Elkay ECH8 2K Series Installation manual

98437C (Rev. B - 10/10)
ECH8*1K ECH8*2K ECH8*3K
INSTALLATION
1. When mounting unit in an open area, to insure proper ventilation,
maintain a 4" (102mm) clearance from cabinet louvers on each side
of cooler . When mounting unit in a cavity or behind a wall maintain
minimum space of 4" (102mm) on each side, 4" (102mm) on the top
and a depth of 12" (305mm).
2. Water inlet is 1/4" (6 mm) O.D. tube. Contractor to supply the
connections as required.
3. Connecting lines to be of unplated copper, thoroughly flushed to
remove all foreign matter before being connected to cooler. If
flushing does not remove all particles, a water strainer should be
installed in supply line. This cooler is manufactured in such a manner
that it does not in any way cause taste, odor, color or sediment
problems.
4. Connect cooler to building supply line with a shut-off valve and
install the in-line strainer between the valve and cooler.
5. Electrical: Make sure power supply is identical in voltage, cycle,
and phase to that specified on cooler serial plate. Never wire
compressor directly to the power supply.
6. This chiller has been designed for use with potable water ONLY.
START-UP
1. Open supply line valve.
2. Purge air from all water lines by operating bubbler valve of
fountain to which cooler is connected. Steady stream assures all
air is removed.
3. Rotate fan to insure proper clearance and free fan action.
4. Connect to electrical power.
TROUBLESHOOTING&MAINTENANCE
Temperature Control: Factory set at 50°F (± 5°) under normal
conditions. For colder water, adjust screw on item no. 12 in
clockwise direction.
Ventilation: Cabinet louvers and condenser fins should be
periodically cleaned with brush, air hose or vacuum cleaner.
Excess dirt or poor ventilation can cause no cold water and
compressor cycling on the compressor overload protector.
Lubrication: Motors are lifetime lubricated.
Actuation of Quick Connect Water Fittings: Cooler is provided
with lead-free connectors which utilize an o-ring seal. To remove
tubing from the fittings, relieve water pressure, push in on gray
collar while pulling on the tubing. To insert tubing, push tube
straight into fitting until it reaches a positive stop, approximately
3/4”.
TUBE IS SECURED
IN POSITION
SIMPLY PUSH IN
TUBE TO ATTACH PUSH IN COLLET TO RELEASE TUBE
PUSHING TUBE IN BEFORE
PULLING IT OUT HELPS TO
RELEASE TUBE
OPERATION OFQUICK CONNECT FITTINGS
NOTE:WATERFLOW
DIRECTION
BUILDINGWATERINLET
SERVICESTOP
(NOT FURNISHED)
1/4"O.D.TUBE
WATERINLET
TOCHILLER
3/8"O.D.UNPLATED
COPPERTUBE CONNECT
COLDWATERSUPPLY
LEGEND
A= 1/4" O.D. TUBE WATER OUTLET
B = 1/4" O.D. TUBE WATER INLET
C = TEMPERATUREADJUSTMENT
D = ELECTRICAL
INSTALLATION, CARE & USE MANUAL
Refrigeration Package

98437C (Rev. B - 10/10)
ECH8*1K ECH8*2K ECH8*3K
PRINTEDINU.S.A.
ITEM
NO. PART NO.
1
2
3
4
5
6
7
8
9
10
*11
12
13
14
15
16
17
18
19
20
21
22
23
24
66810C
28478C
66743C
31490C
20282C
30664C
70018C
56237C
66576C
66703C
36094C
35839C
28477C
35768C
36158C
35959C
100806740570
101516143550
19037000
50930C
27303C
22300C
55996C
66723C
115V ITEMIZED PARTS LIST
DESCRIPTION
*INCLUDES RELAY & OVERLOAD. IF UNDER WARRANTY,
REPLACE WITH SAME COMPRESSOR USED IN ORIGINAL
ASSEMBLY.
NOTE: All correspondence pertaining to any of the above water
cooler or orders for repair parts MUST include model number and
serial number of cooler, name and part number of replacement
part.
EVAPORATORTANKASSY
CABINET
CONDENSER
MOTOR - FAN 115V
BRACKET - FAN MOUNTING
BLADE - FAN
NUT - FAN BLADE
SHROUD - FAN
HEATEXCHANGER
DRIER
COMPRESSOR SERVICE PAK
COLD CONTROL
PANEL - FRONT
COVER - RELAY
OVERLOAD
RELAY
GROMMET
STUD - COMP. MOUNTING
CLIP
BUMPER
BASEPLATE
PANEL - REAR
IN-LINE STRAINER
EVAPORATORTUBE
WIRINGDIAGRAM
ELKAY MANUFACTURING COMPANY • 2222 CAMDEN COURT • OAK BROOK, IL 60523 • 630.574.8484
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.323.0620
REPAIR SERVICE INFORMATION TOLL FREE NUMBER 1.800.260.6640
22
23
4, 5, 6,
7, 8
21
10
912
11, 14, 15, 16,
20
3
2
1
13
24
ITEM
NO. PART NO.
220V - 50 HZ
DESCRIPTION
4
*11
15
16
31430C
36085C
36195C
36050C
MOTOR - FAN 220V
COMPRESSOR SERVICE PAK
OVERLOAD
RELAY
ITEM
NO. PART NO.
220V - 60 HZ
DESCRIPTION
4
*11
15
16
31431C
36092C
36174C
36050C
MOTOR - FAN 220V
COMPRESSOR SERVICE PAK
OVERLOAD
RELAY
