Electrolux ES18K11BCCI User manual

EN Air Conditioner
AR
FR Climatiseur
User Manual
Manuel D'utilisation
(GCC COUNTRYS ONLY)
(GCC COUNTRYS ONLY) (GCC COUNTRYS ONLY) (GCC COUNTRYS ONLY)
(GCC COUNTRYS ONLY) (GCC COUNTRYS ONLY)
(GCC COUNTRYS ONLY)

CUSTOMER CARE AND SERVICE
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number
Warning / Caution-Safety information.
General information and tips
Environmental information.
Subject to change without notice.
2
CONTENTS
1. SAFETY INSTRUCTIONS .................................................................................... 3
2. PRODUCT DESCRIPTION................................................................................... 5
3. INDOOR UNIT DISPLAY ...................................................................................... 6
4. REMOTE CONTROLLER..................................................................................... 6
5. REMOTE CONTROLLER DESCRIPTION ............................................................. 8
6. HOW TO USE THE REMOTE CONTROLLER .................................................... 13
7. HOW TO USE THE INDOOR UNIT..................................................................... 19
8. OPERATING TEMPERATURE ............................................................................ 20
9. EMERGENCY OPERATION ............................................................................... 20
10. CLEANING AND MAINTENANCE ...................................................................... 21
11. OPERATION TIPS.............................................................................................. 23
12. TROUBLESHOOTING ....................................................................................... 25
13. CORRECT DISPOSAL OF THIS PRODUCT....................................................... 26

3ENGLISH
1. SAFETY INSTRUCTIONS
Before the installation and use of the
appliance, carefully read the supplied
instructions. The manufacturer is not
responsible if an incorrect installation and
use causes injuries and damages. Always
keep the instructions with the appliance
for future reference.
1.1 Children and vulnerable
people safety
WARNING!
Risk of suffocation, injury or
permanent disability.
• This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to
ensure that they do not play with the
appliance.
1.2 Installation and Use
WARNING!
Risk of suffocation, injury or
permanent disability.
• Contact an authorised installer for
installation of this unit.
• Contact an authorised service
technician for repair or maintenance of
this unit.
• The socket outlet required to supply
power must be connected and
commissioned by a licenced contractor.
• If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualied
persons in order to avoid a hazard.
• Installation work must be performed
in accordance with the national wiring
standards and the electricity suppliers
service rules by authorised personnel
only.
• If the unit is to be moved to another
location or disposed of, only a suitably
qualied person is permitted to
undertake such work.
• If you notice an unusal situation, such
as a burning smell, please switch off
the power to the air conditioner and
contact an Electrolux service agent. If
this abnormal status continues the air
conditioner may be damaged or even
cause electric shock or re.
• Do not operate the air conditioner with
wet hands. This may cause electric
shock.
• Do not damage or cut off the power
cord or other wires. If this occurs,
please have it repaired or replaced by
an accredited technician.
• Do not connect this air conditioner to a
multi outlet power board.
• Please switch off the power supply to
the air conditioner if it is not to be used
for an extended period. Otherwise, it
will accumulate dust and may cause a
re.
• Before cleaning the air conditioner,
please disconnect the power supply
in order to eliminate the possibility of
electric shock.
• The power supply should be matched
with the air conditioner. Air conditioners
provided with a supply cord should
be connected directly to a power
outlet with a suitable safety switch. Air
conditioners that are hard wired must
be connected to a suitable safety circuit
breaker.
• Please ensure that the power supply
to the air conditioner is stable and
meets the requirements set out in the
installation manual.
• Always ensure the product is installed
with appropriate earthing.
• For safety, be sure to turn off the
circuit breaker before performing any
maintenance or cleaning or when the

4
product is not used for an extended
period of time. Accumulated dust may
cause re or electric shock.
• Select the most appropriate
temperature. It can save electricity.
• Do not keep windows and doors open
for a long time during operation. It will
result in insufcient performance.
• Do not block the air inlet or outlet. It will
result in insufcient performance and
cause malfunctions.
• Keep combustible materials away from
the units at least 1meter. It may cause
re.
• Do not step on the top of the outdoor
unit or place heavy things on it. It may
cause damage or injury.
• Do not attempt to repair the air conditioner
by yourself. Incorrect repairs may cause
electric shock or re. Please contact your
local authorised service centre.
• Do not insert your hands or objects into
the air inlet or outlet. It may cause injury.
• Do not expose animals or plants directly
to the airflow.
• Do not use the unit for any other
purpose, such as preserving food or
drying clothes.
• Do not splash water on the air conditioner.
It may cause electric shock or malfunction.

5ENGLISH
Fresh
3 4
5 6 78
14
1
13
16
12
11
15
9
10
2
Air inlet
Air Outlet
Air inlet (side)
Air inlet (rear)
Air outlet
1 Front panel
2 Digital display
3 Air lter
4 Pre-dust lter
5 Horizontal air flow louver
6 Vertical air flow louver (inside)
7 Manual control button
8 Ion generator (if applicable)
9 Remote controller
10 Remote controller Holder (some units)
11 Refrigerant pipe
12 Drain hose
13 Power cable (some units)
14 Mounting plate
15 Connecting cable
16 Power cable (some units)
All the pictures in this manual are for explanation
purposes only. The actual shape of the indoor unit
you purchased may be slight different on front
panel and display window. The actual shape shall
prevail.
2. PRODUCT DESCRIPTION

6
3. INDOOR UNIT DISPLAY
4. REMOTE CONTROLLER
4.1 How to use the Remote
controller
1. Keep the remote controller where its
signal can reach the receiver of the
indoor unit.
2. When operate the air conditioner, make
sure the remote controller is pointing to
the signal receiver of the indoor unit.
3. When the remote controller sends out
a signal, the symbol will blink in the
display of the remote controller.
4. The indoor unit will acknowledge the
signal with a beep sound when it
receives the signal from the remote
controller.
5. Please press the button of the remote
controller and resend the signal if you
did not hear a beep sound from the
indoor unit.
• The air conditioner will not
operate if curtains, doors or
other materials block the signals
from the remote controller to the
indoor unit.
• Prevent any liquid from falling
into the remote controller. Do not
expose the remote controller to
direct sunlight or heat.
• If the infrared signal receiver on
the indoor unit is exposed to
direct sunlight, the air conditioner
may not function properly. Use
curtains to prevent the receiver
being exposed to sunlight.
• If other electrical appliances react
to the remote controller, either
move these appliances or consult
your local dealer.
21
1 TEMPERATURE indication lamp
• Displays the setting or room temperature
when the unit is operational.
• Displays the malfunction code when fault
occurs.
• Displays the feature code when some
feature is activated.
2 Wireless indication lamp (optional)
• Lights up when Wireless feature is
activated.
**Feature code in indoor unit display
“” Displays for 3 seconds when Timer on is
set or the feature Swing, Turbo or Quiet
is turned on.
“” Displays for 3 seconds when Timer off is
set or the feature Swing, Turbo or Quiet
is turned off.
“” Displays when anti-cold air feature is
turned on.
“” Displays when unit is in defrosting.
“” Displays when Self Clean feature is
turned on (Inverter split type).
Displays when unit is in self-cleaning
(Fixed-speed type).
“” Displays when 80C heating feature is
turned on (some units).

7ENGLISH
4.2 Location of the Remote Controller
Max. 8m
• Keep the remote controller where its
signal can reach the receiver of the
indoor unit (a maximum distance of
8 m is allowed).
• When the remote controller sends
out a signal, the symbol will blink
on the display. The indoor unit will
acknowledge the signal with a beep
sound when it receives an effective
signal.
4.3 Battery installation/replacement
• Remove the back cover from the
remote controller, exposing the
battery compartment and insert two
new alkaline dry batteries (2x AAA 1.5
Volt). Make sure that the polarity of (+)
or (-) is installed correctly.
• Slide the battery compartment cover
back on.
• When changing batteries, do
not use old or varied ones,
otherwise, it may cause
problems with the remote
controller.
• If the remote controller is not
used for a long time, remove
the batteries as old batteries
may leak or corrode and
damage the remote controller.
• The battery life during normal
use is about six months.
• If the remote controller does
not operate normally, please
remove and ret the batteries. If
abnormal operation continues,
replace with new batteries.

8
5. REMOTE CONTROLLER DESCRIPTION
Fresh
1
3
5
7
6
2
4
8
9
13
12
10
11
Type A
8
1
11
1
Type B

9ENGLISH
Type D
112
Type C

10
1. ON/OFF BUTTON
Press the button to switch on or off the
unit
2. MODE BUTTON
Press the button to set the operation
mode: AUTO, COOL, DRY, HEAT and
FAN. Default setting: AUTO.
AUTO HEATCOOL FANDRY
• For Cooling only models, there is
no HEAT mode available.
• In AUTO mode, user can still set
desired temperature.
3. SET BUTTON
Press the button to select some advance
functions.
The select function symbol will flash on the
display, press OK button to conrm it.
See section “How to use the remote
controller“ for the SET function description
in details.
4. OK BUTTON
press the button to conrm the function
you chosed in SET function.
5. FAN BUTTON
Press the button to set the fan speed:
AUTO, LOW, MEDIUM and HIGH. Default
setting: AUTO. In the AUTO and DRY
mode, fan speed can not be set.
Silence
LOW
MED
HIGH
AUTO
2%-20%
21%-40%
41%-60%
61%-80%
81%-100
%
1%
23
20 21 22
24 25 26 27 28 29
14
15
16
17
19
18
30
34
33
31
32
