EchoNous Kosmos Grab and Go on AI Stand User manual

P007633-001 Rev A DU-ECO-0002-40 Rev A 8/26/2022 GCX Corp. Page 1 of 8
Installation Guide
Installation Guide Kosmos Grab and Go on AI Stand
(3) M4 x 12mm PHMS
Parts Reference
(1) 1/8”
e-Enclosure
Tablet
(1) ¼-20 x ¾ SET SCREW
(1) e-Enclosure with cover
(4) M4 x 8mm BHTS
(Button Head Torx Screw)
(1) M3 x 8mm BHTS
(1) T-10, (1) T-15, (1) T-20
(2) Cable Clip
(2) M3.5 x 1.65 x 10mm BHTS
DocuSign Envelope ID: 26EA4BCC-6B8A-408A-AC15-D4FBCB359670

P007633-001 Rev A DU-ECO-0002-40 Rev A 8/26/2022 GCX Corp. Page 2 of 8
Installing tablet mount to column
Using a T20 Torx wrench, secure tablet mount with (4) M4 x 8mm BHTS as
shown.
(4) M4 x 8mm BHTS
(Button Head Torx Screw)
DocuSign Envelope ID: 26EA4BCC-6B8A-408A-AC15-D4FBCB359670

P007633-001 Rev A DU-ECO-0002-40 Rev A 8/26/2022 GCX Corp. Page 3 of 8
(2) Cable Clip
(2) M3.5 x 1.65 x 10mm BHTS
1
Installing e-Enclosure
2
(1) ¼-20 x ¾ Set Screw
DocuSign Envelope ID: 26EA4BCC-6B8A-408A-AC15-D4FBCB359670

P007633-001 Rev A DU-ECO-0002-40 Rev A 8/26/2022 GCX Corp. Page 4 of 8
Connect the 40” USB on the HUB.
3
Connect the HUB Power supply DC cable
(routed through the mouse hole).
4
5
Route the USB cable to the right side and the power
supply to the left. Route the USB cable up the column.
DocuSign Envelope ID: 26EA4BCC-6B8A-408A-AC15-D4FBCB359670

P007633-001 Rev A DU-ECO-0002-40 Rev A 8/26/2022 GCX Corp. Page 5 of 8
Power Supply Mount (supplied with roll stand)
1
2
DocuSign Envelope ID: 26EA4BCC-6B8A-408A-AC15-D4FBCB359670

P007633-001 Rev A DU-ECO-0002-40 Rev A 8/26/2022 GCX Corp. Page 6 of 8
Cable Cleat (supplied with roll stand)
(3) M4 x 12mm PHMS
Attaching e-Enclosure cover
DocuSign Envelope ID: 26EA4BCC-6B8A-408A-AC15-D4FBCB359670

P007633-001 Rev A DU-ECO-0002-40 Rev A 8/26/2022 GCX Corp. Page 7 of 8
Cable Cleat
Store power supply cord on
cable cleat.
Cable Routing
Column Cutouts
Route cable through cutouts in
the column and up to tablet.
Route cables through
cutouts in column.
Make sure column surface
is clean and dry before
installing cable clips.
Cable Clips
(self-adhesive style supplied with cart)
DocuSign Envelope ID: 26EA4BCC-6B8A-408A-AC15-D4FBCB359670

P007633-001 Rev A DU-ECO-0002-40 Rev A 8/26/2022 GCX Corp. Page 8 of 8
Release button is located
on the backside within the
right-side hand grip area.
Tablet Release
To remove the Kosmos Bridge, press the release button (located on the back of mount). Pivot and lift the Kosmos Bridge
out of mount. Power cable will automatically disconnect from Kosmos Bridge.
Locking the Kosmos Bridge
The Kosmos Bridge may need to be locked inside tablet holder. Once the Kosmos Bridge has been
installed, use a T-10 Torx wrench to install (1) M3 x 8mm BHTS into the back of the tablet holder as
shown below. This will lock the release button.
(1) M3 x 8mm BHTS
DocuSign Envelope ID: 26EA4BCC-6B8A-408A-AC15-D4FBCB359670
