Ecostrad Apex User manual

Model: Ecostrad Apex
Model no.: AH18CC-B
1800 W
Ratings: 220 V – 240 V; 50 Hz; Class I; IP65

Introduction
The Ecostrad Apex is a versatile infrared heater that provides radiant infrared heat with a soft orange glow. Suitable
for wall and ceiling mounting, the Apex with its carbon filament element delivers heat that is strong enough to be
effective outdoors but gentle enough for prolonged use in hard-to-heat indoor areas. .
Safety Notes
PLEASE READ THE FOLLOWING INFORMATION CAREFULLY: This infrared heater is designed for safe operation.
Nevertheless, installation, maintenance and operation of this appliance can be dangerous if undertaken incorrectly.
Observing the following procedures will reduce the risk of fire, electric shock, and injury. It will also keep installation
time to a minimum. Save these instructions for future reference.
Caution:
1. CAUTION -- Some parts of this product can become very hot and cause burns. Particular attention has to be
given where children and vulnerable people are present.
2. This appliance is not intended for use by persons, including children, with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
3. Children of less than 3 years should be kept away unless continuously supervised.
4. Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been
placed or installed in its intended normal operating position and they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved. Children aged from 3 years
and less than 8 years shall not plug in, regulate or clean the appliance or perform user maintenance.
5. The unit is at a high temperature during operation. It stays hot for a period after shutdown. Potential danger
would occur when touching it during this period.
6. In order to avoid overheating, do not cover the heater.
Assembly & Location
1. Obey all mounting restrictions listed in installation instructions when installing. The heater must be mounted such
that it cannot be touched accidentally.
2. The unit should be plugged into a socket which is easily visible and reachable. The heater must not be located
immediately below or in front of the socket outlet. The socket must be accessible without having to move the
heater.
3. When assembling, keep clear from any flammable material.
4. Check the power cord and plug carefully before use to make sure they are not damaged. If the supply cord is
damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid
a hazard.
5. This heater is not equipped with a device to control the room temperature. Do not use this heater in small rooms
when they are occupied by persons not capable of leaving the room on their own, unless constant
supervision is provided.
6. Do not install this unit in or near the outlet of a hot air heating system.
7. Do not place the unit close to curtains and/or other flammable objects. Otherwise there will be a risk of these
objects catching fire.
8. The unit is for outdoor use only. This unit must not be used in building sites, greenhouses, barns or stables where
there is flammable dust.
9. Do not use this heater in the immediate surroundings of a bath, shower or swimming pool.
10. Do not use this unit in a place where caustic or volatile air exists, i.e. dust, steam, gas, etc.
11. Do not use this unit as a clothes or towel drier.
12. Do not use this unit as a sauna heater.
13. Do not use this unit in places of animal propagating and raising.

Use & Cleaning
1. The unit must be securely grounded during operation.
2. Do not cover the unit with anything during operation or a short time after it's shut down.
3. Do not wrap the power supply cord around the unit.
4. Do not use this heater with a separate programmer, timer or any other device that switches the heater on
automatically, since a fire risk exists if the heater is covered or positioned incorrectly.
5. The head of the unit is at high temperature during operation. Unplug the unit and wait till it's cool before cleaning.
6. Do not immerse this unit into water for cleaning.
7. The unit must be handled and transported with care, avoiding risk of impact or vibration in transit.
8. If damaged, the unit must be repaired by a professional repair team.
Assembly Instructions
Preparation:
1. Read this instruction manual carefully before installation and use. Keep the
manual in a safe place for future use in case needed.
2. Unpack the carton. Take out the accessories pack from the carton. Make
sure the accessories listed opposite are included. If anything is missing,
contact the retailer immediately and they will provide you with
replacements.
3. You will need the following tools: pencil, screwdriver, cross-head spanner
suitable for M6 screw nut, steel tape measure, power drill and drill bits.
Installation:
The Apex is suitable for wall or ceiling mounting. The instructions below
apply to both types of installation.
PART NAME Qty
1
Expansion Bolt M6*70
1
4
1
2
1
Mounting Plate
1. Drill four holes in the wall or ceiling for the mounting plate, as per the measurements shown in Fig. A.
2. Insert the four Expansion Bolts into the holes. Use a spanner to twist the Screw Nuts on the Expansion Bolts
clockwise until they are securely located in the holes. Unscrew the Screw Nuts and put them aside with the
Washers and Spring Washers for use later.
3. Place the mounting plate on the ceiling or wall, letting the four expansion bolts go through the holes on the
bracket. Fix in place with Washers, Spring Washers and Screw Nut mentioned above. See Fig. B and Fig. C.
4. Line up the Upper Bracket with the Lower Bracket (already secured to the heater). Thread the Screw M8*70
through the holes and screw tightly, using the M8 nut, as per Fig. C.
5. Mount the heater onto the wall or ceiling by sliding the Upper Bracket into the opening on the Mounting Plate. Fix
in place with the two Screw Knobs M6*12.
6. To adjust the angle of the heater, use a screwdriver to unscrew the Screw M8*70 a little. Set the heater to the
desired angle and drive the Screw M8*70 tight again. The adjustable angle is 60° in total: 30° up, 30° down. See
Fig. D.
IMPORTANT: The heater must be installed at least 1.8m from the ground and at least 50cm from
adjacent surfaces. If ceiling mounted, the heater should be at least 50cm from adjacent walls; if wall mounted,
the heater should be at least 50cm from the ceiling and adjacent walls. If wall mounted, the heater must be
orientated so it is horizontally level with the control panel on the left. In all cases, the heater must be positioned at
a height where it cannot be touched during operation.
Screw M8*70
M8 Nut with cover
Screw Knob M6*12
Upper Bracket

PARTS DESCRIPTION
No. PART NAME No. PART NAME
1Expansion Bolt M6*70
8 M8 Nut with cover
2Mounting Plate
9 Lower Bracket
3 Washer
10 Screw M8*70
4 Spring Washer
11Switch
5 Screw Nut M6
6 Screw Knob M6*12
Fig. A Fig. B Fig. C
Fig. D
7Upper Bracket

Using the Heater
1. Plug the unit into a socket. Make sure the power supply is the same as rated: 220 – 240 V.
2. Switch the heater on and off via the large switch on the left side.
Cleaning:
Unplug the unit before cleaning. Wipe with a damp cloth. Do not use too much water.
Disposal of appliances and batteries
After the implementation of the European Directive 2002/96/EU in the national
legal system, the following applies:
Electrical and electronic devices may not be disposed of with domestic waste.
Consumers are obliged by law to return electrical and electronic devices at the end
of their service lives to the public collecting points set up for this purpose or point
of sale. Details of this are defined by the national law of the respective country. This
symbol on the product, the instruction manual or the package indicates that a
product is subject to these regulations. By recycling, reusing the materials or other
forms of utilising old devices, you are making an important contribution to
protecting our environment.
