Edge-Core ECWO5211-L User manual

ECWO5211-L
Enterprise Access Point

Quick Installation Guide
ECWO5211-L Enterprise Access Point ENGLISH
Copyright © 4IPNET, INC. All rights reserved.
FCC CAUTION
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or
transmitter.
For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other
channels is not possible.
This device is restricted to indoor use when operated in the 5.15 to 5.25 GHz frequency range.
※FCC requires this product to be used indoors for the frequency range 5.15 to 5.25 GHz to reduce the
potential for harmful interference to co-channel Mobile Satellite systems.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Quick Installation Guide
ECWO5211-L Enterprise Access Point ENGLISH
Copyright © 4IPNET, INC. All rights reserved.
CE CAUTION
Hereby, Edgecore Networks Corporation declares that the radio equipment type ECWO5211-L is in
compliance with Directive
2014/53/EU.
Frequency Range and Transmit Power
Frequency range (MHz)
Max. transmit power (dBm)
2412-2472
23 dBm
5150-5350
23 dBm
5500-5700
23 dBm
AT
BE
BG
HR
CY
CZ
DK
EE
FI
FR
DE
EL
HU
IE
IT
LV
LT
LU
MT
NL
PL
PT
RO
SK
SI
ES
SE
UK
This device is restricted to indoor use.
Input Power
Power from PoE: IEEE802.3at
Operation Temperature
-20℃(-4℉) to 65℃(149℉)
Model –ECWO5211-L
The device has been tested and passed the requirements of the following standards, and hence fulfills the
EMC and safety requirements of RED within the CE marking requirement.
Radio: EN 300 328 V2.1.1, EN 301 893 V2.1.1
EMC: EN 301 489-1 V2.1.1, EN 301 489-17 V3.1.1
EMC: EN 55032:2015 + AC:2016 Class B, EN 55024:2010 + A1:2015 including the followings:
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4,
EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11
Safety: EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
Caution
This declaration is only valid for configurations (combinations of software, firmware, and hardware)
provided and supported by Edgecore Networks Corporation. The use of software or firmware not
provided and supported by Edgecore Networks Corporation. may result in the equipment no longer being
compliant with the regulatory requirements.
Requirements in
AT/BE/BG/CZ/DK/EE/FR/DE/IS/IE/IT/EL/ES/CY/LV/LI/LT/LU/HU/MT/NL/NO/PL/PT/RO/SI/SK/TR/FI/SE
/CH/UK/HR. 5150MHz ~ 5350MHz is for indoor use only.
In order to ensure compliance with the exposure recommendations to electromagnetic fields, the device
should be used at a minimum distance of 20cm from the body.

Quick Installation Guide
ECWO5211-L Enterprise Access Point ENGLISH
1
Preface
Package Contents
Edgecore ECWO5211-L Outdoor Access Point is an
enterprise-grade dual radio 802.11 a/b/g/n + ac
Wave 2 Access Point with the best performance for
business and industrial applications. Featuring two
2x2 MIMO radios, the ECWO5211-L can
simultaneously support up to 300 and 867 Mbps
data rates in the 2.4 and 5 GHz bands respectively.
ECWO5211-L is compliant with the latest industrial
wireless security standards such as 802.1X and
Wi-Fi Protected Access (WPA and WPA2) which are
required in the tightly secured enterprise network
environments. Furthermore, ECWO5211-L also
features multiple ESSIDs with VLAN tags and
multiple Virtual APs; great for enterprise
applications, such as separating traffic from different
departments using different ESSIDs.
As an Outdoor Access Point, ECWO5211-L
supports wall mounting and poll mounting for
different deployment environments. Besides
ECWO5211-L’s PoE uplink port is able to receive
power from Power over Ethernet (PoE) sourcing
devices, its LAN port also supports PoE with
802.11at standard which make network deployment
more convenient and easier.
This Quick Installation Guide provides instructions
and reference materials to get you started with
Edgecore ECWO5211-L.
1. Edgecore ECWO5211-L x 1
2. Quick Installation Guide (QIG) x 1
3. Metal Strip x 2
4. Antenna (2.4G) x 2
5. Antenna (5G) x 2
It is recommended to keep the original
packing material for possible future shipment
when repair or maintenance is required. Any
returned product should be packed in its
original packaging to prevent damage during
delivery.

Quick Installation Guide
ECWO5211-L Enterprise Access Point ENGLISH
2
System Overview
ECWO5211-L Side ECWO5211-L Back

Quick Installation Guide
ECWO5211-L Enterprise Access Point ENGLISH
3
1
Power LED
ECWO5211-L status. The Power LED will start blinking when the
ECWO5211-L is booting. After finishing booting, the Power LED will always
on.
2
LAN1 LED
Uplink status. The LAN1 LED will light up when there is traffic passing through
the LAN1 port.
3
LAN2 LED
LAN status. The LAN LED will light up when there is traffic passing through the
LAN port.
4
2.4G LED
2.4G Wi-Fi status. The 2.4G LED will blink when there is 2.4G traffic.
5
5G LED
5G Wi-Fi status. The 5G LED will blink when there is 5G traffic.
6
LAN1 (PoE) Port
Offers uplink connection. This port can be used to connect to a controller,
gateway, or directly to the Internet. 802.3at PoE is also supported.
7
Ventilation Valve
Due to extreme weather conditions, water vapor in the ECWO5211-L may
condense. The valve allows ventilation to prevent moisture buildup within the
ECWO5211-L.
8
LAN2 Port
The ports for connections with LAN side devices.
9
Wall Mounting Holes
For hanging ECWO5211-L.
10
Pole Mounting Gap
For mounting ECWO5211-L.

Quick Installation Guide
ECWO5211-L Enterprise Access Point ENGLISH
4
Hardware Installation
Please follow the steps mentioned below to install the hardware of ECWO5211-L :
1. Place the ECWO5211-L at the best location.
The best location for ECWO5211-L is usually at the center of your intended wireless network.
Wall mount
1. Secure screws on the wall.
2. Hang ECWO5211-L on the wall by pole mounting holes.

Quick Installation Guide
ECWO5211-L Enterprise Access Point ENGLISH
5
Pole mount
1. Insert the metal strips through the pole mounting gap.
2. Join the two ends of the metal strips and adjust the length for tight fitting around the pole.
2. Connect the ECWO5211-L to your network device.
Connect one end of the Ethernet cable to the LAN1 (PoE) port of ECWO5211-L and the other end of the
cable to a switch, a router, or a hub. ECWO5211-L is then connected to your existing wired LAN network.
3. Power on the ECWO5211-L .
ECWO5211-L LAN1 (PoE) port is capable of receiving DC currents. Connect an IEEE 802.3at-compliant PSE
device (e.g. a PoE-switch) to the LAN1 (PoE) port of ECWO5211-L with the Ethernet cable.
Now, the Hardware Installation is complete.
To verify the wired connection between ECWO5211-L and your switch / router / hub, please also
check the LED indicator of the respective network devices.

Quick Installation Guide
ECWO5211-L Enterprise Access Point ENGLISH
6
Getting Started
Edgecore ECWO5211-L supports web-based configuration. Upon the completion of hardware installation,
Access Point can be configured through a PC by using its web browser such as Mozilla Firefox 2.0 or Internet
Explorer version 6.0 and above.
The default values of LAN IP address and subnet mask of ECWO5211-L are:
IP Address
192.168.1.10
Subnet Mask
255.255.255.0
Steps:
1. To access the web management interface, connect the administrator PC to the LAN port of ECWO5211-L
via an Ethernet cable. Then, set a static IP address on the same subnet mask as ECWO5211-L in TCP/IP
of your PC, such as the following example:
IP Address: 192.168.1.100
Subnet Mask: 255.255.255.0
2. Launch the web browser on your PC by entering the IP address of ECWO5211-L (http://192.168.1.10) at
the address field, and then press Enter.
Example of entering ECWO5211-L’s default IP Address via a web browser
3. The following Admin Login Page will appear. Enter “admin” for both the Username and Password fields,
and then click Login.
Administrator Login Page

Quick Installation Guide
ECWO5211-L Enterprise Access Point ENGLISH
7
4. After a successful login into ECWO5211-L’s Web user interface (Web UI), a System Overview page of
web management interface will appear, as depicted below.
The Web Management Interface - System Overview Page
Congratulations!
Now, Edgecore ECWO5211-L is installed and configured successfully.
After ECWO5211-L’s network configuration is completed, please remember to change the IP Address
of your PC Connection Properties back to its original settings in order to ensure that your PC functions
properly in its real network environments.
It is strongly recommended to make a backup copy of the configuration settings.
For further configuration and backup information, please refer to the User’s Manual.
P/N: V34320180222
