Elba RH-601 X User manual

RH Series Range Hood
(RH-601 X / RH-602 X)
(RH-901 X / RH-902 X)
Installation Guide
Operation Manual

IMPORTANT REMINDERS
USE
This range hood has been designed for residential household use only.
Commercial usage for café’s, restaurants, and other similar establishments
will void the warranty of this product.
Never use the range hood for purposes other than extracting kitchen smoke
and odor.
Never leave high open flames under the hood when it is in operation.
This range hood is not a toy. Please keep children and other unauthorized
persons not instructed to use the hood away from the appliance.
INSTALLATION
The manufacturer will not be held liable for any damages resulting from
improper installation and/or misuse of the product.
Installation must be carried out by a qualified and authorized ELBA Service
Technician. Failure to do so can void the warranty of this product.
The minimum safety distance between the cooktop and the range hood is
650 millimeters (mm).
Check that the electrical supply from the outlet to which the unit is to be
plugged in is matching with the requirements of the hood, as indicated by
the product label on the range hood.
The exhaust pipe should have a minimum diameter of 120 millimeters (mm)
MAINTENTANCE
Switch off and unplug the appliance from the main power supply before
carrying out any maintenance work. (When disconnecting the appliance, do
not pull on the cord as it might cause a short circuit. Instead, hold the plug
and apply pressure on it when pulling from the wall socket.)
Clean the hood using a damp cloth and a neutral liquid detergent.
Clean and/or replace the filters after the specified time period.
There is risk of fire if cleaning is not carried out in accordance with the
guidelines and instructions as highlighted in the section “CLEANING AND
MAINTENANCE”.
LIABILITY
The Manufacturer will not be held liable for any damages incurred as a
result of the improper installation, usage, and maintenance of this product.

INSTALLATION
Important Notes:
The hood should be placed at a distance of
at least 65 cm from the cooking surface for
maximum performance.
The exhaust pipe should have a minimum
diameter of 120 millimeters (mm)
Ventilation Settings:
Recycling / Indoor Air Ventilation: Turn the adjuster to recycling position.
Install the cover on the air outlet on top of the hood. When turned on, the air
should be coming out from the top front of the hood. It is advisable to use a
charcoal filter to help minimize kitchen odor.
Ducting / Outdoor Air Ventilation: Turn the adjuster to the ducting position.
Attach a flexible aluminum hose or pvc pipe onto the air vent of the hood and
make sure that the passageway is sealed for maximum airflow. There are 2
methods for ventilation, including ' horizontal ventilation' and ' vertical
ventilation'. Please pay attention to the ventilation method during installation.
Horizontal ventilation: As pic. A shows, please use the cover to seal the
outlet on the top, then the air can be vented from back.
Vertical ventilation: As pic B shows, please use the cover to seal the outlet
on the back, then the air can be vented from top.

Installation Method A –Wall Mount
1. Center the unit in the area of installation and cut a hole with a diameter of
120mm for the exhaust pipe in a ducted installation.
(For recycling function installation, the 120mm hole is not required)
2. Drill four (4) holes in a sturdy place according to the center distance of
the mounting points at the back of the unit.
3. Insert a tox/nut into the drilled holes.
4. Insert screws into the tox/nuts in order to mount the hood onto the
desired location, tightening only until ¾ of the length of the screw.
5. Put up the range hood onto the fixed screws and tighten to make sure
the unit is secure before use.
Installation Method B –Cabinet Mount
1. Center the unit in the area of installation and cut a hole with a diameter of
120mm for the exhaust pipe for ducted installation.
(For recycling function installation, the 120mm hole is not required)
2. Drill four (4) holes at the bottom of the hanging cupboard based on the
mounting pattern as seen on the topside of the range hood.
3. Align the hood in the drilled holes and tighten the screws.
*Only use screws specified for wood applications.
4. Make sure the unit is safely secured before use.

OPERATION
Controls
The switch is operated as illustrated.
“ ”, press to turn off
“I”, press to activate speed setting 1
“II” press to activate speed setting 2
“III”, press to activate speed setting 3
“ ”, press to turn on, depress to turn off
CLEANING AND MAINTENANCE
Incandescent Bulbs
This unit comes equipped with
standard incandescent bulbs.
Instruction: To access the bulbs,
removal of the aluminum filters is
mandatory.
Changing the Light
Please make sure that the appliance is switched off during this step.
1. Remove the filters, press the clip located at the front, pull down the filters,
and release the clip.
2. To remove the bulbs, unscrew the bulbs in a counterclockwise direction.
3. Replace with a new bulb, twisting in the opposite direction to tighten.
Recommendation: Replace with a similar wattage bulb (40w Max.)
Do not install a higher wattage bulb as it may cause electrical problems.
Warranty Exemption: The incandescent bulbs are a consumable item and are
not covered by the warranty of this item.

Aluminum Filters
This unit comes equipped with removable
aluminum filters that are to be cleaned on a
regular basis in order to maintain the
performance and longevity of the hood.
Instruction: To remove the filters, press
the clip located at the front, pull down the
filters, and release the clip.
Cleaning the Filters
1. Prepare a large basin with 40-60 degrees Celsius of warm water and
add a mild detergent to mix with the water.
Note: DO NOT use any corrosive detergent when cleaning.
2. Soak the aluminum filters for two (2) to five (5) minutes in the basin to
loosen the buildup of oil and grease.
3. Use a soft brush with fine bristles to gently scrub the aluminum filters.
Apply moderate strength, so as not to damage the filter.
4. Allow the filter to air dry until it is completely free from any moisture.
Recommendation: Clean the filters at least once every month for regular
usage, or more frequently for heavy usage. Visually inspect the filter for trapped
oil and grease on a regular basis in order to maximize the performance of the
hood.
Warranty Exemption: The aluminum filters are a consumable item and are not
covered by the warranty of this item. Any defects caused by the negligence in
cleaning the filters will also void the warranty of the hood.
Cleaning the Body Casing
Do not use harsh / aggressive chemicals and rough sponges that can damage
the material finish of the range hood.
1. Use a soft damp cloth to wipe the body casing to remove dust particles.
2. After which, use a dry cloth wipe down any excessive moisture left by the
damp cloth.
3. You may use a dedicated stainless steel cleaner (for stainless steel
finishes) to finish off the cleaning process.
