© Edwards Limited 2009. All rights reserved. Page 1
Edwards and the Edwards logo are trademarks of Edwards Limited.
Introduction
B723-00-880 Issue C
1Introduction
1.1 Scope and definitions
This manual provides installation, operation and maintenance instructions for the Edwards EXPT Pumping Station.
You must use the EXPT Pumping Station as specified in this manual.
Read this manual before you install and operate the EXPT Pumping Station. Important safety information is
highlighted as WARNING and CAUTION instructions; you must obey these instructions. The use of WARNINGS and
CAUTIONS is defined below.
CAUTION
Cautions are given where failure to observe the instruction could result in damage to the equipment, associated
equipment and process.
A full list of Supplementary Publications is provided at the end of the Contents list of this manual. A number of these
Supplementary Publications will be supplied with your EXPT Pumping Station. The Supplementary Publications
supplied will be the instruction manuals for the components in your EXPT Pumping Station.
The Supplementary Publications you receive also contain WARNING and CAUTION instructions. When you install and
operate the EXPT Pumping Station, you must refer to these Supplementary Publications and obey all of the WARNING
and CAUTION instructions which they contain.
The units used throughout this manual conform to the SI international system of units of measurement.
The following IEC warning labels appear on the product and in the manual.
WARNING
Warnings are given where failure to observe the instruction could result in injury or death to
people.
Warning – refer to accompanying documentation.
Warning – risk of electric shock.
Warning – hot surfaces.

B723-00-880 Issue C
Page 2 © Edwards Limited 2009. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Introduction
1.2 Description
1.2.1 Overview
The EXPT Pumping Station is a fully automatic pumping system which is suitable for a wide range of applications. The
system is capable of utilising an extensive range of standard Edwards backing pumps, turbomolecular pumps and
controllers from a single compact unit. The open system configuration allows easy maintenance of the main pumping
components.
The function of the controller depends on your system configuration and will control the backing pump and
turbomolecular pump plus optional accessories. For systems with turbo and instrument controllers, up to three active
gauges may be used using the convenient gauge interface incorporated into the system housing. Both controllers are
provided with a large clear graphic display and easy-to-use control interface via a touch sensitive keypad. The system
incorporates an RS232/485 interface for control and data monitoring on a remote PC and a logic interface for
interface with associated system hardware.
Both systems are base mounted and come in two sizes. The EXPT1 base uses robust rubber feet as standard, castors
are optional. The EXPT2 base uses castors as standard to allow ease of transportation.
1.2.2 General description of the EXPT pumping station major components
For the general description of the major components used on the EXPT Pumping Station, click on the appropriate
instruction manual reference against each product type.
1.2.3 Electrical protection
The EXPT Pumping Station has a double-pole thermal circuit breaker which provides short circuit protection. The
backing pump and TIC Controller both have overload protection.
1.2.4 Accessories
A wide range of standard accessories is available for the major components of the EXPT Pumping Station; refer to
Section 7.
Diaphragm pump XDD1 (A746-01-885)
Rotary vane pumps E2M0.7 / E2M1.5 (A371-22-880 Section 1.2)
RV3 / RV5 / RV8 / RV12 (A652-01-880 Section 1.2)
Turbomolecular pumps EXT70H / EXT255H 24 V (B722-20-880 Section 1.2)
EXT75DX / EXT255DX (B722-40-880 Section 1.2)
Scroll pumps XDS5 / XDS10 (A726-01-880 Section 1.2)
TIC controller Turbo controller (D397-12-880 Section 1.2)
Turbo instrument controller (D397-22-880 Section 1.2)

© Edwards Limited 2009. All rights reserved. Page 3
Edwards and the Edwards logo are trademarks of Edwards Limited.
Introduction
B723-00-880 Issue C
Figure 1 - Components of the EXPT pumping station (typical system shown)
11.Earth stud
12.Heater supply (turbomolecular
pump remote use only)
13.Backing line valve
14.Flexible bellows
15.Turbomolecular pump
16.TIC controller
17.Castors (standard on EXPT2 systems)
1. Mains ON/OFF
2. Logic interface
3. Serial communications port
4. Mains input
5. Heater fuse
6. Backing pump fuse
7. TAV vent valve
8. Backing pump
9. Vacuum gauge inputs
10.Backing pump supply

B723-00-880 Issue C
Page 4 © Edwards Limited 2009. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
This page has been intentionally left blank.

© Edwards Limited 2009. All rights reserved. Page 5
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
B723-00-880 Issue C
2Technicaldata
Note: The operating, storage conditions and performance of the EXPT Pumping Station depends on the major
components fitted to the EXPT Pumping Station; refer to the technical data in the appropriate
supplementary publications.
2.1 General
* Measured under ideal conditions and will increase on uneven floor surfaces, slopes etc.
Dimensions Refer to Figure 2
Mass Refer to Tables 1and 2
Electrical data Refer to Table 3
Degree of protection (to IEC34-5: 1981) IP20
Initial force required to push the EXPT pumping station*
(for systems with castors) 3.5 kgf max.
Table 1 - EXPT1 pumping station mass
EXT pump TIC controller Backing pump Inlet flange Mass (kg)
70H / 75DX TIC (100 W)
XDD1
NW40 22.9
DN63ISO-K 23
DN63CF 24.9
E2M0.7/1.5
NW40 26.4
DN63ISO-K 26.5
DN63CF 28.4
255H / 255DX TIC (200 W) XDD1 DN100 ISO-K 25.5
DN100CF 27.75
Table 2 - EXPT2 pumping station mass
EXT pump TIC controller Backing pump Inlet flange Mass (kg)
70H / 75DX TIC (100 W)
RV3 / 5
NW40 38
DN63ISO-K 38.1
DN63CF 40
RV8 / 12
NW40 42.7
DN63ISO-K 42.8
DN63CF 44.7
XDS5
NW40 39.4
DN63ISO-K 39.5
DN63CF 41.4
XDS10
NW40 40.9
DN63ISO-K 41
DN63CF 42.9

B723-00-880 Issue C
Page 6 © Edwards Limited 2009. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
2.2 Electrical data
Table 3 lists the electrical requirements for the different EXPT Pumping Stations.
255H / 255DX TIC (200 W)
RV3 / 5 DN100 ISO-K 40.6
DN100CF 42.85
RV8 / 12 DN100 ISO-K 45.3
DN100CF 47.55
XDS5 DN100 ISO-K 42
DN100CF 44.25
XDS10 DN100 ISO-K 43.5
DN100CF 45.75
Table 3 - Electrical data
Backing pump TIC
controller Supply voltage 50/60 Hz Current (A) Maximum power kW
Full load Start *
XDD1
100 W 0.355
100 4.67
110-120 4.04
220-240 2.07
200 W
100 6.02
0.49110-120 5.14
220-240 2.57
E2M0.7
100 W 110-120 4.34 8.14 0.365
220-240 2.27 4.07
200 W 110-120 5.44 9.24 0.5
220-240 2.77 4.57
E2M1.5
100 W 110-120 5.54 14.44 0.435
220-240 2.67 6.77
200 W 110-120 6.64 15.54 0.57
220-240 3.17 7.27
RV3 / 5
100 W
100 8.15 33.94
0.575110-120 7.04 20.875
220-240 3.67 16.87
200 W
100 9.5 43.1
0.71110-120 8.14 35.04
220-240 4.17 17.37
Table 2 - EXPT2 pumping station mass (continued)
EXT pump TIC controller Backing pump Inlet flange Mass (kg)

© Edwards Limited 2009. All rights reserved. Page 7
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
B723-00-880 Issue C
Note: * If the EXPT Pumping Station uses a rotary vane pump, the system may draw up to the start current value
shown in Table 3. You must use a slow blow fuse to prevent unnecessary fuse failures, the start current
could typically last for several seconds and generally occurs when the rotary vane pump oil is cold.
2.3 Legislation and standards
The legislation and standards with which the EXPT Pumping Station complies are listed in full on the Declaration of
Conformity shown on the front inside cover of this manual.
2.4 Operating and storage data
2.5 Fuse ratings
RV8/12
100 W
100 10.35 36.44
0.825110-120 10.24 22.375
220-240 5.27 19.27
200 W
100 11.7 45.6
0.96110-120 11.34 37.54
220-240 5.77 19.77
XDS5/10
100 W
100 10.75
0.575110-120 9.64
220-240 4.87
200 W
100 12.1
0.71110-120 10.74
220-240 5.37
Table 4 - Operating and storage data
General items Reference data
Ambient operating temperature range 0 °C to 35 °C
Ambient storage temperature range -30 °C to 70 °C
Maximum ambient operating humidity Max 90% RH non cond at 40 °C
Maximum operating altitude 2000 m max.
Equipment type Fixed equipment, for indoor use only
Pollution degree 2
Table 5 - Fuse ratings
General items Reference data
BX bakeout band fuse (Heater)
90 to 132 V a.c. electrical supply 1 A, type F 20 mm
180 to 264 V a.c. electrical supply 0.5 A, type F 20 mm
Backing pump
Refer to backing pump documentation 10 A, type T 20 mm (maximum)
Table 3 - Electrical data (continued)
Backing pump TIC
controller Supply voltage 50/60 Hz Current (A) Maximum power
kW
Full load Start *

B723-00-880 Issue C
Page 8 © Edwards Limited 2009. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
2.6 Earth stud
2.7 Electrical connections
2.8 Connections
Note: The connectors listed in Table 8 offer the same functionality as the connectors on the TIC Controller. Refer
to the TIC instruction manual for full details for these connectors.
Table 6 - Earth stud
General items Reference data
Earth stud M5
Table 7 - Electrical connections
General items Reference data
Electrical supply (refer to Figure 1, item 4)
Inlet plug type CEE/IEC 320 (16 A)
Backing pump (refer to Figure 1, item 10)
Outlet socket type CEE/IEC 320
Max power 600 W
Bakeout band (refer to Figure 1, item 12)
Outlet socket type CEE/IEC 320
Max power 150 W
Table 8 - Connections
General items Reference data
Active gauge connectors
Connector type FCC/RJ45, 8-way
Power supply 24 V d.c.
Logic interface
Connector type 25-way sub-miniature ‘D’ type socket
Power supply 24 V d.c.
Serial communications
Connector type 9-way sub-miniature ‘D’ type socket

© Edwards Limited 2009. All rights reserved. Page 9
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
B723-00-880 Issue C
Figure 2 - Equipment dimensions (mm) (XDD1 and EXT75DX shown)
Position Base or pump description Dimension
AEXPT1 380.0
EXPT2 500.0
B
EXT70H ISO63/CF63 415.0
NW40 422.0
EXT75DX
ISO63 415.0
NW40 427.0
CF63 434.0
EXT255H/
EXT255DX ISO100 450.1
CF100 450.1

B723-00-880 Issue C
Page 10 © Edwards Limited 2009. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
This page has been intentionally left blank.

© Edwards Limited 2009. All rights reserved. Page 11
Edwards and the Edwards logo are trademarks of Edwards Limited.
Installation
B723-00-880 Issue C
3 Installation
3.1 Safety
zWhen you refer to a manual supplied as a Supplementary Publication, you must obey all of the WARNING and
CAUTION instructions in the manual.
zA suitably trained and supervised technician must install the EXPT Pumping Station.
zCheck that all the required parts are available and of the correct type before you start work.
zEnsure that the installation technician is familiar with the safety procedures which relate to the products
pumped. Wear the appropriate safety-clothing when you come into contact with contaminated components.
zIsolate the other components in your system from the electrical supply so that they cannot be operated
accidentally.
zDo not reuse O-rings and Co-Seals if they are damaged.
zDispose of components, grease and oil safely (refer to Section 6).
zTake care to protect sealing-faces from damage.
zLeak-test the system after installation and seal any leaks found.
3.2 Unpack and inspect
Remove the outer cover and all packing materials, remove the protective covers from the inlet and outlet ports,
inspect the system for any damage. If the EXPT Pumping Station is damaged, notify your supplier and the carrier in
writing within three days; state your order number and invoice number. Retain all packing materials for inspection.
Do not use the EXPT Pumping Station if it is damaged. Check that your package contains the items listed in Table 9.
If any item is missing, notify your supplier within three days.
If the EXPT Pumping Station is not to be used immediately, replace the protective covers. Store the EXPT Pumping
Station in suitable conditions as described in Section 6.1.
WARNING
Obey the safety instructions given below and take note of appropriate precautions. If you do not,
you can cause injury to people and damage to equipment.
Table 9 - Checklist of components
Qty Description Check (✓)
1 EXPT Pumping Station ❏
1 Instruction Manual Package ❏
1 Logic Interface Interlock D-Connector ❏
1TMPFlangeInletSeal ❏
1 Rotary Pump Oil (RV/E2M pumps only) ❏
1 XDS Silencer (optional on systems with XDS pumps) ❏

B723-00-880 Issue C
Page 12 © Edwards Limited 2009. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Installation
3.3 Locate the EXPT pumping station
CAUTION
When lifting the EXPT Pumping Station, do not attempt to support the mass of the system from the backing
pump.
CAUTION
When lifting the EXPT Pumping Station, always use slings with sufficient length to prevent damage of the system
components.
Before attempting to lift the EXPT Pumping Station, move the system (on its pallet) close to the operating position.
Ensure that you provide a firm level base before removing the system from its pallet. It is advisable to always use
mechanical lifting equipment when moving the heavier EXPT2 systems. Use slings around the base of the system from
front to back, make sure each sling is routed between the castors or feet and the base guides to prevent slippage.
Alternatively use straps with lifting hooks. Refer to Figure 3 which shows where to locate the slings or lifting hooks.
CAUTION
When locating the EXPT Pumping Station, care should be taken not to restrict the ventilation grid located under
the base of the system. Failing to observe this may result in over heating of the controller and the
turbomolecular pump.
WARNING
Heavy objects can cause muscle strain or back injury. It is advisable to use suitable lifting
equipment when moving the EXPT Pumping Station.
WARNING
(Applicable for systems with base castors) For your safety, both front castors must be locked when
the system is in operation. If you do not and the turbomolecular pump seizes, movement of the
system may damage equipment and injure people.

© Edwards Limited 2009. All rights reserved. Page 13
Edwards and the Edwards logo are trademarks of Edwards Limited.
Installation
B723-00-880 Issue C
Figure 3 - Position the lifting slings/lifting hooks
3.4 Fill the rotary pump with oil
If the EXPT Pumping Station uses a EM or RV series rotary or rotary vane pump you must fill it with the correct quantity
of oil (supplied with the equipment) before you operate the equipment, as described in the pump Instruction Manual.
3.5 XDS scroll pump silencer
The silencer is used to reduce exhaust noise during pump down and gas ballast operations. This part may be ordered
and supplied (not fitted) with the system or can be ordered as an optional extra. To fit the silencer, follow the
instructions in manual A505-97-880.
3.6 Fit accessories (optional)
If you wish to fit accessories to the EXPT Pumping Station, fit them now, before you start to install the EXPT Pumping
Station into your vacuum system. Install accessories as described in the instruction manuals supplied with the
accessories. Refer to Section 7 for further information on the accessories available and for specific fitting instructions
to fit the accessories to the EXPT Pumping Station.
Note: The use of water coolers and BX bake-out bands on the EXPT Pumping Station is not permitted. If you wish
to fit these accessories, it is advisable to install the turbomolecular pump away from the EXPT Pumping
Station. For further details regarding turbomolecular pump remote mounting please contact Edwards UK.

B723-00-880 Issue C
Page 14 © Edwards Limited 2009. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Installation
3.7 Connect the EXPT pumping station to your vacuum system
Note: If the vacuum system is to be supported by the EXPT Pumping Station, the mass of the vacuum system must
not be greater than the maximum mass which can be supported by the turbomolecular pump (refer to the
EXT Pump Instruction Manual). Use the co-seal or copper gasket (supplied with the equipment) with a
suitable clamp to secure to the vacuum system. Alternatively you may wish to use a pipeline to connect the
vacuum system to the inlet of the turbomolecular pump. Refer to the EXT Pump Instruction Manual for
further details.
3.8 Connect to your exhaust extraction system
Note: For further information, refer to the instruction manual which corresponds to the backing pump fitted to
your EXPT Pumping Station.
3.9 Connect the electrical supply
Check that your electrical supply is suitable for this equipment. Refer to Table 3 for the electrical requirements for
this equipment. The EXPT Pumping Station is supplied with an electrical cable which includes a moulded
IEC connector fitted at one end, the other end of the cable will be fitted with a moulded plug suitable for connection
to the local electrical supply.
3.10 Additional earth bonding
The electrical supply cable normally provides protective earthing for electrical safety. If this is not the case, or if
additional earth bonding is required, the earth stud located on the base at the rear of the EXPT Pumping Station
should be connected to your vacuum system.
3.11 Configure the EXPT pumping station
As supplied, the TIC Controller has been reconfigured for the TIC Pumping Station to suit most vacuum applications
and will:
When the TIC System ON is selected:
zSwitch on both the backing pump and the turbomolecular pump *.
zClose the TAV vent valve.
zOpen the backing valve.
WARNING
If you install your vacuum system directly onto the EXPT Pumping Station, the centre of gravity of
the mass must be above and within 300 mm of the centre line.
WARNING
Ensure that the electrical installation of the EXPT Pumping Station conforms with your local and
national safety requirements. It must be connected to a suitably fused and protected electrical
supply and a suitable earth point.
WARNING
Ensure the mains cord is routed so as not to cause a trip hazard.
