Eighteeth CuringPen User manual

s
CuringPen
LED Curing Light USER MANUAL
Changzhou Sifary Medical Technology Co.

Page 3 / 30
Content
1. Scope of CuringPen.................................................................. 4
1.1 Parts Identification .......................................................... 4
1.2 Components and accessories ....................................... 5
1.3 Optional accessories ...................................................... 5
2. Symbols Used ............................................................................ 6
3. Before Use................................................................................... 7
3.1 Scope of application........................................................ 7
3.2 Contraindications............................................................. 7
4. Setting up the CuringPen ........................................................ 8
4.1 Install the light source head........................................... 8
4.2 Install the disposable sleeve.......................................... 8
4.3 Install the protective light shield .................................... 8
4.4 Charging......................................................................... 10
5. Use Interface..............................................................................11
5.1 Panel key.........................................................................11
6. Setting........................................................................................ 12
6.1 Selecting memory.......................................................... 12
6.2 Advanced setting........................................................... 13
7. Operation................................................................................... 14
7.1 Charge ............................................................................ 14
7.2 Handpiece operation..................................................... 15
7.3 Operation mode............................................................. 17
8. Maintenance ............................................................................. 19
9. Error Warning ........................................................................... 20
10. Troubleshooting .................................................................... 21
11. Technical Data........................................................................ 23
12. EMC Tables............................................................................. 24
13. Statement................................................................................ 29

Błąd! Użyj karty Narzędzia główne, aby zastosować
标题 1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główn
e, aby zastosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 4 / 30
1.Scope of CuringPen
1.1 Parts Identification
5
1
2
3
4
6
○,1Light source head
○,2 Protective light
shield
○,3Disposable sleeve
○,4handpiece
○,5Adapter
○,6Charging base

Błąd! Użyj karty Narzędzia główne, aby zastosować
标题 1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główn
e, aby zastosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 5 / 30
1.2 Components and accessories
Handpiece (1pcs)
ORDER CODE:6551003
Light source head(1pcs)
ORDER CODE:6551001
Disposable sleeve（100pcs）
ORDER CODE:6542002
Adapter (1pcs)
ORDER CODE:6516001
Charging base (1pcs)
ORDER CODE:6551004
Protective light shield (1pcs)
ORDER CODE:6551005
1.3 Optional accessories
Light curing depth test board (1pcs)
ORDER CODE:6503011
Protective light glasses (1pcs)
ORDER CODE:6541001

Błąd! Użyj karty Narzędzia główne, aby zastosować
标题 1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główn
e, aby zastosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 6 / 30
2. Symbols Used
Warning
If the instructions are not followed properly,
operation may lead to hazards for the product
or the user/patient.
NOTE
Additional information, explanation of
operation and performance.
SN
Serial number
REF
Catalogue number
Manufacturer
Date of manufacture
Safety class II device
Type B applied part
Direct current
WEEE(Waste of Electrical and Electronic
Equipment )Directive Marking
Store in a dry place
Consult instructions for use
EC REP
Authorized Representative in the European
Community
Temperature limitation
Relative humidity
kPa
Transport and storage pressure conditions:70
kPa - 106 kPa
Manufacturer’s LOGO

Błąd! Użyj karty Narzędzia główne, aby zastosować
标题 1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główn
e, aby zastosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 7 / 30
3. Before Use
3.1 Scope of application
Suitable for the purpose of curing dental resins and composites or detecting
caries.
This device must only be used in hospital environments, clinics or dental
offices by qualified dental personnel
3.2 Contraindications
Do not use the device for non-endodontic dental procedures.
Safety and effectiveness have not been established in pregnant women and
children.
Warning
Read the following warnings before use:
1. The device must not be placed in humid surroundings or anywhere
where it can come into contact with any type of liquids.
2. Do not expose the device to direct or indirect heat sources. The device
must be operated and stored in a safe environment.
3. The device requires special precautions with regard to electromagnetic
compatibility (EMC) and must be installed and operated in strict
compliance with the EMC information. In particular, do not use the device
in the vicinity of fluorescent lamps, radio transmitters, remote controls,
portable or mobile RF communication devices and do not use this system
near the active HF Surgical Equipment in the hospital .Do not charge,
operate or store at high temperatures. Comply with the specified operating
and storage conditions.
4. Protective light shield and a disposable sleeve are compulsory during
treatment.
5. If irregularities occur in the device during treatment, switch it off.
Contact the agency.
6. Never open or repair the device yourself, otherwise, void the warranty

Błąd! Użyj karty Narzędzia główne, aby
zastosować 标题 1 do tekstu, który ma się tutaj pojawić. Błąd!
Użyj karty Narzędzia główne, aby zastosować 标题 1 do tekstu,
który ma się tutaj pojawić.
Page 8 / 30
4. Setting up the CuringPen
4.1 Install the light source
head
Make sure the light source
head alignment the slots of
handpiece, plug them together until
it “click” securely into place.
The light source head can be
360 degrees rotated without take
off, make it easy to watch the LCD
in treatment
WARNING
⚫After connecting the light
source head and the
handpiece, pull it gently
to make sure the
connection is good.
⚫Make sure the assembly
is connected properly,
otherwise might cause
unexpected fault, even
hurt the patients
4.2 Install the disposable
sleeve
Take a disposable sleeve and
gently insert it into the handpiece
from the light source head.
4.3 Install the protective
light shield
Make sure the light source
head alignment the slots of the
protective light shield, plug them
together.
WARNING
⚫Disposable sleeve must
be discarded after use
⚫The light source head,
protective light shield and
handpiece should be
cleaned and disinfected
after each treatment.
Avoid direct exposure of the
lamp to the eyes during working

Błąd! Użyj karty Narzędzia główne, aby
zastosować 标题 1 do tekstu, który ma się tutaj pojawić. Błąd!
Użyj karty Narzędzia główne, aby zastosować 标题 1 do tekstu,
który ma się tutaj pojawić.
Page 9 / 30

Błąd! Użyj karty Narzędzia główne, aby
zastosować 标题 1 do tekstu, który ma się tutaj pojawić. Błąd!
Użyj karty Narzędzia główne, aby zastosować 标题 1 do tekstu,
który ma się tutaj pojawić.
Page 10 / 30
4.4 Charging
Plug the USB of adapter into the
charge base, and plug the other end
into a power outlet, the Power LED on
charge base will light up (green).
NOTE
⚫Only the original adapter
could be used.
Put the handpiece all the way
into the charge base, the charge
state will show on the screen.
Charging indication appears
on the screen, and flashes slowly ,
when battery is fully charged or in
a state near full charge, the flash
will stop
NOTE
⚫Put the handpiece into
the charge base in the
right direction,
otherwise the
handpiece will not be
recharged.

Błąd! Użyj karty Narzędzia główne, aby
zastosować 标题 1 do tekstu, który ma się tutaj pojawić. Błąd!
Użyj karty Narzędzia główne, aby zastosować 标题 1 do tekstu,
który ma się tutaj pojawić.
Page 11 / 30
5.Use Interface
5.1 Panel key
s
1
2
○,1 main switch
○,2“S” Setting key
Turn Power On
Press more than 0.5 seconds
to turn on the instrument
Memory Change
Press setting key during standby
state
Turn Power Off
Long press to turn power off.
Advanced setting
During power off state, holding
down press .“S” then press to
entry advanced setting, Press “S”
till target setting, press to
adjust, then press “S”to confirm
M0
1500mW/cm²
15s
12
3
4
○,1 Battery
○,2 Memory
○,3 Curing light intensity
○,4 Curing time

Błąd! Użyj karty Narzędzia główne, aby
zastosować 标题 1 do tekstu, który ma się tutaj pojawić. Błąd!
Użyj karty Narzędzia główne, aby zastosować 标题 1 do tekstu,
który ma się tutaj pojawić.
Page 12 / 30
6.Setting
6.1 Selecting memory
M0
1500mW/cm²
15s
Memory Change
There are 6 built-in memory programs, namely
M0, M1, M2, RAMP, PULSE, Detect. Press setting
key to change the memory during standby state
Curing Power
mW/cm ²1500
Light intensity setting
The memory programs of M0, M1 and M2 can be
customized to 2300mW/cm2, 1500mW/cm2 or
1000mW/cm2. Long Press “S” to enter the light
intensity setting menu, then press “S” to change
or press main switch to confirm and exit.
On the light intensity setting menu, long press “S”
to enter the time setting menu.
NOTE
⚫The light intensity of RAMP, PULSE and
Detect memory programs are built-in,
and the user cannot modify the
settings.
Curing Time
Sec05
Curing Time setting
In the curing time setting menu, press “S” to
select different times. The time selection is
different under different light intensity:
light
intensity(mW/cm²)
time selection(sec)
2300
01,02,03
1500
05,10,15,20
1000
05,10,15,20
600
10,15,20,25
Long press “S” or short press to exit the setting.
The current memory program automatically saves
the setting parameters.

Błąd! Użyj karty Narzędzia główne, aby
zastosować 标题 1 do tekstu, który ma się tutaj pojawić. Błąd!
Użyj karty Narzędzia główne, aby zastosować 标题 1 do tekstu,
który ma się tutaj pojawić.
Page 13 / 30
6.2 Advanced setting
Auto Off
min5
During power off state, holding down
press “S” then press to entry the
“Auto power off time” setting.
It can be set to 1min, 5min, 10min or
15min.
Press to change setting, press “S” to
enter the next setting “Volume” volume
setting mode.
Volume
mid
In the volume setting menu, press “S” to
select different settings. It can be set to
“Off”, “low”, “mid” or “high”.
Press to change setting, press “S”
to enter the next setting “Hand” hand
setting mode.
Hand
Right
The right hand and the left hand can be
set in the “Hand” setting menu, Press
to change setting, press “S” to enter the
next setting.
L1
The last item is the firmware version,
and the handpiece shuts down
automatically within 1 s after the version
information is displayed.

Błąd! Użyj karty Narzędzia główne, aby
zastosować 标题 1 do tekstu, który ma się tutaj pojawić. Błąd!
Użyj karty Narzędzia główne, aby zastosować 标题 1 do tekstu,
który ma się tutaj pojawić.
Page 14 / 30
7.Operation
7.1 Charge
Displays the present remaining amount of the
battery.
Less than 15% remains, please charge.
NOTE
⚫If the power if less than 15%, must be
recharged within 30 days, otherwise
the battery will be damaged.
Charging indication appears on the screen, and
flashes slowly , when battery is fully charged or
in a state near full charge, the flash will stop
Fully charged will take about 4 hours,
depending on residual battery power and
battery state.
It can be recharged 300-500 times, depending
on the operating conditions of the device.
NOTE
⚫When changing, other function will
forcibly stop, take from charge base,
press main switch, the last function
will recall.
WARNING
⚫Do not change the battery, only trained technician or
distributor can change the battery, the electronic parts will
be damaged if use a wrong battery or install with a wrong
way.

Błąd! Użyj karty Narzędzia główne, aby
zastosować 标题 1 do tekstu, który ma się tutaj pojawić. Błąd!
Użyj karty Narzędzia główne, aby zastosować 标题 1 do tekstu,
który ma się tutaj pojawić.
Page 15 / 30
7.2 Handpiece operation
After the handpiece main unit
is turned on, press to start
the light intensity output, and the
time will start counting down.
Press any key to interrupt the
output during the light intensity
output.
There is a beep every 5s
while working, and the output is
automatically turned off after the
countdown ends.
WARNING
⚫When the device is
working, do not directly
illuminate the eyes,
otherwise it will cause
injury.
⚫Do not directly
illuminate the skin,
otherwise high
temperature burns may
occur.
NOTE
⚫After the device is used
continuously for 10
times at 2300mW/cm2, it
will be prohibited to use
the highest light
intensity output within 1
minute, Used to prevent
the lamp from
overheating
⚫When using, the light
should be directly
irradiated onto the
curing dental resins and

Błąd! Użyj karty Narzędzia główne, aby
zastosować 标题 1 do tekstu, który ma się tutaj pojawić. Błąd!
Użyj karty Narzędzia główne, aby zastosować 标题 1 do tekstu,
który ma się tutaj pojawić.
Page 16 / 30
composites to avoid
improper exposure.
⚫The disposable
protective cover and
protective light shield
are highly
recommended.
When the device is in standby
mode, it will automatically shut
down when it reaches the set
time. The factory default setting
is 5 minutes
WARNING
⚫Before using, please try it outside the oral cavity to ensure that
there is no problem with the function of the device.
⚫ Do not disassemble the lamp during treatment .
NOTE
⚫If there is any abnormal functioning, stop using the device and
report to company
⚫Gloves are compulsory during treatment
⚫Always clean the handpiece and light source head after each
treatment.

Błąd! Użyj karty Narzędzia główne, aby
zastosować 标题 1 do tekstu, który ma się tutaj pojawić. Błąd!
Użyj karty Narzędzia główne, aby zastosować 标题 1 do tekstu,
który ma się tutaj pojawić.
Page 17 / 30
7.3 Operation mode
M0、M1、M2
Standard mode
In these three modes, the light
intensity can be set to
2300mW/cm², 1500mW/cm² or
1000mW/cm².
Wavelength：385nm-515nm
When pressed, the setting
light intensity is output
immediately, and the sound is
prompted every 5 seconds.
100%
light intensity
Time
RAMP
Ramp Mode
Light intensity : 1000mW/cm²。
Wavelength: 385nm-515nm
When pressed, the light
intensity gradually increases to
1000mW/cm2 in the first 5
seconds, and then continues to
output 1000mW/cm2, prompting
the sound every 5 seconds.
100%
light intensity
Time
PULSE
PULSE Mode
Light intensity : 1000mW/cm²

Błąd! Użyj karty Narzędzia główne, aby
zastosować 标题 1 do tekstu, który ma się tutaj pojawić. Błąd!
Użyj karty Narzędzia główne, aby zastosować 标题 1 do tekstu,
który ma się tutaj pojawić.
Page 18 / 30
Wavelength: 385nm-515nm
When pressed，the output
light intensity is 1000mW/cm2
and flashes once every 1
second, prompting the sound
every 5 seconds.
100%
light intensity
Time
Detect
Detecting mode
Light intensity : 600mW/cm²
Wavelength: 385nm-410nm
100%
Light intensity
Time
When pressed，he setting
light intensity is output
immediately, and the sound is
prompted every 5 seconds.
NOTE
⚫This mode is only
suitable for detecting
dental calculus, caries,
cracks, etc.
WARNING
⚫Detect Mode cannot be
used to cure dental
resins and composites,
otherwise there is a risk
of incomplete curing.

Błąd! Użyj karty Narzędzia główne, aby
zastosować 标题 1 do tekstu, który ma się tutaj pojawić. Błąd!
Użyj karty Narzędzia główne, aby zastosować 标题 1 do tekstu,
który ma się tutaj pojawić.
Page 19 / 30
8.Maintenance
Disinfection components
handpiece
Light source head
Adapter
Charging base
Protective light shield
Wipe all the surfaces with a cloth lightly moistened with Ethanol for
Disinfection (Ethanol 70 to 80vol%) at least 2min, repeat for 5 times.
WARNING
⚫Do not use anything except Ethanol for Disinfection (Ethanol
70 to 80 vol%).
⚫Do not use too much ethanol as it’s going into machine and
damage the components inside.
Disposable components
Disposable sleeve（100pcs）
WARNING
⚫Please discard it after use and do not use it again.
⚫The product has been disinfected with ethylene oxide, so there
is no need to disinfect it before use.

Błąd! Użyj karty Narzędzia główne, aby
zastosować 标题 1 do tekstu, który ma się tutaj pojawić. Błąd!
Użyj karty Narzędzia główne, aby zastosować 标题 1 do tekstu,
który ma się tutaj pojawić.
Page 20 / 30
9.Error Warning
Low Battery
The battery is too low. Charge it
immediately
Fault:
Blue Error
Blue LED broken, contact your
distributor.
Fault:
Blue Overload
Blue LED overload, contact your
distributor.
Fault:
Violet Error
Violet LED broken, contact your
distributor.
Fault:
Violet Overload
Violet LED overload, contact your
distributor.
!
The temperature of the light
source head is higher than
expectation, turn the power off or
waiting more than 1 minutes to
let it cold down.
