Edsal MRWB-4 User manual

Safety Instructions
Safety Instructions
Safety Instructions
These units should be placed on a level surface. Failure to do so can result in poor product performance or create a
possible safety hazard. This unit should be securely anchored to a wall or floor with suitable fasteners, which are not
included. Do not use this unit for anything other than the manufactures intended purpose. DO NOT STAND ON ANY
PART OF THE UNIT, OR USE IT AS A LADDER. Evenly distribute the weight on each level and always keep the
heavier loads on the bottom. Use care when working with metal parts.
Heavy Duty 4’
1 Drawer Work Bench
MODEL NUMBER
MRWB - 4
MRWB
MRWB
MRWB -
-
-4 3 Shelf 1 Drawer
4 3 Shelf 1 Drawer
4 3 Shelf 1 Drawer -
-
-60”h x 24”d x 48”w
60”h x 24”d x 48”w
60”h x 24”d x 48”w
Description
36” Post (Top Back)
36” Post (Bottom Front)
Brace
Beam
24” Post (Bottom Back)
Top Shelf Support
Drawer Mount
Drawer Slide
Drawer Shelf Braces
Peg Board
Wood Shelf
Wood Drawer Shelf
Wood Top Shelf
Hardware
Qty.
2
2
4
5
2
1
2
2
2
1
2
1
1
4
Part Number
HWPT3602T
HWPT3602
RWBE2303
RWBE4703
HWPT2402
RWSS4803
RWDM2305
RWDS2003
RWDB4302
PGBD4820
RLPB2448
RPB43017
RPB2489
NB4
Part Size
36”
36’
24”
48”
24”
48”
N/A
N/A
43”
20” x 48”
24” x 48”
17” x 43”
9” x 48”
#10-24
General Instructions
General Instructions
General Instructions
Assembly is done with the rivets of the beams and braces fitting into the slots of the post. A rubber mallet may be used
on the beams and braces to seat the rivets properly. A hammer can also be used, providing one uses a cloth or a block
of wood between the hammer head and the parts to prevent damage. Tap gently and be sure the rivets are straight and
fully engaged.
Should you have any comments, damage, missing parts, or problems with assembly of this unit please feel
free to contact our Edsal manufacturing facility at, [phone] and request customer service. We can
also be reached on the internet at the following email address : [e-mail].
To obtain replacement parts, please provide the following information :
- Model # - Part # & Description - Location Purchased - Date Purchased
Consumer Products Division
Edsal Manufacturing Company
4400 South Packers Avenue
Chicago, IL 60609 www.edsal.com
Heavy Duty Work Bench

Start by taking one (1) 24” bottom back post, one (1) 36”
top back post, and one (1) post coupler, and join the two
post together to create the back post. Take one (1) 24”
brace with the shelf ledge facing up, and one (1) long
36” bottom front post and attach the rivets of the brace to
the top two (2) holes of the 36” long post. Take the back
post and attach the opposite rivets of the brace to the 2nd
set of holes on the back post. Tap brace down to seat.
Attach the bottom 24” brace to the bottom of the front
post and the opposite end to the bottom of the back post,
tap brace down to seat. Take one (1) drawer mount and
attach rivets to the front and back post holes located be-
low the 24” brace, tap down to seat. Take one (1) drawer
slide and insert it into the slide of the drawer mount. Re-
peat steps for the opposite end assembly.
Assembly Instructions for MRWB
Assembly Instructions for MRWB
Assembly Instructions for MRWB -
-
-4
4
4
Take four (4) 48” beams with the bend facing up, and
attach the rivets even with the braces from the two end
assembly's, and tap down to seat. Install the top shelf
support by installing the rivets to the back post using the
top two (2) holes. Install one (1) 48” beam with the
bend facing down, to the top holes of the back posts,
even with the rivets from the top shelf.
Place the peg board to the inside of the back post of the work
bench. Using the 3rd hole from the top of the back post,
align the holes of the peg board to the holes on the back
post, and fasten using the nuts and bolts provided. Use the
bottom holes of the top post and align the holes from the peg
board, and fasten using the same nuts and bolts. Take the
two (2) 43” drawer shelf braces and with the shelf ledge fac-
ing down, insert the two (2) rivets into the two (2) holes lo-
cated on the drawer slides, for the front and back of the
drawer.
Add the wood shelves to the top shelf support, the draw-
ers, the bottom shelf, and the work surface to finalize the
assembly of the workbench.
Step
1
Step
2
Step
3
Step
4
3rd Hole Down
Post are direc-
tional. The slot
must point down.
Drawer Mount
Drawer Slide 36” Bottom Front Post
Peg Board
Post
Coupler
24” Bottom Back Post
36” Top
Back
Post
24” Bot-
tom Back
Post
43” Drawer Shelf Braces
(Bend facing down)
(Back side also)
Top Shelf Support
48” Beams
48” Beam
(Bend facing down)
36” Top Back Post
24” Brace
Tap Lightly
Shelf Ledge Up
