INSTALLATION INSTRUCTIONS
1. Remove shipping brace from mounting box and discard.
2. Fasten mounting box into wall cutout using screws or bolts (provided by others) through the holes or knock
outs provided on each side of the mounting box. See Rough-In drawing found in Product Specication
Sheet.
3. Install fountain body to mounting box using #10 x .63 inches (16mm) PHSM screws and large clips provided.
4. Place refrigeration package into mounting box and connect water lines. (See Page 3 for details)
5. Water inlet is 3/8 inches O.D. and waste tube is 1-1/4 inches O.D. Contractor is to supply waste trap and
service stop valve in accordance with local codes.
6. Connecting lines to be unplated copper and thoroughly ushed to remove all foreign matter before connecting
to refrigeration package. The furnished strainer (Item 18) should be added to the supply line.
7. Connect the refrigeration package to the supply line service stop valve. Connect supplied fountain (internal
plumbing) tubes as shown in (Fig. 1, Pg. 3) or (Fig. 2, Pg. 3) . Remove any burrs from water tubes before
inserting into ttings. (See Fig. 7, Pg. 4, and Fig. 8, Pg. 4). DO NOT SOLDER TUBES INSERTED INTO
THE STRAINER AS DAMAGE TO THE O-RINGS MAY RESULT.
8. Electrical: Insure power supply is identical in voltage, hertz, and phase to that specied on the refrigeration
package serial plate. Never wire compressor directly to the power supply.
9. Turn water supply on and check thoroughly for leaks.
10. Release air from tank by depressing push button; a steady stream of water assures all air is removed.
11. Re-check for leaks.
12. Stream height is factory set at 35psig (0.24MPa). If supply pressure varies greatly from this, turn
adjustment screw on regulator (Item 1, Pg 5). Clockwise adjustment will raise the stream height and
counter-clockwise adjustment will lower stream height. For best adjustment, stream should hit basin
approximately 6-1/2 inches from the bubbler.
13. Rotate fan blade on refrigeration package to insure proper clearance and free fan action.
14. Connect power supply.
15. Install grill using #8 x 1.00 inches (25mm) PH screws and small clips provided.
TROUBLE SHOOTING AND MAINTENANCE
1. Orice Assy: Mineral deposits on orice can cause water ow to spurt or not regulate. Mineral deposits
may be removed from orice with a small round le not over 1/8 diameter or a small diameter wire.
CAUTION: Do not le or cut orice materials.
2. Actuation of Quick Connect Water Fittings: Cooler is provided with lead-free connectors which utilize
an o-ring water seal. To remove tubing from the tting, relieve water pressure, push in on the gray collar
while pulling on the tubing (See Fig. 7, Pg. 4). To insert tubing, push tube straight into the tting until it
reaches a positive stop, approximately 3/4 inches.
This product has been designed for use with potable water ONLY, at a supply line pressure
of 20 to 100psig (0.14 - 0.69 MPa ) and a maximum water temperature of 90ºF (32ºC).
