Electrolux EPM09CRC-A1 User manual

EN AIR CONDITIONER USER MANUAL 2
EPM09CRC-A1
EPM12CRC-A1

2www.electrolux.com
WE’RE THINKING OF YOU
CUSTOMER CARE AND SERVICE
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with
it decades of professional experience and innovation. Ingenious and stylish, it has been
designed with you in mind. So whenever you use it, you can be safe in the knowledge that
you’ll get great results every time.
Welcome to Electrolux.
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Subject to change without notice.
Warning / Caution-Safety information.
General information and tips.
Environmental information.
Australia:
www.electrolux.com.au
New Zealand:
www.electrolux.co.nz
Visit our website to:
CONTENTS
1. SAFETY INFORMATION ������������������������������������������������������������������������������������� 3
2. SAFETY INSTRUCTION ������������������������������������������������������������������������������������� 8
3. UNIT DESCRIPTION ����������������������������������������������������������������������������������� 11
4. ACCESSORIES INCLUDED ��������������������������������������������������������������������� 11
5. INSTALLATION INSTRUCTIONS ��������������������������������������������������������������������� 12
6. AIR CONDITIONER FEATURES ��������������������������������������������������������������������� 15
7. OPERATING INSTRUCTIONS ��������������������������������������������������������������������� 15
8. CARE & CLEANING ������������������������������������������������������������������������������������������� 21
9. TROUBLE SHOOTING ����������������������������������������������������������������������������������� 22
10. ENVIRONMENTAL CONCERNS ��������������������������������������������������������������������� 23
11. WARRANTY �������������������������������������������������������������������������������������������������� 24

3ENGLISH
1. SAFETY INFORMATION
WARNING!
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety�
Children should be supervised to ensure that they do not play
with the appliance�
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons in
order to avoid a hazard�
This manual explains the proper use of your new air
conditioner� Please read this manual carefully before using the
product� This manual should be kept in a safe place for handy
reference�
Symbol Note Explanation
WARNING
CAUTION
CAUTION
CAUTION
This symbol shows that this appliance uses a
ammable refrigerant. If the refrigerant is leaked
and exposed to an external ignition source, there is
a risk of re.
This symbol shows that the operation manual
should be read carefully.
This symbol shows that a service personnel should
be handling this equipment with reference to the
installation manual.
This symbol shows that information is available such
as the operating manual or installation manual.
CAUTION!
• Contact authorised service technician for repair or
maintenance of this unit�
• The air conditioner is not intended for use by young children
of inrmed persons without supervision�
• Young children should be supervised to ensure that they do
not play with the air conditioner�

4www.electrolux.com
1.2 Warnings
CAUTION!
Warnings for use
• Do not modify any part of this product�
• Do not insert anything into any part of the unit�
• Ensure the power supply used has an appropriate voltage
rating� Only use a 220 - 240V, 50Hz, 10A mains electricity
supply� Use of a power supply with an improper voltage rating
can result in damage to the unit and possibly re�
• Always use a anti-explosive circuit breaker or fuse with the
proper amp rating� Do not, under any circumstances, use
wire, pins or other objects in place of a proper fuse�
1.1 Important notes
1� Do not operate unit without the air lter�
2� Do not operate unit near any heat source or open re�
3� Do not expose the unit outside to direct sunlight and rain�
4� Always store or move the unit in an upright position�
5� Do not cover the appliance when in operation or
immediately after use�
6� Always drain condensation before storing unit�
7� The appliance shall not be installed in the laundry�
• There are local council rules regarding maximum allowable
noise levels emitted by air conditioners�
• If the power cord is to be replaced, replacement work shall
be performed by authorised personnel only�
• Installation work must be performed in accordance with the
national wiring standards by authorised personnel only(if
applicable)� Incorrect connection can cause overheating and
re�
• Take care not to catch ngers on fan when adjusting
horizontal louvres�
• The fuse in the main board is 250V 3�15A�
• Cleaning and user maintenance shall not be made by children
without supervision� Be aware that refrigerants may not
contain an odour�

5ENGLISH
CAUTION!
Warning - Power cord
• This power plug must only be plugged into an appropriate
wall socket� Do not use in conjunction with any extension
cords�
• Push the power plug securely into the socket and make sure
it is not loose�
• Do not pull, deform, or modify the power supply cord, or
immerse it in water� Pulling or misuse of the power supply
cord can result in damage to the unit and cause electrical
shock�
• If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualied
person in order to avoid a hazard� Use only the manufacturer
specied power cord for replacement�
• This appliance must be earthed� This appliance is equipped
with a cord having an earth wire� The plug must be plugged
into an outlet that is properly installed and earthed� Do not
under any circumstances cut or remove the earthed pin from
this plug�
• In the event of any abnormality with the air conditioner (eg�
a burning smell), do not pull out the plug directly, open
the window for ventilation rstly, then turn the unit off and
disconnect the power supply�
Plug
Earthed pin

6www.electrolux.com
1.3 Usage cautions
• Be sure to turn the unit off and disconnect the power supply
cord before performing any maintenance or cleaning�
• Do not put unit near any heat source or open re when you
replacing the lters�
• Do not splash or pour water directly onto the unit� Water can
cause electrical shock or equipment damage�
• Drainage should be performed whenever moving the air
conditioner� If any water remains in the tank, it may spill out
while being moved�
• To ensure proper drainage, the drainage hose must have
no kinks and must not be elevated during dehumidicatioin
mode� If not, the drained water may spill out into the room�
• The temperature around the drainage hose must not be
below freezing point when used� Drained water may freeze
inside the hose, causing water inside the unit to overow into
the room�
• Do not block the exhaust air outlet with obstacles� Cooling
performance may be reduced or stop completely�
• Provide a anti-explosive residual current device (RCD) in
order to protect against electric shock in accordance with
Australian Standard and Wiring Rules�
• Exposure to direct airow for an extended period of time
could be hazardous to your health� Do not expose occupants,
pets, or plants to direct airow for extended periods of time�
• Do not use this air conditioner for non-specied special
purposes (e�g� preserving precision devices, food, pets,
plants, and art objects)� Usage in such a manner could harm
such property�
• Do not use means to accelerate the defrosting process or to
clean, other than those recommended by the manufacturer�
• The appliance shall be stored in a room without continuously
operating ignition sources (for example: open ames, an
operating gas appliance or an operating electric heater)�
• Do not pierce or burn�
• Compliance with national gas regulations shall be observed�
• Keep ventilation openings clear of obstruction�
• The appliance shall be stored in a well-ventilated area where
the room size larger than 12 m2�

7ENGLISH
WARNING!
• Thoroughly read all of the warnings�
• When defrosting and cleaning the appliance, do not use any
tools other than those recommended by the manufacturer�
• The appliance must be placed in an area without any
continuous sources of ignition (for example: open ames, gas
or electrical appliances in operation)�
• Do not puncture and do not burn�
• Refrigerant gases can be odourless�
• The appliance must be installed, used and stored in an area
that is greater than 12 m2�
• This appliance contains R290 refrigerant gas� See rating label
on side of unit for details�
• R290 is a refrigerant gas that complies with the European
directives on the environment� Do not puncture any part of
the refrigerant circuit�
• If the appliance is installed, operated or stored in a
nonventilated area, the room must be designed to prevent the
accumulation of refrigerant leaks resulting in a risk of re or
explosion due to ignition of the refrigerant caused by electric
heaters, stoves, or other sources of ignition�
• The appliance must be stored in such a way as to prevent
mechanical failure�
• Individuals who operate or work on the refrigerant circuit must
have the appropriate certication issued by an accredited
organisation that ensures competence in handling refrigerants
according to a specic evaluation recognized by associations
in the industry�
• Repairs must be performed based on the recommendations
from the manufacturing company� Maintenance and repairs
that require the assistance of other qualied personnel must
be performed under the supervision of an individual specied
in the use of ammable refrigerants�
PLEASE NOTE: CHECK THE PLATE FOR THE TYPE OF
REFRIGERANT GAS USED IN YOUR APPLIANCE�
Specic information regarding appliances with R290
refrigerant gas�

8www.electrolux.com
2. SAFETY INSTRUCTION
2.1 Notes on Operation
• Allow 4 minutes for the compressor
to restart cooling� If you turn the air
conditioner off and immediately restart
it, allow 4 minutes for the compressor
to restart cooling� There is an electronic
device in the unit that keeps the
compressor turned off for 4 minutes for
safety�
• In the event of a power failure during
use, allow 4 minutes before restarting
the unit� After power is reinstated,
restart the air conditioner� If the power
was off for less than four minutes,
be sure to wait at least four minutes
before restarting the unit� if you restart
the air conditioner within four minutes,
a protective device in the unit may
cause the compressor to shut off� This
protective device will prevent cooling for
about 5 minutes� Any previous setting
will be cancelled and the unit will return
to its initial setting�
• When you turn the unit off in cooling
mode, the compressor will shut off
immediately and the upper/under fan
motor will stop running after 5 seconds;
if operate the unit to fan mode from
cooling mode, the compressor will shut
off immediately and the under fan motor
will stop running after 5 seconds; and if
operate the unit to heating mode from
cooling mode, the compressor will shut
off immediately and the under fan motor
will stop running after 30 seconds�
• Low temperature operation: Is your
unit freezing up? Freezing may occur
2.2 Warning during usage
To prevent injury to the user or other
people and property damage, the following
instructions must be followed�
Incorrect operation due to ignoring
instructions may cause harm or damage�
The seriousness is classied by the
following indications:
This symbol indicates the possibility
of death or serious injury�
Warning during usage
This symbol indicates the possibility
of injury or damage to property�
WARNING!
WARNING!
CAUTION!
Meanings of symbols used in this manual
are shown below:
This symbol indicates never to do
this�
This symbol indicates always do
this�
when the unit is set close to 18°C in
low ambient temperature conditions,
especially at night� In these conditions, a
further temperature drop may cause the
unit to freeze� Setting the unit to a higher
temperature will prevent it from freezing�
• Dehumidication mode increases room
temperature� The unit generates heat
during dehumidication mode and the
room temperature will rise� Warm air will
be blown out from the exhaust air outlet,
but this is normal and does not indicate
a problem with the unit�
• This air conditioner blows the warm air
generated by the unit outside the room
via the exhaust hose while in cool mode�
In the mean time, the same amount
of air will enter the room from outside
through any openings of the room�
• Any person who is involved with
working on or breaking into a refrigerant
circuit should hold a current valid
certicate from an industry-accredited
assessment authority, which authorises
their competence to handle refrigerants
safely in accordance with an industry
recognised assessment specication�
• Servicing shall only be performed
as recommended by the equipment
manufacturer� Maintenance and repair
requiring the assistance of other skilled
personnel shall be carried out under the
supervision of the person competent in
the use of ammable refrigerants�
• The working temperature range of the
air conditioner is 5-43oC (41-109oF)�

9ENGLISH
warning meaning
Plug in power plug properly
Otherwise, it may cause electric shock, re
and explosion due to excess heat generation
Do not operate or stop the unit by inserting
or pulling out the power plug
It may cause electric shock, re and
explosion
due to heat generation
Do not use a damaged or unspecied
power cord
It may cause electric shock, re and
explosion
� If the power cord is damaged, it
must be replaced by the manufacturer or
an authorised service centre or a similarly
qualied person in order to avoid a hazard
Do not modify power cord length or share
the outlet with other appliances
It may cause electric shock, re and
explosion
due to heat generation
Do not operate with wet hands or in damp
environment
It may cause electric shock
Do not allow water to run into electric
parts
It may cause failure of unit or electric
shock
Always install circuit breaker and a
dedicated power circuit
Incorrect installation may cause electric
shock, re and explosion
Unplug the unit if strange sounds, smell, or
smoke comes from it
It may cause electric shock, re and
explosion
Do not use the socket if it is loose or
damaged
It may cause electric shock, re and
explosion
Do not open the unit during operation It may cause electric shock, re and
explosion
Keep rearms away It may cause re and explosion
Do not use the power cord close to
heating appliances
It may cause electric shock, re and
explosion
Do not use the power cord near ammable
gas or combustibles, such as gasoline,
benzene, thinner, etc�
It may cause
electric shock, re and
explosion
Ventilate room before operating air
conditioner if there is a gas leakage from
another appliance
It may cause explosion, re, explosion
and burns
Do not disassemble or modify unit It may cause failure and electric shock
Always ensure effective earthing Incorrect earthing may cause electric
shock
Do not direct airow at room occupants This could harm your health

10 www.electrolux.com
CAUTION!
caution meaning
When the air lter is to be removed, do not
touch the metal parts of the unit
It may cause an injury
Do not clean the air conditioner with water Water may enter the unit and degrade the
insulation� It may cause an electric shock
Ventilate the room well when used
together with a stove, etc�
An oxygen shortage may occur
When the unit is to be cleaned, switch off
and remove the plug from the power outlet
Do not clean unit when power is on as
it may cause re, explosion and electric
shock, it may cause an injury
Do not place a pet or house plant where it
will be exposed to direct air ow
This could injure the pet or plant
Do not use for special purposes Do not use this air conditioner to
preserve precision devices, food, pets,
plants, and art objects� It may cause
deterioration of quality, etc�
Stop operation and close the window in
storm or cyclone
Operation with windows opened may
cause wetting of indoor and soaking of
household furniture
Hold the plug by the head of the power
plug when taking it out
It may cause electric shock and damage
Turn off the main power switch when not
using the unit for a long time
It may cause failure of product or re and
explosion
Do not place obstacles around air-inlets or
inside of air-outlet
It may cause failure of appliance or
accident
Always insert the lters securely� Clean
lter once every two weeks
Operation without lters may cause failure
Do not use strong detergent such as wax
or thinner - use a soft cloth
Appearance may be deteriorated due to
change of product colour or scratching of
its surface
Do not place heavy object on the power
cord and ensure that the cord is not
compressed
There is danger of re, explosion or electric
shock
Do not drink water drained from air
conditioner
It contains contaminants and could make
you sick
Use caution when unpacking and installing Sharp edges could cause injury
If water enters the unit, turn the unit off
at the power outlet and switch off the
circuit breaker� Isolate supply by taking the
power-plug out and contact a qualied
service technician
It could cause electric shock and damage
