EGO ST1400E-ST User manual

LINE TRIMMER
OPERATOR'S MANUAL
56 VOLT LITHIUM-ION
CORDLESS LINE TRIMMER
MODEL NUMBER ST1400E-ST
WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
MNL_EGO_ST1400E-ST_AV01.01_210409

B1 B2
C2C1
LOW
1. Rear Handle
4. Hinge
2. High/low-speed Switch
3. Adjustable Front-Assist Handle
5. Line-Loading Button
6. Guard
11. Trimmer Head (Bump Head)
17. Electric Contacts
A
7. Lock Pole
8. Height
Locking Collar
9. Switch Trigger
10. Locking Tongue
15. Battery
Release Button
16. Latch
12. Line
Cutting Blade 13. Release
Tab
14. Cutting Line
18. Ejection
Mechanism
19. Hex Wrench

D
H
E
I
J2
G
J1
F
Front-Assist Handle
Clamping Block
Wing Nut
Locking
Pole

M
K
P
R
LOW
L
O
Q
S
13 cm
1
2
High/low-speed Switch
Switch Trigger

UT
V
Bushing Upper Cover
Nut
Washer
Spring
Trimmer Line
Lower Cover
Spool Assembly
Upper Base Cover

56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — ST1400E-ST6
READ ALL INSTRUCTIONS!
READ OPERATOR’S MANUAL
Residual risk! People with electronic devices, such
as pacemakers, should consult their physician(s) before
using this product. Operation of electrical equipment
in close proximity to a heart pacemaker could cause
interference or failure of the pacemaker.
SAFETY SYMBOLS
The operation of any power tools can result in foreign
objects being thrown into your eyes, which can result
in severe eye damage. Before beginning power tool
operation, always wear safety goggles or safety glasses
with side shields and a full face shield when needed.
We recommend a Wide Vision Safety Mask for use over
eyeglasses or standard safety glasses with side shields.
Safety Alert Precautions that involve your
safety.
Read
Operator’s
Manual
To reduce the risk of
injury, user must read and
understand operator’s
manual before using this
product.
Wear Eye
Protection
Always wear safety goggles
or safety glasses with side
shields and a full face shield
when operating this product.
Wear
Safety
Footwear
Wear non-slip safety
footwear when using this
equipment.
Wear Ear
Protection
Always wear ear protection
when operating this product.
Wear
Protective
Gloves
Protect your hands with
gloves when handling blade
or blade guard.
Wear Head
Protection
Wear an approved safety
hard hat to protect your
head.
Beware
of blade
thrust
Warn the operator of the
danger of blade thrust.
No round
blade
Do not install round cutting
blades.
2.4mm
Line
Diameter
The Diameter of the nylon
cutting line
38cm
Cutting
Width
The Max. cutting width of
line trimmer
Ricochet
and Keep
Bystanders
Away
Thrown objects can ricochet
and result in personal injury
or property damage. Ensure
that other people and pets
remain away from the line
trimmer when it is in use.
15m
Keep
Bystanders
Away
Ensure that other people and
pets remain at least 15m
away from the line trimmer
when it is in use.
Do Not
Expose To
Rain
Do not use in the rain or
leave outdoors while it is
raining.
XX
Noise
Guaranteed sound power
level. Noise emission to the
environment according to
the European community’s
Directive.
EU
Declaration
of
Conformity
This product is in
accordance with applicable
EC directives.
WEEE
Waste electrical products
should not be disposed of
with household waste. Take
to an authorized recycler.
V Volt Voltage
n0
No Load
Speed Rotational speed, at no load
min-1 Per Minute Revolutions per minute
Direct
Current
Type or a characteristic of
current
Kg Kilogram Weight

56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — ST1400E-ST 7
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings,
instructions, illustrations and specifications provided
with this power tool. Failure to follow all instructions
listed below may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
WORK AREA SAFETY
◾Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
◾Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
◾Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
PERSONAL SAFETY
◾Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools may
result in serious personal injury.
◾Use personal protective equipment. Always wear
eye protection. Protective equipment such as a dust
mask, non-skid safety shoes, hard hat or hearing
protection used for appropriate conditions will reduce
personal injuries.
◾Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energizing power tools that have the switch
on invites accidents.
◾Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result
in personal injury.
◾Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
◾Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewelry or long hair
can be caught in moving parts.
◾If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
devices can reduce dust-related hazards.
◾Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of second.
POWER TOOL USE AND CARE
◾Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
◾Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
◾Remove the battery pack, if detachable, from the
power tool and/or activate any battery disabling
device before clearing jammed material, making
any adjustments, changing accessories, cleaning, or
storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
◾Store idle power tools out of the reach of children and
do not allow persons unfamiliar with power tool or
these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
◾Maintain power tools and accessories. Check
for misalignment or building of moving parts,
breakage of parts and any other condition that may
affect the power tools operation. If damaged, have
the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
◾Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
◾Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
◾Keep handles and grasping surface dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
◾Keep cables away from the working area of the
tool. During operation cables may be hidden from view
and can be accidentally damaged by the tool.

56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — ST1400E-ST8
BATTERY TOOL USE AND CARE
◾Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when use with
another battery pack.
◾Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
◾When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connections from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
◾Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation
or burns.
◾Do not use a battery pack or tool that is damaged
or modified. Damaged or modified batteries may
exhibit unpredictable behavior resulting in fire,
explosion or risk of injury.
◾Do not expose a battery pack or tool to fire
or excessive temperature. Exposure to fire or
temperature above 100°C may cause explosion.
◾Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified
range may damage the battery and increase the risk
of fire.
SERVICE
◾Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
◾Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
WARNING: Read all safety warnings,
instructions, illustrations and specifications
provided with this power tool. Failure to follow all
instructions listed below may result in electric shock,
fire and/or serious injury.
Save all warnings and instructions for future
reference.
TRAINING
◾Read the instructions carefully. Be familiar with the
controls and the proper use of the machine.
◾Never allow people unfamiliar or children with these
instructions to use the appliance. Local regulations can
restrict the age of the operator.
◾Keep in mind that the operator or user is responsible
for accidents or hazards occurring to other people or
their property.
PREPARATION
◾Never operate the machine while people, especially
children, or pets are nearby.
◾Wear eye protection and stout shoes at all times while
operating the machine.
◾The distance between the machine and bystanders
shall be at least 15m.
◾Never operate the machine while the operator is tired,
ill or under the influence of alcohol or other drugs.
OPERATION
◾Use the machine only in daylight or good artificial light.
◾Never operate the machine with damaged guards or
shields or without guards or shields in place.
◾Switch on the motor only when the hands and feet are
away from the cutting means.
◾Always disconnect the machine from the power supply
(i.e. remove that battery pack).
◾whenever leaving the machine unattended;
◾before clearing a blockage;
◾before checking, cleaning or working on the
machine;
◾after striking a foreign object;
◾whenever the machine starts vibrating abnormally.
◾Take care against injury to feet and hands from the
cutting means.
◾Always ensure that the ventilation openings are kept
clear of debris.
MAINTENACE AND STORAGE
◾Disconnect the machine from the power supply
(i.e. remove the battery pack) before carrying out
maintenance or cleaning work.
◾Use only the manufacturer’s recommended
replacement parts and accessories.
◾Inspect and maintain the machine regularly. Have the
machine repaired by an authorized repairer.

56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — ST1400E-ST 9
◾When not in use, store the machine out of the reach
of children.
OTHER SAFETY WARNINGS
◾Avoid Dangerous Environments – Don’t use
appliances on damp or wet slope.
◾Keep guards in place and in working order.
◾Keep hands and feet away from the cutting area.
◾To reduce the risk of injury, never work on a ladder
or on any other insecure support. Never hold the
cutting unit above waist height.
◾Check the cutting unit at a regular short intervals
during operation, or immediately if there is a
noticeable change in cutting behavior.
◾For best results, your battery should be charged in
a location where the temperature is greater than
5°C and less than 40°C. Do not store it outside or in
vehicles.
◾If you are approached, stop the motor and cutting
unit.
◾Warn the operator of the danger of blade thrust
(only using with 3-teeth blade).
◾Blade thrust may occur when the spinning blade
contacts an object that it does not immediately cut.
◾Blade thrust can be violent enough to cause the unit
and/or operator to be propelled in any direction, and
possibly lose control of the unit.
◾Blade thrust can occur without warning if the blade
snags, stalls or binds.
◾Blade thrust is more likely to occur in areas where it
is difficult to see the material being cut.
◾Do not attach any blade to a unit without proper
installation of all required parts. Failure to use the
proper parts can cause the blade to fly off and
seriously injure the operator and/or bystanders.
Discard blades that are bent, warped, cracked,
broken, or damaged in any way. Use a sharp blade.
A dull blade is more likely to snag and thrust
(only using with 3-teeth blade).
◾A coasting blade/line can cause injury while it
continues to spin after the motor is stopped or
trigger is released. Maintain proper control until
the blade/line has completely stopped rotating.
◾Use only with EGO’s battery packs and chargers.
BATTERY PACK CHARGER
BA1400, BA2800, BA1400T,
BA2800T, BA2240T CH2100E, CH5500E
◾Battery tools do not have to be plugged into an
electrical outlet; therefore, they are always in
operating condition. Be aware of possible hazards
even when the tool is not operating. Take care when
performing maintenance or service.
◾Do not wash with a hose; avoid getting water in
motor and electrical connections.
◾If situations occur that are not covered in this
manual, use care and good judgment. Contact the
EGO Customer Service Center for assistance.
SAVE THESE INSTRUCTIONS!
SPECIFICATIONS
Voltage 56 V
No-load Speed
Low speed set:
3000-4500 RPM
High speed set:
4000-5800 RPM
Cutting Mechanism Bump Head
Cutting Line Type 2.4mm nylon
twist line
Cutting Width 35cm
Recommended Operating
Temperature 0°C-40°C
Recommended Storage
Temperature -20°C-70°C
Optimum Charging Temperature 5°C-40°C
Weight (without battery pack) 5.8kg
PACKING LIST
PART NAME QUANTITY
Line trimmer 1
Guard 1
Front-assist handle assembly 1
Hex wrench 1
Operator’s manual 1

56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — ST1400E-ST10
DESCRIPTION
KNOW YOUR LINE TRIMMER (Fig. A)
1. Rear Handle
2. High/Low Speed Switch
3. Adjustable Front-Assist Handle
4. Hinge
5. Line-Loading Button
6. Guard
7. Lock Pole
8. Height Locking Collar
9. Switch Trigger
10. Locking Tongue
11. Trimmer Head (Bump Head)
12. Line Cutting Blade
13. Release Tab
14. Cutting Line
15. Battery Release Button
16. Latch
17. Electric Contacts
18. Ejection Mechanism
19. Hex Wrench
ASSEMBLY
WARNING: If any parts are damaged or missing,
do not operate this product until the parts are replaced.
Use of this product with damaged or missing parts could
result in serious personal injury.
WARNING: Do not attempt to modify this product
or create accessories not recommended for use with
this Line trimmer. Any such alteration or modification is
misuse and could result in hazardous condition leading
to possibly serious personal injury.
WARNING: To prevent accidental starting that
could cause serious personal injury, always remove the
battery pack from the tool when assembling parts.
UNFOLDING THE SHAFT
WARNING: Do not hold the shaft at the joints in
order to avoid pinching your hands or fingers.
WARNING: Do not attempt to start the trimmer
until the shaft has been locked. Unfold the shaft gently,
ensuring the cable inside the shaft, and lock with two
screws by the supplied wrench (Fig.B1 & B2).
MOUNTING THE GUARD
WARNING: Always wear gloves when mounting or
replacing the guard. Take care of the blade on the guard
and protect your hand from cutting.
WARNING: Never operate the tool without the
guard firmly in place. The guard must always be on the
tool to protect the user! When the guard is fixed, never
attempt to remove or adjust the guard, if a replacement
is needed, it should be performed by a qualified service
technician!
Position your trimmer so that the trimmer head faces
up (Fig.C1). Align the guard mounting holes with the
assembly holes and then lock the guard onto the shaft
base with two screws (Fig.C2).
NOTICE: Make sure the guard is fixed according to Fig.
C1 & C2, any reverse fixing will cause great danger!
MOUNTING AND ADJUSTING THE FRONT-ASSIST
HANDLE
1. Loosen the locking pole in the front-assist handle
and remove the locking pole and wing nut from the
front-assist handle (Fig. D).
2. Push the front assist-handle onto the shaft between
the Height Locking Collar and hinge (Fig. E).
3. Insert the clamping block into the handle slot (Fig. F).
4. Mount the locking pole lever and pre-tighten the
wing nut. Make sure that the front-assist handle is
positioned upwards and points toward the top of the
rear handle (Fig. G).
5. Pull up the level of the lock pole so that you can
easily move/rotate the loop handle to where you feel
comfortable, then lock the lever of the locking pole
(Fig. H).
WARNING: The tool cannot be used without the front
handle securely fixed.
ADJUSTING THE REAR HANDLE
If the length of the shaft is not suitable for operation, you
can adjust the length of the shaft through this Height
Locking clamp.
1. Remove the battery pack from the trimmer.
2. To adjust the trimmer height, open the height locking
clamp, and then slide the shaft up or down to desired
height, securing it in place by depressing the locking
clamp (Fig. I).

56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — ST1400E-ST 11
NOTICE: The front assist-handle may require to be
readjusted after the trimmer height is changed.
OPERATION
WARNING: Do not allow familiarity with this product
to make you careless. Remember that a careless fraction
of a second is sufficient to inflict serious injury.
WARNING: Always wear safety goggles or safety
glasses with side shield, along with hearing protection.
Failure to do so could result in objects being thrown into
your eyes and other possible serious injuries.
WARNING: Do not use any attachments or
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories not
recommended can result in serious injury.
WARNING: To prevent serious personal injury,
remove the battery pack from the tool before servicing,
cleaning, changing attachments or removing material
from the unit.
You may use this product for the purposes listed below:
Trimming: Used for removing grass and weeds up
against walls, fences, trees and borders.
Cutting: Used for cutting the grass that is difficult to
reach using a normal mower.
NOTICE: The tool is to be used only for its prescribed
purpose. Any other use, for example edge trimming, is
deemed to be a case of misuse.
ATTACHING/DETACHING THE BATTERY PACK
Fully charge before first use.
To Attach
Align the battery ribs with the mounting slots and press the
battery pack down until you hear a “click” (Fig. J1)
To Detach
Depress the battery-release button and pull the battery
pack out as Fig. J2 shown.
HOLDING THE LINE TRIMMER
Hold the line trimmer with both hands: One hand on the
rear handle and the other on the front-assist handle.
NOTICE: The trimmer head is parallel to the ground at
a proper cutting distance without the operator bending
over (Fig. K).
STARTING/STOPPING THE LINE TRIMMER
To Start
Move the locking tongue forwards then depress the
switch trigger.
The trigger is stepless speed adjusting. The more you pull
up the trigger, the higher speed it is (Fig. L).
To Stop
Release the switch trigger.
NOTICE: The motor runs only when the lock-off button
and trigger are both pressed.
WARNING: Always remove the battery pack from the
line trimmer during work breaks and after finishing work.
SPEED ADJUSTMENT FUNCTION (FIG.L)
The line trimmer has two speeds. Position “LOW” is for
low speed while Position “HIGH” for high speed.
USING THE LINE TRIMMER
WARNING: To avoid serious personal injury, wear
goggles or safety glasses at all times when operating this
unit. Wear a face mask or dust mask in dusty locations.
Clear the area to be cut before each use. Remove all
objects, such as rocks, broken glass, nails, wire, or line
that can be thrown or become entangled in the cutting
attachment. Clear the area of children, bystanders
and pets. At a minimum, keep all children, bystanders
and pets at least 15m away; there still may be risk to
bystanders from thrown objects. Bystanders should be
encouraged to wear eye protection. If you are approached,
stop the motor and cutting attachment immediately.
Before each use, check for damage/worn parts
Check the bump head, guard and front-assist handle
and replace the parts that are cracked, warped, bent, or
damaged in any way.
The line-cutting blade on the edge of the guard can
dull over time. It is recommended that you periodically
sharpen it with a file or replace it with a new blade.
WARNING: Always wear gloves when mounting the
guard or servicing the table. Take care of the blade on the
guard and protect your hand from cutting.
After each use, clean the trimmer.
CAUTION: Obstructions in the vents will prevent
the air from flowing into the motor housing and result in
overheating or damaged of the motor.

56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — ST1400E-ST12
◾Use only mild soap and a damp cloth to clean the tool.
Never let any liquid get inside the tool; never immerse
any part of the tool into a liquid.
◾Keep air vents in the motor housing from debris at all
times.
◾WARNING: Never use water for cleaning your
trimmer. Avoid using solvents when cleaning plastic
parts. Most plastics are susceptible to damage from
various types of commercial solvents. Use clean
cloths to remove dirt, dust, oil, grease, etc.
ADJUSTING CUTTING LINE LENGTH
The trimmer head allows the operator to release more
cutting line without stopping the motor. As line becomes
frayed or worn, additional line can be released by lightly
tapping the trimmer head on the ground while operating
the trimmer (Fig. M).
NOTICE: Line release will require multiple tapping as the
cutting line becomes shorter.
WARNING: Do not remove or alter the line cutting
blade assembly. Excessive line length will cause the motor
to overheat and may result in serious personal injury.
LINE REPLACEMENT
NOTICE: Always use the recommended nylon cutting
line with a diameter that does not exceed 2.4mm. Using
line other than that specified may cause the line trimmer
to overheat or become damaged.
WARNING: Never use metal-reinforced line, wire,
or rope, etc. These can break off and become dangerous
projectiles.
1. Remove the battery pack.
2. Remove the remaining cutting line, if necessary.
3. Cut 4m of cutting line. Insert the line to the mounting
hole inside the eyelet (Fig. O). Push and pull the
line from the other side until equal amounts of line
appear on both sides of the spool.
4. Install the battery pack onto the string trimmer.
5. Press and hold the line-loading button to start the
line-winding motor. The line will be wound into the
trimmer head continuously (Fig. P).
6. Watch the remaining line length carefully. Briefly
press the line loading button to adjust the length until
13cm of the line is showing on each side.
7. Push down on the trimmer head while pulling on the
lines to manually advance the line in order to check
for proper assembly of the cutting line.
When the cutting line breaks from the line outlet or the
cutting line is not released when the trimmer head is
tapped, follow the steps below
1. Remove the battery pack from the trimmer.
2. Press the release tabs on the trimmer head and
remove the lower cover assembly by pulling it
straight out (Fig. Q).
3. Remove the cutting line from the spool.
4. Insert the spring into the slot in the lower cover
assembly (Fig. R).
5. With one hand holding the trimmer, use another hand
to grasp the lower cover assembly with the release
tabs. Press the lower cover assembly until it snaps
into place, at which time you will hear a distinct click
sound (Fig. S).
6. Follow the instructions in the “LINE REPLACEMENT”
section to reload the cutting line.
TRIMMER HEAD REPLACEMENT
WARNING: If the head loosens after it is fixed in
position, replace it immediately. Never use a trimmer
with a loose cutting attachment. Replace a cracked,
damaged or worn out cutting head immediately,
even if damage is limited to superficial cracks. Such
attachments may shatter at high speed and cause
serious injury.
REMOVE THE TRIMMER HEAD
1. Remove the battery pack from the trimmer.
2. Press the release tabs on the trimmer head and
remove the lower cover assembly of the trimmer
head by pulling it straight out (Fig. Q).
3. Remove the cutting line from the trimmer head.
4. Take the spring out of the spool assembly, if
necessary. Save it for reassembly (Fig. R).
5. Wear gloves. Use one hand to grasp the spool
assembly to stabilize it, and use the other hand to
hold an impact wrench (not included) to loosen the
nut in a counterclockwise direction (Fig. V).
6. Remove the nut, spool retainer, upper cover, upper
base cover, from the motor shaft (Fig. T).
NOTICE: Two bushings easily fall off the motor shaft,
please save them carefully for reassembly.
7. Replace with a new trimmer head and mount it in
following steps.
INSTALL THE NEW TRIMMER HEAD
1. Mount the bushings in motor shaft and mount the
upper base cover assembly into place (Fig. T).

56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — ST1400E-ST 13
2. Mount the upper cover, spool assembly, washer and
nut in that order. Use an impact wrench on the nut to
tighten it (Fig. U&V).
3. Mount the lower cover assembly.
4. Reload the cutting line.
5. Start the tool to see whether the string trimmer will
work normally. If it does not, reassembly as described
above.
MAINTENANCE
WARNING: When servicing, use only identical
replacement parts. Inspect and maintain the machine
regularly. To ensure safety and reliability, all repairs
should be performed by a qualified service technician.
WARNING: Battery tools do not have to be plugged
into an electrical outlet; therefore, they are always in
operating condition. To prevent serious personal injury,
take extra precautions and care when performing
maintenance, service or for changing the cutting
attachment or other attachments.
WARNING: To prevent serious personal injury,
remove the battery pack from the tool before servicing,
cleaning, changing add-on attachments or removing
material from the unit.
CAUTION: Obstructions in the vents will prevent
the air from flowing into the motor housing and result in
overheating or damaged of the motor.
CLEANING THE UNIT
◾Clean the unit using a damp cloth with a mild detergent.
Never let any liquid get inside the tool; never immerse
any part of the tool into a liquid.
◾Do not use any strong detergents on the plastic
housing or the handle. They can be damaged by certain
aromatic oils, such as pine and lemon, and by solvents
such as kerosene. Moisture can also cause a shock
hazard. Wipe off any moisture with a soft dry cloth.
◾Use a small brush or the air discharge of a small vacuum
cleaner brush to clean the air vents on the rear housing.
◾Keep air vents in the motor housing from debris at all times.
SHARPEN THE LINE-CUTTING BLADE
WARNING: Always protect your hands by wearing
heavy gloves when performing any maintenance on the
line-cutting blade.
1. Remove the line-cutting blade from the guard accessory.
2. Secure the blade in a vise.
3. Carefully file the cutting edges of the blade with a
fine-tooth file or sharpening stone, being careful to
maintain the original cutting-edge angle.
4. Replace the blade onto the guard and secure it in
place with the two screws.
STORING THE UNIT
◾Remove the battery pack from the line trimmer when it
is not in use.
◾Clean the tool thoroughly before storing it.
◾Store the unit in a dry, well-ventilated area, locked-up or
up high, out of the reach of children. Do not store the unit
on or adjacent to fertilisers, petrol, or other chemicals.
Protecting the environment
Do not dispose of electrical equipment,
used battery and charger into household
waste! Take this product to an authorized
recycler and make it available for
separate collection. Electric tools must be
returned to an environmentally
compatible recycling facility.

56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — ST1400E-ST14
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
String trimmer fails
to start.
◾The battery pack is not attached
to the line trimmer.
◾Remove battery, check contacts and reinstall
the battery pack.
◾No electrical contact between
the trimmer and battery.
◾Attach the battery pack to the line trimmer.
◾The battery pack is depleted. ◾Charge the battery pack.
◾The lock off trigger is not
being moved forward before
depressing the switch trigger.
◾Move the locking tongue forwards and then
press the switch trigger.
String trimmer stops
while cutting.
◾The guard is not mounted on the
trimmer, resulting in an overly
long cutting line and motor
overload.
◾Remove the battery pack and mount the guard
on the trimmer.
◾Heavy cutting line is used. ◾Use recommended nylon cutting line with
diameter no greater than 2.4mm.
◾The motor shaft or trimmer head
is bound with grass.
◾Stop the trimmer, remove the battery, and
remove the grass from the motor shaft and
trimmer head.
◾The motor is overloaded. ◾Remove the trimmer head from the grass.
The motor will recover to work as soon as
the load is removed. When cutting, move the
trimmer head in and out of the grass to be cut
and remove no more than 20cm of length in a
single cut.
◾The battery pack or string
trimmer is too hot.
◾Cool the battery or string trimmer.
◾The battery pack is
disconnected from the tool.
◾Re-install the battery pack.
◾The battery pack is depleted. ◾Charge the battery pack.
◾Unbalance after installation of
cutting line.
◾Tap the trimmer head to make the rope length
symmetrical.

56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — ST1400E-ST 15
PROBLEM CAUSE SOLUTION
Trimmer head will not
advance line.
◾The motor shaft or trimmer head
is bound with grass.
◾Stop the trimmer, remove the battery, and clean
the motor shaft and trimmer head.
◾There is not enough line on the
spool or the line break from the
eyelet.
◾Remove the battery and replace the cutting line
follow “LINE REPLACEMENT” section in this
manual.
◾The line is tangled. ◾Remove the battery and replace the cutting line
follow “LINE REPLACEMENT” section in this
manual.
◾The line is too short. ◾Remove the battery and replace the cutting line
follow “LINE REPLACEMENT” section in this
manual.
Grass is wrapped
around trimmer head
and motor housing.
Cutting tall grass at ground level. Cut tall grass from the top down, removing no
more than 20cm in each pass to prevent wrapping.
Cracks on the trimmer
head or the spool
retainer comes loose
from spool base.
◾The trimmer head is worn out. ◾Replace the trimmer head immediately; follow
the section “TRIMMER HEAD REPLACEMENT”
in this manual.
◾The nut that locks the trimmer
head is loose.
◾Open the trimmer head and use an impact
wrench to tighten the nut.
The cutting line cannot
be wound into the trim-
mer head properly.
◾The cutting line is too long. ◾Cut the line so that about 13cm long is showing
on each side.
◾Grass debris or dirt has
accumulated in the trimmer
head and blocked the movement
of line spool.
◾Remove the battery, open the trimmer head and
clean it thoroughly.
◾Motor is overheated due to
repeatedly operating the line
winding system.
◾Let string trimmer work under no load for a few
minutes to cool the motor, then try to reload
the line.
◾Low battery ◾Charge the battery.
The cutting line cannot
be passed through the
trimmer head when
inserting the line.
◾The cutting line is split or bent
at the end.
◾Cut the worn end of line and reinsert.
◾The lower cover is not released
to position after reinstalling.
◾Attach the battery pack onto the trimmer; press
the line loading button to briefly start the power
loading to release the lower cover.

56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — ST1400E-ST16
WARRANTY
EGO WARRANTY POLICY
5 year warranty on EGO outdoor power equipment and 3 year warranty on EGO Power+ System battery packs and
chargers.
Please contact EGO customer service on Australia 1300 000 EGO(1300 000 346),
New Zealand 0508 000 EGO (0508 000 346) any time you have questions or warranty claims.
LIMITED SERVICE WARRANTY
FOR FIVE YEARS from the date of original retail purchase, this EGO product is warranted against defects in material or
workmanship. Defective product will receive free repair.
FOR THREE YEARS from the date of original retail purchase, the EGO Power+ System battery pack and charger are
warranted against defects in material or workmanship. Defective product will receive free repair.
This warranty does not cover the blade, which is a part that can wear out from normal use within the warranty period.
◾This warranty applies only to the original purchaser at retail and may not be transferred.
◾The warranty period for any EGO product or part used for industrial, professional or commercial purpose is one year.
◾This warranty is void if the product has been used for rental purpose.
◾This warranty does not cover the damage resulting from modification, alteration or unauthorized repair.
◾This warranty only covers defects arising under normal usage and does not cover any malfunction, failure or defect
resulting from misuse, abuse (including overloading of the product beyond capacity and exposure to water or rain),
accidents, neglect or lack of proper installation, and improper maintenance or storage.
◾This warranty does not cover normal deterioration of the exterior finish, including but not limited to scratches, dents,
paint chips, or to any corrosion or discoloring by heat, abrasive and chemical cleaners.
HOW TO OBTAIN SERVICE
For warranty service, please contact EGO customer service on Australia 1300 000 EGO(1300 000 346),
New Zealand 0508 000 EGO (0508 000 346). When requesting warranty service, you must present the original dated
sales receipt. An authorized service center will be selected to repair the product according to the stated warranty terms.
ADDITIONAL LIMITATIONS
Chervon Australia Pty Ltd ABN 36 165 077 501(“Chervon”) warrants to the original domestic purchaser that this
product will be free from defects in materials and workmanship for 5 years from date of purchase, and any battery or
charger will be free from defects in materials and workmanship for 3 years from date of purchase. To make a claim,
return the faulty item together with proof of purchase directly to your closest service agent or to the place of purchase.
Any handling and transportation costs (and other expenses incurred in claiming this warranty) are not covered by this
warranty and will not be borne by Chervon. The replacement product or part or repaired product will be made available
for your collection at an address nominated by Chervon. Where a valid warranty claim is made, Chervon will replace
the defective product or repair the fault. Where the product is repaired, Chervon may use refurbished parts. This
warranty does not cover normal wear and tear, misuse or abuse. This warranty may also be further limited or voided
as specifically detailed in the product Manual. Chervon has no other liability under this warranty.The benefits to you
given by this warranty are in addition to other rights and remedies imposed by State and Federal legislation that cannot
be excluded. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure. Chervon Australia Pty Ltd, Unit 14, 5 Kelletts Road, Rowville, VIC 3178.
Phone Number: Australia 1300 000 EGO(1300 000 346), New Zealand 0508 000 EGO (0508 000 346).
Email address: [email protected].
