Edelbrock Universal Electric Fuel Pump Relay
CATALOG #1795
INSTALLATION INSTRUCTIONS
PLEASE study these instructions carefully before beginning this installation. Most installations can be accomplished with
common tools and procedures. However, you should be familiar with and comfortable working on your vehicle. If you do
not feel comfortable performing this installation, it is recommended to have the installation completed by a mechanic. If
youhaveanyquestionsorproblems,pleasecallourTechnical Hotline at: 1-800-416-8628, 7:00 am - 5:00 pm, Pacific
Standard Time, Monday through Friday or e-mail us at [email protected].
DESCRIPTION: The Edelbrock Fuel Pump Relay kit is for use with Edelbrock electric fuel pumps. Use of a relay with
electric fuel pumps ensures proper wiring, which reduces risk of damage to the fuel pump and results in consistent fuel
pressure. The Edelbrock Universal Electric Fuel Pump Relay Kit may also be used with other electric fuel pumps,
depending on amperage draw.
CAUTION: DO NOT exceed 25 amps at a continuous draw. Relay will handle amperage peaks up to 30 amps.
INSTALLATION INSTRUCTIONS: See the following wiring diagram for proper wiring sequence.
Edelbrock Corporation • 2700 California St. • Torrance, CA 90503
Tech Line: 800-416-8628 • E-Mail: [email protected]
PLEASEfill out and mail your warranty card. Remember to write the model number of this product in the “Part #____” space. THANK YOU.
FUEL PUMP WIRING DIAGRAM, PART #1795
