Product Name Specs
EASY TO USE AND POPULAR
3" Chipper/Shredders
Model Engine* Size Chipper Hopper Chipper Weight Start Clutch Tires
(LxWxH) Capacity Size Shredders (Lbs.)
SC3270 Honda 38"x23"x46" 3" 12" x 22" 2 chipper blades 242 recoil manual 410/350-4
(70380) 270 cc 12 shredder knives pneumatic
SC3270T* Honda 44"x57"x49" 3" 12" x 22" 2 chipper blades 330 recoil manual 480/400-8
(70580) 270 cc 12 shredder knives pneumatic
*Model 70580 is road towable
Model SC3270T (70580)
Model SC3270 (70380)
The new "Four-Wheel Tow Hitch", 75591-00,
allows for easy hookup and towing capabilities.
These chipper/shredders have easy access to
the discharge door, making debris simple to
move.
Wet
Debris
.75" 1.5"
Standard
.375"
These chipper/shredders come with 1.5"
standard screen, 3 additional screens
available.

Find a dealer near you!
Call us at 800.247.7335 or
Log onto www.BearCatProducts.com
237 12th St. NW • P.O. Box 849, West Fargo, ND 58078
Email: [e-mail]
Fax: [phone]
270 CC HONDA OHV ENGINE
•Fuel consumption is .7 gallons per hour at full load.
TWO CHIPPING BLADES
High chrome content reversible, heat treated chipper steel blades
[3.125" x 2" x .25"] quickly chip limbs up to 2.75" [7.6cm] diameter.
The cutting edge is machined at a 45-degree angle for more steel up
front. The 45-degree angle also draws the wood into the chipper.
SHREDDING EFFICIENCY
Exclusive serrated, free-swinging shredder knives are heat-treated
for strength and durability. Two edges, which are easily reversed,
double the shredding life. Mounted in a staggered pattern to reduce
any dead space.
BALANCED ROTOR
•2 chipping blades and 12 shredder knives.
•Double-belt rotor drive.
BUILT TO LAST
•Extra strength and reinforcements in areas that matter most
•Built to last with 16 gauge steel construction.
LARGE HOPPER
• Extra wide, extra deep, 15.75" x 7.5"
BOTH MODELS HAVE STANDARD COURSE SCREEN - 1.5" HOLES
DISCHARGE SCREEN
•Heavy-duty discharge screens available in 4 different sizes to t
your particular needs.
•Quick and easy to change
STABILITY
Wide tire track and full width front leg give maximum stability.
DIAMOND SHAPED CHIPPER CHUTE
Enables you to insert most irregular limbs even if they have some
knobs on them.
PNEUMATIC TIRES WITH GREASE ZERKS
Wheels feature grease zerks, enabling easy greasing of the hub.
DIMENSIONS:
• SC3270 (70380) – Length: 38", Width: 23", Height: 46"
• SC3270T (70580) – Length: 44", Width: 57", Height: 49"
DECIBEL LEVELS:
• SC3270 (70380) – 111 decibels
• SC3270T (70580) – 111 decibels
SAFETY
• Meets all applicable ANSI safety standards.
OPTIONS:
• 70089 - Leaf Tamper
• 70251 - Blower Attachment Package
(ALL MODELS EXCEPT SC3206 70050)
• 70303 - Fine Screen: .375" Holes
• 70305 - Medium Screen: .75" Holes
• 70494 - Wet Debris Screen
• 70301 - Standard Coarse Screen
Backed by ECHO Bear Cat's
WARRANTY
2 year consumer
1 year commercial
3" Chipper/Shredders Specs
