1 ABOUT YOUR TESTER
The Elcometer 1620 Cupping Tester is a robust and simple-to-use instrument
for assessing the cupping capability of coatings applied onto metal sheets up to
1.2 mm (0.05”) thick.
The metal sheet is firmly clamped into a hardened steel die. Reduction gears
drive a 20 mm (0.79”) diameter ball (the punch) onto the underside of the metal
sheet, causing the sheet to cup. The coated surface of the metal sheet is
viewed and the drive mechanism is stopped when the coating begins to crack.
The amount of cupping is then read from a gauge mounted on the instrument.
1.1 Standards
The Elcometer 1620 can be used in accordance with the following National and
International Standards
• EN13523-6, supersedes ECCAT6
• ISO 1520, supersedes BS 3900-E4, DIN 53156, DIN 53232, NBN T22-104,
NF T30-019.
• JIS K 5600-5-2
1.2 What the box contains
• Elcometer 1620 Cupping Tester
• Gauge
• Gauge holder (for setting zero)
• Zero setting sheet
• Illuminated magnifying glass with clamp
• Operating instructions
T
1620_TMA_0320_00_05_19394.fm Page 2 Thursday, January 17, 2013 10:54 AM

3
R
en
The Elcometer 1620 Cupping Tester is packed in a cardboard and foam
package. Please ensure that this packaging is disposed of in an
environmentally sensitive manner. Consult your local Environmental Authority
for further guidance.
To maximise the benefits of your new Elcometer 1620 please take some
time to read these Operating Instructions. Do not hesitate to contact
Elcometer or your Elcometer supplier if you have any questions.
1620_TMA_0320_00_05_19394.fm Page 3 Thursday, January 17, 2013 10:54 AM

4
R
en
2 GETTING STARTED
2.1 The parts of your tester
Figure 1. Parts of the tester
2.2 Installation
Fasten the tester onto a rigid table. Four holes are provided in the mounting
flange for this purpose.
TOL.
SET
0.00
mm
ON
OFF
.
MODE DATA
Die
tightening
ring
Gauge
Die
chamber
Crank
Magnifying
Glass
1620_TMA_0320_00_05_19394.fm Page 4 Thursday, January 17, 2013 10:54 AM

5
R
en
2.3 Digital gauge
The Elcometer 1620 is fitted with a digital gauge.
To switch the gauge on, press the ON/OFF button. Press and hold to switch off.
After changing the battery the gauge will need to be zeroed. To zero the gauge,
see “Zeroing the gauge” on page 7. The battery is located under the battery
compartment cover; use a small screwdriver to remove the cover.
Figure 2. Battery Holder
3 TESTING A SPECIMEN
3.1 Procedure
1. Unscrew the die tightening ring until there is sufficient clearance between
the halves of the die as observed in the die chamber.
2. Ensure the top of the punch is below the top of the die, see Figure 4 on
page 7.
1620_TMA_0320_00_05_19394.fm Page 5 Thursday, January 17, 2013 10:54 AM

6
R
en
3. Place the sample to be tested in the die chamber and screw down the die
tightening ring until the sheet is clamped firmly (see Figure 3).
Figure 3. Metal sheet clamped in the die and ready for cupping test
4. Rotate the handle at a constant speed of 1 revolution per second to raise
the punch.
5. While the punch is moving upwards, use the illuminated magnifying glass to
observe the sample through the aperture in the top of the die tightening
ring.
As soon as cracks appear in the paint, stop the punch and record the
cupping reading on the gauge.
6. Rotate the handle to lower the punch below the level of the die.
7. Unscrew the die tightening ring and remove the sample.
1620_TMA_0320_00_05_19394.fm Page 6 Thursday, January 17, 2013 10:54 AM

7
R
en
4 ZEROING THE GAUGE
The tester is supplied from the Elcometer factory correctly set to zero and ready
to use. If the gauge is removed, reset or the battery changed it must then be set
to zero using the following procedure.
1. Unscrew the die tightening ring until there is sufficient clearance between
the halves of the die as observed in the die chamber.
2. Ensure the punch is below the level of the top of the die (see Figure 4).
Figure 4. Set punch below top of die
3. Place setting sheet in die chamber and screw down die tightening ring until
setting sheet is clamped firmly (see Figure 5).
Figure 5. Clamping the setting sheet
1620_TMA_0320_00_05_19394.fm Page 7 Thursday, January 17, 2013 10:54 AM

8
R
en
4. Remove the gauge from the tester
(unscrew the clamping screw), place
the gauge into the gauge holder and
tighten the retaining screw gently (see
Figure 6).
Figure 6.
5. Place the gauge and holder into the
aperture of the die tightening ring; the
gauge sensor should touch the setting
sheet (see Figure 7).
6. Switch on the gauge (press ON/OFF ).
Figure 7.
7. If ‘INC’ is displayed on the gauge it is in ‘relative’ mode and should be
changed to ‘absolute’ mode by pressing and holding SET until ‘INC’ is no
longer displayed.
SET
0.00
mm
ON
OFF
. MODE DAT A
SET
0.00
mm
ON
OFF
.
MODE DATA
1620_TMA_0320_00_05_19394.fm Page 8 Thursday, January 17, 2013 10:54 AM
