Eighteeth E-connect S User manual

0197
E-connect
S
USER MANUAL

Content
1. Scope of E-connect S.......................................................................................................................4
1.1 Parts Identification............................................................................................................4
1.2 Components and Accessories........................................................................................5
1.3 Options (sold separately)................................................................................................5
2. Symbols used in the User Manual.................................................................................................6
3. Before Use...........................................................................................................................................7
3.1 Intended Use.....................................................................................................................7
3.2 Contraindications..............................................................................................................7
4. Installing the E-connect S ...............................................................................................................8
4.1 Installation of the contra angle........................................................................................8
4.2 Install the file.....................................................................................................................8
4.3 Connecting measuring wire............................................................................................9
4.4 Connecting charge base.................................................................................................9
5. Use Interface.....................................................................................................................................11
5.1 Panel key...........................................................................................................................11
5.2 Screen display...................................................................................................................12
5.3 Terms and definition .........................................................................................................14
6. Setting.................................................................................................................................................15
6.1 Selecting memory...........................................................................................................15
6.2 Setting parameters.........................................................................................................15
6.3 Preset programs.............................................................................................................18
6.4 Advanced setting............................................................................................................19
6.5 Parameter logic...............................................................................................................21
7. Operation...........................................................................................................................................24
7.1 Charge..............................................................................................................................24
7.2 Motor operation...............................................................................................................25
7.3 Apex operation and not suitable condition..................................................................27
8. Cleaning, Disinfection and Sterilization ....................................................................................32
8.1 Foreword..........................................................................................................................32
8.2 General recommendations............................................................................................32
8.2.1 The user is responsible for the sterility of the product for the first cycle and
each further usage as well as for the usage of damaged or dirty instruments, where
applicable after sterility..........................................................................................................32
8.2.2 For your own safety, please wear personal protective equipment (gloves,
safety glasses, etc.)...............................................................................................................32
8.2.3 Use only a disinfecting solution which is approved for its efficacy
(VAH/DGHM-listing, CE marking, and FDA approval) and in accordance with the DFU
of the disinfecting solution manufacturer............................................................................32
Page 2 / 47

8.2.4 The water quality has to be convenient to the local regulations especially for
the last rinsing step or with a washer-disinfector...............................................................32
8.2.5 Thoroughly clean and wash the components before autoclaving...................32
8.2.6 Do not lubricate the motor handpiece.................................................................32
8.2.7 Do not clean the contra angle with an ultrasonic cleaning device..................32
8.2.8 Do not use bleach or chloride disinfectant materials........................................32
8.3 Autoclavable Components............................................................................................32
8.4 Disinfection Components..............................................................................................36
9. Error Warning ...................................................................................................................................37
10. Troubleshooting.............................................................................................................................38
11. Technical Data................................................................................................................................41
12. EMC Tables......................................................................................................................................42
13. Statement.........................................................................................................................................46
Page 3 / 47

1Scope of E-connect S
1. Scope of E-connect S
1.1 Parts Identification
1
2
3
5
6
4
7
8
9
1.Charge Base
2.Handpiece
3.Contra Angle
4.Insulating Sleeve
5.File Clip (2 pcs)
6.Lip Hook (2 pcs)
7.Measuring Wire
8.Adapter
9.Spray Nozzle
Page 4 / 47

1Scope of E-connect S
1.2 Components and Accessories
Motor Handpiece (1pcs)
Part No. 6051035
Charge Base (1pcs)
Part No. 6051036
ContraAngle (1pcs)
Part No. 6036006
Adapter (1pcs)
Part No. 6016007+6016008
Measuring Wire (1pcs)
Part No. 6015011
Lip Hook (2pcs)
Part No. 6072002
File clip (2pcs)
Part No. 6051005
Insulating Sleeve (1pcs)
Part No. 6004027
Spray Nozzle (1pcs)
Part No. 6051038
1.3 Options (sold separately)
Handpiece Base
Part No. 6005002
Apex Tester (1pcs)
Part No. 6015012
Page 5 / 47

2Symbols used in the User Manual
2. Symbols used in the User Manual
WARNING
If the
instructions are not followed properly, operation may
lead to hazards for the product or the user/patient.
NOTE
Additional information, explanation of operation and
performance.
Serial number
Catalogue number
Manufacturer
Date of manufacture
LOT
Lot of manufacture
Class II equipment
Type B applied part
CE marking
Direct current
WEEE directive marking
Keep dry
134 C
Can be autoclaved up to a maximum temperature of 134°
Celsius
Authorized Representative in the European Community
55 C
20 C
Temperature limitation
80%
20%
Humidity limitation
106kPa
70kPa
Atmospheric pressure limitation
Manufacturer’s LOGO
Consult instructions for use
Washer-disinfector for thermal disinfection
Page 6 / 47

3Before Use
3. Before Use
3.1 Intended Use
E-connect S is a cordless endodontic treatment motorized handpiece with root
canal measuring capability. It can be used to enlarge canals while monitoring the
position of the file tip inside the canal. It can be used as a low-speed motorized
handpiece and device for measuring canal length.
This device must only be used in hospital environments, clinics or dental
offices by qualified dental personnel and not used in the oxygen-rich environment.
3.2 Contraindications
The integrated apex locator of the E-connect S is contraindicated in cases
where patient/user carry medical implants such as pace makers or cochlear
implants etc.
Do not use the device for implants or other non-endodontic dental procedures.
Safety and effectiveness have not been established in pregnant women and
children.
WARNING
Read the following warnings before use:
1. The device must not be placed in humid surroundings or anywhere where it can
come into contact with any type of liquids.
2. Do not expose the device to direct or indirect heat sources. The device must be
operated and stored in a safe environment.
3. The device requires special precautions with regard to electromagnetic
compatibility (EMC) and must be installed and operated in strict compliance with the
EMC information. In particular, do not use the device in the vicinity of fluorescent
lamps, radio transmitters, remote controls and do not use this system near the
active HF Surgical Equipment in the hospital. Portable RF communications
equipment (including peripherals such as antenna cables and external antennas)
should be used no closer than 30 cm (12 inches) to any part of the E-connect S,
including cables specified by the manufacturer. Otherwise, degradation of the
performance of this equipment could result. Do not charge, operate or store at high
temperatures. Comply with the specified operating and storage conditions.
4. Gloves and a rubber dam are compulsory during treatment.
5. If irregularities occur in the device during treatment, switch it off. Contact the
agency.
6. Never open or repair the device yourself，otherwise, void the warranty.
Page 7 / 47

4Installing the E-connect S
4. Installing the E-connect S
4.1
Installation of the
contra angle
Make sure 4
pins on contra angle
alignment the slots of handpiece, plug
them together until it “click” securely
into place.
The contra angle can be 340 degrees
rotated without take off, make it easy to
watch the LCD in treatment by rotating
the contra-angle.
WARNING
●Make sure the
assembly is
connected properly,
otherwise might
cause unexpected motor reverse, even
hurt the patients
●After connecting the contra angle and
handle,
pull it gently to make sure the
connection is good.
The improve insulation of the contra
angle during co
mbine apex, we
recommend using an insulating sleeve.
You can also use disposable sleeve
(sold separately) instead of insulating
sleeve
NOTE
Without the insulatin
g sleeve, when
performing the apex measurement with
handpiece, wear appropriate insulated
gloves, and make sure the contra angle
does not touch the lips. It is advisable
to use a rubber dam when performing
such treatments.
4.2 Install the file
Turn the file
back and forth until it is
lined up with interior latch groove and
slips into place, lock the file into the
contra angle.
Hold down the push button on the
contra angle and can release the file.
Push
Button
Page 8 / 47

4Installing the E-connect S
Single apex
function only
WARNING
●
Inspect the file head before inserting
the file. Do not use the damaged file
head.
●Make sure the motor is stopped when
inserting and removing files.
●
Be careful when inserting and
rem-oving files to avoid injury to fingers.
●Take care not to touch the Main switch
when putting files in. this will cause the
file to rotate.
●Pull the file gently to make sure that the
file is secure in handpiece properly,
otherwise it may pop out and hur
t the
patient.
4.3
Connecting measuring
wire
If want activity apex measurement
function, uncap the USB cover on
handpiece, insert measuring wire.
Insert lip hook into white slot, insert file
clip into black slot.
NOTE
It’s not necessary to connect file clip
during motor combine apex function, only
during single apex function.
NOTE
Match colors to
connect the lip hook
and file clip, if connect lip hook with
black slot, apex auto start will have no
function.
4.4
Connecting charge
base
Plug the USB of adapter into the
charge base, and plug the other end
into a power outlet, the Power LED on
charge base will light up (green).
NOTE
Only the original adapter could be
used.
Black
White
Power LED
Page 9 / 47

4Installing the E-connect S
Put the handpiece all the way into the
charge base, the charge state will show
on the screen.
NOTE
Put the handpiece into the charge base
in the right direction, otherwise the
handpiece will not be recharged.
If only need a base to put the device on
dentist element of dental chair ( without
charge function ), handpiece base is
recommended ( sold separately ) to
instead of charge base.
Page 10 / 47

5Use Interface
5.Use Interface
5.1 Panel key
①●Main switch
②Display Screen
③S Setting key
④<Decrease key
⑤>Increase key
Turn Power On
Press ●more than 0.5 seconds to
turn on the instrument
Memory Change
Press <or >during standby
state
Operation mode Change
Press S once during standby state,
press <or >to change, then
press ●or wait 5 seconds to
confirm
Parameter Adjustment
Press S till target parameters, press
<or >to adjust, then press ●
or wait 5 seconds to confirm
Preset Program Selection
Long press S to entry preset
program during standby state, press
<or >to change, then press ●
to confirm
Turn Power Off
Holding down press S then press
●
Advanced setting
During power off state, holding down
press S then press ●to entry
advanced setting, Press S till target
setting, press <or >to adjust,
then press ●to confirm
Page 11 / 47

5Use Interface
5.2 Screen display
M1 350 rpm
Fwd N cm·3.0
3
2
1
45 6 7
rpm
N cm·
350
5
4
3
2
1
12
3
4
Reference point
AP 132
1
2 3 4
Standby interface
①Memory mode number
②Speed of this memory program
③Unit of speed: Revolutions Per
minute
④Residual battery power
⑤Operation mode
⑥Torque of this memory program
⑦Unit of torque: Newton centimeter
Standard working mode
①The set maximum torque
②Real time torque
③Torque display scale
④The preset speed
Reference point interface
①Flash bar of apical reverse position
②Apex (Major/Anatomic apical
foramen)
③0.5mm meter reading (Very near
Minor/Physiological apical foramen)
④1mm-3mm (Estimate dimension)
distance scale from apex (Estimate
dimension)
Page 12 / 47

5Use Interface
M0
EAL
AP 1 32
1
2
3
3
1
2
05
2
AP
13
mm
0.5
03
02
01
00
-1
04
2
1
Canal measurement standby
interface
①Memory mode number
M0 is apex stand-alone memory
②Electronic apex locator
③Apex flash bar
Canal measurement start interface
①Indication number
The number has no represent of
actual length, only for indication
②Canal length indicator bar
③Apex flash bar (apex stand-alone
mode) or reference point flash bar
(motor combine with apex mode)
Canal measurement approach apex
interface
①The estimate dimension from apex
(Major/Anatomic apical foramen)
②Canal length indicator bar
Page 13 / 47

5Use Interface
5.3 Terms and definition
Fwd Forward ( Clockwise rotation )
Rev
Reverse ( Counter clockwise rotation )
Be applied to special file, inject calcium hydroxide and other
solutions
REC
Reciprocation
Be applied to reciprocating file, path file and rotary file
protection by setting some special angle
ATC
Adaptive torque control
Up to setting torque, the motor will move with reciprocating
mode; when torque reduce to normal value, the motor will
clockwise rotate
EAL
Electronic apex locator
In the mode, the device will work like a stand-alone apex
locator
AP
Apex
Major apical foramen or Anatomic apical foramen
R.L
Torque reverse less
The motor will not reverse rotation no matter how large the
torque load is
Reference point
During combined length determination, normally apical reverse
must active before reaching major apical foramen, setting
apical reverse position by change the flash bar
FWD Angle Forward angle (Clockwise rotation angle), activating in REC
andATC operation mode
REV Angle Reverse angle (Counter Clockwise rotation angle), activating
in REC andATC operation mode
Memory Mode Such as M0-M10
Operation Mode Such as FWD, REV, REC andATC
Page 14 / 47

6Setting
6.Setting
6.1 Selecting memory
M1
350
rpm
Fwd N cm·
3.0
2
1
3 4
E-connect S has 11 memory programs, press <
or >to change during standby state, the
memory number (○
1E
A) will change according.
M1-M10 is standard working memory for canal
shaping, every memory has its own speed (A○
2E
A),
mode (A○
3E
A) and torque (A○
4E
A), all this these
parameters can be changed (See chapter 6.2
Setting parameters).
M0
EAL
AP 1 32
M0 is special memory for stand-alone apex locator
function (See chapter 7.3
Apex operation and
not suitable condition).
6.2 Setting parameters
WARNING
All the parameters must be set according to files, make sure all the parameters are
expected before starting the motor, otherwise has risk of file broken.
M1 350 rpm
Fwd N cm
·
3.0
1
Before start the motor, check the operation mode
(A○
1E
A) is correct, otherwise press S once during
standby state, press <or >to change.
Op e ra ti on M od e
Fwd
E-connect S has 4 operation modes: FWD, REV,
REC and ATC (See chapter 5.3 Terms and
definition to get the explanations of these
modes).
Page 15 / 47

6Setting
NOTE
When choice REV mode, a slow beep alarm
sound appears after starting the motor, used for
indicating counter clockwise rotation happening.
Repeatedly press S to check all the next level parameters of this operation
mode are expected, press <or >to change if not.
NOTE
The parameter will differ in difference mode according to certain logic (See
chapter 6.5 Parameter logic).
Speed
300 rpm
The speed setting can be adjusted from 120 rpm
to 1000 rpm.
NOTE
The speed of REC andATC operation mode is
difference according to certain logic (See chapter
6.5 Parameter logic).
Torque L imit
3.0 N cm ·
The torque setting can be adjusted from 0.5 N·cm
to 4.0 N·cm, and R.L (torque reverse less) is also
available.
NOTE
The torque of REC and ATC operation mode is
difference according to certain logic (See chapter
6.5 Parameter logic).
WARNING
When choice R.L (torque
reverse less), a slow
beep alarm sound appears after starting the motor.
Be careful to use this function, very professional
skill is needed, otherwise has risk of file broken.
Auto Start
ON
E-connect S integrated apex locator, if the lip hook
is connecting with patient’s lip, when the endo file
entering root canal, the motor will start
automatically.
Press <or >
to shut off this function if not
expected, press ●to start and stop the motor.
WARNING
The motor will start automatically if handpiece
Page 16 / 47

6Setting
(without insulating sleeve) or file touch the
patient’s lip or operator’s fingers (without insulating
glove), take care to avoid this, the file rotated by
motor has risk of injure someone.
Auto Stop
OFF
When the endo file out of root canal, the motor will
not auto stop with default setting, Press <
or >to select auto stop “ON” if needed.
Apical Action
Reverse
Because of integrated apex locator, when the file
reaches the reference point, the motor will
response according to setting, it can be Reverse,
SlowDown, Stop and Off.
Press <or >to change.
Reverse:
rotation direction changing till the file
upward a little bit by operator, rotation direction will
change back again.
SlowDown: rotation slowdown when approach the
reference point, will reverse if reach.
Stop:
rotation stop when reach the reference
point, upward a little bit and will rotate again.
Off: rotating as usual even if reach the reference
point.
Reference point
AP 132
1
During combined length determination, normally
apical reverse must active before
reaching major
apical foramen, Press <or >to set apical
reverse position by change the flash bar (A○
1E
A), the
motor
will reverse while reaching the flash bar
every time.
FWD Angle
120°
Activating in REC and ATC operation mode.
forward angle (Clockwise rotation angle) can be
adjusted by operator from 30° to 370°, Press <
or >to change.
REV Angle
150°
Activating in REC and ATC operation mode.
reverse angle (Counter Clockwise rotation angle)
can be adjusted by operator from 30° to 370°,
Press <or >to change.
NOTE
The sum of FWD Angle and REV Angle must be
greater than 120°, the motor system has closed
the angle not needed. For example: if you set
FWD Angle 30°, the REV Angle must be setting
greater than 90°.
Page 17 / 47

6Setting
6.3 Preset programs
350 rpm
F wd
N cm
· 3. 0
1
2
M1
Protaper SX&S1
Protaper S2
Protaper F1
For convenience, we preset some common file
system.
Long press S to entry preset program during
standby state, the interface will show as left.
M1 (A○
1E
A) meanings the current memory mode, you
can replace it by preset program (A○
2E
A)
press <or >to change, then press ●to
confirm.
300 rpm
F wd
N cm
·
2. 5
2
1 3
OneShape
OneFlare
2Shape
OneCurve
4
If you selecting “OneCurve” (
A○
1E
A
), the operation
mode (A○
2E
A), speed (A○
3E
A) and torque limit (A○
4E
A) will
change according to the file system default setting.
NOTE
ProtaperA
○
RE
A, GATESA
○
RE
A, Pro.GliderA
○
RE
A, and Wave oneA
○
RE
Ais a registered trademark of Dentsply.
MtwoA
○
RE
A, Flex.MasterA
○
RE
A, ReciprocA
○
RE
AandR-PilotA
○
RE
Ais a
registered trademark of VDW.
K3XFA
○
RE
A, TFA
○
RE
Ais a registered trademark of
SybronEndo.
OneGA
○
RE
A, OneShapeA
○
RE
A, OneFlareA
○
RE
A, 2ShapeA
○
RE
Aand
OneCurveA
○
RE
Ais a registered trademark of
Micro-Mega
XPendo.ShaperA
○
RE
A, XPendo.FinisherA
○
RE
A, iRaceA
○
RE
A,
BT-RaceA
○
RE
Aand BioRaceA
○
RE
Ais a registered
trademark of FKG
OneCurve 300 rpm
Fwd
Ncm·
2.5
13 4 2
And the memory mode (A○
1E
A) will change according,
also operation mode (A○
2E
A), speed (A○
3E
A) and torque
limit (A○
4E
A) will charge according to the file system
default setting.
NOTE
All of memory mode (from M1-M10) can be
replaced with same mothed.
Page 18 / 47

6Setting
OneCurve
350 rpm
Fwd Ncm·
3.0
1
2
The parameters of “OneCurve” can also be
changed make it different from default setting, and
there will be 4 corners around the parameter (A○
1E
A)(A○
2E
A).
If want to change back to default setting, long
press S to entry preset program during standby
state, select “OneCurve” and press
●to confirm, the default setting will be recalled,
and the 4 corners around will disappear.
If want to change back to M1 (or M2-M10), long
press S to entry preset program during standby
state, press <or >to select M1 (or M2-M10)
again, then press ●to confirm
WARNING
Changing the default setting is not recommended
only if you are very sure it can be changed,
otherwise has risk of file broken.
6.4 Advanced setting
Ve rsi on s
E.1.1.008
During power off state, holding down press S then
press ●to entry advanced setting, the version
number software will appear on the display screen.
E-connect S can update software very easy without
tools and software. Contact your distributor to update if
necessary.
NOTE
After updating, all of the setting parameters will be
covered.
Auto Power Off
10 Min
Press S again, the “Auto Power Off” time can be
change, press <or >to adjust, then press ●
to confirm.
The “Auto Power Off” time can be set from 3-15
minutes.
Page 19 / 47

6Setting
Auto Return time
5 Se c
Press S again, the “Auto Return time” can be
change, it means when setting parameters just like
speed and torque, the system will back to standby
interface if there is no operation in 5 seconds.
press <or >to adjust, then press ●to
confirm.
The “Auto Return time” can be set from 3-15 seconds.
Bee pe r Vol um e
V ol . 2
Press S again, the “Beeper Volume” can be change,
press <or >to adjust, then press ●to
confirm.
The “Beeper Volume” can be set from 0-3.
Habit hand
Right Hand
Press S again, the “Habit hand” can be change,
press <or >to adjust, then press ●to
confirm.
The right hand and the left hand can be set.
Startup memory
M1
Press S again, the “Start memory” can be change, it
means every time turn power on, which memory mode
will appear first.
press <or >to adjust, then press ●to
confirm.
M1 and Last (the memory mode number when you turn
power of ) can be set.
Calibration
OFF
Press S again, entry “Calibration” function, press <
or >to select “ON”, press ●to start calibration.
WARNING
●Before calibrating, making sure the original contra
angle is installed, and do not install the file.
●The torque will not correct if calibration without
original contra angle or any load on contra angle chuck,
and has risk of file broken.
Calibration
1000 rpm
The motor speed will increase from 120 to 1000 rpm.
When the speed up to 1000 rpm, the calibration
successful and automatic power off.
Page 20 / 47
