Elkay 4420BF1UDB Series User manual

PAGE 1
4420BFDB_FTN_A LK4420BFDB_FTN_A
1000003948 (Rev. B - 03/20)
4420BFDB Fountains are among the easiest to install Fountains on the market today.
To assure you install these models easily and correctly, PLEASE READ THESE
SIMPLE INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK YOUR
INSTALLATION FOR COMPLIANCE WITH PLUMBING, ELECTRICAL, AND OTHER
APPLICABLE CODES. After installation, leave these instructions with the Fountain for
future reference.
Owners Manual
Models 4420BF1LDB* and 4420BF1UDB*
Bi-Level Tubular Bottle Filler Fountain with Pet fountain
INSTALLER
Models (LK)4420BF1LDB* Models (LK)4420BF1UDB*

PAGE 2
4420BFDB_FTN_A LK4420BFDB_FTN_A
1000003948 (Rev. B - 03/20)
1. This fountain is to be mounted on a smooth, at, nished surface with adequate support structure. NOTE: Mounting structure
must be capable of supporting 300 lb. load on fountain.
2. Refer to rough-in for plumbing.
3. Install shut-o󰀨 valve on water supply. (Valve not furnished)
4. Locate and install fountain using 3/8" minimum fasteners. (Fasteners not furnished)
5. Prior to installing the bottle ller to the center mounting position of fountain, insert the drain pipe (Item #15) by positioning the
short end of drain pipe through mounting plate of bottle ller. Next, place the aesthetic collar (item # 29) onto the center
mounting position of the fountain ensuring the vertical edge of the collar is upright and the curved edge sits below the mount
ing surface. Mount bottle ller to fountain with collar centered between the two pieces. Install bottle ller to fountain and secure
with supplied hardware.
6. Prior to installing the bottle ller to the arm mount of fountain, insert the drain pipe (Item #14) into the arm tunnel and adjust
drain to lean to the left side of the arm when facing the button. Next, place the aesthetic collar (Item # 29) onto the arm
mounting position of the fountain ensuring the vertical edge of the collar is upright and the curved edge sits below the
mounting surface. Mount bottle ller to arm with collar centered between the two pieces. Install bottle ller to arm being
sure drain tube is above mounting plate of ller. Install ller to fountain and secure with supplied hardware.
7. Connect water supply and fountain drain. Connect drain waste "Tee" to fountain drain tubes. Connect outlet of "Tee" to
drainage system. Water connection and drain must comply with local codes.
8. Turn on water supply and check all connections for leaks.
CAUTION: This fountain is rated for inlet water pressure of 20-105 PSI. A pressure reducing regulator should be used if the
inlet water supply exceeds 105 PSI. Any damage caused by reason of connecting this product to supply line
pressures lower than 20 PSI or higher than 105 PSI is not covered by warranty.
9. Water supply 3/8" O.D. unplated copper tube. Waste 1-1/2" IPS. Contractor to supply waste trap and service stop valve in
accordance with local code.
10. Connecting lines to be made of unplated copper and should be thoroughly ushed to remove all foreign matter before being
connected to fountain. This fountain is manufactured in such a manner that it does not in any way cause taste, odor,color,
or sediment problems.
11. Connect fountain to supply line with a shut-o󰀨 valve and install a 3/8" unplated copper water line between the valve and
the fountain. Remove any burrs from outside of water line. Push the tubes straight into the ttings until they reach a
positive stop, approximately 3/4" (See Fig. 3). DO NOT SOLDER TUBES INSERTED INTO PLASTIC FITTINGS AS
DAMAGE TO THE O-RINGS MAY RESULT.
IMPORTANT
ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON
IMPORTANT! INSTALLER PLEASE NOTE.
THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC. TO WATER LINES
IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY OCCUR AWAY FROM THE
BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTO A FOUNTAIN, CREATING AN
ELECTROLYSIS WHICH CAUSES A METALLIC TASTE OR AN INCREASE IN THE METAL CONTENT OF THE
WATER. THIS CONDITION IS AVOIDABLE BY USING THE PROPER MATERIALS AS INDICATED. ANY DRAIN
FITTINGS PROVIDED BY THE INSTALLER SHOULD BE MADE OF PLASTIC TO ELECTRICALLY ISOLATE THE
FOUNTAIN FROM THE BUILDING PLUMBING SYSTEM.
INSTALLATION INSTRUCTIONS

PAGE 3
4420BFDB_FTN_A LK4420BFDB_FTN_A
1000003948 (Rev. B - 03/20)
LEGEND A = 3/8" O.D. UNPLATED COPPER TUBE CONNECT - SHUT OFF VALVE BY OTHERS B = ACCESS PANEL ( 8" X 10" ) C = REMOVABLE BOTTOM COVER
FINISHED FLOOR
4420BF1LDB
* ADA REQUIREMENT
6 9/16" 167mm
30" 762mm
C
A
1-1/2" DRAIN
B
B
8" 203mm
41 7/16" 1053mm
ORIFACE
HEIGHT
10" 254mm
O
8 - O.500" HOLES
EQUALLY SPACED ON
TWO O12.00" B.C.
26" 660mm
O14"
356mm
(2 PL)
22" 559mm
19" 483mm
40 5/16" 1025mm RIM HEIGHT
3" 76mm
29" 737mm
10" 254mm
O
27 1/8" 689mm
37 3/16" 945mm 14 9/16" 371mm
10" 254mm
O
57 3/16" 1453mm
*

PAGE 4
4420BFDB_FTN_A LK4420BFDB_FTN_A
1000003948 (Rev. B - 03/20)
LEGEND A = 3/8" O.D. UNPLATED COPPER TUBE CONNECT - SHUT OFF VALVE BY OTHERS B = ACCESS PANEL ( 8" X 10" ) C = REMOVABLE BOTTOM COVER 4420BF1UDB
FINISHED FLOOR
* ADA REQUIREMENT
*
4420BF1UDB
B
B
C
1-1/2" DRAIN
A
8 -
O
.500" HOLES
EQUALLY SPACED ON TWO
O
12.00" B.C.
26" 660mm
O
14" 356mm
(2 PL)
22" 559mm
10" 254mm
O
10" 254mm
O
10" 254mm
O
64 1/16" 1627mm
8" 203mm
6 9/16" 167mm
30" 762mm
44 1/16" 1119mm
14 9/16" 371mm
19" 483mm
29" 737mm
27 1/8" 689mm
33 7/16" 850mm
RIM
HEIGHT
34 9/16" 878mm
ORIFACE
HEIGHT
3" 76mm

PAGE 5
4420BFDB_FTN_A LK4420BFDB_FTN_A
1000003948 (Rev. B - 03/20)
Vandal-Resistant Bubbler
FIG. 1
16
19, 27
26
826
6
17
10
1
24
20
25
4
4
4
4
16 1
3
1
16
9
13
REV. DESCRIPTION
MATERIAL:
SCALE: CH. BY: APPROVED BY:
DR. BY:
REL. ECN: DATE:
B
6400 PENN AVENUE SAVANNA, ILLINOIS 61074
MANUFACTURING CO.
TOLERANCES UNLESS OTHERWISE SPECIFIED:
This Print is the Property of ELKAY MANUFACTURING CO. and is
loaned subject to return upon demand and upon the express condition
that it is not to be used directly or indirectly without our permission for
purposes other than those for which it was furnished.
2 PLACE DECIMAL ± .03 1 PLACE METRIC ± .8 MM
3 PLACE DECIMAL ± .005 2 PLACE METRIC ± .1 MM
ANGLES ±.50°
FOR REVISIONS
SEE SHEET 1 OF 10
SHEET 5 OF 10
SEE SHEET 1 OF 10
4420BFDB TUBULAR BI-LEVEL FOUNTAIN
1 : 8
CGK
CGK
D
21
27
38
62
31
21
11 24
22
27
13
10
42
62
49
30
10
13
42
62
61
28
63
20
29
6 SEE NOTE 13
58
78SEE NOTE 11
20
28
3748
21
16 59
10
13
1659
52 OR
33
25
43
43
43
61
16
3SEE NOTE 5
34
32 45
33 45
63
29 22 24
24
11
11
37
3748
48
52 OR
22
20
29
28
63
61
45
8SEE NOTE 13
NCR-02488
RDZ
5/1/17
ASY99052C
61
62
61
62
61
62
61
59
18, 27
28
27
28
22
27
ARM ONLY 14
15
25
11
21
23
28
29
2
BASIN

PAGE 6
4420BFDB_FTN_A LK4420BFDB_FTN_A
1000003948 (Rev. B - 03/20)
B CA
SIMPLY PUSH IN
TUBE TO ATTACH
TUBE IS SECURED
IN POSITION
PUSH IN COLLET
TO RELEASE TUBE
OPERATION OF QUICK CONNECT FITTINGS
PUSHING TUBE IN BEFO
RE
PULLING IT OUT HELPS T
O
RELEASE TUBE
OPERATION OF QUICK CONNECT FITTINGS
SIMPLY PUSH IN
TUBE TO ATTACH
TUBE IS SECURED
IN POSITION
PUSH IN COLLET
TO RELEASE TUBE
PUSHING TUBE IN BEFORE
PULLING IT OUT HELPS TO
RELEASE TUBE
A B C
ITEM
NO.
PART NO.
ITEMIZED PARTS LIST
DESCRIPTION
28467C
1000003814*
40551C
0000000325
1000003812*
1000003813*
45926C
45724C
45726C
0000000466
45931C
55996C
66346C
66816C
66815C
97446C
101570540560
75724C
97247C
98678C
98530C
98679C
98680C
98681C
1000003692
1000003693
98682C
1000003694
1000003695
98683C
98684C
98685C
98686C
1000005456
1000003490
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
NS
Basin
Cover - Round Plate
Tailpipe
Kit - Drain Plug/Gasket
Access Panel
Bottom Cover
Drain Tube - 1-1/2" x 27-1/2" Lg.
Tailpipe - 1-1/4" x 10"Lg.
Drain Plug 1-1/2" (Dog Bowl)
Kit - Bubbler (Dog Bowl)
Plug - Drain (BF)
In - Line Strainer
Drain Tube
Tube - Drain (Arm Only)
Tube - Drain
Kit - Bubbler (VR)
Gasket
Screw - 1/4"x20 x 3/4" LG. Pinned Torx
Kit - VR Torx Screws/Bit
Kit - 1.0 GPM Regulator (BF Only)
Kit -
Kit - Nozzle
Kit - Aerator/Key
Kit - Blank Bottle Filler Trim
Kit - LK4420BFDB Bottle Filler Trim
Kit - 4420BFDB Bottle Filler Trim
Kit - Push Button w/Blank Nameplate
Kit - Push Button w/LK4420BFDB Nameplate
Kit - Push Button w/4420BFDB Nameplate
Kit - Plastic Drain
Kit - 90° Plastic Drain
Kit - 4400 Series Hardware
Kit - Bottle Filler Waterway
Aesthetic Collar
Drain Tube (Not Shown)
5
27
12
5
11
See Fig. 4
10
TROUBLESHOOTING AND MAINTENANCE
STREAM HEIGHT ADJUSTMENT:
Stream height is factory set at 35 PSI. If supply pressure
varies greatly from this, insert a small straight bladed
screwdriver through the access hole in the center of the
push button and turn the adjustment screw. Clockwise
adjustment will raise the stream and counterclockwise
adjustment will lower the stream. For best adjustment,
the stream should be approximately 1 1/2" above the
top of the bubbler . (See Fig. 4)
FIG. 4
ACTUATION OF QUICK CONNECT WATER FITTINGS:
Fountain is provided with lead-free connectors which utilize an
o-ring water seal. To remove tubing from the tting, relieve water
pressure, push in on the gray collar while pulling on the tubing. (see
Fig.2) To insert tubing, push tube straight into tting until it reaches
a positive stop, approximately 3/4".
PRINTED IN U.S.A.
Halsey Taylor – halseytaylor.com
Elkay – elkay.com
FOR PARTS CONTACT YOUR LOCAL DISTRIBUTOR OR CALL TECHNICAL SERVICES AT 1.800.834.4816
1333, BUTTERFIELD ROAD, DOWNERS GROVE, ILLINOIS 60515
*select color option to complete part number
*FINISH COLOR OPTIONS – Choose color option to
complete your model number, add as sux example:
4420BF1UDBEVG
Matte nish: Evergreen = EVG
Gloss nish:
Beige = BGE Gray = GRY Terracotta = TER
Black = BLK Orange = ORN White = WHT
Blue = BLU Purple = PUR Yellow = YLW
Brown = BRN Red = RED
FIG. 3
FIG. 2
NOTE: WATER FLOW
DIRECTION
BUILDING WATER INLET
SERVICE STOP
(NOT FURNISHED)
1/4" O.D. TUBE
WATER INLET
TO COOLER
3/8" O.D. UNPLATED COP-
PER TUBE CONNECT
COLD WATER SUPPLY
NS = Not Shown
