INSTRUCTIONS FOR
EXTRA HEAVY DUTY GARAGE/WORKSHOP
TROLLEY
MODEL NO: CX103
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice
regulations are adhered to when using this trolley.
9Always load evenly with the centre of gravity of the load as near centre of the trolley as
possible.
8DO NOT overload the trolley - see section 2.
9Use the trolley in a suitable work area.
9Keep the work area clean, uncluttered and ensure there is adequate lighting.
9Keep the trolley clean and tidy in accordance with good workshop practice.
8DO NOT use the trolley for any purpose other than that for which it is designed.
8DO NOT stand on the trolley, use it as a ladder or allow others to ride on the trolley.
9Use the wheel locks to prevent the trolley from inadvertently moving.
8DO NOT leave unattended, especially when loaded, unless the wheels are locked, chocked
or the trolley otherwise secured.
8DO NOT use trolley on uneven ground and do not run over curbs or steps - use a ramp.
8DO NOT use trolley if any part is significantly damaged, paying particular attention to the
wheels.
9Keep children and unauthorised persons away from the work area.
2. INTRODUCTION
Garage or workshop trolley with a total capacity of 80kg. Deep-walled shelves, each of which may be installed base down or base up to give
either tool and component security or unobstructed access. Fitted with four large castors, two with a brake.
3. CONTENTS
Carefully unpack the product and check the contents against the diagram and parts list below. Should any items be missing or damaged contact
your Sealey stockist.
4. ASSEMBLY
4.1. Mount tray (2) to the upper hole in the end frames (3) and loosely fix with four M6 x 32mm bolts (1). Make sure the dished holes on the
end frames are facing outwards.
4.2. Mount the two other trays (2) to the middle and lower holes in the end frames (3) and loosely fix with M6 x 32mm bolts (1).
4.3. Tighten all bolts (1).
4.4. Turn the trolley over, install castors (4 & 5) into the bottom of the end frames and fix with the M6 x 12mm bolts (6).
4.5. Turn the trolley upright. The trolley is ready to use.
CX103 | Issue 4 10/01/17
Original Language Version
© Jack Sealey Limited
Refer to
instructions

5. OPERATION
Item Part No: Description
1 CX101D.01 BOLT M6 x 32mm
2 CX101D.02 TRAY
3 CX101D.03 HANDLE
4 CX101D.04 CASTOR WHEEL c/w BRAKE
5 CX101D.05 CASTOR WHEEL
6 CX101D.06 BOLT M6 x 12mm
7 CX101D.08 WASHER
8 CX101D.09 SPRING WASHER
9 CX101D.10 NUT
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
Sole UK Distributor, Sealey Group.
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk.
IP32 7AR
www.sealey.co.uk
[e-mail]
01284 757500
01284 703534
CX103 | Issue 4 10/01/17
Original Language Version
© Jack Sealey Limited
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email [e-mail] or telephone [phone].
