Electrolux FAS156N1 User manual

Product No. FAS156N1A
Series heavy duty
Color N/A
Volts 115
BTU-Cooling 15100 BTU
Owner's Guide 309000855
Market North America
P40L2006.eps FAS156N1A.eps Heavy Duty FAS Wiring Diagram.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995409363
04/05/05
(EN/SERVICE/KC)
099
ROOM AIR
CONDITIONER
Model No.
FAS156N1
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995409363 FAS156N1A
05/04 2
RECOMMENDED SPARE PARTS

FAS156N1A Publication No: 5995409363
# Functional Parts 3 05/04
* Non-Illustrated Parts
RECOMMENDED SPARE PARTS
POS. NO PART NO. DESCRIPTION
1 5304414097 Rail, cabinet bottom, rear
2 5304408741 Grille, rear panel, aluminum
3 309623906 Cabinet, wrapper/sleeve
4 5303211056 Bracket, sash lock
5 5304414116 Rail, cabinet top, front
6 5304414933 Retainer, shutter mount, cabinet side
7 309645602 Shutter, accordion panel, RH/LH, window closure
8 5304414929 Frame, shutter, gray, RH, extension
9 5304416310 Rail, cabinet bottom, front
10 # 5304430864 Overload Protector
11 # 309603117 Compressor
12 # 5303306719 Condenser
13 309632910 Base, compressor mtg., with studs
14 309623201 Shroud, cond fan motor
15 309623501 Tray, evap drip
16 # 309634101 Evaporator
17 # 5303311048 Fan Blade, with clamp
18 # 309630615 Motor, fan, 1 Speed
19 309630302 Cover, blower wheel, top
20 309623602 Bulkhead, control system
21 309623401 Bulkhead, air system
22 309900101 Frame, cabinet front
23 309900301 Louver, horizontal
24 309630102 Housing, blower scroll
25 # 309633001 Blower Wheel, plastic, with clamp
26 309630203 Plate, scroll cover
27 # 309902201 Remote Control, transmitter, with lcd
28 309900201 Panel, front grille
29 309900601 Handle, vent opener
30 309639001 Filter, micro-biologic, framed
31 309902801 Detent, vent handle
32 309321402 Door, vent, with actuator
33 309901701 Overlay, control display
34 309900501 Enclosure, input pcb, control panel
35 # 309901601 PC Board, input/display
36 5304413781 Hardware, PCB support
37 309630404 Control Box
38 # 309900701 Ionizer
39 309111201 Grommet, wire protector
40 309904601 Louver, vertical
41 # 309901401 PC Board, power, 115 V, variable speed
42 309900401 Wheel, louver adjuster
43 # 5304430863 Capacitor, 370 V, 60+10 mfd
44 5304414108 Holder, thermistor clip, 5/16"
45 5303303077 Strap, capacitor mtg.
46 # 309343111 Power Cord, electric, 14 AWG, 115 V, type A
47 # 309201602 Sensor, thermistor, ambient temp
48 # 309201603 Sensor, thermistor, evap defrost
49 # 309330502 Manifold Assembly, with rings
50 5303302254 Nut, expansion type
55 # 309651801 Tube, suction, copper

Publication No: 5995409363 FAS156N1A
05/04 4
RECOMMENDED SPARE PARTS

FAS156N1A Publication No: 5995409363
# Functional Parts 5 05/04
* Non-Illustrated Parts
RECOMMENDED SPARE PARTS
POS. NO PART NO. DESCRIPTION
56 # 309651701 Tube, discharge, copper
57 # 309333001 Tube, capillary, copper, top
58 # 309333201 Tube, capillary, copper, middle
59 # 309333101 Tube, capillary, copper, bottom
60 # 309111001 Fitting, reducer, .101/.104 ID, copper tube
61 # 5303290357 Strainer
63 # 5304417722 Tube, process, copper, cond. outlet
64 5304414105 Bracket, cab support, RH
65 3001815 Support, angle bracket, window sill mt.
66 5304414106 Bracket, cab support, LH
67 5304414928 Frame, shutter, gray, LH, extension

Publication No: 5995409363 FAS156N1A
05/04 6
WIRING DIAGRAM
BK=Black(Noir) BL=Blue(Bleu) BR=Brown(Brun) G=Green(Vert) R=Red(Rouge) W=White(Blanc) Y=Yellow(Jaune)
Alternate Internal Overload Compressor (Autre Surcharge Interne Du Compresseur)
Ion.
J3210
309902101/01
Fan(Ventilateur)
Room Sensor (Sonde D' Ambiance)
Evap Sensor (Sonde Anti Givre)
Compressor (Compresseur)
Fan motor (Moteur Du Ventilateur)
Compressor capacitor (Condensateur Du Compresseur)
C
S
W
R
R
BK
Fan motor capacitor (Condensateur Du Ventilateur)
S
W
C
Connector (Connecteur)
Compressor Overload (Surcharge Du Compresseur)
R
R
BR
G (Vert)
GND
BK
N
Compressor Relay (Relais Du Compresseur)
3
4
BK
R
Ionizer(Ion)
(Optional) (Facultatif)
G (Vert)
GND
Ribbed (Blue) Raye(Bleu)
Plain (Brown) Ordinaire(Brun)
BK
WOR Y
(OU)
