Echo CH4540* User manual

RELIABLE POWER YOU CAN TAKE WITH YOU!
4" & 5" PTO Chippers
Model Engine Size Chipper Feed Feed Weight 3 Point PTO
(LxWxH) Capacity System Opening (Lbs.) Hitch
CH4540* PTO 48"x45"x87" 4" manual feed 5.5""x7" 600 Cat. 1 540 rpm
(73454)
CH5540H* PTO 94"x40"x93" 5" hydraulic 5.5"x7" 980 Cat. 1 540 rpm
(74554)
Option:
73071 Digital Programmable Feed Sensor and Hour Meter for (Model 74554 only)
*Models CH4540 (73454) and CH5540H (74554) - Tractors with 540 rpm PTO Drive, Engine HP Ratings from 13 hp diesel and 15 hp gas to
45 hp.
Category 1 Tree Point Hitch
“There's no need to change any-
thing --- it is head and shoulders
above the competition!”
Richard Raynes
Cutts Island, Kittery Point, Maine
Model CH5540H (74554)
Shown above is the CH4540 (73454)
4" PTO Chipper.
Fold down feed trey comes standard
on the CH5540H (74554) Hydraulic
PTO Chipper.
Find a dealer near you!
Call us at 800.247.7335 or
Log onto www.BearCatProducts.com
P.O. Box 849, West Fargo, ND 58078
Email: [email protected]
Fax: [phone]

4" & 5" PTO Chipper Specs
Models CH4540 (73454), CH5540H (74554)
20" [51cm] DIAMETER DISC
20" [51cm] x 1.25 [3.175cm] thick rotor disc weighs
140 lbs. [63.5kg], machine balanced.
PTO DRIVE
The PTO Drive, category one 3-point that
weighs 600 lbs. [272kg.] Belt Driven.
FOUR CHIPPING BLADES
All have the same reversible chipper blades, heat treated
chipper steel with a chrome content. 3.125" x .25"
ADJUSTABLE, 4-WAY ANVIL
To ensure good quality chipping ability.
DOUBLE BANDED BELT DRIVE
HYRAULIC FEED SYSTEM on Model CH5540H ONLY
•15" Diameter feed roller
•Maximum capacity of 3 Gallons/minute at 2500 PSI
•Electric/Hyrdaulic system to control feed roller direction
MANUAL FEED SYSTEM on Model CH4540 ONLY
•45-Degree chipping blade edge angle helps
pull the logs and limbs into the 73454.
EASY ACCESS DISC
The rotor is accessible through the hinged disc cover by remov-
ing one bolt, which exposes one half of the disc for easy access to
the chipping blades and for easy inspection and maintenance.
HEAVY-DUTY CONSTRUCTION
•.25" Thick steel throughout, seam welded.
INTEGRATED DISCHARGE CHUTE
Put the chips where you want them with the dedicated blower. 360°
rotatable, 8" [20cm] diameter steel tubing with adjustable spout
cap allows you to put the chips where you want them the rst time.
LARGE FEED HOPPER
Feed your prunings or limbs into a 27" x 28" [68.6cm x 71.1cm] open-
ing.
CHIPPER CHUTE
Opening is 5.5" x 7" [14cm x 17.8cm] (for side limbs)
MAXIMUM FEED SIZE
• CH4540 (73454) – 4"
• CH5540H (74554) – 5"
2" [5.08CM] BALL COUPLER
WEIGHT
•CH4540 (73454) PTO CHIPPER Weighs 600lbs.
•CH5540H (74554) PTO CHIPPER Weighs 980lbs.
SAFETY
• Meets all ANSI safety standards.
