Elkay FLEXI-GUARD ESRC8 3GJO Series Installation manual

97759C (REV. E - 7/03)
ESRC8*1G ESRC8*3GJO ESRC13*3GJO ESRDC*C
PAGE 1
With FLEXI-GUARD®
Installation/Care/Use Manual
USES HFC-134A REFRIGERANT
FIG. 1
SEE FIG. 3
SEE DETAIL
ABOVE
26
6
2
43
8 - See Fig. 4
42
7
14
41
18
15, 16
& 17
28
25
37
13
23
44
22
30
29
127
19, 20, 21
3, 4, 5
39
24
45
40
38
46

97759C (REV. E - 7/03)
ESRC8*1G ESRC8*3GJO ESRC13*3GJO ESRDC*C
PAGE 2
FIG. 2
* RECOMMENDED HEIGHT FOR ADULTS.
DECREASE HEIGHT FOR CHILDREN.
* ALTURA RECOMENDADA PARA ADULTOS.
REDUZCA PARA LOS NIÑOS.
* HAUTEUR RECOMMANDÉE POUR LES
ADULTES. INSTALLEZ PLUS BAS POUR LES ENFANTS.
FINISHED FLOOR PISO ACABADO PLANCHER FINI
MOUNTING BOX
SHIPPING POSITION OF FASTENING CLIP
COOLER BASE
POSITION FASTENING CLIP AS SHOWN AFTER COOLER IS HUNG IN PLACE
DETAIL A
DETAIL B
SEE DETAILS A & B
MOUNTING BOX
ROUGH-IN
D = ELECTRICAL OUTLET LOCATION
UBICACIÓN DE LA TOMA DE ELECTRICIDAD EMPLACEMENT DE LA PRISE DE COURANT
E = INSURE PROPER VENTILATION BY MAINTAINING 4" (102mm) (MIN.) CLEARANCE FROM CABINET LOUVERS TO WALL.
ASEGURE UNA VENTILACIÓN ADECUADA MANTENIENDO UN ESPACIO E 4" (102mm) (MÍN.) DE HOLGURA ENTRE LAREJILLADE VENTILACIÓN DEL MUEBLE Y LA PARED ASSUREZ-VOUS UNE BONNE VENTILATION EN GARDANT 4" (102mm) (MIN.) ENTRE LES ÉVENTS DE LENCEINTE ET LE MUR.
F = POWER CORD 1-1/2FEET (457mm) LONG
CABLE ELÉCTRICO DE 1½ PIE, 457 mm DE LARGO CORDON DALIMENTATION 1-1/2' (457mm)
LEGEND/LEYENDA/LÉGENDE A = RECOMMENDED WATER SUPPLY LOCATION 3/8 O.D. UNPLATED COPPER TUBE CONNECT STUB 1-1/2 IN. (38 mm) OUT
FROM WALL SHUT OFF BY OTHERS SE RECOMIENDA UBICAR EL TUBO CORTO DE CONEXIÓNALTUBO DE COBRE SIN CHAPAR DE 3/8" DE DIÁM. EXT. A1-1/2"
(38 mm) FUERA DE LALLAVE DE PASO EN LA PARED COLOCADA POR TERCEROS.
EMPLACEMENT RECOMMANDÉ D'ALIMENTATION EN EAU PAR TUBE EN CUIVRE NON PLAQUÉ DE 3/8 PO. (9,5 mm) D.E.
CONNECTANT UNE TUYAUTERIE DE 1-1/2 PO. (38 mm) DEPUIS LE ROBINET D'ARRÊT FOURNI PAR D'AUTRES.
B = RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/4 O.D. DRAIN
UBICACIÓN RECOMENDADA PARA EL DRENAJE DE SALIDA DE AGUA, DE 1¼ DE DIÁMETRO. EMPLACEMENT RECOMMANDÉ POUR LE DRAIN DE D.E. 1-1/4" DE SORTIE DEAU.
C = 1-1/4 TRAP NOT FURNISHED**
PURGADOR DE 1¼ NO PROPORCIONADO** SIPHON 1-1/4 NON FOURNI**

97759C (REV. E - 7/03)
ESRC8*1G ESRC8*3GJO ESRC13*3GJO ESRDC*C
PAGE 3
FIG. 3
Stream height is factory set at 35 PSI. If supply pressure varies greatly
from this, remove items 31 and 32 and adjust screw on item 34. Clockwise
adjustment will raise stream and counter-clockwise adjustment will lower
stream. For best adjustment, stream should hit basin approximately 6-1/2"
(165mm) from bubbler.
NOTE:
WHEN INSTALLING REPLACEMENT BUBBLER
AND PEDESTAL, TIGHTEN NUT (ITEM 12) ONLY
TO HOLD PARTS SNUG IN POSITION.
DO NOT OVER TIGHTEN.
BASIN
IMPORTANT
ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON
START UP
Also See General Instructions
8) Replace the front panel and secure by retightening all screws.
FIG. 4
10
11
12
89
WRAPPER
34
32
33
31 35 36
INSTALLATION OF COOLER AND TRAP
1) Hang the unit from the mounting box by placing tabs from the upper backside of the basin over top of the
upper flange on the mounting box, and mount trap, as shown in Figure 2.
NOTE: Mounting box and trap MUST be supported securely. Add fixture support carrier if wall will not provide adequate support.
IMPORTANT:
2) Secure cooler in place by positioning fastening clips as shown in Figure 2 - Detail B.
3) Install straight valve for 3/8 in. O.D. unplated copper tube.
4) Remove the access panel on the underside of the cooler and set it aside.
5) Connect water inlet line--See Note 4 of General Instructions.
6) Remove the slip nut and gasket from the trap and install them on the cooler waste line making sure that the end of the waste
line fits into the trap. Assemble the slip nut and gasket to the trap and tighten securely.

97759C (REV. E - 7/03)
ESRC8*1G ESRC8*3GJO ESRC13*3GJO ESRDC*C
PAGE 4
PARTS LIST
ITEM NO. PARTNO. DESCRIPTION
31517C
27321C
30699C
70018C
31490C
70009C
50186C
56073C
40322C
56011C
55997C
75580C
62152C
66202C
50144C
70184C
70418C
36094C
36158C
35768C
35959C
66501C
40041C
40429C
50074C
20593C
20594C
70208C
31513C
66505C
55996C
27239C
40089C
40048C
15005C
61313C
40169C
50986C
See Color Table
40038C
40619C
50105C
27093C
27292C
27331C
27094C
40043C
70817C
15009C
100322740560
31525028
40493C
56092C
Power Cord
Fan Bracket
Fan Blade
Hex Nut - Fan Blade
Fan Motor
Screw (Fan Motor)
Shroud - Fan
Bubbler Assy
Orifice Assy
Housing Assy
Pedestal
Locknut
Condenser
Drier
Grommet - Compressor Mtg.
Hair Pin - Cotter
Washer
Compressor Serv. Pak EMI 70 HNR
Overload
Cover - Relay
Relay
Heat Exchanger
Tailpipe Assy (8 Gal)
Precooler Assy (13 Gal)
Tailpipe Gasket
Basin - Stainless Steel
Basin - Glass Filler
Screw - Basin Mtg.
Cold Control
Evaporator Assembly (8 Gal)
Strainer
Bracket - Precooler
Cover
Button
Retaining Nut
Regulator
Hex Nut
Regulator Holder
Wrapper
Strainer - Beehive
Ferrule - Tailpipe
Tailpipe Gasket
Angle-Front Corner
Bracket-Basin Mounting
Frame-Back/Bottom
Bracket-Front
Locknut
Fitting - Elbow 1/4 Stem
Nipple - Bubbler (GF)
Gasket
O-Ring
Glass Filler
Poly Tubing (Cut to length)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18*
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
NS
ELKAY MANUFACTURING COMPANY  2222 CAMDEN COURT  OAK BROOK, IL 60523  630.574.8484
PRINTED IN U.S.A.
*INCLUDES RELAY & OVERLOAD. IF UNDER WARRANTY,
REPLACE WITH SAME COMPRESSOR USED IN ORIGINAL
ASSEMBLY.
NOTE: All correspondence pertaining to any of the above
water coolers or orders for repair parts MUST include Model
No. and Serial No. of cooler, name and part number of replace-
ment part.
COLOR TABLE
PANEL COLOR Item No. 37
Part No.
Gray Beige
Almond
Stainless Steel
Sandalwood
Granite
Light Gray
21017C
21481C
21013C
21480C
27208C
27209C
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.323.0620
220V 60Hz
35827C
31431C
36092C
36174C
36050C
66223C
35826C
Power Cord
Fan Motor
Compressor Serv. Pak
Overload
Relay
Heat Exchanger
Power - Inlet
PART. NO. DESCRIPTIONITEM NO.
1
5
18*
19
21
22
-
47
48 49 50
FIG. 5
