Edwards SCU-750 User manual

D397-51-880
Issue E Original
Instruction Manual
Profibus Module for SCU-750/800/1400/1500/1600
Description Item Number
Profibus Module for SCU-750/800/1400/1500/1600 D397-51-500

This product has been manufactured under a quality management system certified to ISO 9001:2008
Declaration of Conformity
We, Edwards Limited,
Crawley Business Quarter,
Manor Royal,
Crawley,
West Sussex, RH10 9LW, UK
declare under our sole responsibility, as manufacturer and person within the EU authorised
to assemble the technical file, that the product(s)
Profibus Module for SCU-750/800/1400/1500/1600 0397-51-500
to which this declaration relates is in conformity with the following standard(s) or other
normative document(s)
EN61326-1:2013 Electrical equipment for measurement, control and laboratory
(Class B Emissions, Use. EMC requirements. General requirements
Industrial Immunity)
and fulfils all the relevant provisions of
2014/30/EU Electromagnetic Compatibility (EMC) Directive
Note: This declaration covers all product serial numbers from the date this Declaration was
signed onwards.
16.07.2015, Eastbourne
Larry Marini, Senior Technical Manage
r
Date and Place
P200-02-300 Issue E

© Edwards Limited 2014. All rights reserved. Page i
Edwards and the Edwards logo are trademarks of Edwards Limited.
Contents
D397-51-880 Issue E
Contents
Section Page
1 INTRODUCTION ....................................................................................1
1.1 Scope and definitions ................................................................................................... 1
1.2 Outline description ...................................................................................................... 2
1.3 Applicable SCU models .................................................................................................. 2
2 TECHNICAL DATA .................................................................................3
2.1 Mechanical data .......................................................................................................... 3
2.2 Operating and storage data ............................................................................................ 3
2.3 Electrical data ............................................................................................................ 3
2.3.1 d.c. Power connector ................................................................................................... 3
2.3.2 Profibus connector ...................................................................................................... 4
2.3.3 RS232 Connector ......................................................................................................... 5
3 INSTALLATION .....................................................................................6
3.1 Unpack and inspect ...................................................................................................... 6
3.2 Fitting the module ....................................................................................................... 6
3.2.1 Rack mounting ........................................................................................................... 7
3.2.2 Panel mounting .......................................................................................................... 7
3.2.3 DIN rail mounting ........................................................................................................ 7
3.3 Electrical connections ................................................................................................... 8
3.4 Bus termination .......................................................................................................... 9
3.5 SCU-750 control unit set up ............................................................................................ 9
3.6 SCU-800/1400/1500/1600 control unit set up ......................................................................10
3.7 iX-455 control unit set up .............................................................................................10
4 OPERATION ...................................................................................... 11
4.1 Profibus system information ..........................................................................................11
4.2 Simple set up instructions .............................................................................................11
4.3 Front panel display .....................................................................................................11
4.4 Address set up ...........................................................................................................12
4.5 Baud rate .................................................................................................................14
4.6 Software format ........................................................................................................14
4.6.1 Parameterisation ........................................................................................................15
4.6.2 Configuration ............................................................................................................15
4.6.3 Configuration failure ...................................................................................................15
4.6.4 Diagnostics description ................................................................................................16
4.6.5 Data exchange values ..................................................................................................16
4.7 Software modules .......................................................................................................17
4.7.1 Module 01 - Pump Command ..........................................................................................17
4.7.2 Module 02 - Pump State ...............................................................................................18
4.7.3 Module 03 - Warning flags .............................................................................................18
4.7.4 Module 04 - Failure flags ..............................................................................................19
4.7.5 Module 05 - Pump Speed ...............................................................................................20
4.7.6 Module 06 - Motor Current ............................................................................................20
4.7.7 Module 07 - Motor Temperature ......................................................................................20
4.7.8 Module 08 - Control Unit Temperature ..............................................................................20
4.7.9 Module 09 - Supervisor software version ............................................................................20
4.7.10 Module 10 - Motor Drive software version ..........................................................................21
4.7.11 Module 11 - Active Magnetic Bearing software version ...........................................................21
4.7.12 Module 12 - Profibus software version ...............................................................................21
4.7.13 Module 13 - Pump Serial Number .....................................................................................21
4.7.14 Module 14 - Control Unit Serial Number ............................................................................21
gea/0033/11/08

D397-51-880 Issue E
Page ii © Edwards Limited 2014. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Contents
4.7.15 Module 15 - Pump Run Time ..........................................................................................21
4.7.16 Module 16 - Control Unit Run Time ..................................................................................21
4.7.17 Module 17 - Damage Limit counter ..................................................................................22
4.7.18 Module 18 - Speed Setpoint ...........................................................................................22
4.7.19 Module 19 - Xh Vibration ..............................................................................................22
4.7.20 Module 20 - Xb Vibration ..............................................................................................22
4.7.21 Module 21 - Z Vibration ................................................................................................22
4.7.22 Module 22 - Speed Demand ...........................................................................................23
5 MAINTENANCE ................................................................................... 24
5.1 Fault finding .............................................................................................................24
6 STORAGE AND DISPOSAL ....................................................................... 25
6.1 Storage ...................................................................................................................25
6.2 Disposal ...................................................................................................................25
7 SPARES AND ACCESSORIES ..................................................................... 26
7.1 Introduction .............................................................................................................26
7.2 Accessories ...............................................................................................................26
Index .............................................................................................. 27
For return of equipment, complete the HS Forms at the end of this manual.
Illustrations
Figure Page
1 Pin connections for the 2-way power connector .................................................................... 3
2 Pin connections for 9-way ‘D’ type socket ........................................................................... 4
3 Pin connections for 9-way ‘D’ type plug ............................................................................. 5
4 Dimensions of the Profibus module (mm) ............................................................................ 6
5 Panel mounting the module ............................................................................................ 7
6 DIN rail mounting the Module .......................................................................................... 8
7 Profibus module rear connections .................................................................................... 9
8 Profibus front panel display ...........................................................................................11
Tables
Table Page
1 Pin connections for 9-way ‘D’ type socket ........................................................................... 4
2 Pin connections for 9-way ‘D’ type plug ............................................................................. 5
3 Component checklist .................................................................................................... 6
4 Serial interface cable ................................................................................................... 8
5 SCU-750 control unit command interface and communications parameters ................................... 9
6 Front panel symbols and their functions ............................................................................12
7 Address switch settings ................................................................................................12
8 Summary of software modules ........................................................................................17
9 Fault finding guide ......................................................................................................24

© Edwards Limited 2014. All rights reserved. Page 1
Edwards and the Edwards logo are trademarks of Edwards Limited.
INTRODUCTION
D397-51-880 Issue E
1 INTRODUCTION
1.1 Scope and definitions
This manual provides installation, operation and maintenance instructions for the Edwards SCU Series Profibus
Module. The module must be used as specified in this manual.
Read this manual before installing and operating the module. Important safety information is highlighted as WARNING
and CAUTION instructions; these instructions must be obeyed. The use of WARNINGS and CAUTIONS is defined below.
CAUTION
Cautions are given where failure to observe the instruction could result in damage to the equipment, associated
equipment and process.
Throughout this manual, page, figure or title numbers are sequential.
The following labels appear on the module:
WARNING
Warnings are given where failure to observe the instruction could result in injury or death to
people.
Warning - refer to accompanying documentation.
Edwards offer European customers a recycling service.

D397-51-880 Issue E
Page 2 © Edwards Limited 2014. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
INTRODUCTION
1.2 Outline description
The SCU Series Profibus Module provides a Profibus DP V0 slave interface for the SCU turbomolecular pump control
units listed in Section 1.3. The module communicates with the control unit using the RS232 interface. Commands
received from the Profibus network are relayed to the control unit. Data from the control unit is stored in the module
and transmitted over the Profibus network when requested. The front panel of the module has four LEDs which
indicate the status of the module and the Profibus network. The Profibus slave address is set using rotary switches.
The back panel of the module has a 9-way 'D' connector for the Profibus network, a 9-way 'D' connector for the RS232
link to the control unit and a power connector.
Refer to the product manuals listed in Section 1.3 for full operation of the turbo pump control units.
1.3 Applicable SCU models
The Large-Medium Series Profibus Module is for use with the following SCU models:
WARNING
Edwards take no responsibility for damage or injury caused by improper use of the equipment.
WARNING
This equipment provides remote control of an Edwards Turbo pump. Refer to the safety
information in the turbo pump control unit manual.
WARNING
This unit should not be relied upon for safety related functions.
SCU Control Unit Product Manual
SCU-750 MT-56E-101
SCU-800 MT-49E-101
SCU-1400 MT-72E-101
SCU-1500 MT-59E-101
SCU-1600 MT-76E-101
STP-iX455 series control unit MT-64E-002

© Edwards Limited 2014. All rights reserved. Page 3
Edwards and the Edwards logo are trademarks of Edwards Limited.
TECHNICAL DATA
D397-51-880 Issue E
2 TECHNICAL DATA
2.1 Mechanical data
Refer to Section 3.2 for installed dimensions and panel cut-out.
2.2 Operating and storage data
2.3 Electrical data
2.3.1 d.c. Power connector
Figure 1 - Pin connections for the 2-way power connector
Weight 0.28 kg
Dimensions 129 x 30.5 x 117 mm
Ambient operating temperature 0°C to 40°C
Humidity Max 90% RH non-condensing
Maximum altitude 2000 m
IP rating IP30 - indoor use only
Ambient storage temperature -30°C to 70°C
WARNING
Do not exceed the maximum supply voltage. Excessive supply voltage will cause permanent
damage to the control electronics and may result in a mechanical hazard in some failure
conditions.
Electrical supply 9 V d.c. to 52 V d.c.
Power consumption 5 W max. Switch on surge 500 mA max.
Fuse No internal fuse
Connector type 2 Way Receptacle. Mating part is cable-mount
Terminal Block (supplied). Suitable parts include:
Phoenix MSTB 2.5/2-G-5.08; Weidmuller BLZ 5.08/2;
Amp 796634-2; IMO 21.950/2 (Refer to Figure 1).

D397-51-880 Issue E
Page 4 © Edwards Limited 2014. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
TECHNICAL DATA
2.3.2 Profibus connector
Figure 2 - Pin connections for 9-way ‘D’ type socket
Connector type 9-way ‘D’ type socket (Refer to Figure 2)
Profibus Data signals Electrically compliant with RS485 specification.
Isolated from chassis.
Profibus Power Supply 10 mA supply (protected) for external terminator
resistors if required.
Chassis For Profibus cable screen connection
Repeater control signal Digital signal, nominally 0-5 V but with series 340 ohm
resistor. High = module transmitting. Low = Receiving
or Idle.
Table 1 - Pin connections for 9-way ‘D’ type socket
Pin Allocation
1
2
3
4
5
6
7
8
9
Shell
Chassis (box)
Not connected
Profibus Data + (B)
Control Signal for Repeater
Profibus Data reference (isolated)
Profibus 5V output (isolated)
Not connected
Profibus Data - (A)
Not connected
Chassis (box)

© Edwards Limited 2014. All rights reserved. Page 5
Edwards and the Edwards logo are trademarks of Edwards Limited.
TECHNICAL DATA
D397-51-880 Issue E
2.3.3 RS232 Connector
Figure 3 - Pin connections for 9-way ‘D’ type plug
Table 2 - Pin connections for 9-way ‘D’ type plug
Connector type 9-way ‘D’ type plug (Refer to Figure 3)
For connection to serial comms port of SCU control
unit only.
RS232 protocol 9600 baud, 1 stop bit, 8 data bits, no parity
Pin Allocation
1
2
3
4
5
6
7
8
9
Shell
Not connected
RS232 receive
RS232 transmit
Not connected
RS232 common
Not connected
Not connected
Not connected
Not connected
Chassis (box)

D397-51-880 Issue E
Page 6 © Edwards Limited 2014. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
INSTALLATION
3 INSTALLATION
3.1 Unpack and inspect
Remove all of the packaging material and check the module. If the module is damaged, follow the Edwards return of
equipment procedures that are laid out in the back of this manual. Do not use the module if it is damaged.
Check that the package contains the items that are listed in Table 3. If any of these items are missing, notify the
supplier in writing within three days. If the module is not to be used immediately, store in suitable conditions as
described in Section 6.1.
3.2 Fitting the module
CAUTION
The unit is IP30 rated. Please ensure that the unit is not installed where fluids can enter into the Module.
The module can be rack mounted, panel mounted, DIN rail mounted or free-standing. Sufficient space must be
provided at the rear of the unit for the cables. If right-angled connectors are used additional space will be required.
If the unit is to be used free-standing it should be laid flat to ensure stability. The four self-adhesive rubber feet can
be used to prevent sliding. Figure 4 shows the dimensions of the module with the rubber feet attached.
Figure 4 - Dimensions of the Profibus module (mm)
Table 3 - Component checklist
Quantity Description Check()
1Module 
1 Instruction Manual 
1 DC Power Connector 
2DINRailclips 
2 Mounting screws 
4 Rubber feet 
1 CD (includes GSD file) 
1 RS-232 cable for SCU connection 

© Edwards Limited 2014. All rights reserved. Page 7
Edwards and the Edwards logo are trademarks of Edwards Limited.
INSTALLATION
D397-51-880 Issue E
3.2.1 Rack mounting
For Rack mounting the unit should be fitted in a space 6HP wide x 3U high, using the 2-off M2.5 screws provided.
3.2.2 Panel mounting
For panel mounting cut the aperture in the panel using the dimensions shown in Figure 5. The module can be fixed
into the panel with the 2-off M2.5 screws.
Figure 5 - Panel mounting the module
3.2.3 DIN rail mounting
For DIN rail mounting the 2 clips should be attached to the module using 2-off M3 screws provided (one in the centre
of each clip), as shown in Figure 6. The clips should then be roughly aligned with the box sides. The clips can then
be fitted to a suitable DIN-rail, as shown in Figure 6.

D397-51-880 Issue E
Page 8 © Edwards Limited 2014. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
INSTALLATION
It is recommended to use end stops on a DIN rail system.
Figure 6 - DIN rail mounting the Module
3.3 Electrical connections
1. A 2 m cable is supplied in the kit fitted with 4-40 UNC jack screws at both ends. Some of the SCU control units
use M3 jack sockets, but if applicable, the cable supplied in the kit can be used. If not, please make up a cable
according to the table below.
Note 1: The cable must not connect to any of the other 6 pins of the 9-way D-type plug (SCU end).
Note 2: It is recommended that the cable be screened with the screen connected to the backshell at each end.
2. Connect the RS232 connector of the Profibus module to connector X3A of the SCU. Do not use connector X3B of
the SCU.
3. Connect the Profibus network to the Profibus connector using standard Profibus cables. Refer to Section 3.4 for
details of bus termination.
4. Connect a suitable power supply to the DC power connector using the mating cable-mount terminal block
supplied.
WARNING
If access to the DC power connector is restricted an additional isolation device should be provided
which will be easily accessible by an operator.
Table 4 - Serial interface cable
SCU Control Unit
9-way ‘D’ type plug Connection Profibus Module
9-way ‘D’ type socket
Pin 2 (Tx) ______________________ Pin 2 (Rx)
Pin 3 (Rx) ______________________ Pin 3 (Tx)
Pin 5 (GND) ______________________ Pin 5 (common)

© Edwards Limited 2014. All rights reserved. Page 9
Edwards and the Edwards logo are trademarks of Edwards Limited.
INSTALLATION
D397-51-880 Issue E
Figure 7 - Profibus module rear connections
Take care during cable installation that all electrical cables are safely secured and cannot present a trip hazard.
3.4 Bus termination
Bus termination is not supplied with the module, but must be used as for a normal Profibus DP system. Bus
termination must be used at both ends of the Profibus trunk and not anywhere else. If the module is placed at one
end of the trunk a connector containing the standard termination resistors should be used. The appropriate 5 V and
0 V signals are supplied on the standard pins for this purpose.
3.5 SCU-750 control unit set up
The control unit command interface and communication parameters must be set up. The procedure for how to do
this is detailed below:
1. Ensure the small slide switch on the front of the control unit labelled "REMOTE" is set to the ON position.
2. Enter the "Parameter Set Mode" by pressing the SELECT and UP switches simultaneously.
3. For each menu item the options can be seen and changed by pushing the UP and DOWN buttons. When the menu
item parameter is set to the desired option press the ENTER button, which will temporarily set that parameter
to the value selected and immediately move to the next parameter.
4. Follow this process for all 13 parameters as shown in Table 5.
Table 5 - SCU-750 control unit command interface and communications parameters
Parameter Value to set
1 Remote mode RS232/485 Com. Note: DO NOT SET RS232/485 Modbus or Lonworks
or I/O Remote. This is the only parameter which will not be at the
factory default value.
2 Speed Setpoint Value in RPM. This must not be greater than the maximum value for
the pump.
3 TMS function Disable - unless the system has this additional hardware.
4 Inhibit Command Disable
5 Leak valve option Disable
6SecondDamagelimit Enable
7 Baud Rate 9600
8 Bit Length 8
9Stopbit 1
10 Parity None
11 Driver Type RS232
12 Node address Not important
13 Storage Yes - Read instructions below

D397-51-880 Issue E
Page 10 © Edwards Limited 2014. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
INSTALLATION
5. When the Storage parameter is due to be set select Yes and then press ENTER to store the other 12 parameter
values. Wait until the display shows "Storage OK" then press the SELECT switch to exit the parameter setting
mode.
6. Note that if during the parameter setting process no switch is pressed for 1 minute, the parameter setting mode
will end and all changes will be lost. In this event repeat the process.
3.6 SCU-800/1400/1500/1600 control unit set up
The control unit command interface and communication parameters must be set up. Either use the procedure below
or refer to the control unit manual for the procedure to do this.
1. Ensure the small slide switch on the front of the control unit labelled “REMOTE” is set to the ON position.
2. Enter the “Parameter Set Mode” by pressing the SELECT and UP switches simultaneously.
3. For each menu item the value can be changed by using the UP and DOWN buttons. The ENTER button will allow
access to sub-menus and temporarily set that parameter. The SELECT button generally has a “jump-over”
function. Note if no switch is pressed for 1 minute, the parameter setting mode will end and all changes will be
lost. In this event repeat the process.
4. 1st menu item is REMOTE MODE. Push ENTER and adjust setting (UP/DOWN buttons) until the value shown is
COM1. Press ENTER to temporarily store.
5. 2nd menu item is Speed Setpoint. Push SELECT to leave unchanged.
6. 3rd menu item is TMS function. Push SELECT to leave unchanged.
7. 4th menu item is Inhibit Command. Push SELECT to leave unchanged.
8. 5th menu item is Leak Valve Option. Push SELECT to leave unchanged.
9. 6th menu item is Warning function. Push SELECT to leave this parameter unchanged.
10.7th menu item is COM1 Set. Push ENTER as this must be correct.
Set Baud Rate to 9600 and push ENTER.
Set Bit length to 8 and push ENTER.
Set Stop bit to 1 and push ENTER>
Set Parity to None and push ENTER.
Set Driver type to RS232 and push ENTER.
RS485 ID push SELECT to leave unchanged.
Push SELECT to exit COM1 Menu.
11.Next menu item is COM2 Set. Push SELECT to leave unchanged.
12.Next menu item is STORAGE. Select YES then push ENTER to start the storage process and wait until the display
shows “Storage OK”. N.B. for successful storage the pump must be connected to the control unit.
13.After “Storage OK” message push ENTER.
14.The SCU then provides the opportunity to modify the date and time. Press SELECT to leave unchanged.
3.7 STP-iX455 series control unit set up
COM1 RS-232 settings need to be as factory default values (Baud Rate: 9,600 bps; Bit Length: 8 bit; Stop Bit: 1 bit;
Parity: None; Drive Type: RS232).
In order to obtain control by Profibus the iX-455 control unit must also be set up for remote operation. See
Section 9.2.4 of the control unit manual (“Input Operation Port Setting”) for instructions on how to do this.

© Edwards Limited 2014. All rights reserved. Page 11
Edwards and the Edwards logo are trademarks of Edwards Limited.
OPERATION
D397-51-880 Issue E
4OPERATION
4.1 Profibus system information
The Profibus module is for connection to a Profibus DP network and operates as a V0 slave only.
The Profibus master requires a GSD file for each slave. The GSD file for this slave is contained on the CD supplied
with the unit and has the file name "EDW0B32.GSD", which is registered with the Profibus Association.
When configuring the system the "ID" number will be 0B32 and the unit's description will be
"STP series (except SCU-350)".
Note: The GSD file should not be altered.
4.2 Simple set up instructions
1. Install the module and connect the cables as described in Section 3.
2. Set up the STP pump and SCU control unit according to the instruction manuals.
3. Set the address switches on the Profibus module.
4. Apply power (or power cycle the Profibus module, for example by disconnecting then reconnecting the power
connector).
5. Load the GSD file into the Profibus system configurator.
6. Select "STP series (except SCU-350)" as a slave and set the address to match the address switches.
7. Select Module 01 to provide on and off control of the turbo pump and select Module 02 to monitor turbo pump
state. Add other Profibus software modules as required.
4.3 Front panel display
Figure 8 - Profibus front panel display

D397-51-880 Issue E
Page 12 © Edwards Limited 2014. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
OPERATION
4.4 Address set up
The module address can be set from 0 to 125 using the two hexadecimal rotary switches on the front panel. The lower
switch defines the lower half of the address byte (nibble) and the upper switch defines the upper half of the address
byte. Each node on a Profibus network must have a unique address. The address switches will only be read by the
unit at power up. Any change of address setting after power up will be ignored until next power up.
The following table may assist.
Table 6 - Front panel symbols and their functions
Symbol Name Function
Data exchange Module is in data exchange as defined by the Profibus standard.
Off-line Module is not in data exchange as defined by the Profibus standard.
Error ON at the same as Offline LED = Configuration or parameterisation
error:
Flashing at 1 Hz = Invalid address selected.
Power Internal 5 V supply is operating.
Upper address
switch Sets value of upper nibble of address (Hexadecimal).
Lower address
switch Sets value of lower nibble of address (Hexadecimal).
Table 7 - Address switch settings
Address in
Decimal
Upper switch
setting Lower switch setting Address in
Decimal
Upper switch
setting Lower switch setting
000633F
1016440
2026541
3036642
4046743
5056844
6066945
7077046
8087147

© Edwards Limited 2014. All rights reserved. Page 13
Edwards and the Edwards logo are trademarks of Edwards Limited.
OPERATION
D397-51-880 Issue E
9097248
10 0 A 73 4 9
11 0 B 74 4 A
12 0 C 75 4 B
13 0 D 76 4 C
14 0 E 77 4 D
150F784E
16 1 0 79 4 F
17 1 1 80 5 0
18 1 2 81 5 1
19 1 3 82 5 2
20 1 4 83 5 3
21 1 5 84 5 4
22 1 6 85 5 5
23 1 7 86 5 6
24 1 8 87 5 7
25 1 9 88 5 8
26 1 A 89 5 9
27 1 B 90 5 A
28 1 C 91 5 B
29 1 D 92 5 C
30 1 E 93 5 D
311F945E
32 2 0 95 5 F
33 2 1 96 6 0
34 2 2 97 6 1
35 2 3 98 6 2
36 2 4 99 6 3
37 2 5 100 6 4
38 2 6 101 6 5
39 2 7 102 6 6
40 2 8 103 6 7
41 2 9 104 6 8
42 2 A 105 6 9
43 2 B 106 6 A
44 2 C 107 6 B
45 2 D 108 6 C
46 2 E 109 6 D
Table 7 - Address switch settings (continued)
Address in
Decimal
Upper switch
setting Lower switch setting Address in
Decimal
Upper switch
setting Lower switch setting

D397-51-880 Issue E
Page 14 © Edwards Limited 2014. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
OPERATION
Note: If the address is set to a value greater than 125 (decimal) the RED error LED will flash at around 1 Hz and
the module will go on-line. If this occurs, either change the address and cycle the power or remove power
and change the address.
4.5 Baud rate
All 10 standard DP baud rates are supported. These are: 9.6Kbd; 19.2Kbd; 45.45Kbd; 93.75Kbd; 187.5Kbd; 500Kbd;
1.5Mbd; 3Mbd; 6Mbd; 12Mbd. The unit has no facility for adjusting baud rate as detection is automatic and will
therefore respond to the baud rate chosen by the master.
4.6 Software format
The slave software is based upon a modular configurable architecture so the user has considerable control of the
contents of the data exchange messages.
The software modules (defined in the GSD files) relate to the control unit serial communications objects.
When the unit is linked onto the Profibus it will be parameterised and then configured before entering data exchange.
The parameterisation and configuration choices are in the GSD file and its comments describe the data content of
the input, output and parameterisation bytes. These choices will often be made using a third party configurator such
as SyCon that presents a user-friendlier interface.
16-bit valves are transmitted with the MSB first and the LSB last.
47 2 F 110 6 E
48 3 0 111 6 F
49 3 1 112 7 0
50 3 2 113 7 1
51 3 3 114 7 2
52 3 4 115 7 3
53 3 5 116 7 4
54 3 6 117 7 5
55 3 7 118 7 6
56 3 8 119 7 7
57 3 9 120 7 8
58 3 A 121 7 9
59 3 B 122 7 A
60 3 C 123 7 B
61 3 D 124 7 C
62 3 E 125 7 D
Table 7 - Address switch settings (continued)
Address in
Decimal
Upper switch
setting Lower switch setting Address in
Decimal
Upper switch
setting Lower switch setting

© Edwards Limited 2014. All rights reserved. Page 15
Edwards and the Edwards logo are trademarks of Edwards Limited.
OPERATION
D397-51-880 Issue E
4.6.1 Parameterisation
Parameterisation is used for control values which are only to be changed occasionally. These values are only
transmitted at the start of data exchange. The only value used as a parameter in these units is speed setpoint. This
is included with module18. See Section 4.7.18 for details. If module18 is not selected as part of the data exchange
configuration the existing value of speed setpoint will be used, as this is retained following a power down.
4.6.2 Configuration
During configuration the user can define what modules are required and in which order the data is transferred. The
unit simply adds the input and output data bytes to the message maps in the order that they are defined in the
configuration message.
Example:
Module = Mod_A 3 bytes in (Ai1, Ai2, Ai3), 1 byte out (Ao1)
Module = Mod_B 2 bytes in (Bi1, Bi2), 2 bytes out (Bo1, Bo2)
A) Configure Mod_A, Mod_B gives
Output map: -
Input map:-
B) Configure Mod_B, Mod_A gives
Output map:-
Input map:-
Data is always referred to the Master so output is Control data from Master to Slave and Input data is feedback from
Slave to Master. There are many software modules and many bytes of data. Care must be taken in correctly selecting
and aligning the data into the system.
4.6.3 Configuration failure
Most of the software modules can be configured with most of the turbo pump control units but there are some
exceptions. Which SCU’s can be used with which Profibus software modules is shown in Section 4.7.
If one of these modules is inappropriately configured the unit will not enter data exchange. Instead the number of
the first failed module will be placed in the extended diagnostics. Additionally the unit’s front panel error LED (red)
will be illuminated.
Byte1 Byte2 Byte3
Ao1 Bo1 B02
Byte1 Byte2 Byte3 Byte4 Byte5
Ai1 Ai2 Ai3 Bi1 Bi2
Byte1 Byte2 Byte3
Bo1 Bo2 Ao1
Byte1 Byte2 Byte3 Byte4 Byte5
Bi1 Bi2 Ai1 Ai2 Ai3

D397-51-880 Issue E
Page 16 © Edwards Limited 2014. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
OPERATION
4.6.4 Diagnostics description
The modules use extended diagnostics in the format below.
Max_Diag_Data_Len = 12
Loss of serial comms may be due to the SCU being turned off or the RS232 cable being disconnected. It will take up
to 9 seconds to detect. If this occurs the Slave will signal the Master with a ‘Data High’ flag in the Frame Control byte
but will continue to be in Data Exchange with the data values all set to zero. The extended diagnostics message will
be available to the Master.
If RS232 communications are restored the Slave will again signal the Master with a ‘Data High’ flag in the Frame
Control byte and will return to ‘good’ Data Exchange values. Again the extended diagnostics message will be available
to the Master.
4.6.5 Data exchange values
Data update rate (latency) is fixed and not affected by which software modules are included in the Data Exchange
message. The update rate is not the same for all parameters and will be up to 9 seconds for some parameters.
At the beginning of Data Exchange, particularly but not only, when Data Exchange has started due to power up of
either the Turbo control unit or the Profibus Module or due to RS-232 cable reconnection, the data values will either
be old or zero. These values will be successively corrected over the first few seconds of Data Exchange. For some
parameters this process will take up to 9 seconds.
Bytes 1-6 7 8 and 8 10 and 11 12
Description
Mandatory No of bytes of
extended
diagnostics (6)
Module failed
parameterisation,
MSB in 8, LSB in 9
Module failed
configuration,
MSB in 10, LSB in
11
Serial comms
lost (0=OK,
1=lost)
