Eighteeth Fast-Fill User manual

0197
Fast-Fill
USER MANUAL

Page 3 / 37
Content
1. Scope of Fast-Fill...............................................................................................................................4
1.1 Parts Identification............................................................................................................4
1.2 Components and Accessories........................................................................................5
1.3 Options (sold separately) ................................................................................................5
2. Symbols used in the User Manual.................................................................................................6
3. Before Use...........................................................................................................................................8
3.1 Intended Use.....................................................................................................................8
3.2 Contraindications..............................................................................................................8
4. Installing the Fast-Fill .....................................................................................................................10
4.1 Installation of Gutta-percha...........................................................................................11
4.2Installation of Cartridge..................................................................................................11
4.3 Installation of adapter.....................................................................................................12
4.4 Connecting charge base ...............................................................................................12
5. Use Interface.....................................................................................................................................13
6. Setting.................................................................................................................................................15
6.1 Memory Parameter Setting ...........................................................................................15
6.2 Advanced Setting ...........................................................................................................16
7. Operation ...........................................................................................................................................17
7.1 Charge..............................................................................................................................17
7.2 Heating and Using..........................................................................................................18
7.3 Changing Gutta-percha .................................................................................................19
8. Maintenance......................................................................................................................................21
8.1 Daily cleaning..................................................................................................................21
8.2 Changing silver tube of cartridge .................................................................................22
8.3 Cleaning, Disinfection and Sterilization.......................................................................24
9. Troubleshooting...............................................................................................................................30
10. Technical Data................................................................................................................................31
11. EMC Tables......................................................................................................................................32
12. Statement.........................................................................................................................................36

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 4 / 37
1. Scope of Fast-Fill
1.1 Parts Identification
1
2
3
4
6
5
1.Charge Base
2.Handpiece
3.Cartridge nut (2PCS)
4.Silver tube (2PCS)
5. Adapter
6.Bending Tool

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 5 / 37
1.2 Components and Accessories
Fast-Fill Handpiece (1pcs)
Part No. 6351002
Charge Base (1pcs)
Part No. 6351003
Adapter (1pcs)
Part No.6316001+6316005
Cartridge nut (2pcs)
Part No. 6351207
Bending tool (1pcs)
Part No. 6351010
Silver tube (1pcs)
Size: 25Ga
Color: Black
Part No. 6351208 (Disposable)
Silver tube (1pcs)
Size: 23Ga
Color: Natural
Part No. 6351209 (Disposable)
1.3 Options (sold separately)
Silver tube (1pcs)
Size: 20Ga
Color: Black
Part No. 6351211 (Disposable)
Handpiece Base
Part No. 6005002

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 6 / 37
2. Symbols used in the User Manual
WARNING
If the instructions are not followed properly, operation may
lead to hazards for the product or the user/patient.
NOTE
Additional information, explanation of operation and
performance.
Serial number
Catalogue number
Manufacturer
Date of manufacture
LOT
Lot of manufacture
Class II equipment
Type B applied part
CE marking
Direct current
WEEE directive marking
Keep dry
134 C
Can be autoclaved up to a maximum temperature of 134°
Celsius
Authorized Representative in the European Community
55C
20C
Temperature limitation
80%
20%
Humidity limitation
106kPa
70kPa
Atmospheric pressure limitation
Manufacturer’s LOGO
Consult instructions for use

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 7 / 37
Washer-disinfector for thermal disinfection

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 8 / 37
3. Before Use
3.1 Intended Use
Fast-Fill is intended for heating and extruding Gutta-percha into cleaned and
shaped canals during root canal treatment.
This device must only be used in hospital environments, clinics or dental offices
by qualified dental personnel and not used in the oxygen-rich environment.
3.2 Contraindications
This device must not be used in cases where a patient has been fitted with an
implanted heart pacemaker (or other electrical equipment) and has been cautioned
against the use of small electrical appliances (such as electric shavers, hair dryers,
etc.)
Safety and effectiveness have not been established in pregnant women and
children.
WARNING
Read the following warnings before use:
1. The device must not be placed in humid surroundings or anywhere where it can
come into contact with any type of liquids.
2. Do not expose the device to direct or indirect heat sources. The device must be
operated and stored in a safe environment.
3. The device requires special precautions with regard to electromagnetic
compatibility (EMC) and must be installed and operated in strict compliance with the
EMC information. In particular, do not use the device in the vicinity of fluorescent
lamps, radio transmitters, remote controls and do not use this system near the active
HF Surgical Equipment in the hospital. Portable RF communications equipment
(including peripherals such as antenna cables and external antennas) should be
used no closer than 30 cm (12 inches) to any part of the Fast-Fill, including cables
specified by the manufacturer. Otherwise, degradation of the performance of this
equipment could result. Do not charge, operate or store at high temperatures.
Comply with the specified operating and storage conditions.
4. Gloves and a rubber dam are compulsory during treatment.
5. If irregularities occur in the device during treatment, switch it off. Contact the
agency.
6. Never open or repair the device yourself, otherwise, void the warranty.
7. Cautions should be exercised when use the device to fill the teeth with thin dentinal
root walls.

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 9 / 37

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 10 / 37
4.Installing the Fast-Fill

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 11 / 37
4.1 Installation of Gutta-
percha
Push the Gutta-percha into the
handpiece.
NOTE
This product is not included the Gutta-
percha. Please use the Gutta-percha
that is recommended by Sifary. Refer
to the Technical data of this manual for
the recommended Gutta-percha size.
4.2 Installation of Cartridge
Screw the cartridge along the thread of
the handpiece to install.
The needle on cartridge cannot be
turned or bended by hand.
Use bending tool to bend the needle.
Use bending tool with the hexagonal
hole matched to rotate the needle.
Unscrew the cartridge from the
handpiece to disassemble.
WARNING
➢To remove the cartridge. As shown in
the picture, touch the flow heater
with finger rapidly, make sure it is not
hot before operation. If the
temperature is too high, waiting 3~5
minutes till it is cooling.
➢Even if the cartridge cools down
already, we strongly recommend not
to touch the needle on cartridge.
There is a risk of heat injury or
damage the cartridge. Hold the black
shell to remove.

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 12 / 37
4.3 Installation of adapter
Plug the head into the base if they are
separated in the package.
4.4 Connecting charge base
Plug the USB of adapter into the
charge base, and plug the other end
into a power outlet.
The Power LED on charge base will
light up in green.
NOTE
Only the original adapter could be
used.
Put the handpiece all the way into the
charge base. The charge state will show
on the screen.
NOTE
Put the handpiece into the charge base
in the right direction, otherwise the
handpiece will not be charged.
If only need a base to put the device on
dentist element of dental chair (without
charge function), handpiece base is
recommended to use instead of charge
base.
Power LED

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 13 / 37
5.Use Interface
1
2
3
4
5
○,1 Main switch
○,2 Indicator light
○,3 Display Screen
○,4 Set switch
○,5 Power switch
Turn Power On
Long press .
Change Memory
Shot press to change temperature memory from
T1 to T3.
Memory Parameter Setting
During standby state, holding down press more
than 2 seconds to enter memory parameter setting.
Parameter T1 to T3 can be set independently. Press
till target setting, press to adjust, then press
to confirm.
Heating
During standby state, shot press and the
indicator light flashes.
Stop heating
During heating state, shot press .
Pushing out Gutta-percha
When the heating is completed, the indicator light will
be on. Holding down press .
Turn Power Off
Long press more than 2 seconds.
Advanced setting
During power off state, holding down press
then press to enter advanced setting. Press

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 14 / 37
till target setting, press to adjust, then press
to confirm.

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 15 / 37
6.Setting
6.1 Memory Parameter Setting
Fast-Fill has 3 memory programs (T1,T2,T3),
press to change during standby state, the
memory number will change accordingly.
During any memory, holding down press in 2
seconds, the “Temperature” of this memory can be
changed.
Press till target temperature, the temperature
can be set from 100℃ to 200℃.
Press to confirm and enter next interface.
The “Push Speed” of this memory can be
changed.
Press till target speed, the speed can be set
Low, Mid, High.
Press to confirm and enter next interface.
The “Change GP” can be chosen.
Confirm the Gutta-percha need to change or not,
press to adjust.
If choose “No”, Press to confirm and return to
standby interface.
If choose “Yes”, see chapter 7.3 Changing Gutta-
percha for more information.

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 16 / 37
6.2 Advanced Setting
Auto PowerOf f
Min
5
During power off state, holding down press
then press to enter advanced setting, the
“AutoPowerOff” will appear on the display screen.
Press to adjust, the auto power off time can be
set to 5, 10 and 15 minutes.
Press to confirm and enter next interface.
Beep V olume
Vol 1
The “Beep Volume” can be changed. Press to
adjust. The “Beep Volume” can be set to 0, 1 and 2.
Press to confirm and enter next interface.
RestoreSettings
NO YES
The “RestoreSettings” can be changed. Press
to adjust, press to confirm and enter next
interface.
NOTE
If choose “YES”, all the setting parameters will be
covered by factory settings.
Save
NO YES
The “Save” can be chosen.
Confirm the setting need to save or not, press
to adjust, press to save and power off.

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 17 / 37
7.Operation
7.1 Charge
Display the present remaining amount of
the battery.
Less than 15% remains, please charge.
NOTE
If the power if less than 15%, the device
must be recharged within 30 days,
otherwise the battery will be damaged.
Alternative charging method
Charge without charge base is also
available, connect adapter to handpiece
directly, the charge state will show on the
screen.
Charge with charge base is
recommended (See chapter 4.4
Connecting charge base)
NOTE
Only the original adapter could be used.
Do not use the handpiece during the
charging.
Charging indication appears on the
screen, and flashes slowly, when battery
is fully charged or in a state near full
charge, the flash will stop. Fully charged
will take about 4 hours, depending on
residual battery power and battery state.
It can be recharged 300-500 times,
depending on the operating conditions of
the device.
WARNING
Do not change the battery, only trained
technician or distributor can change the
battery. The electronic parts will be

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 18 / 37
damaged if use a wrong battery or install
with a wrong way.
7.2 Heating and Using
Shot press to heat the cartridge during
standby state.
NOTE
Push out insufficiently warmed Gutta-percha
about 10mm before each use.
The LED flashes in blue slowly during heating.
When up to target temperature, the flash will
stop and stay in blue.
WARNING
If the handpiece is not operated for a long time
after the heating completed, press to stop
heating.
Do not place the heated cartridge in the root
canal for more than 5 seconds to prevent
thermal injury to the patient.

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 19 / 37
1
Heating indication, When the set
temperature is reached, heating process will
switch off and “ ”will display on screen.
2
Direction of pushing
3
Real time heating temperature
4
Gutta-percha residual
After heating completed, hold down press
to push out Gutta-percha. At the same time,
1
the light of direction flashes,
2
the
residual Gutta-percha bar will change
according. Press to exit and return to
standby interface.
NOTE
If there is a little residual Gutta-percha in handpiece or cartridge, tighten the
cartridge again to prevent leak Gutta-percha after heating.
If there is too much residual Gutta-percha in handpiece or cartridge, please refer
to daily cleaning process.
Please use good mobility Gutta-percha, otherwise the Gutta-percha will leak. If
leaking please refer to daily cleaning process.
7.3 Changing Gutta-percha
During standby state, holding down press
in 2 seconds to entry memory
parameter setting. Press till “Change
GP”. Press till “Yes” and press to
confirm.

Błąd! Użyj karty Narzędzia główne, aby zastosować 标题
1 do tekstu, który ma się tutaj pojawić. Błąd! Użyj karty Narzędzia główne, aby zas
tosować 标题 1 do tekstu, który ma się tutaj pojawić.
Page 20 / 37
Hea ting...
Firstly, the handpiece will heat to about
150℃ to melt the residual Gutta-percha.
Secondly, the pushrod pushes forward
until the Gutta-percha is exhausted. the
direction of push rod movement displays
on the screen.
Then, the direction and position of push
rod display on the screen. The push rod
needs returning to original position. This
operation needs about 50 seconds.
Finally, when the push rod is back to
original position, “Please insert GP” will
display on the screen. Press any key to exit
and return to standby interface.
NOTE
During this state, press can stop and return to standby interface.
After pushing the Gutta-percha bar into
handpiece with medical forceps, screw
down the cartridge.
NOTE
If there is some Gutta-percha in the
handpiece, it is inconvenient to install the
Gutta-percha bar. Push the residue to the
bottom of cavity with the pin on bending
tool.
