Tektronix TDS5000B Series Instruction sheet

TDS5000B Series
Digital Phosphor Oscilloscope
ZZZ
Read This First
xx
www.tektronix.com
*P061433105*
061-4331-05

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14200 SW Karl Braun Drive
P.O . Bo x 50 0
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.

Table of Contents
General Safety Summary .......................................................................................... 1
Compliance Information ........................................................................................... 2
EMC Compliance........................... ...... .......................... ...... .......................... ... 2
Safety Compliance.............................. ................................ ............................... 4
Environmental Considerations .................... ...... .......................... ...... ..................... 6
Preface .......... ...... .......................... ...... .......................... ...... .......................... ..... 7
Quick Start User Manual Information............................................................................ 8
Getting Started ............ ...... .......... ...... .......... ...... .......... ...... .......... ...... .......... ..... 8
Operating Requirements ......... .... .............. .... .......... .... .............. .... .......... .... ......... 8
PoweringOntheInstrument................................................................................. 10
Powering Off the Instrument .... .......................... ...... .......................... ...... ............ 10
Removing the Power ..... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... 11
Using Your Instrument ........... .... .......... .... .............. .... .......... .... .............. .... ........ 11
Standard Accessories ... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .. 11
Service Manual Information.. ...... .......................... ...... .......................... ...... .............. 12
Options... .. .......... .......... .. ........ .. .......... .......... .. ........ .. .......... .......... .. ........ .. .... 12
Side and Rear Panels ........... ...... .......................... ...... .......................... ...... ........ 12
Cleaning ....................................................................................................... 14
PC Interface Board and Motherboard Cable Connections ....................... ...... .................. 15
039-0185-xx Service Information......... .. ..... ..... .. ........ .. ........ .. ..... ..... .. ........ .. ........ .. 17
Replaceable Parts ..... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... .... 28
Specification and Performance Verification .................................................................... 31
TDS5000B Read This First i

Table of Contents
ii TDS5000B Read This First

General Safety Summary
Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
To Avoid Fire or Personal
Injury
Use Proper Power Cord. Use only the power cord specified for this product and
certified for the country of use.
Connect and Disconnect Properly. Do not connect or disconnect probes or test
leads while they are connected to a voltage source.
Ground the Product. This product is grounded through the grounding conductor
of the power cord. To avoid electric shock, the grounding conductor must be
connected to earth ground. Before making connections to the input or output
terminals of the product, ensure that the product is properly grounded.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
The inputs are not rated for connection to mains or Category II, III, or IV circuits.
Connect the probe reference lead to earth ground only.
Do Not Operate Without Covers. Do not operate this product with covers or
panels removed.
Avoid Exposed Circuitry. Do not touch exposed connections and components
when power is present.
Do Not Operate With Suspected Failures. If you suspect that there is damage to
this product, have it inspected by qualified service personnel.
Do Not Operate in Wet/Damp Conditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.
Provide Proper Ventilation. Refer to the manual’s installation instructions for
details on installing the product so it has proper ventilation.
Terms in this Manual These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
TDS5000B Read This First 1

Compliance Information
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
Symbols and Terms on the
Product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read
the marking.
WARNING indicates an injury hazard not immediately accessible as you
read the marking.
CAUTION indicates a hazard to property including the product.
The following symbol(s) may appear on the product:
Compliance Information
This section lists the EMC (electromagnetic compliance), safety, and
environmental standards with which the instrument complies. This EMC section
replaces the Certifications and Compliances section in Table 1–11, of the
TDS5000B Series Technical Reference manual (071-1420-xx).
EMC Compliance
EC Declaration of
Conformity – EMC
Meets intent of Directive 2004/108/EC for Electromagnetic Compatibility.
Compliance was demonstrated to the following specifications as listed in the
Official Journal of the European Communities:
EN 61326-1:2006, EN 61326-2-1:2006. EMC requirements for electrical equipment
for measurement, control, and laboratory use. 1234
CISPR 11:2003. Radiated and conducted emissions, Group 1, Class A
IEC 61000-4-2:2001. Electrostatic discharge immunity
IEC 61000-4-3:2002. RF electromagnetic field immunity 5
IEC 61000-4-4:2004. Electrical fast transient/burst immunity
IEC 61000-4-5:2001. Power line surge immunity
IEC 61000-4-6:2003. Conducted RF immunity 5
IEC 61000-4-11:2004. Voltage dips and interruptions immunity 6
2TDS5000B Read This First

Compliance Information
EN 61000-3-2:2006. AC power line harmonic emissions
EN 61000-3-3:1995. Voltage changes, fluctuations, and flicker
European Contact.
Tektronix UK, Ltd.
Western Peninsula
Western Road
Bracknell, RG12 1RF
United Kingdom
1This product is intended for use in nonresidential areas only. Use in residential areas may cause electromagnetic
interference.
2Emissions which exceed the levels required by this standard may occur when this equipment is connected to a
test object.
3To ensure compl iance wit h the EMC standards listed here, high quality shie lded inte rface cab les should be us ed.
4Instrument rebooting may be experienced where the EUT takes longer than 10 seconds to recover from IEC
61000-4-11 transient immunity test.
5Under these conditions, the specifications are amended as follows: 1 mV/division to 1 V/division: < 0.2 division
waveform displacement or < 0.4 division increase in peak -to peak noise for (IEC 61000-4-3 and IEC 61000-4-6
tests)
6Performance Criterion C applied at the 70%/25 cycle Voltage-Dip and the 0%/250 cycle Voltage-Interruption test
levels (IEC 61000-4-11).
Australia / New Zealand
Declaration of
Conformity – EMC
Complies with the EMC provision of the Radiocommunications Act per the
following standard, in accordance with ACMA:
CISPR 11:2003. Radiated and Conducted Emissions, Group 1, Class A, in
accordance with EN 61326-1:2006 and EN 61326-2-1:2006.
TDS5000B Read This First 3

Compliance Information
Safety Compliance
EC Declaration of
Conformity – Low Voltage
Compliance was demonstrated to the following specification as listed in the
Official Journal of the European Communities:
Low Voltage Directive 2006/95/EC.
EN 61010-1: 2001. Safety requirements for electrical equipment for
measurement control and laboratory use.
U.S. Nationally Recognized
Testing Laboratory Listing
UL 61010B-1. Standard for electrical measuring and test equipment.
Canadian Certification CAN/CSA-C22.2 No. 61010.1-97. Safety requirements for electrical
equipment for measurement, control, and laboratory use. Part 1.
Additional Compliances IEC 61010-1: 2001. Safety requirements for electrical equipment for
measurement, control, and laboratory use.
Equipment Type Test and measuring equipment.
Safety Class Class 1 – grounded product.
Pollution Degree
Description
A measure of the contaminants that could occur in the environment around
and within a product. Typically the internal environment inside a product is
considered to be the same as the external. Products should be used only in the
environment for which they are rated.
Pollution Degree 2. Normally only dry, nonconductive pollution occurs.
Occasionally a temporary conductivity that is caused by condensation must
be expected. This location is a typical office/home environment. Temporary
condensation occurs only when the product is out of service.
Pollution Degree Pollution Degree 2 (as defined in IEC 61010-1). Note: Rated for indoor use only.
4TDS5000B Read This First

Compliance Information
Installation (Overvoltage)
Category Descriptions
Terminals on this product may have different installation (overvoltage) category
designations. The installation categories are:
Measurement Category IV. For measurements performed at the source of
low-voltage installation.
Measurement Category III. For measurements performed in the building
installation.
Measurement Category II. For measurements performed on circuits directly
connected to the low-voltage installation.
Measurement Category I. For measurements performed on circuits not
directly connected to MAINS.
Overvoltage Category Overvoltage Category II (as defined in IEC 61010-1)
TDS5000B Read This First 5

Compliance Information
Environmental Considerations
This section provides information about the environmental impact of the product.
Product End-of-Life
Handling
Observe the following guidelines when recycling an instrument or component:
Equipment Recycling. Production of this equipment required the extraction and
use of natural resources. The equipment may contain substances that could be
harmful to the environment or human health if improperly handled at the product’s
end of life. In order to avoid release of such substances into the environment and
to reduce the use of natural resources, we encourage you to recycle this product
in an appropriate system that will ensure that most of the materials are reused or
recycled appropriately.
This symbol indicates that this product complies with the applicable European
Union requirements according to Directives 2002/96/EC and 2006/66/EC
on waste electrical and electronic equipment (WEEE) and batteries. For
information about recycling options, check the Support/Service section of the
Tektronix Web site (www.tektronix.com).
MercuryNotification. This product uses an LCD backlight lamp that contains
mercury. Disposal may be regulated due to environmental considerations. Please
contact your local authorities or, within the United States, refer to the E-cycling
Central Web page (www.eiae.org) for disposal or recycling information.
Perchlorate Materials. This product contains one or more type CR lithium
batteries. According to the state of California, CR lithium batteries are
classified as perchlorate materials and require special handling. See
www.dtsc.ca.gov/hazardouswaste/perchlorate for additional information.
Restriction of Hazardous
Substances
This product has been classified as Monitoring and Control equipment, and is
outside the scope of the 2002/95/EC RoHS Directive.
6TDS5000B Read This First

Preface
Preface
The following information affects the TDS5000B Series Quick Start User manual
and the TDS5000B Series Service manual.
TDS5000B Read This First 7

Quick Start User Manual Information
Quick Start User Manual Information
Getting Started
Use the following information to replace or clarify information contained in your
instrument quick start user manual documentation.
Operating Requirements
Place the bottom feet of the instrument on a cart or bench and observe the
following clearance requirements:
Top, Rear, Front, and Right Side: 0 in (0 mm)
Left Side: 3 in (76 mm)
Bottom: 0.75 in (19 mm) minimum or 0 in (0 mm) standing on feet, flip
stand down
CAUTION. To ensure proper cooling, keep the bottom and sides of the instrument
clear of obstructions.
8TDS5000B Read This First

Quick Start User Manual Information
Environmental Requirements
Characteristic Description
Humidity, operating 20% to 80% relative humidity with a maximum
wet bulb temperature of +29 °C (+84.2 °F) at
or below +45 °C (+113 °F) noncondensing.
Upper limit derated to 30% relative humidity
at +45 °C (+113 °F)
Altitude, operating 9,842 ft. (3,000 m)
Temperature, ambient operating +5 °C to +45 °C (+41 °F to +113 °F)
Maximum voltage
1MΩinput impedance 150 VRMS CAT I, and ≤400 peak
For steady-state sinusoidal waveforms,
derate at 20 dB/decade above 200 kHz to
9VRMSat≥3MHz
50 Ωinput impedance <1 Vrms for settings below 100 mV/div
<5 Vrms for 100 mV/div settings and above
TDS5000B Read This First 9

Quick Start User Manual Information
Powering On the Instrument
Power Supply Requirements
Source voltage and frequency Power consumption
100-240 VRMS ±10%, 47-63 Hz, or
115 VRMS ±10%, 360-440 Hz
<220 watts
WARNING. To avoid fire or shock hazard that could result in injury or loss of life,
observe all ratings and markings on the product. Consult the product manual for
further ratings information before making connections to the product.
Powering Off the Instrument
10 TDS5000B Read This First

Quick Start User Manual Information
Removing the Power
Using Your Instrument
Documentation for your instrument is found by selecting Help >
Documentation....
Before using your instrument, read the following information in the quick start
user manual:
Safety Summary
Creating an Emergency Startup Disk
Getting Acquainted with Your Instrument
Standard Accessories
The standard accessories list in the TDS5000B Series Quick Start User manual
(071-1355-XX) has been upgraded to include the following discs:
TDS5000B Series Operating System Restore disc (SN B040000 and above)
063-4160-xx.
TDS5000B Series Operating System Restore disc (SN B030000 to B039999)
063-3985-xx.
TDS5000B Series Operating System Restore disc (SN B020000 to SN
B029999) 063-3759-xx
TDS5000B Series Operating System Restore disc (SN B010100 to SN
B019999) 063-3693-xx
NOTE. Only serial numbers below B060100 include a floppy disc.
TDS5000B Read This First 11

Service Manual Information
Service Manual Information
Use the following information to replace or clarify information contained in
your TDS5000B Series Digital Phosphor Oscilloscopes (071-1362-XX) service
manual. This service manual is on the Tektronix Web site.
Options
The TDS5054B and TDS5104B instruments have been upgraded to include the
following options: Option 18 (Touch Screen) and Option 3M (16 M points record
length).
Side and Rear Panels
The following side-panel illustrations (in the Theory of Operation section) have
been upgraded to include the latest component locations and are for reference
only. Use the instructions in the TDS5000B Series Quick Start User manual
(071-1355-XX) to connect your instrument.
12 TDS5000B Read This First

Service Manual Information
TDS5000B Read This First 13

Service Manual Information
Cleaning
Use these procedures to clean your oscilloscope. If additional cleaning is required
have your oscilloscope serviced by qualified service personnel.
Exterior Cleaning Clean the exterior surfaces of the chassis with a dry lint-free cloth or a soft-bristle
brush. If any dirt remains, use a cloth or swab dipped in a 75% isopropyl alcohol
solution. Use a swab to clean narrow spaces around controls and connectors.
Do not use abrasive compounds on any part of the chassis that may damage the
chassis.
Clean the On/Standby switch using a dampened cleaning towel. Do not spray or
wet the switch directly.
CAUTION. Do not use chemical cleaning agents that might damage the plastics
used in this oscilloscope. Use only deionized water when cleaning the front-panel
buttons. Use a 75% isopropyl alcohol solution as a cleaner and rinse with
deionized water. Before using any other type of cleaner, contact your Tektronix
Service Center or representative.
Clean the flat panel display surface by gently rubbing the display with a
clean-room wipe (such as Wypall Medium Duty Wipes, #05701, available from
Kimberly-Clark Corporation).
14 TDS5000B Read This First

Service Manual Information
PC Interface Board and Motherboard Cable Connections
Replace Figures 6-17 and 6–18 in the Removal and Installation Procedures).
Figure 6-17: PC Interface board and motherboard cable connections
TDS5000B Read This First 15

Service Manual Information
Figure 6-18: Desktop hard drive removal
16 TDS5000B Read This First
