EGO POWER PPX1000 User manual

TELESCOPIC POWER POLE
OPERATOR'S MANUAL
56-VOLT LITHIUM-ION
TELESCOPIC POWER POLE
MODEL NUMBER PPX1000/PPX1000-FC
WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
Español p. 51
Français p. 25
FOR USE WITH EGO POWER+
TELESCOPIC POWER POLE ATTACHMENTS

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC2
TABLE OF CONTENTS
Safety Symbols ..........................................3
Safety Instructions......................................4-8
Introduction .............................................9
Specications ...........................................9
Packing List .............................................9
Description .........................................10-12
Assembly ...........................................13-15
Operation ...........................................16-19
Maintenance ...........................................20
Troubleshooting .........................................21
Warranty ...........................................22-24

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC 3
READ ALL INSTRUCTIONS!
READ AND UNDERSTAND
OPERATOR'S MANUAL
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The
safety symbols and the explanations with them deserve your careful attention and
understanding. The symbol warnings do not, by themselves, eliminate any danger.
The instructions and warnings they give are no substitutes for proper accident
prevention measures.
WARNING: Be sure to read and understand all safety instructions in this
Operator’s Manual, including all safety alert symbols such as “DANGER,” “WARNING,”
and “CAUTION” before using this tool. Failure to following all instructions listed below
may result in electric shock, re, and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION.
May be used in conjunction with other symbols or pictographs.
WARNING! The operation of any power tools can result in foreign
objects being thrown into your eyes, which can result in severe eye
damage. Before beginning power tool operation, always wear safety
goggles or safety glasses with side shield and a full face shield when
needed. We recommend a Wide Vision Safety Mask for use over
eyeglasses or standard safety glasses with side shields. Always use eye protection
which is marked to comply with ANSI Z87.1.

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC4
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may appear on this product. Read,
understand, and follow all instructions on the machine before attempting to assemble
and operate it.
Safety Alert Indicates a potential personal injury hazard.
Read & Understand
Operator's Manual
To reduce the risk of injury, user must read and
understand the operator’s manual before using
this product.
Eye Protection
Always wear safety goggles or safety glasses
with side shields and a full face shield when
operating this product.
Recycle Symbols
This product uses lithium-ion (Li-ion) batteries.
Local, state, or federal laws may prohibit
disposal of batteries in ordinary trash. Consult
your local waste authority for information
regarding available recycling and/or disposal
options.
IPX5 Ingress Protection
Degree Protection from splashing water
V Volt Voltage
cm Centimeter Length or size
in. Inch Length or size
kg Kilogram Weight
lb Pound Weight
°C Degrees Celsius Temperature
°F Degrees Fahrenheit Temperature
Direct Current Type or a characteristic of current

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC 5
GENERAL BATTERY-OPERATED POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings, instructions, illustrations and specications
provided with this power tool. Failure to follow all instructions listed below may result in
electric shock, re and/or serious injury.
WARNING! Read all safety warnings designated by the symbol and
all instructions.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power
tool or battery-operated (cordless) power tool.
General Power Tool Safety Warnings –Working area safety.
◾Keep work area clean and well lit. Cluttered or dark areas invite accidents.
◾Do not operate power tools in explosive atmospheres, such as in the
presence of ammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
◾Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
General Power Tool Safety Warnings – Electrical safety.
◾Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adaptor plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce risk of electric shock.
◾Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
◾Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
◾Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords increase the risk of electric
shock.
◾When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
◾If operating a power tool in a damp location is unavoidable, use a
Ground-fault circuit interrupter protected supply. Use of GFCI reduces the
risk of electric shock.

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC6
General Power Tool Safety Warnings – Personal Safety.
◾Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the inuence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
◾Use personal protective equipment. Always wear eye protection. Protective
equipment such as a dust mask, non-skid safety shoes, hard hat or hearing
protection used for appropriate conditions will reduce personal injuries.
◾Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery pack, picking up
or carrying the tool. Carrying power tools with your nger on the switch or
energizing power tools that have the switch on invites accidents
◾Remove any adjusting key or wrench before turning the power tool on.
A wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
◾Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
◾Dress properly. Do not wear loose clothing or jewelry. Keep your hair and
clothing away from moving parts. Loose clothes, jewelry or long hair can be
caught in moving parts.
◾If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use
of dust collection can reduce dust-related hazards.
◾Do not let familiarity gained from frequent use of tools allow you to
become complacent and ignore tool safety principles. A careless action
can cause severe injury within a fraction of a second.
General Power Tool Safety Warnings – Power Tool Use And Care.
◾Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the rate for
which it was designed.
◾Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and must be
repaired.

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC 7
◾Disconnect the plug from the power source and/or remove the battery
pack, if detachable, from the power tool and/or activate any battery
disabling device before clearing jammed material, making any
adjustments, changing accessories, cleaning, or storing power tools.
Such preventive safety measures reduce the risk of starting the power tool
accidentally.
◾Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.
◾Maintain power tools and accessories. Check for misalignment or
binding of moving parts, breakage of parts and any other condition that
may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power
tools and accessories.
◾Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
◾Use the power tool, accessories and tool bits, etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from those
intended could result in a hazardous situation.
◾Keep handles and grasping surfaces dry, clean and free from oil and
grease. Slippery handles and grasping surfaces do not allow for safe handling
and control of the tool in unexpected situations.
◾Keep cables away from the working area of the tool. During operation
cables may be hidden from view and can be accidentally damaged by the tool.
◾This 56V Telescopic Power Pole PPX1000/PPX1000-FC may be used with
only the following EGO attachments:
ATTACHMENT TYPE MODEL NUMBER
Pole Saw PSX2500/PSX2500-FC
Hedge Trimmer PTX5100/PTX5100-FC
General Power Tool Safety Warnings – Battery Tool Use And Care.
◾Recharge only with the charger specied by the manufacturer. A charger
that is suitable for one type of battery pack may create a risk of re when used
with another battery pack.
◾Use power tools only with specically designated battery packs. Use of
any other battery packs may create a risk of injury and re.

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC8
◾When battery pack is not in use, keep it away from other metal objects,
like paper clips, coins, keys, nails, screws or other small metal objects,
that can make a connection from one terminal to another. Shorting the
battery terminals together may cause burns or a re.
◾Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, ush with water. If liquid contact
eyes, additionally seek medical help. Liquid ejected from the battery may
cause irritation or burns.
◾Do not use a battery pack or tool that is damaged or modied. Damaged
or modied batteries may exhibit unpredictable behavior resulting in re,
explosion or risk of injury.
◾Do not expose a battery pack or tool to re or excessive temperature.
Exposure to re or temperature above 265 °F (130°C) may cause explosion.
◾Follow all charging instructions and do not charge the battery pack or
tool outside the temperature range specied in the instructions. Charging
improperly or at temperatures outside the specied range may damage the
battery and increase the risk of re.
◾Use only with the battery packs and chargers listed below:
BATTERY PACK CHARGER
BA1400, BA1400-FC, BA2800, BA2800-FC,
BA4200, BA4200-FC, BA1400T, BA1400T-FC,
BA2240T, BA2240T-FC, BA2800T, BA2800T-FC,
BA4200T, BA4200T-FC, BA5600T, BA5600T-FC,
BAX1501, BAX1501-FC
CH2100, CH2100-FC,
CH5500, CH5500-FC,
CH2800D, CH2800D-FC,
CH7000, CH7000-FC,
CHX5500, CHX5500-FC
WARNING! Do not use the shoulder strap when the tool equipped with the
battery pack BAX1501/BAX1501-FC. Failure to do that could result in serious personal
injury.
General Power Tool Safety Warnings – Services.
◾Have your power tool serviced by a qualied repair person using only
identical replacement parts. This will ensure that the safety of the power tool
is maintained.
◾Never service damaged battery packs. Service of battery packs should only
be performed by the manufacturer or authorized service providers.
SAVE THESE INSTRUCTIONS!
ADDITIONAL SPECIFIC SAFETY RULES CAN BE FOUND IN THE
OPERATOR’S MANUAL FOR APPLICABLE ATTACHMENT

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC 9
INTRODUCTION
Congratulations on your selection of the 56V telescopic power pole. It has been
designed, engineered and manufactured to give you the best possible dependability
and performance.
Should you experience any problem you cannot easily remedy, please contact EGO
customer service center 1-855-EGO-5656.
This manual contains important information on the safe assembly, operation and
maintenance of your product. Read it carefully before using the product. Keep this
manual handy so you can refer to it at any time.
SERIAL NUMBER _____________________ DATE OF PURCHASE _________________
YOU SHOULD RECORD BOTH SERIAL NUMBER AND DATE OF PURCHASE AND KEEP THEM IN A
SAFE PLACE FOR FUTURE REFERENCE
SPECIFICATIONS
Voltage 56V
Weight (Without accessories) 8.60 lb. (3.9 kg)
Recommended Operating Temperature 14−104°F(-10−40°C)
Recommended Storage Temperature -4−158°F(-20−70°C)
* For the appliance WITHOUT battery pack
PACKING LIST
PART NAME QUANTITY
Telescopic Power Pole 1
Combi-wrench 1
Shoulder Strap 1
Operator’s Manual 1

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC10
DESCRIPTION
KNOW YOUR POWER POLE (Fig. 1)
The safe use of this product requires an understanding of the information on the tool and
in this operator’s manual, as well as knowledge of the project you are attempting. Before
using this product, familiarize yourself with all operating features and safety rules.
Tool Support
1
Shaft-Release
Button
Clamping Knob
Front Handle
Shoulder-Strap Eyelet
Lock-off Switch
On/Off Trigger
Battery-Release
Button
Wrench Holder
Combi-wrench
Ejection
Mechanism
Latch
Shoulder Strap
Main Handle
Locking knob
Coupler
Telescopic Tube

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC 11
TOOL SUPPORT
Serves as a support when resting the tool on the ground.
MAIN HANDLE
For ease of operation and to help prevent loss of control.
ON/OFF TRIGGER/ LOCK-OFF SWITCH
Turns the tool ON and OFF. The lock-off switch must be squeezed before pressing
the on/off trigger. The two on/off triggers give the user exibility to use either of them
depending on the operation or personal preference.
CARRYING EYELET
For connecting with the shoulder strap.
FRONT HANDLE
Provides rm and comfortable gripping area for prolonged operations.
TELESCOPIC TUBE
Retracts to ease storage and transportation. Extends to increase the cutting height.
PPX1000/PPX1000-FC maximum extended length is 37-3/4” (96 cm).
CLAMPING KNOB
Locks the telescopic tube at any position. Marked with lock and unlock mark for
identication.
COUPLER
Provides quick attaching/detaching of compatible cutting head attachments.
SHAFT-RELEASE BUTTON
To quickly lock/unlock the connection with the attachment.
LOCKING KNOB
Tightens connection between the coupler and the attachment shaft.

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC12
BATTERY-RELEASE BUTTON
Releases the battery pack from the tool.
LATCH
Locks the battery pack when installing it.
EJECTION MECHANISM
Aids in battery pack removal.
COMBI-WRENCH
Intended for adjusting chain tension and loosening/tightening of the cover nut of
PSX2500/PSX2500-FC pole saw attachment.
WRENCH HOLDER
Stores the combi-wrench.

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC 13
ASSEMBLY
WARNING: If any parts are damaged or missing, do not operate this
product until the parts are replaced. Use of this product with damaged or missing
parts could result in serious personal injury.
WARNING: Do not attempt to modify this product or create accessories
not recommended for use with this telescopic power pole. Any such alteration or
modication is misuse and could result in a hazardous condition leading to possible
serious personal injury.
WARNING: Always remove the battery pack from the product when you are
assembling parts, making adjustments, cleaning, or when the product is not in
use.
UNPACKING
◾Inspect the tool carefully to make sure that no breakage or damage occurred
during shipping.
◾Do not discard the packing material until you have carefully inspected and
satisfactorily operated the tool.
◾If any parts are damaged or missing, please return the product to the place of
purchase.
CONNECTING AN ATTACHMENT TO THE TELESCOPIC POWER POLE
WARNING: Read and understand entire Operator’s Manual for each optional
attachment used with this telescopic power pole and follow all warnings and
instructions. Failure to follow all instructions could result in electric shock, re and/or
serious personal injury.
WARNING: This 56V telescopic power pole is designed to be used only
with the EGO attachment models that are specied in this Operator’s Manual
or subsequently introduced by EGO for use with this telescopic power pole. Use
of other, unauthorized attachments could cause serious personal injuries or property
damage.
WARNING: Some accessories have specic requirements related to safety.
Always pay special attention to such instructions in the manual that accompanies each
accessory.

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC14
WARNING: Never install, remove, or adjust any attachment while the
telescopic power pole is running or with the battery installed.
The attachment connects to the telescopic power pole by means of a coupler device.
1. Switch off the tool and remove the battery pack.
2. Loosen the locking knob.
3. Align the arrow on the attachment shaft with the insert indication on the coupler
and push the attachment shaft into the coupler until you hear a clear “click”
sound. The coupler should be positioned all the way to the LINE on the shaft that
indicates that the attachment is properly mounted into place (Fig. 2).
2Shaft-Release Button Insert Indication for
Attachment Shaft
Locking knob
Arrow on the
Attachment Shaft
Line
4. Pull the shaft of the attachment to verify that it is securely locked into the coupler.
If not, push the attachment shaft into the coupler until it snaps into place.
5. Tighten the locking knob securely.
WARNING: To avoid serious personal injury, be certain that the locking
knob is fully tightened before operating the equipment. Check it periodically for
tightness during use.
DETACHING THE ATTACHMENT FROM THE TELESCOPIC POWER POLE
1. Switch off the tool and remove the battery pack.
2. Loosen the locking knob.
3. Press the shaft-release button and, with the button depressed, pull the
attachment shaft out of the coupler.

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC 15
ATTACHING THE SHOULDER
STRAP (Fig. 3)
Depress the strap hook to open it and
attach it onto the shoulder strap eyelet.
TELESCOPIC TUBE (Fig. 4)
The product is equipped with a telescopic
tube that could extend up to 37-3/4” (96
cm). The clamping knob is used to lock the
telescopic tube in position at any extended
length.
1. To extend the telescopic tube,
loosen the clamping knob by
following the arrow on the “unlock”
icon. The telescopic tube will slide
freely.
2. Pull the telescopic tube out to
desired length of extension.
3. To lock the telescopic tube in position, tighten the clamping knob by following the
arrow on the “lock” icon.
WARNING: To prevent pinching of hands or ngers, extend and retract the
telescopic tube with caution.
3
Strap Hook
Shoulder Strap Eyelet
4
Indication for
Maximum Degree
Clamping Knob

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC16
OPERATION
WARNING: Do not allow familiarity with this product to make you careless.
Remember that a careless fraction of a second is sufcient to inict serious injury.
WARNING: Always wear safety goggles or safety glasses with side shield
marked to comply with ANSI Z87.1. Failure to do so could result in objects being
thrown into your eyes and other possible serious injuries.
WARNING: Do not use any attachments or accessories not recommended
by the manufacturer of this product. The use of attachments or accessories not
recommended can result in serious personal injury.
INSTALLING/REMOVING THE BATTERY PACK
WARNING: Always remove the battery pack from the product when you are
assembling parts, making adjustments, cleaning, or when not in use. Removing
the battery pack will prevent accidental starting that could cause serious personal
injury.
NOTE: Fully charge the battery pack before rst use.
To install battery pack (Fig. 5)
1. Align the ribs of the battery pack
with the mounting slots in the
telescopic power pole's battery port.
2. Press the battery pack towards the
telescopic power pole until it snaps
into position.
NOTE: Make sure that the latch on the
bottom of the battery pack snaps in
place and the battery pack is secured to the telescopic power pole before beginning
operation. Failure to securely seat the battery pack could cause the battery pack to fall
out, resulting in serious personal injury.
5Mounting Slot
Rib

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC 17
To remove battery pack (Fig. 6)
WARNING: Serious injury could
result if the battery pack falls. NEVER
remove the battery pack at a high
location. Always be aware of the location
of your feet and children or pets around
you when pressing the battery release
button.
1. Hold the battery pack in the palm of
your hand.
2. Press the battery-release button
with your thumb. The battery pack
will disengage from the latch.
3. Grasp the battery pack and remove
it from the telescopic power pole.
WARNING: To avoid serious
personal injury, always remove the
battery pack before carrying or
transporting the tool.
SHOULDER STRAP
For safe and comfortable operation,
put on the shoulder strap across the
shoulder, as shown in Fig. 7, to relieve the
weight on the operator’s arms. Adjust the
shoulder strap to a comfortable operating
position.
There are two ways to release the strap.
Take it off from your shoulder directly
(Fig. 8) or press the hook of the strap
and take it apart from the shoulder strap
eyelet on the shaft (Fig. 9).
7
8
9
61
2
Battery-Release
Button

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC18
WARNING: In a hazardous situation, take the shoulder strap off your
shoulder immediately.
HOLDING THE TELESCOPIC
POWER POLE
The telescopic power pole is equipped
with an innovative dual-trigger system
(Fig. 10). Each trigger can be used
independently to switch the tool on or off.
This system provides the most ergonomic
operation in daily use (Fig. 11 & 12).
10 Rear Trigger Front Trigger
11
12

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC 19
STARTING/STOPPING THE
TELESCOPIC POWER POLE
(FIG.13)
To start the telescopic power
pole
Use either of the on/off trigger. Move the
lock-off switch forward and then press
the on/off trigger. The tool will start. The
more pressure applied on the on/off
trigger, the higher the speed of the head attachment is.
To stop the telescopic power pole
Release the trigger to stop the telescopic power pole.
WARNING: Always remove the battery pack from the telescopic power pole
during work breaks and after nishing work.
13
On/off Switch
Lock-off Switch

56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC20
MAINTENANCE
WARNING: Before inspecting, cleaning or servicing the unit, stop the motor,
wait for all moving parts to stop, and remove the battery pack. Failure to follow
these instructions can result in serious personal injury or property damage.
WARNING: When servicing, use only identical replacement parts. Use of any
other parts can create a hazard or cause product damage.
NOTICE: Before each use, inspect the entire product for damaged, missing, or loose
parts such as screws, nuts, bolts, caps, etc. Tighten securely all fasteners and caps
and do not operate this product until all missing or damaged parts are replaced. Please
contact customer service or a qualied service center for assistance.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to
damage from various types of commercial solvents and may be damaged by their use.
Use clean cloth to remove dirt, dust, oil, grease, etc.
WARNING: Do not at any time let brake uids, gasoline, petroleum-based
products, penetrating oils, etc., come in contact with plastic parts. Chemicals can
damage, weaken or destroy plastic which can result in serious personal injury.
CLEANING THE TELESCOPIC POWER POLE
1. Stop the motor and remove the battery pack.
2. Clean dirt and debris from the telescopic power pole using a damp cloth with a
mild detergent.
NOTICE: Do not use any strong detergents on the plastic housing or the handle. They
can be damaged by certain aromatic oils such as pine and lemon, and by solvents such
as kerosene.
STORING THE TELESCOPIC POWER POLE
1. Remove the battery pack from the telescopic power pole before storing.
2. Clean all foreign material from the telescopic power pole.
3. Store it in a place that is inaccessible to children.
4. Keep away from corrosive agents such as garden chemicals and de-icing salts.
