Eden HA33S Specification sheet

HA33S
Wireless alarm system
Operation and Installation
Manual
0
A PROBLEM?
Do not hesitate to call us on our hotline on 0825 560 650.
Our technicians will be happy to help you to refine your installation.

CONTENTS
Introduction 2
1. Package Contents HA33S .......................................................................................2
2. Installation planning ...........................................................................................................2
3. Installation and programming of the system.........................................................3
3.1 Installation and programming of the alarm center.......................................................................3
3.1.1 Installing the alarm center ..................................................................................................3
3.1.2 Programming the alarm center...........................................................................................3
3.1.2.1 Setting the PIN ..........................................................................................................3
3.1.2.2 Resetting the PIN ......................................................................................................4
3.1.2.3 Setting the triggering mode ......................................................................................4
3.1.2.4 Test Mode .................................................................................................................4
3.1.2.5 Key tones ..................................................................................................................5
3.2 Installation and programming of the accessories .......................................................................5
3.2.1 Programming the accessories ...........................................................................................5
3.2.2 Deleting the accessories ....................................................................................................5
3.2.3 Remote control....................................................................................................................6
3.2.4 Motion detector ...................................................................................................................6
3.2.5 Opening magnetic detector ................................................................................................7
3.3 Programming the phone dialer....................................................................................................7
3.3.1 Programming the alarm message ......................................................................................7
3.3.2 Programming the phone numbers .....................................................................................7
3.3.3 Deleting the phone numbers ..............................................................................................8
4. Activating & Deactivating the alarm center ............................................................8
4.1 Activating the system ..................................................................................................................8
4.1.1 Activating without delay time ..............................................................................................8
4.1.2 Activating with delay time ...................................................................................................8
4.2 Deactivating the system .............................................................................................................8
5. Function Table ..........................................................................................................9
IMPORTANT TIPS .......................................................................................................10
TECHNICAL SPECIFICATIONS ..................................................................................11
WARRANTY CARD .....................................................................................................12
1
A PROBLEM?
Do not hesitate to call us on our hotline on 0825 560 650.
Our technicians will be happy to help you to refine your installation.

Introduction
HA33S system is a standalone alarm system with a built-in telephone dialler, designed to improve
the security of your home. The HA33S system protects your home by emitting an audible an alarm if
the sensors on the windows or doors, or if the PIR motion detectors are triggered. It can be activated
or deactivates by entering a personal code or with a remote control. All sensors are wireless
transmitters to avoid cables, always difficult to conceal.
1. Package Contents HA33S
The alarm system HA33S contains the following parts:
1 x Central and control
unit HA32
3 x PIR detector
2 x Opening contact
2 x Remote control
●Installation & Operation Manual
●Installation kit
●Battery for the elements
2. Installation planning
Select the different places where you want to install the sensors.
Window and door sensors are usually placed in main or secondary entrance but you can also use
them to secure windows.
PIR motion detectors are usually installed on top of a wall and placed in a room requiring protection,
such as the living room or the entrance hall.
The alarm center is usually placed near the main entrance.
The sensors must not be more than 30 meters from the alarm center. This distance may be reduced
by the number of doors or walls through which the sensor must send its radio signal.
2
A PROBLEM?
Do not hesitate to call us on our hotline on 0825 560 650.
Our technicians will be happy to help you to refine your installation.

3. Installation and programming of the system
3.1 Installation and programming of the alarm center
3.1.1 Installing the alarm center
Prepare the installation of the alarm system by inserting two screws into the
wall 50 mm apart horizontally and at sufficiently high above the ground.
- Open the battery compartment on the back of the HA33S.
- Insert the 4 alkaline batteries LR06 "AA" type
- Close the battery compartment on the back of the HA33S
- Mount the alarm center in the selected place
Your alarm system is now ready to be programmed
LOW BATTERY: When the batteries in the alarm center must be changed, the
alarm center will beep every 30 seconds and the yellow light will flash.
ALARM CENTER LOCATION
Check and pay attention to the following points before choosing a location and installing the alarm
center:
-
Make sure to install the alarm center in an area where an intruder may not reach without
passing in front of a magnetic sensor, or an infrared detector.
- The alarm center must be mounted near a telephone plug or a BOX.
- The alarm center should not be visible from the outside.
-
To avoid the risk of electromagnetic interference, do not place the alarm center within a
meter of large metal objects or appliances, refrigerators, washing machines, high voltage
wires, electrical panel, etc.
- To ensure the best possible reception, the mounting height should be greater than or
equal to 1.5 m from the ground level.
3.1.2 Programming the alarm center
3.1.2.1 Setting the PIN
A personal code should first be saved using the buttons on the alarm center. This code is to be
chosen by you, it will be used to activate or deactivate the alarm. Change the code as follows:
- First enter the factory code 1234
- Then press the No. 6 button, a beep will sound and the red and yellow LEDs will light up.
- Enter your 4-digit personal code
- Press the No. 6 button to confirm the code change, a beep will sound that will confirm that
your code has been changed.
To change your code again, repeat the previous steps but replace the factory code by your code.
3
A PROBLEM?
Do not hesitate to call us on our hotline on 0825 560 650.
Our technicians will be happy to help you to refine your installation.

3.1.2.2 Resetting the PIN
If you forget the PIN, you can reset the alarm center with the factory code without affecting the other
settings.
To do so, remove the batteries from the alarm center for a few minutes. After replacing the batteries
the personal code is again 1234
3.1.2.3 Setting the triggering mode
In case of alarm three different triggering modes can be selected with the alarm center.
Mode No. 1
Enter 1234 (or your personal code) followed by 01
In this mode, when an alarm is triggered, the alarm center will sound for 30 seconds, then it will stop
for 45 seconds. This cycle is repeated 10 times
Mode N ° 2
Enter 1234 (or your personal code) followed by 02
In this mode, when an alarm is triggered, the alarm center will sound for 45 seconds, then it will stop
for 30 seconds. This cycle is repeated 10 times
Mode No. 3
Enter 1234 (or your personal code) followed by 03
In this mode, when an alarm is triggered, the alarm center will remain silent but will dial the phone
numbers.
Operation of the phone dialer:
The phone dialer will call the numbers during the 45 second pause between 2 30 seconds alarms. So
the phone dialer will call the first number during the first 45 second pause, the second number during
the second 45 second pause, etc..
3.1.2.4 Test Mode
You can put the alarm center in test mode, so that a chime sounds (ding-dong) upon detection.
This test mode is used to test the proper operation of the detectors, as well as the distance between
the alarm center and the elements.
Switching on the test mode:
- Enter 1234 (or your personal code) followed by 3
Switching off the test mode:
- Enter 1234 (or your personal code) followed by 4
4
A PROBLEM?
Do not hesitate to call us on our hotline on 0825 560 650.
Our technicians will be happy to help you to refine your installation.

3.1.2.5 Key tones
You can deactivate the alarm center key tones by entering 1234 (or your personal code) followed by
8.
To reactivate the beeps, simply repeat the same operation.
3.2 Installation and programming of the accessories
3.2.1 Programming the accessories
IMPORTANT: Accessories have a booting delay, it is therefore imperative to insert batteries into
each accessory 5 to 10 minutes before you start programming.
TIP: For an easier learning, set all the elements on a table in front of you, prior to the installation in
the selected location.
Before the alarm center can communicate with the accessories, a learning procedure should be
executed.
To learn a new accessory:
- On the alarm center enter 1234 (or your personal code) followed by the red and yellow
LEDs will flash
-
Press for 3 seconds the deactivation button of the remote control or learning button of the
accessory you wish to add (see drawing below).While receiving the signal, the red and
yellow LEDs will stay on and a beep will sound to confirm
3.2.2 Deleting the accessories
The alarm center can not erase each accessory independently. If you want to delete an accessory,
you should delete all elements. Which means, after resetting the memory, you will have to reprogram
each accessory.
To delete all the accessories:
- On the alarm center enter 1234 (or your personal code) followed by #, a beep will sound
and the red and yellow LEDs will light up
- Re-enter 1234 (or your personal code) followed by #, a beep will sound to confirm the
accessories have been deleted.
The alarm center exits the accessory deleting mode automatically after 15 seconds or by entering
1234 (or your personal code) followed by 4
5
A PROBLEM?
Do not hesitate to call us on our hotline on 0825 560 650.
Our technicians will be happy to help you to refine your installation.

3.2.3 Remote control
The remote control is used to activate the various functions of
your alarm center (Deactivating, Activating without delay time,
Activating with delay time, Chime)
The remote control is powered by a Lithium CR2032 type
battery, which under normal conditions, has a life cycle of over
one year.
If the battery is in good condition, the LED on the remote lights
up permanently, when a key is pressed.
However, if the battery is low, the LED will flash
when a key is pressed.
A Light
B Activation without delay time
G Activating with delay time
D Deactivating
E Chime
3.2.4 Motion detector
Installing the detector
Open the PIR detector by removing the screws and insert the
1.5 volt alkaline batteries (AAA).
Mount the bracket to the wall using the supplied screws and
plugs.
Put the detector on the bracket and secure is with the screw.
Adjust the detector so that it is directed towards the centre of the
room.
LOW BATTERY: When the detector battery needs to be changed, the detector light flashes every 30
seconds.
Note: The adjustment button on the detector sensor is not used in alarm configuration.
Less sensitive detector
More sensitive
detector
6
A PROBLEM?
Do not hesitate to call us on our hotline on 0825 560 650.
Our technicians will be happy to help you to refine your installation.

3.2.5 Opening magnetic detector
Installing the detector
The detector and magnet can be installed either by using double
sided (supplied) tape or screws.
Mount the magnet on the door (or window) and the detector (the part
containing the battery) on the jamb. The tip of the arrow on the
magnet should face the mark on the detector (see picture).
The space between the magnet and the detector should not exceed
10 mm. If necessary, the detector can be mounted upside down.
Open the battery cover by sliding it as shown in the drawing below.
The detector is secured by two screws on the back side.
The top screw is used to clip the detector while the bottom screw
goes through the bottom of the battery compartment, through the
pre-drilled hole.
Insert the 3V (CR2032) battery, the + side up, and close the lid
When the door or window is opened, the red light turns on a few
moments.
LOW BATTERY: When the detector battery needs to be changed,
the detector light is weak or does not light up.
3.3 Programming the phone dialer
3.3.1 Programming the alarm message
During the call, the alarm center sends a message must be first recorded. The message is 6 seconds
long.
To record the message:
-Press 1234 (or your personal code) followed by 5
- Stand 20-30 cm away from in the alarm center and record your message
-If your message lasts less than 6 seconds, press any button to stop recording
3.3.2 Programming the phone numbers
You can save up to 4 phone numbers, which will be dialled one after the other, in the sequence in
which you saved them in case of alarm.
To save the phone numbers:
- Press 1234 (or your personal code) followed by 7, the red and yellow LEDs will flash
- Enter the first phone number
- Press to confirm
- Repeat the same procedure for the other numbers
If you do not enter any number, the alarm center will exit the programming mode automatically after
30 seconds.
7
A PROBLEM?
Do not hesitate to call us on our hotline on 0825 560 650.
Our technicians will be happy to help you to refine your installation.

3.3.3 Deleting the phone numbers
The alarm center can not erase each number independently, if you want to delete one number, you
have to delete all of them. Which means, after resetting the memory, you will have to reprogram each
phone number.
To delete all the phone numbers:
- On the alarm center enter 1234 (or your personal code) followed by 9, a beep will sound
and the red and yellow LEDs will light up
- Re-enter 1234 (or your personal code) followed by 9, a beep will sound to confirm the
accessories have been deleted.
The alarm center exits the accessories deleting mode automatically after 15 seconds or by entering
1234 (or your personal code) followed by 4
4. Activating & deactivating the alarm center
4.1 Activating the system
When activating the system, regardless of the selected mode, there is an exit delay time of 15
seconds.
The first 10 seconds are silent then you will hear 1 beep every second, followed by a long beep at
the end of the delay time confirm activation.
4.1.1 Activating without entry delay time
On the alarm center
- Press 1234 (or your personal code) followed by 1
On the remote control:
- Press
In this mode you will have an exit delay time of 15 seconds, but no entry delay time. Which means
that the alarm center should be deactivate before entering your home.
4.1.2 Activating with an entry delay time
On the alarm center
- Enter 1234 (or your personal code) followed by 2
On the remote control:
- Press
In this mode you will have an exit delay time of 15 seconds, and a silent entry delay time of 15
seconds.
4.2 Deactivating the system
On the alarm center
- Enter 1234 (or your personal code) followed by 4
On the remote control:
- Press
8
A PROBLEM?
Do not hesitate to call us on our hotline on 0825 560 650.
Our technicians will be happy to help you to refine your installation.

5. Function Table
Number
sequence to
perform on the
alarm center
Function Description
1 2 3 4 + 0 1 Triggering mode # 1
The alarm center rings for 30 seconds and then
stops for 45 seconds. This cycle is repeated 10
times
1 2 3 4 + 0 2 Triggering mode # 2
The alarm center remains silent for 45 seconds
and then rings for 30 seconds. This cycle is
repeated 10 times
1 2 3 4 + 0 3 Triggering mode # 3
The alarm center remains silent but dials phone
numbers
1 2 3 4 + 1
Activation without entry
delay time
No entry delay time after detection
1 2 3 4 + 2
G Activating with entry
delay time
Entry delay time of 15 seconds after detection
1 2 3 4 + 3
Test mode
Test of the system (Chime in case of detection)
1 2 3 4 + 4
Deactivation
Deactivates the alarm center
1 2 3 4 + 5
Alarm message
Record the alarm message (6 seconds max.)
1 2 3 4 + 6
Personal code
Changes the personal code
1 2 3 4 + 7
Programming phone
numbers
Saving phone numbers to call in case of alarm
1 2 3 4 + 8 Key tones
Activates or deactivates the beep when you
press keys
1 2 3 4 + 9 Deleting phone numbers
Deletes all phone numbers stored in the alarm
center
1 2 3 4 +
Programming accessories
Programming accessories (12 max.)
1 2 3 4 + #
Deleting of accessories
Clears all accessories stored in the alarm center
NOTE: 1234 is the default code. If you set a personal code, then you have
to use it
9
A PROBLEM?
Do not hesitate to call us on our hotline on 0825 560 650.
Our technicians will be happy to help you to refine your installation.
