Echo Bear Cat CH922DH User manual

GETS THE JOB DONE FAST!
9" Capacity Chippers!
Model CH922DH (74950)
Model Engine Size Chipper Feed Feed Weight Wheel Tires
(LxWxH) Capacity System Opening (Lbs.) Base
CH911DH Kubota 119"x79"x89" 9" hydraulic 9"x9" 2480 68” P215
(72928) 1.1 Liter Diesel 75R15
CH922DH Kubota 119"x79"x89" 9" hydraulic 9"x9" 2700 68“ P215
(74950) 2.2 Liter Diesel 75R15
Option:
71677 2" Ball Coupler For Pintle Hitch
Four reversible chipper blades mounted
on a dynamically balanced disc weigh
in at 275 lbs. [125kg] Maintenance and
service is quick and easy with a hinged
disc cover.
A full set of gauges enables the operator
to monitor primary functions at all times.
Both models are electric start (battery
included).
Find a dealer near you!
Call us at 800.247.7335 or
Log onto www.BearCatProducts.com
P.O. Box 849, West Fargo, ND 58078
Email: [email protected]
Fax: [phone]

9" Chipper Specs
Models CH911DH (72928), CH922DH (74950)
76cm [30"] DIAMETER DISC
1.25" [76cm] diameter by 1.25" [3.2cm] thick rotor disc
that weighs 275 lbs. [125kg]. Machined to balance. Disc
turns at 1500 RPM. .75" [4.45cm] diameter rotor shaft.
ENGINES
Kubota engine 1.1 Liter Diesel, 69 cu. In. [1.1 L] Max torque:
73.5 N.m [7.5 kgf.m] at 2,200 rpm, runs at 3,000 rpm.
Warranty 2 yrs. 2000 hrs on everything, 3 yrs., 3000 hrs ma-
jor components coverage. Kubota engine 2.2 Liter Diesel,
134 cu. In. [2.2L] Max torque: 147 N.m [15 kgf.m] at 1,800
rpm, runs at 2,800 rpm. Warranty 2 yrs. 2000 hrs. on ev-
erything, 3 yrs., 3000 hrs. major components coverage.
FUEL CAPACITY
18 gallons [68 liters]. Fuel consumption on the 1.1 Liter Kubota
is 1.7 gal [7.57 liters] Per hour at full load. Fuel consumption on
the 2.2 Liter Kubota is 3 gal. [14.2 liter] per hour at full load.
HYDRAULIC FEED SYSTEM
White 45 cu. in. [737cc] hyd motor, 10-micron spin on lter. Self-con-
tained system with innite speed settings, dedicated neutral and full
reverse, pump output. 25 liters/min [6.6 gal per min.] and 4HP with
maximum pressure and maximum ow. Feed system operates under
[1750 PSI [119atm], 3 gal. [11.4 liter] tank capacity.
Single 15" [38cm] diameter top feed roller. Feed rate is
0 - 150 FPM [0-45 meters/min.].
MANUAL BELT ENGAGEMENT LEVER
FEED SYSTEM
15" [38 cm] diameter feed roller containing 10 knife blades,
four reversible chipping blades, adjustable Feed chute is
30.25" X 30.75" [77x77cm] tray 27" [68cm] off the ground.
Feed table is 38" [96.5cm ] long.
Infeed hopper opening is 9"x9" [23cm x 23cm].
Drop-down feed tray with locking safety pin.
EASY ACCESS
The rotor is accessible through the hinged disc cov-
er, which exposes one half of the disc for easy access
to the chipping blades and for easy clean out.
HEAVY-DUTY CONSTRUCTION
9"x9" [.95cm] thick steel face plate on the disc housing; .25"
[6.35mm] thick steel on the wrap around with welded construction.
INTEGRATED BLOWER
Put the chips where you want them with the dedicated blower. 360°
rotatable, 8" [20cm] diameter steel tubing with adjustable spout
cap allows you to put the chips where you want them the rst time.
ADJUSTABLE JACK
Roller wheel with 850 lb. [385kg.] Rating. Adjustable jack allows
one person to easily maneuver the chipper around and hook up to a
vehicle.
TRIPLE-BANDED BELT DRIVE FOR
BETTER TRANSFER OF POWER
HIGHWAY TOWABLE
68" [172cm] tread width (center to center) and P215 75R15
tires with 3000 lb. [1360kg] torsion axle suspension en-
ables the chipper to be easily towed down the highway. Light
kit with license plate holder. Tow chains standard.
TELESCOPING TONGUE
Adjustable length and height. The length may be adjusted
up to 45 cm [18"] with 4 pin settings on the pintle hitch.
5cm [2"] coupler hitch available as an accessory.
DIMENSIONS:
• Length 119" [302cm].
• Width 79" [200cm]
• Height 226cm [89"]
WEIGHT:
• Model CH911DH (72928) – 2480 lbs [1125kg]
• Model CH922DH (74950) 2700 lbs [1225kg.]
SAFETY:
• Safety chains standard
• Meets all applicable ISO and CE safety standards.
