Elived YD1008 User manual

33LBS
15KG
Max:
Max:200x200mm/8x8"
Min:75x75mm/3x3"
14"~40"
(V1)
If you have any questions, please contact us via
YD1008 INSTALLATION INSTRUCTION
- 1 -
Velcro cable ties X3 Bubble level X1
[email protected]

- 2 -
Hammer
3/8"(10mm)
Masonry Drill Bit
5/32"(4mm)
Wood Drill Bit
AwlStud Finder
Socket Wrench
3/8"(10mm)
ElectrodrillScrewdriverPencil
3 What is your wall
made of?
Solid concrete
wall?
●This product is designed for use in wood stud or solid concrete wall.
- DO NOT install into drywall alone.
●The wall must be capable of supporting five times the weight of the TV and mount
combined.
●Do not apply this product to any purpose not indicated by ELIVED.
●Incorrect installation may result in product damage or body injury. ELIVED shall
bear no responsibility for any damage or injury resulted from incorrect installation,
incorrect assembly or misuse.
Please read this instruction carefully before installation.
If you do not understand these instructions or have doubts about the safety of the
installation, assembly or use of this product, contact Customer Service via
[email protected]
5 Safety Caution
2M2M
Band Tape
Drywall with
wood studs?
CAUTION:
Yes --- Perfect!
No --- This mount is NOT compatible.
MAX:
200mm/8"
MAX:200mm/8"
Yes --- Perfect!
No --- This mount is NOT compatible.
4 Installation Tools
(Not Included)
2Does your TV
(including accessories)
weigh less than
33 LBS (15 KG)?
Before getting started, let’s make sure this mount is perfect for you!
33LBS
15KG
Max:
DO NOT install
into drywall alone
Perfect! Perfect!
Wood Stud Install
Concrete Install
1Is your TV VESA
equal to/greater than
75x75mm/3x3" and
equal to/less than
200x200mm/8x8"?

Arm and Wall Plate
Hardware Included
01 x1 02 x1
Monitor Plate
- 3 -
Extenders
03 x4
This product
contains small items that could
be a choking hazard if
swallowed. Before starting
assembly, verify all parts are
included and undamaged. If any
parts are missing or damaged,
do not return the damaged item
to your dealer; please contact
our customer service team.
Never use damaged parts!
NOTE: Not all parts and
hardware included will be used.
WARNING:
Philips Screws
M6 x 15mm
M6 x 30mm
Philips Screws
M4 x 12mm
M4 x 30mm
Washers
Ø6mm
M4-5-6
Spacers
L10mm
x4
x4 x4x4
Philips Screws
M8 x 25mm
x4 x4 x4
Spacers
L5mm
x4
TV Screws / Washers
M-A M-B M-C M-D M-E M-F
Hardware （Wall /Product)
ST6.3 x 60mm
Lag Bolts
x2 x1
B C DA
Open end wrench Nuts Bolts
x4 x4

1. Select TV screw diameter: Thread screws by hand into the threaded holes on the
back of your TV to select which screw diameter fits your TV.
2. Select TV screw length: When attaching brackets to the TV, be careful not to over
tighten screws and be sure that screws do not bottom out in the mounting holes.
Measure and note the width and the height
of the square or rectangle formed from the
VESA holes pattern .
M6M4 M8
Correct Correct
Too Long
Too Short
- 4 -
STEP 1 Select Proper TV Screw
STEP 2 Mesure Your TV pattern
W
H
2M2M
75mm ≈3in.
200mm ≈8in.

- 5 -
STEP 3-1 Select Monitor Plate Configuration
STEP 3-2 Assemble Monitor Plate and Extenders
Select the configuration A , B , C, or D to use based on the measurement from STEP 2.
If your TV hole pattern is greater
than 100x100mm, attach
extenders [03] to monitor plate
[02]using Nut [C] and Bolt [D] .
for VESA hole pattern:
150x150mm, 200x200mm
for VESA hole pattern:
100x200mm for VESA hole pattern:
200x100mm
BD
C
for VESA hole pattern:
75x75mm, 100x100mm.
A
VESA Patter
(WxH) Configuration VESA Pattern (WxH) Configuration
75mm x 75mm A C
100mm x 100mm A D
B C
100mm x 200mm
150mm x 150mm
200mm x 100mm
200mm x 200mm
02
B
D
C
CD
75mm
100mm
75mm
100mm
200mm
200mm
150mm
150mm
200mm
100mm
200mm
100mm
03
03
02

STEP 4A Wall Plate Installation (Wood stud)
4A-1 Locate your studs. Verify and
mark the center of the stud by
finding the stud edges using an
awl, a thin nail, or an
edge-to-edge stud finder.
- 6 -
M-B
M-A
Use the shorter
screws
M-B
M-C
M-E
Not for M8 screws
M-B
M-A
Use the longer screws
M-B
M-E
Not for M8 screws
M-FM-D
STEP 3-3
Attach the Brackets
(a) for Flat Back
(b) for Round Back / Extra space
Top of TV
Top of TV

4A-2
Position the wall plate at
your desired height and line up
the holes with your stud center
line. Level the wall plate and
mark the pilot hole locations x2.
01
4A-3
Drill pilot holes using a 5/32 in. (4 mm)
diameter drill bit.
IMPORTANT: Pilot holes must be
in. (70 mm).
Be sure to drill into the center of thestud.
drilled to a depth of
5/32 in.
Ø4 mm
in. (70 mm)
4A-4
01 A
A
Install wall plate using lag bolts .
Tighten the lag bolts until they are
pulled firmly against the wall plate .
01
- 7 -
01
Level
01
A
UP
2

- 8 -
01
Position the wall plate at
your desired height , level
the wall plate and mark the
pilot hole locations x2.
4B-1
A
STEP 4B Wall Plate Installation (Concrete or Brick)
Contact us by email [email protected] to have
these additional pieces shipped directly to you.
Concrete Wall Anchor
3pcs
Concrete wall anchor (NOT INCLUDED)
01
A
A
01
Install wall plate using
lag bolts and anchors (not
included). Tighten the lag
bolts until they are
pulled firmly against the wall
plate .
01
Level
4B-2
4B-3
2.75in 70 mm
Ø 10 mm
Ø 10 mm
Drill pilot holes
01
UP
2

(Tilting)
Lift and hang TV assembly onto arm and wall plate. Secure the monitor plate to the arm and
wall plate with the removed screws and
washers from the previous step.
(Leveling)
Loosen the screws Tighten the screwsTilt the TV
+3 /-10°
Loosen the screw Tighten the screw
Level the TV
Tilting angle adjustment (+3° / -10°)
Adjust TV to your desired angle then fasten tilting screws with open end wrench.
Leveling adjustment
If needed, TV can be leveled via adjusting the screw with the open end
wrench or screwdriver.
- 9 -
B
Adjustments
STEP 5 Lift and Hang TV with Brackets onto Wall Bracket
B
Remove 2 preassembled
screws and washers before
hang TV on to the wall
bracket, and save them for
using to next step.
Loosen Tighten
B
B B
B B

Product dimensions:
- 10 -
Switch Screen Horizontally and Vertically
+3°/-10°
380mm
68mm
210mm
200mm
100mm
115.8mm
If needed, the TV can be rotated ±90 degrees for switching screen between horizontally and vertically.
Use the open end wrench to loosen and tighten
this screw if necessary.
Screwdriver can be used for adjusting the screw
to secure the TV direction if need.
Horizontal screen
±90°
Vertical screen
B
0° up 90° up
