DSE DSE2157 User manual

DEEP SEA ELECTRONICS
2157 Output Expansion Installation Instructions
Introduction
DSE2157 relay expansion module is used in conjunction with the DSE7000 series controllers to
provide additional relay output functionality. The relay outputs are configured in the ‘host controller’,
the DSE2157 module is not itself configured apart from the ‘ID switch’ detailed below.
For further details on configuring the ‘host controller’ you are referred to the relevant configuration
software manual.
Controls and indications
LED Indications
Function Colour Action
Power on / Link lost RED Steady when DC supply is connected and data is being received
from the host controller.
Flashing when the DC supply is connected and the data
connection to the host controller is not operating.
Status 1-8 RED Lit when the corresponding relay is active
ID switch
The rotary ID switch is used to select the ‘ID’ of the 2157 expansion module as the host controller is
capable of giving instructions to a number of 2157 expansion modules at the same time (consult
relevant modules instructions for further details on number of supported expansion units).
The enclosure cover must be unclipped and removed to gain access to the switch. The switch should
be operated using a small screwdriver and set to match the required ID.
NOTE : The ID must be a unique number, different from the ID of any other 2157 module
connected to the host controller.
If two or more 2157 controllers are required to ‘mimic’ each other then they should be
configured with different IDs, and both configured the same in the host controller.
NOTE : The selection of the ID of other types of expansion modules WILL NOT interfere/clash
with the ID of the 2548. For instance if the 2548 is set to ID 4, it is acceptable to have a different
type of expansion module (for instance 2130) set to ID 4 also.
053-034
ISSUE 2
ID Switch
Power on /
Link lost LED
8 x Status LED
(1 LED per
relay)

Typical wiring diagrams
NOTE : Configuration of the outputs is performed in the host controller.
Dimensions
Overall size 164.6mm x 76.4mm x 48.9mm (6.48” x 3.01” x 1.93”)
Mounting type DIN rail or chassis mounting
Din rail type EN 50022 35mm type only
Mounting holes M4 clearance
Mounting hole centres 152.37mm x 64.50mm (6.00” x 2.54”)
Deep Sea Electronics Plc.
Tel:[phone]
Fax: [phone]
LO CALL (from UK BT landlines) :
Telephone [phone]
Email: [e-mail]
Web:
www.deepseaplc.com
Deep Sea Electronics Inc.
Phone: [phone]
Fax: [phone]
TOLL FREE (USA only) : Tel: [phone]
Email: [e-mail]
Web: www.deepseausa.com
Deep Sea Electronics Plc.
(Far East)
Tel:[phone]
Fax: [phone]
Email: [e-mail]
Web: www.deepseaplc.com

DEEP SEA ELECTRONICS
DSEEXTRA®
DSE2157 relay output expansion module
057-083
Author : Anthony Manton
COMPLEX SOLUTIONS
MADE SIMPLE

DSE2157 relay output expansion module
2
057-083 Issue 1 DSE2157 relay output expansion operator manual
Deep Sea Electronics Plc
Highfield House
Hunmanby
North Yorkshire
YO14 0PH
ENGLAND
Sales Tel: [phone]
Sales Fax: [phone]
E-mail : [e-mail]
Website : www.deepseaplc.com
DSE2157 relay output expansion module
© Deep Sea Electronics Plc
All rights reserved. No part of this publication may be reproduced in any material form (including
photocopying or storing in any medium by electronic means or other) without the written permission of
the copyright holder except in accordance with the provisions of the Copyright, Designs and Patents
Act 1988.
Applications for the copyright holder’s written permission to reproduce any part of this publication
should be addressed to Deep Sea Electronics Plc at the address above.
Any reference to trademarked product names used within this publication is owned by their respective
companies.
Deep Sea Electronics Plc reserves the right to change the contents of this document without prior
notice.
Amendments since last publication
Amd. No. Comments
Typeface : The typeface used in this document is Arial. Care should be taken not to mistake the upper
case letter I with the numeral 1. The numeral 1 has a top serif to avoid this confusion.

DSE2157 relay output expansion module
057-083 Issue 1 DSE2157 relay output expansion operator manual 3
1 BIBLIOGRAPHY.................................................................................................. 4
2 INTRODUCTION.................................................................................................. 4
3 SPECIFICATIONS ............................................................................................... 5
3.1 PART NUMBERING................................................................................................................. 5
3.1 POWER SUPPLY..................................................................................................................... 5
3.2 DSENET®................................................................................................................................. 5
3.3 OUTPUTS................................................................................................................................. 6
3.4 DIMENSIONS ........................................................................................................................... 6
3.5 APPLICABLE STANDARDS ................................................................................................... 6
4 INSTALLATION ................................................................................................... 7
5 USER CONNECTIONS........................................................................................ 7
5.1 TERMINAL SPECIFICATION .................................................................................................. 7
5.1.1 CONNECTOR A ................................................................................................................ 7
5.1.2 CONNECTOR B ................................................................................................................ 7
6 TYPICAL WIRING DIAGRAM ............................................................................. 8
7 CONTROLS AND INDICATIONS ........................................................................ 9
7.1 LED INDICATIONS .................................................................................................................. 9
7.2 ID SWITCH ............................................................................................................................... 9
8 FAULT DIAGNOSIS .......................................................................................... 10
9 MAINTENANCE, SPARES, REPAIR AND SERVICING ................................... 10
10 WARRANTY ................................................................................................... 10
11 DISPOSAL ...................................................................................................... 10
11.1 WEEE (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT) .................................10
11.2 ROHS (RESTRICTION OF HAZARDOUS SUBSTANCES...............................................10

DSE2157 relay output expansion module
4
057-083 Issue 1 DSE2157 relay output expansion operator manual
1 BIBLIOGRAPHY
This document refers to and is reffered to by the following DSE publications which can be obtained
from the DSE website www.deepseaplc.com
DSE PART
DESCRIPTION
057-074 7000 series operators manual
057-077 7000 series configuration software manual
2 INTRODUCTION
This document details the installation requirements of the DSE2157 relay expansion module part of
the DSEExtra® range of ancilliary modules.
The manual forms part of the product and should be kept for the entire life of the product. If the
product is passed or supplied to another party, ensure that this document is passed to them for
reference purposes.
This is not a controlled document. You will not be automatically informed of updates. Any future
updates of this document will be included to the DSE website at www.deepseaplc.com
DSE2157 relay expansion module is used in conjunction with the DSE7000 series controllers to
provide additional relay output functionality. The relay outputs are configured in the ‘host controller’,
the DSE2157 module is not itself configured aside from the ‘ID switch’ detailed below.
For further details on configuring the ‘host controller’ you are referred to the relevant configuration
software manual (refer to the section entitled Bibliography elsewhere in this document).

DSE2157 relay output expansion module
057-083 Issue 1 DSE2157 relay output expansion operator manual 5
3 SPECIFICATIONS
3.1 PART NUMBERING
2157 - 001 - 00
At the time of this document production, there are no variants of this product and there have been no
revisions of the module hardware.
3.1 POWER SUPPLY
Minimum supply voltage 8V continuous, 4V for up to 5 minutes.
Cranking dropouts Able to survive 0V for 50mS providing the supply was at least 10V before
the dropout and recovers to 5 volts afterwards.
Maximum supply voltage 35V continuous (protection to 60V)
Maximum operating
current
325mA at 12V, 152mA at 24V
Conditions: All relays energised.
Maximum standby current 70mA at 12V, 32mA at 24V
Conditions: All relays de-energised.
3.2 DSENET®
DSEnet is the interconnection cable between the host controller and the expansion module(s) and
must not be connect to any device other than DSE equipment designed for connection to the DSEnet.
Cable type Two core screened twisted pair
Cable characteristic impedance 120Ω
Recommended cable Belden 9841
Belden 9271
Maximum cable length 1000m (1km) when using Belden 9841 or direct equivalent.
500m (0.5km) when using Belden 9271 or direct equivalent.
DSEnet topology Bus with no stubs (spurs)
DSEnet termination 120Ω. Fitted internally to host controller. Must be fitted externally
to the ‘last’ expansion module by the customer .
Maximum expansion modules Refer to host controller documentation
NOTE : As a termination resistor is internally fitted to the host controller, the host controller
must be the ‘first’ unit on the DSEnet. A termination resistor MUST be fitted to the ‘last’ unit on
the DSEnet. For further details, please see the section entitled ‘typical wiring diagram’
elsewhere in this document.
Product type
DSE 2157
input
expansion
module
2157
Variant
Standard
product 00
Hardware revision
Revision 1 001

DSE2157 relay output expansion module
6
057-083 Issue 1 DSE2157 relay output expansion operator manual
3.3 OUTPUTS
Relay rating 2A DC rated (Max 30V)
3.4 DIMENSIONS
Overall size 164.6mm x 76.4mm x 48.9mm
(6.48” x 3.01” x 1.93”)
Mounting type DIN rail or chassis mounting
Din rail type EN 50022 35mm type only
Mounting holes M4 clearance
Mounting hole centres 152.37mm x 64.50mm
(6.00” x 2.54”)
Dimensions in mm
3.5 APPLICABLE STANDARDS
BS
4884
-
1
:1992
This document conforms to BS4884-1 1992 Specification for
presentation of essential information.
BS
4884
-
2:1993
This document conforms to BS4884-2 1993 Guide to content
BS
4884
-
3:1993
This document conforms to BS4884-3 1993 Guide to presentation
BS EN 60068
-
2
-
1
(Minimum temperature) -30°C (-22°F)
BS EN 60068
-
2
-
2
(Maximum temperature) +70°C (158°F)
BS EN 60950
Safety of information technology equipment, including electrical
business equipment
BS EN 61000
-
6
-
2
EMC Generic Immunity Standard (Industrial)
BS EN 61000
-
6
-
4
EMC Generic Emission Standard (Industrial)
BS EN 60529
(Degrees of protection
provided by enclosures)
IP21
UL508
NEMA rating enclosure type 1 (indoor use only)
In line with our policy of continual development, Deep Sea Electronics, reserve the right to change specification without notice.

DSE2157 relay output expansion module
057-083 Issue 1 DSE2157 relay output expansion operator manual 7
4 INSTALLATION
The DSE2130 is designed to mounted within a control panel, on the panel DIN rail utilising the integral
mounts. For dimension and mounting details, see the section entitled Specification, Dimensions
elsewhere in this document.
5 USER CONNECTIONS
5.1 TERMINAL SPECIFICATION
Connection type Screw terminal, rising clamp, no internal spring
Min cable size 0.5mm²(AWG 20)
Max cable size 2.5mm²(AWG 14)
Recommended cable
size Refer to tables below
Relay rating 2A DC rated (Max 30V)
Update rate The host controller updates the 2157 relay state every 100ms. It is not
recommended to use the 2157 relays for load switching control.
5.1.1 CONNECTOR A
Terminal
Function Recommended size
1 DC supply positive 1.0mm²(AWG 18)
2 DC supply negative 1.0mm²(AWG 18)
3 Screen DSEnet only. Do not connect to earh
4 A 0.5mm²(AWG 20) DSEnet only
5 B 0.5mm²(AWG 20) DSEnet only
5.1.2 CONNECTOR B
Terminal
Function
Recommended size
6 Relay 1 1.0mm²(AWG 18) Normally open
7 Relay 1 1.0mm²(AWG 18)
8 Relay 2 1.0mm²(AWG 18) Normally open
9 Relay 2 1.0mm²(AWG 18)
10 Relay 3 1.0mm²(AWG 18) Normally open
11 Relay 3 1.0mm²(AWG 18)
12 Relay 4 1.0mm²(AWG 18) Normally open
13 Relay 4 1.0mm²(AWG 18)
14 Relay 5 1.0mm²(AWG 18) Common
Normally closed
Normally open
15 Relay 5 1.0mm²(AWG 18)
16 Relay 5 1.0mm²(AWG 18)
17 Relay 6 1.0mm²(AWG 18) Common
Normally closed
Normally open
18 Relay 6 1.0mm²(AWG 18)
19 Relay 6 1.0mm²(AWG 18)
20 Relay 7 1.0mm²(AWG 18) Common
Normally closed
Normally open
21 Relay 7 1.0mm²(AWG 18)
22 Relay 7 1.0mm²(AWG 18)
23 Relay 8 1.0mm²(AWG 18) Common
Normally closed
Normally open
24 Relay 8 1.0mm²(AWG 18)
25 Relay 8 1.0mm²(AWG 18)
NOTE : Normally open / normally closed refers to the contacts when the DC supply is removed
from the module. The powered up state of the module depends upon configuration of the
connected ‘host module’.

DSE2157 relay output expansion module
8
057-083 Issue 1 DSE2157 relay output expansion operator manual
6 TYPICAL WIRING DIAGRAM
