Elkay FGDF710-10-1G Installation manual

98361C (05/07)
FGDF710-10-1G FGDF710-10-2G
PAGE1
Installation/Care/Use Manual
USESHFC-134AREFRIGERANT
FIG. 1
FGDF710-10-1GSHOWN
SEE FIG. 4 7
16
SEE FIG. 3
25, 8
23
21, 22, 32 29, 30, 31
14
15
13
24
17, 18, 19, 20
26
27
28
9

98361C (05/07) PAGE2
FGDF710-10-1G FGDF710-10-2G
LÍNEADELAPARED LIGNE DU MUR
FINISHED FLOOR PISOACABADO PLANCHERFINI
FIG. 2
D = POWER CORD 4 FEET (1219mm) LONG
CABLEELÉCTRICODE4PIE (1219mm), DE LARGO CORDOND’ALIMENTATION 4' (1219mm)
E = INSURE PROPER VENTILATION BY MAINTAINING 4" (102mm) (MIN.) CLEARANCE FROM CABINET LOUVERS TO WALL.
ASEGUREUNAVENTILACIÓNADECUADAMANTENIENDO UNESPACIO E 4" (102mm) (MÍN.)DEHOLGURAENTRE LA REJILLADEVENTILACIÓN DELMUEBLEYLAPARED ASSUREZ-VOUSUNEBONNE VENTILATION EN GARDANT 4" (102mm) (MIN.) ENTRE LESÉVENTSDEL’ENCEINTE ET LE MUR.
F = TO LEVEL UNIT, LOOSEN SCREWS TO ADJUST BASE FOR CONTACT WITH FLOOR. TIGHTEN SCREWS AFTER UNIT HAS BEEN LEVELED. PARANIVELAR LAUNIDAD,AFLOJELOSTORNILLOSPARAAJUSTARLABASEPARAQUE HAYACONTACTO CON ELPISO. APRIETELOSTORNILLOSDESPUÉS DEQUESEHAYANIVELADO LAUNIDAD. POUR NIVELER L’UNITÉ,DESSERREZ LESVISPOURAJUSTER LABASEAUCONTACTAVECLEPLANCHER. SERREZ LES
VIS APRÈSQUEL’UNITÉAITÉTÉNIVELÉE.
LEGEND/LEYENDA/LÉGENDE A= RECOMMENDED WATER SUPPLY LOCATION. SHUT OFF VALVE (NOT FURNISHED) TOACCEPT 3/8 O.D. UNPLATED COPPER TUBE.
POSICIÓN DEABASTECIMIENTO DEAGUA RECOMENDADA. VÁLVULACERRADA(NOAMUEBLADO)
PARAACEPTAR 3/8" O.D. TUBO DE COBRE NO PLATEADO. ENDROIT D’APPROVISIONNEMENT EN EAU RECOMMANDÉ. LAVALVE ARRÊTÉE (NON FOURNI) POUR ACCEPTER 3/8" PO. (9,5mm) TUBE COULEUR CUIVRE NON PLAQUÉ. B = RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/4” O.D. DRAIN
UBICACIÓNRECOMENDADAPARAELDRENAJEDE SALIDADEAGUA, DE1-1/4"DEDIÁMETRO. EMPLACEMENTRECOMMANDÉ POUR LE DRAIN DE D.E.1-1/4"DE SORTIE D’EAU.
C = 1-1/4 TRAP NOT FURNISHED
PURGADORDE1-1/4 NO PROPORCIONADO SIPHON1-1/4 NON FOURNI

98361C (05/07)
FGDF710-10-1G FGDF710-10-2G
PAGE3
Stream height is factory set at 35 PSI. If supply pressure varies greatly from this,
remove Items 1 & 2 and adjust screw on Item 4. Clockwise adjustment will raise
stream and counter-clockwise adjustment will lower stream. For best adjustment,
stream should hit basin approximately 6-1/2" (165mm) from bubbler.
BASIN
FIG. 4
4
3
1
5
6
2
12
10
Note: Wheninstallingreplacement bubbler, tightennut(Item 12)
only to hold parts snug in position. Do not over tighten.
FIG. 3
11

98361C (05/07) PAGE4
FGDF710-10-1G FGDF710-10-2G
REPAIR SERVICE INFORMATION TOLL FREE NUMBER 1.800.260.6640
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.323.0620
ELKAY MANUFACTURING COMPANY • 2222 CAMDEN COURT • OAK BROOK, IL 60523 • 630.574.8484
PRINTED IN U.S.A.
DESCRIPTION
40089C
40048C
15005C
61313C
40169C
50986C
21781C
21782C
50189C
56092C
98118C
100322740560
15009C
55996C
66506C
31513C
31501C
31490C
30664C
70018C
20282C
50144C
19037000
66203C
66558C
66764C
20460C
21482C
21239C
21486C
35774C
35768C
36222C
36221C
75706C
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
*28
29
30
31
32
PARTNO.
Cover
Button
Regulator Retaining Nut
Regulator
Hex Nut
RegulatorHolder
Basin & Drain Assy.
Basin & Drain Assy. (GF)
Fan - Shroud
Poly Tubing (Cut To Length)
Bubbler Assembly
Washer
BubblerNipple
Strainer
Evaporator Assy
Cold Control
PowerCord
FanMotor
Fan Blade
Fan Blade Nut
Fan Motor Bracket
Grommet - Compressor Mtg.
Clip - Compessor Mtg.
Drier
Heat Exchanger
Condenser
Front Panel (Stainless Steel)
FrontPanel (Sandalwood)
Cabinet (Stainless Steel)
Cabinet(Sandalwood)
Compressor Serv. Pak FF10HBK
Cover - Relay
Overload
Relay
Stud - Compressor Mtg.
ITEM NO.
PARTS LIST 115V
*REPLACEWITHSAME COMPRESSORUSEDINORIGINALASSEMBLY.
NOTE: All correspondence pertaining to ELKAY water coolers or orders
for repair parts MUST include Model No. and Serial No. of cooler, name
and part number of replacement part.
12
FIG. 5
11
Glass Filler Shown for Reference Only.
Llenador de cristal demostrado para la
referenia solamente.
Remplisseur de verre montré pour la
référence seulement.
BASIN
DESCRIPTION
22543C
66505C
31505C
31430C
66202C
66508C
36085C
36195C
36050C
7
14
16
17
23
24
*28
30
31
PARTNO.
Basin & Precooler Assy.
Evaporator Assy.
PowerCord
FanMotor
Drier
Heat Exchanger
Compressor Serv Pak
Overload
Relay
ITEM NO.
PARTS LIST 230V-50/60Hz
