Eldat EasyWave RCP04 User manual

C , if you would
like to select another ring tone or change the
ring tone length.
2. Select the desired ring tone by repeated
pressing of the PROG button .
You can change the ring tone length after the
ring tone melody is finished. To do this press
the PROG button, until the desired ring tone
length is reached.
3. Now press the transmission button, for which
you want to use these settings. The device will
confirm that the transmission code has been
programmed successfully by playing an
acknowledgement signal and a brief flashing
of the programming and loudspeaker button.
Once completed, the device will automatically
switch back to operation mode.
Repeat step 1 to 3 to program additional
transmission codes.
Note: In case no transmission code is confirmed
within a period of 30 seconds during program-
ming, the radio bell will automatically switch back
to operation mode.
Any programming operation can be canceled by
pressing the loudspeaker button.
In case an additional transmission code is
received and all 32 memory positions have been
used up a warning signal will play for about four
seconds . No additional transmission code will be
programmed. The device will switch back to
operation mode.
ontinue with step 2 and step 3
GB
Wall outlet
Loudspeaker
Loudspeaker
button
Programming button
Flashlight
GB F/B (PL)
D(A/NL/S/N) CH
Plug-In Radio Bell RCP04
Safety Advice
Models Intended Use
Function
Select/Change Ring Tone and
Ring Tone Length
Start Up
Package Content
RCP04-5001E-01 868.30 MHz D
RCP04-5001E-02 868.30 MHz GB
RCP04-5001E-04 868.30 MHz F/B
RCP04-5001E-05 868.30 MHz CH
The device may only be operated indoors and
only as a radio bell and as wall outlet for mains
consumer load or low voltage consumer load.
The manufacturer will not be liable for damage
caused by improper or inappropriate use.
You can specify a ring tone melody and ring tone
lenght for each transmitter button. Select the
desired settings on the radio bell and confirm by
learning the transmission code (step 1 to step 3).
Please note that subsequent changing of the ring
tone and the ring tone lenght for transmission
codes already learned is not possible. The
transmission code for which you would like to
change the settings, must be deleted (see section
“Delete transmission code") and memorized
again with new settings.
1. Press the programming button of the radio bell
(approx. 5 seconds). The programming button
will flash slowly and the device will play an
acknowledgement signal.
Memorize the transmission code now, if you
want to use the radio bell with factory settings
(see step 3).
The Plug-In Radio Bell RCP04 receives Easy-
wave transmission codes from programmed hand
transmitters or wall transmitters. Once the
transmission button is pressed, a ring tone will
play and/or a light will begin to flash.
The wall outlet of the radio bell can be used as a
mains output socket for any electric device.
(230 V AC /50 Hz, bis 16 A)
A total of 32 transmission codes can be
programmed into the unit. A specific ring tone and
ring tone length can be allocated to each
transmission code.
Three different melodies are available as ring
tones: Westminster, March, Ringing Bell
The ring tone length can be set at a maximum
of 60 seconds, which is defined by the number
of repititions of the melody.
Five different combinations of gong volumes
and flashing lights can be selected:
- Quiet and flashing light
- Loud and flashing light,
- Muted (only flashing light),
- Quiet without flashing light,
- Loud without flashing light.
From the factory, the radio bell is set to the march
melody and at the volume “quiet / flashing light".
1. Plug the radio bell into any wall outlet, you can
hear an acknowledgement signal.
2. A transmission code is assigned to each
button of the radio transmitter. Transmit the
trasmission codes of the transmitter to the
radio bell (see section “Ring tone and ring tone
length select/change“).
Caution: Make sure that there is no interference
with the wireless connection. Do not mount the
device in a distribution box, metal casings or in
direct proximity to large metal objects.
Wall outlet radio gong RCP04,
operating instructions
Please read these instructions
carefully before using the device!
We do not accept any liability for personal injury
or damage to property caused by incorrect
handling or non-observance of the safety
instructions!
Observe the valid laws and regulations as well
as the manufacturer's instructions
Attention! Observe the admissible supply
voltage and the maximum contact load of the
wall outlet (16A, 230 VAC / 50 Hz)!
Have malfunctioning devices checked by the
manufacturers!
Do not open the appliance's casing!
for the
devices to be operated!
Do not make any unauthorized alterations or
modifications to the unit!
PROG
Plug systems
PROG
select ring tone
transfer factory setting:
or
select ring tone length
press the
PROG-button
repeatedly, until
desiredring tone
is played.
keep PROG-
button pressed for
the desired length
of the ring tone.
> 5 s
press send buton
Westminster
March
Ringing Bell
PROG
PROG

81308 0708 GB
1. Keep the PROG button pressed for approx
5 seconds. The PROG button will flash slowly
and you will hear an acknowledgement signal.
2. Press the PROG and mode button at the same
time. You will hear an intermittent signal tone
and both buttons will flash quickly.
3. Press the transmission button of the trans-
mission code you would like to delete until a
brief acknowledgement signal is played and
both buttons light up. The transmission code
has been deleted and the device will auto-
matically switch back to operational mode.
Attention! With a RESET all memorized
transmission codes as well as all relevant settings
are deleted and factory settings are activated.
1. Press the programming button of teh radio bell
(approx. 5 seconds). The programming button
will flash slowly and the device will play an
acknowledgement signal.
2. Press the PROG and mode button at the same
time. You will hear an intermittent signal tone
and both buttons will flash quickly.
3. Press the PROG and loudspeaker button until
a brief acknowledgement signal is played and
both buttons light up. and the radio gong will
switch back to its default settings.
Delete Transmission Code
Reset to Default Settings
> 5 s
approx.1,6 s
> 5 s
> 1,6 s
> 1,6 s
1. Briefly (< 1.6 seconds)press the mode button.
The programmed ring tone will play.
2. Press the loudspeaker button several times
while the ring tone is being played. The device
will switch to the next volume / flashlight
option.
If you do not press the loudspeaker button,
this setting will be accepted after ring tone
melody has stopped playing.
Changing Ring Tone Volume /
Switching Flashlight On and Off
Disposal
Conformity
Customer Service
Put the packaging material into the
recycling bins for cardboard, paper and
plastics.
Dispose of the waste product via a collec-
tion point for electronic scrap or via your
specialist dealer.
Waste electrical products should not be
disposed of with household waste!
The product fulfils the essential require-
ments of the R&TTE directive
1999/5/EG.
Warranty
We will remedy defects on the device based on
material or production errors within the statutory
warranty period or exchange the device.
Any unauthorized tampering with, or modifica-
tions to, the product shall render this warranty null
and void.
For application in: EU/CH/FL/IS/N
The Declaration of Conformity can be found on
the internet at: www.eldat.de
General Information
If the device does not work properly despite
proper handing or in case of damage, please
contact your retailer or the following adress:
ELDAT GmbH
Im Gewerbepark 14
15711 Zeesen
Germany
Phone: + 49 (0) 33 75 / 90 37-0
Fax: + 49 (0) 33 75 / 90 37-90
Internet: www.eldat.de
E-Mail: [email protected]
Frequency: 868.30 MHz
Modulation: FSK
Radio channels: 1
Range: Outdoor: approx. 100 m,
Indoor: approx. 30 m
Opperating voltage: 230 V AC / 50 Hz
Power consumption: max. 7 mA
Protective class: II
Protective type: IP 20
Operating
temperature: -20°C to +60°C
Max. relative air
humidity: 60%
Mains output: Power plug
non switchable
Max. contact load: 16 A / 230 V AC
Dimensions
(HxWxD) 122 x 50 x 38,3 mm
Weight: approx. 190 g
Technical Details
Loud +
flashing
light
Mute
Quiet
(no flashing
light)
Loud (no
flashing
light)
Quiet +
flashing
light
< 1,6 s
Press the
loadspeaker
button until the
desired
combination is
played..
PROGPROG
To cancel press the loudspeaker button
To cancel press the loudspeaker button
PROGPROG
PROG
PROG PROG
