Thank you for your purchase of this Elcometer 501 Pencil Hardness Tester. Welcome to Elcometer.
Elcometer are world leaders in the design, manufacture and supply of inspection equipment for concrete
and coatings. Our concrete inspection products include a comprehensive range of concrete, and civil
engineering inspection equipment. Our coatings products cover all aspects of coating inspection, from
development through application to post application inspection.
This Elcometer 501 Pencil Hardness Tester is a world beating product. With the purchase of this product
you now have access to the worldwide service and support network of Elcometer. For more information visit
our website at www.elcometer.com
1 ABOUT YOUR GAUGE
The purpose of the Elcometer 501 Pencil Hardness Tester is to provide a rapid, inexpensive method for
determination of the comparative scratch resistance and hardness of a coating.
This test is known as the Wolff-Wilborn method. A coated panel is placed on a firm horizontal surface and the
pencil is held firmly against the coating, point away from the operator, at a 45°angle. The pencil is then pushed
away from the operator. The hardness of the pencils is increased until one or both of the following defects mark
the coating:
1. Plastic deformation; a permanent indentation in the paint surface without cohesive fracture.
2. Cohesive fracture; the presence of a visible scratch or rupture in the surface of the paint film, material
having been removed from the paint film.
The Elcometer 501 Pencil Hardness Tester is designed to use a standard wooden black lead pencil, and is
supplied with a full set of fourteen, covering 6H (very hard) to 6B (very soft).

R
3
1.1 WHAT THE BOX CONTAINS
• Elcometer 501 Pencil Hardness Tester
• Pencil Set (14 pencils, grades 6H – 6B)
• Setting Block
• Pencil Sharpener x 2
• Abrasive Paper Block
• Operating Instructions
• Carrying Case
The Elcometer 501 Pencil Hardness Tester is packed in a cardboard and foam package. Please ensure that
this packaging is disposed of in an environmentally sensitive manner. Consult your local Environmental
Authority for further guidance.
1.2 STANDARDS
The Elcometer 501 Pencil Hardness Tester can be used in accordance with the following National and
International Standards: ASTM D 3363, BS 3900-E19, EN 13523-4 supersedes ECCA T4, ISO 15184.
Note: For ASTM D 3363, the test is started using the hardest pencil and continued down the scale of hardness
to determine the two end points:
1. The pencil that will not cut or gouge the coating
2. The pencil that will not scratch the coating

R
4
2 TEST PROCEDURE
2.1 BEFORE YOU START
The test should be carried out at 23°C ± 2°C (73.5° F ± 3.5°F) and 50% ± 5% relative humidity, unless
otherwise agreed.
2.2 PREPARE THE PENCIL
1. Prepare the pencil using the special pencil sharpeners supplied.
Use sharpener T501190451 for pencils 6H, 5H, 4H, 3H, 2H, H, F, HB, B and 2B.
Use sharpener T501190452 for pencils 3B, 4B, 5B and 6B.
Sharpen until approximately 5 mm to 6 mm (0.25") of lead, is exposed taking care to leave the
exposed lead unmarked.
2. Hold the pencil at 90°to the abrasive paper and rub the lead until a flat, smooth and circular cross-
section is achieved. Ensure that the edge is free of chips or nicks (Figure 1).
Figure 1. Edge of lead must be free of chips or nicks
X

R
5
2.3 MOUNT PENCIL IN TESTER
Support the Pencil Tester on the setting
block (Figure 2). Fit the softest pencil,
6B, into the body of the tester, with the tip
of the pencil resting on the surface of the
paint film. Lock the pencil in place with
the thumbscrew and then remove the
setting block.
2.4 PREPARE THE SCRATCH
Place the test panel on a level, firm,
horizontal surface. Place the Pencil
Tester with the pencil facing away from
you and push the Tester a distance of
approximately 6 mm (0.25"). Apply the
push force to the back of the unit,
between the wheels, so as not to
contribute to the load on the pencil. The
speed of the Pencil Tester should be
between 0.5 mm/s to 1 mm/s.
2.5 INSPECT THE SCRATCH
Check the surface for scratches or gouges by either close visual inspection, by feel using a fingernail or, if
agreed, using a microscope with between x6 and x10 magnification.
Thumbscrew
Setting Block
Direction of
Motion
Figure 2. Using setting block to mount pencil in tester

R
6
2.6 CHANGE PENCIL HARDNESS
If no marking has occurred repeat the test (2.2 to 2.5) with the next hardest pencil.
Note: If using the ASTM D 3363 method and the lead has cut through or scratched the surface of the
coating, select the next softest pencil and repeat the test (2.2 to 2.5).
For ASTM D 3363 identify the end point of the test as follows:
• Gouge hardness – The hardest pencil that leaves the coating uncut over a stroke length of at least 3
mm.
• Scratch hardness – The hardest pencil that will not rupture or scratch the coating.
2.7 REPEAT THE TEST
The test procedure (2.2 to 2.6) should be repeated 12 mm (0.5") away from the first test.
When repeating the test, rotate the pencil to ensure that the edge of the lead in contact with the test panel
is not chipped or crumbled. If necessary the pencil should be prepared again (2.2).
If the two test results differ by more than one unit of pencil hardness, discard the results and repeat the test.

R
7
2.8 TEST REPORT
The following information should be contained in any report on the results of the Pencil Test:
• The type of defect resulting from the test; see “About your gauge” on page 2.
Note: In some cases the two test end points will be the same.
• The make and manufacture of the pencils used.
• Any deviation from standard conditions including the temperature and humidity conditions of the test
and the roughness of the coating surface.
• The magnification of the microscope, if one is used.
3 STORAGE AND TRANSIT
Store the instrument in its case when it is unused for long periods of time, and during transit.
4 MAINTENANCE
The Elcometer 501 Pencil Hardness Tester is designed to give many years reliable service under normal
operating and storage conditions. Special maintenance will not normally be required under these conditions.
An occasional wipe with a dry cloth will help to keep the instrument in good condition.
If dirt or any other contaminant is found on the wheels, it should be removed immediately.
The Hardness Tester does not contain any user-serviceable components. In the unlikely event of a fault,
the Elcometer 501 should be returned to your local Elcometer supplier or directly to Elcometer.

R
8
5 TECHNICAL SPECIFICATION
5.1 GAUGE
5.2 PENCIL SET SUPPLIED WITH NEW INSTRUMENTS.
5.3 CARRYING CASE
Overall Dimensions (without pencil fitted): 130 mm x 63 mm x 50 mm (5" x 2.5" x 2")
Overall Dimensions (with pencil fitted): 130 mm x 130 mm x 50 mm (5" x 5" x 2")
Material: Powder Coated Steel
Weight (tester and pencil): 2.1 kg (4 lb 10¼ oz)
Load Applied by Pencil: 750 g (7.36 N)
Pencil Type: Faber Castell 9000
Quantity: 14
Grades: 6H, 5H, 4H, 3H, 2H, H, F, HB, B, 2B, 3B, 4B, 5B, 6B
Material: Polypropylene foam-lined with cutouts to store 501 Pencil
Hardness Tester and Accessories
Dimensions: 300 mm x 220 mm x 75 mm (11.8" x 8.7" x 3")

R
9
6 SPARES
6.1 CONSUMABLE ITEMS
The following items are supplied with the Elcometer 501 Pencil Hardness Tester. Replacements are
available from your local Elcometer supplier or direct from Elcometer.
Description Sales Part No.
Replacement Pencil Set: T50115771
Individual grades of pencil in boxes of 12 See table below for Sales Part No.
Description Part Number Description Part Number
Hardness Pencils 6B KT003080P001 Hardness Pencils F KT003080P008
Hardness Pencils 5B KT003080P002 Hardness Pencils H KT003080P009
Hardness Pencils 4B KT003080P003 Hardness Pencils 2H KT003080P010
Hardness Pencils 3B KT003080P004 Hardness Pencils 3H KT003080P011
Hardness Pencils 2B KT003080P005 Hardness Pencils 4H KT003080P012
Hardness Pencils B KT003080P006 Hardness Pencils 5H KT003080P013
Hardness Pencils HB KT003080P007 Hardness Pencils 6H KT003080P014

R
10
6.2 REPLACEMENT ITEMS
The following items can be replaced if lost or damaged and can also be obtained your local Elcometer
supplier or direct from Elcometer.
7 RELATED EQUIPMENT
In addition to the 501 Pencil Hardness Tester, Elcometer produces a wide range of other Hardness Testing
Equipment. Users of the Elcometer 501 Pencil Hardness Tester may also benefit from the following
Elcometer product ranges:
• Elasticity and Resistance Deformation Testers
• Appearance Testers
• Washability, Brushability and Abrasion Testers
For further information contact Elcometer, your local Elcometer supplier or visit www.elcometer.com
Description Sales Part No.
Replacement Pencil Sharpener: T501190451 for pencils 6H to 2B
T501190452 for pencils 3B to 6B
Setting Block: T50119011
Sandpaper Block T50115779
