for Modbus application
scenarios. The feature of unlimited packet length can replace the communication cable, making it the most convenient choice for
Modbus wireless upgrade. The station works in 433MHz frequency band, with communication distance up to 3km. Wireless digital
radio as a medium of communication, as well as optical fiber, microwave, open wire, there is a certain scope of application: it provides
some special conditions, private network monitoring signals in real-time and reliable data transmission, low cost, easy installation and
maintenance, diffraction capability is strong, flexible network structure, the coverage is far characteristic, suitable for some more and
occasions, such as dispersion and complex geographical environment with PLC, RTU, rain gauge, level gauge and other data terminal
is connected.
1.2. Certificate
E90-dtu has obtained the "radio transmission equipment model approval certificate", whose approval code is：
CMIIT ID:2017FP5780。
E90-DTU has obtained the "explosion-proof certificate", whose number is: test no.201711000975
E90-dtu has obtained the "electrostatic surge detection report" issued by China testing institute, whose number is
CNEx18.1461.
E90-dtu has obtained the "appearance design patent certificate", and its patent number is ZL 2016 3 0501980.3.
E90-DTU has obtained the "utility model patent certificate", and its patent number is ZL 2016 2 1410691.3.
E90-dtu has obtained the "CE certificate" (mandatory eu certification), whose verification number is
CCISE180514601V.
E90-DTU has obtained an "FCC certificate" with the ID of 2ALPH-E90-DTU.
E90-DTU has obtained the "RoHS certificate" (mandatory EU environmental protection certification), and its report
number is DTI201807025245.

Chengdu Ebyte Electronic Technology Co,;Ltd E90-DTU (433C30) user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 3
1.3. Features
★All the core components of the original import, compared with the current similar imported digital radio, the most
advanced function, the smallest size, the best price.
★Infinite packet length, support uninterrupted transmission,Modbus adaptation.
★Tailored for Modbus,all direct replacement of RS-485 cable.
★Simple and efficient power supply design, support power supply device or line pressure mode, support 10~28V
power supply.
★Transmission power up to 1w, and multi-level adjustable, all technical indicators up to the European industrial
standards.
★Temperature compensators are adopted to make the frequency stability better than ±1.5PPM.
★Operation temperature range: -40℃～+85℃, applicable for various harsh environment, it is real industrial grade
products
★All aluminum alloy shell, compact size, easy installation, good heat dissipation; Perfect shielding design, good
electromagnetic compatibility, strong anti - interference ability.
★Power reverse connection protection, over-connection protection, antenna surge protection and other multiple
protection functions, greatly increasing the reliability of thestation.
★Powerful software functions, all parameters can be set through programming: such as power, frequency, air speed,
address ID, etc
★Ultra-low power consumption, the standby current is only 23mA (power saving mode and sleep mode power
consumption is lower), the emission current 0.3A.
★Built-in watchdog, and accurate time layout, once an exception, the module will automatically restart, and can
continue to work in accordance with the previous parameter Settings.
2. Operation
Main parts
1、First step is to mount antenna, then battery, making sure the dial switch is on its right status. User gets on the power
by choosing either VCC/GND or power adapter.

Chengdu Ebyte Electronic Technology Co,;Ltd E90-DTU (433C30) user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 4
2、Using USB-(RS232) converter or USB-RS(485) converter or other way to link computer and DTU.
3、Firing up two XCOMs, choosing Baud rate 9600bps, 8N1, the setting which serial port transmission can be
achieved.

Chengdu Ebyte Electronic Technology Co,;Ltd E90-DTU (433C30) user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 5
4、User needs to open the mode switch first before link DTU with computer if the user wants to modify parameters.
Firing up E90-DTU 数传电台配置软件 (E90-DTU parameter configuration application) to modify related
parameters. The mode switch must be reopened to achieve transmission after the configuration.
模式 0 出厂默认状态 模式 2 进行参数配置
3. Installation Specification
3.1. Structure

Chengdu Ebyte Electronic Technology Co,;Ltd E90-DTU (433C30) user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 6
Pin NO.
Name
Function
Description
1
DB-9 female socket
RS-232 interface
Standard RS-232 interface
2
3.81 terminal block
RS-485, powerinterface
Standard RS-485 interface and pressureline powerinterface
3
PWR-LED
Power LED
Red, lit when the poweris on
4
TXD-LED
Transmit LED
Yellow, blinks when sending data
5
RXD-LED
Receive LED
Yellow, blinks when receiving data
6
DC powerinterface
Power interface
In-line round hole, outerdiameter 5.5mm, diameter 2.5mm
7
DIP switch
DIP switch
Controlled by working mode
8
Antenna interface
SMA-K interface
external thread, 10mm, 50Ωcharacteristic impedance

Chengdu Ebyte Electronic Technology Co,;Ltd E90-DTU (433C30) user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 7
3.2. Dimension
单位：mm

Chengdu Ebyte Electronic Technology Co,;Ltd E90-DTU (433C30) user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 8
4. Interface Defination
4.1. Power interface definition
Users can choose ⑥DC power interface, using the power adapter supply with the interface of the 5.5mm outer
diameter , 2.5mm diameter ;
Also choosethe VCC and GND terminal power supply, only chooseany one of the power supply is OK;
E90-DTU can use10~ 28V DC power supply, but it is recommended to use 12V or 24V DC power supply.
4.2. RS232 Interface definition
The E90-DTU can be connected to thedevice via RS-232 using the standard DB-9 interface.
4.3. RS485 Interface definition
E90-DTU can connect the 485_A terminal and 485_B terminal with the device RS-485 A terminal and B terminal.
Pin NO.
Definition
Function
Description
1
VCC
Crimping powerinterface, positive
10 ~ 28V DC, recommended 12V or 24V
2
GND
Crimping powerinterface, negative
The powersupply negativepole is connected to the system
ground and the housing
3
485_B
RS-485 interface, interface B
The RS-485 interface B is connected tothe device interface B

Chengdu Ebyte Electronic Technology Co,;Ltd E90-DTU (433C30) user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 9
4
485_A
RS-485 interface, interface A
The RS-485 interface A is connected to thedevice interface A
★Note: The transceiver will be in poor communication when connected to multiple devices , it is recommended to be
connected to a single device, please try to use parallel 120Ω resistor between 485_A terminal and 485_B.
5. Technical indicators
5.1. Model specifications
Model
Frequency
Transmit
power
Distance
Specifications
Application
Hz
W
km
E90-DTU
(230C27)
230
0.5
2.8
Diffraction
capability,support
Modbus
Industrial PCL cable to wireless, polling
data acquisition, remote monitoring
★Note: Test condition: in clear and open air without shelters, 12V /2A power supply, 5dBi gain sucker antenna over 2
meters height from theground, with the factory default parameters.
NO.
Model
Specification
Description
1
Size（H*W*D）
82 * 62 * 25 mm
See more at 3.2 Dimension
2
Weight
130g
Tolerance: 4.5g
3
Temperature
-40℃～85℃
Meet industrial level
4
Antenna impedance
50 Ω
Standard 50 Ω characteristic impedance
5
Supply voltage
+10 ~ +28V DC
It is recommended to use 12Vor 24V
6
Communication interface
RS232/RS485
Standard DB9 hole / 3.81 terminal block
7
Baud rate
Default 9600
from 1200 to 115200 bps
8
Address
Default 0
65536 configurable addresses
