EKSA H1 User manual

User Manual
H1

1
Specifications
Size: 2.7 mm * 1.85 mm
Sensitivity: -25 ± 1 dB
Frequency Response: 100 Hz – 10 kHz
Impedance: 2.2 kΩ
Polar Pattern: Omnidirectional
Mic: EKSAtelecom VoicePure Technology
Music Time: ≈57 hours (70% volume)
Talk Time: ≈30 hours (70% volume)
Charging Time: ≈1.5 hours
Bluetooth Version: 5.0
Effective Wireless Range: 30 m / 99 ft
(Max 50 m / 164 ft without obstacles)
Speaker Diameter: 40 mm
Impedance: 32 Ω ± 15%
Sensitivity: 114 ± 3 dB
Frequency Response: 20 Hz – 20 kHz
Package Contents
EKSAtelecom H1 Wireless Headset
Type-C Charging Cable
Carry Pouch
User Manual 1 2 4
User Manual
H1
3
①
②
③
④
EN

Product Overview
2
3
4
1
5
6
8
9
7
Call Indicator
EKSAtelecom VoicePure Technology
Type-C Charging Port
Volume +
Bluetooth Indicator
Multi-Function Button (MFB)
Volume -
Mic Mute Button
Charging Indicator
2
7
6
4
8
3 9
5
2
1

3
Operation Guide
Multi-Function Button:
Volume Button:
Press for 3 seconds: Headphone on/off
Click: Play/Pause
Triple Click: Voice Assistant/Siri
Click: Volume + / -
Press for 2 seconds to
next/previous track
Click: Microphone on/off
Mic Mute Button:
x1
x3
3″
x1
2″
x1
Siri

4
x1
Call Functions
Answer
Reject
x2
Double Click
x1
Click
Press for 2 seconds
Click
Hang up
Amy
Redial:
Audio Switching:
Call Handling:
Redial your
last call
number
2″
Press for 2 seconds
2″
During a call, you can switch your audio device.
Amy

5
Call Functions
Three-Way Calling:
Amy
00:10
On the phone
New call Tom
Amy
x1
Click
x2
Double Click
2″
Answer a new
call and hang
up your
current call
Tom Amy Tom Amy TomAmy
Keep your
current call and
reject a new call
Tom Amy
Keep your
current call
Answer a
new call
Three-way calling mode
During a three-way call
Double Click
Switch between two calls
x2
Press for 2
seconds

6
Bluetooth Pairing
EKSA-H1
EKSA-H1EKSA-H1
1. Turn on EKSAtelecom H1,
until its Bluetooth indicator
flashes alternately between
red and blue, indicating that
the headset is in pairing
mode.
2. Turn on the Bluetooth of your device, activate the search feature, and
select “EKSA-H1”. After pairing, the Bluetooth indicator flashes slowly
in blue light with a voice prompt “your headset is connected”,
confirming a successful connection.
3. To connect to a new device, turn off the Bluetooth of the currently paired
device and follow the above steps to connect successfully to a new device.
Note:
1. Keep the distance between the EKSAtelecom H1 and your device within 1 meter.
2. If necessary, the pin code to complete pairing is “0000”.
3. While in pairing state, if a connection cannot be established within 10 minutes,
the headset will turn off automatically.
4. When the headset is turned on again, it will connect to the last connected device
automatically.
5. Compatibility issues may arise when connecting directly to a computer via
Bluetooth. Preferably with an adapter (not included).
device A device B
3″

7
Dual Pairing
EKSA-H1
OFF
device A
device A
device B device B
1. After successfully connecting the EKSAtelecom H1 to device A, turn off the
Bluetooth of device A. The headset’s Bluetooth indicator flashes in red and
blue alternately to signify pairing mode.
2. Turn on the Bluetooth of device B, activate search mode, and connect to
"EKSA-H1".
3. Turn on the Bluetooth of device A to connect with "EKSA-H1". This puts
both devices A and B in a simultaneous connection with "EKSA-H1".

8
Reset
When EKSAtelecom H1 is in connected/pairing mode, press and hold the
"volume +" and "volume -" buttons simultaneously for 6 seconds until the LED
lights up in red and blue, indicating the pairing information is cleared.
6″
The Bluetooth indicator flashes
alternately in red and blue.
1. When the battery is less than 10%, the headset will give a voice prompt
"battery low" every 3 minutes. Please charge it as soon as possible.
2. When EKSAtelecom H1 is not in use, please charge it at least once every
2 months.
3. Please use the original charging cable for charging. Charging voltage can't
exceed 5 V.
Charging
≤1.5h
5 V 1 A
Red
Blue
