AirCFS-100S
02-47/2019 Rev.: 0
9
1
3
4
5
4
2
8
6
7
10
+
-
4
Click!
2b
1
+
-
3
Characteristics
EN
General instrucions
Cloud app assignment
It is done in your Smartphone application. Enter the relevant information on the product
cover into the application.
Set the sensing type (sensor LS, WS, MS or pulse output S0).
Internet of Things (IoT)
• The IOT wireless communications category describes the Low Power Wide Area
(LPWA). This technology is designed to provide full-range coverage both inside and
outside buildings, energy-saving and low-cost operation of individual devices. The
Sigfox network is available to use this standard.
Sigfox network information
• The network supports bidirectional communication but with a limited number of feed-
backs. It uses the free frequency band divided by Radio Frequency Zones (RCZ).
• RCZ1 (868 MHz) Europe, Oman, South Africa
• RCZ2 (902 MHz) North America
• RCZ3 (923 MHz) Japan
• RCZ4 (920 MHz) South America, Australia, New Zealand, Singapore, Taiwan
• Sigfox has more coverage across countries, so it is better suited for long distance mo-
nitoring.
• For more information on this technology, please visit www.sigfox.com.
Caution for proper operation:
• Products are installed according to the wiring diagram given for each product.
• For proper device functionality, it is necessary to have sucient coverage of the selec-
ted network at the installation site.
• At the same time, the device must be registered in the network. Successful device re-
gistration on a given network requires a charge for trac.
• Each network oers dierent tari options - it always depends on the number of me-
ssages you want to send from your device. Information on these taris can be found in
the current version of the ELKO EP pricelist.
Temperature, humidity,
atmospheric pressure sensor
Made in Czech Republic
Assembly
Description
• The AirCFS-100 is designed to measure temperature, relative humidity and atmo-
spheric pressure.
• The device incorporates the IP65 design, so it is possible to use it in agriculture in
outdoor areas (down sensor), e.g. vineyards, orchards ...
• It is also suitable for use in harsh indoor areas, which require greater protection of
the device, for example. Greenhouses.
• With the wireless solution and Sigfox communication, it can communicate instant-
ly to your chosen location and be operated immediately.
• Data is sent to the server from which it can be subsequently displayed as a smart-
phone, application, or Cloud notication
• Anti-sabotage: If access to the device is unauthorized, a message is immediately
sent to the server.
• Power supply 1x 3.6 V batteries SAFT.
• Battery power can be sent to the server when it is powered by a battery.
1. Tamper
2. Programming pins
3. Button SET
4. Hole for mounting on the wall
Ø 4.3 mm / 0.2”
5. Antenna
6. Battery
7. LED indication
8. Sensor connection terminal
9. Sensor cover
10. Sensor
1. Using a at-blade screwdriver gradually slide it into one groove and the other in the lid
and swing open the cover.
2. The product can be attached in two ways:
a) Directly on a at surface by gluing * - apply a suitable adhesive to the bottom of the
base. Place the base in the desired location and let it dry.
b) Using a suitable fastener ** by screwing - drill holes into the base with two holes of
suitable diameter corresponding to the position of the holes in the bottom of the box.
Place the base at the desired location and attach it with suitable bonding material
according to the substrate.
3. Insert the battery into the sensor and check correct location (the sensor functionality
message is sent to the application when the battery are inserted).
4. Replace and snap the front cover. When closing, the handles have to be snapped to their
original position. To ensure the degree of protection, tighten the grommet carefully.
* The glue must meet the optimal conditions for product placement (inuence of tem-
perature, humidity ...)
** For example, a screw or screw of max. Ø 4 mm can be used as a suitable fastener mate-
rial, 13 mm (distance to the partition in the box) must be added to the required length
for attachment to the substrate.
CleverFarm a.s.
Vídeňská 188/119d
619 00 Brno
www.cleverfarm.org

2 / 4
3
Click!
1
+
-
2
When handling a device unboxed it is important to avoid contact with
liquids. avoid unnecessary contact with the components of the device. Do
not touch the metal objects inside the unit.
Safe handling
Recommendations for installation
• Before mounting, check the range and location of the product and the antenna. Ensure
the correct location - see Warning.
• The sensor is suitable for outdoor use. Operating conditions are consistent with con-
ventional chemically non-aggressive environments.
• The recommended working position is vertical; sensor down.
• The product does not require special handling and maintenance.
Function
When the power is connected, the transmitter sends the initial message to the server.
Any unauthorized interference with a device immediately sends the message to the
server.
Temperature, humidity and press read every 5 minutes. Report on the measured values,
the sensor sends every 30 min.
Restart
• Open the cover. Power interruption (remove the battery from the device).
• Press SET> 1min.
• Connect power (insert battery). Close the cover.
Replacing batteries
1. Using a at-blade screwdriver gradually slide it into one and then the other groove in
the lid and swing open the cover.
2. Remove the discharged battery and insert a new battery into the holder. Beware of
polarity. Both LEDs will ash 3 times (see device status indication).
3. Replace and snap the front cover.
Notice:
Only use batteries designed for this product correctly inserted in the device! Immediately replace
weak batteries with new ones. Do not use new and used batteries together. If necessary, clean the
battery and contacts prior to using. Avoid battery shorts! Do not dispose of batteries in water or
re. Do not dismantle batteries, do not try to charge them and protect them from extreme heating
- danger of leakage! Upon contact with acid, immediately rinse the aected area with a stream of
water and seek medical attention. Keep batteries out of the reach of children. If it is suspected that
the battery has been swallowed or somehow placed inside the body, consult a doctor immediately.
Give the doctor information about the type of battery (from battery case, device or its manual, etc.)
to determine the chemical composition of the battery. Batteries must be recycled or returned to an
appropriate location (e.g. collection container) in accordance with local legal provisions.
Device states
When the tamper is pressed, the LED is turned o!
Note:
R... LED red
G... LED green
* 1) Planned
power supply (external or battery),
reset unit
error MAC / error MODULU
start unit ok
opening the cover
test, cancel,„long press“
temperature measurement, ...
sending / receiving data
it is necessary to disconnect the power
supply (external or battery), after 60 seconds
after the LED goes out, insert the battery
the battery may be discharged
a discharged battery or a damaged
product
Unit initialization
Start
SIM ERR *1)
ERR *1)
Successful network connection * 1)
Measurement
Tamper
SET button short press (< 2s)
Measurement signaling
Communication
Communication
Other known states
Does not respond to the SET
button
The unit is still in reset
The unit does not respond even
after removal insert the battery
Indication
3 x R + G blinks
5 x ashes R (repeatedly)
1 x ashes R
without indication
1 x ashes G
1 x ashes G
1 x ashes R
any LED lights
still indicates start
without indication

3 / 4
UPLINK / DOWNLINK
UPLINK
DOWNLINK
Note
0123456789
0x09 Heartbeat
period
Measurement
period
Threshold
Temperature
dierence
Threshold
Humidity 1
Threshold
Humidity 2
Threshold
Temperature 1
Threshold
Temperature 2
Threshold
Pressure 1
Threshold
Pressure 2
Heartbeat period 0 - 127 [x min]
Heartbeat message period
128 - 255 [(x - 127) h]
Measurement period 1 - 255 [s] Measurement period for temperature /
humidity
Threshold Temperature
dierence 0 - 50 [°C] Threshold dierence for temperature /
humidity
Threshold Humidity 1 0 - 100 [%] Threshold level 1 for humidity
Threshold Humidity 2 0 - 100 [%] Threshold level 2 for humidity
Threshold Temperature 1 -40 - 120 [°C] Threshold level 1 for temperature
Threshold Temperature 2 -40 - 120 [°C] Threshold level 2 for temperature
Threshold Pressure 1 900 - 1250 kPa Threshold level 1 for pressure
Threshold Pressure 2 900 - 1250 kPa Threshold level 2 for pressure
UPLINK
Byte 0 1 2 3
Bit 76543210
Version
FW Subversion FW Version FW Sigfox Subversion FW Sigfox
Name Unit Example
Battery V Battery =
30 + B
10
Temperature °C Temperature = (
(T - 1)
211 - 1 x 165)- 40
Humidity % Humidity =
H - 1
210 - 1 x 100
Press kPa Press = (
(P - 1)
212 - 1 x 250)+ 850
Byte0123 4
Bit 765432107654321076543210765432107654321 0
Battery (B) Temperature (T) Humidity (H) Press (P) Reserved

4 / 4
AirCFS-100S
WarningTechnical parameters
Read the operating instructions before installing the device and putting it into opera-
tion. Instruction manual is designated for mounting and also for user of the device. It is
always a part of its packing. Installation and connection can be carried out only by a per-
son with adequate professional qualication upon understanding this instruction man-
ual and functions of the device, and while observing all valid regulations. Trouble-free
function of the device also depends on transportation, storing and handling. In case you
notice any sign of damage, deformation, malfunction or missing part, do not install this
device and return it to its seller. It is necessary to treat this product and its parts as elec-
tronic waste after its lifetime is terminated. Before starting installation, make sure that all
wires, connected parts or terminals are de-energized. While mounting and servicing ob-
serve safety regulations, norms, directives and professional, and export regulations for
working with electrical devices. Do not touch parts of the device that are energized – life
threat. To ensure the transmission of the radio signal, make sure that the devices in the
building where the installation is installed are correctly located. Unless otherwise stated,
the devices are not intended for installation in outdoor and damp areas, they must not
be installed in metal switchboards or in plastic cabinets with metal doors - this prevents
transmission of the radio frequency signal. iNELS Air is not recommended for control-
ling life-saving instruments or for controlling hazardous devices such as pumps, heaters
without thermostat, lifts, hoists, etc. - radio frequency transmission may be overshad-
owed by obstruction, interference, transmitter battery may be discharged etc., thereby
disabling the remote control.
Power supply
Battery power:
Battery life by frequency *:
1x 10 minutes
1x 60 minutes
1x 12 hours
1x 24 hours
Setting
Setting:
Alarm Detection:
Battery status view:
Control
Control:
Inputs
Digital sensor:
Measuring range
Temperature sensor:
Tolerance:
Humidity sensor:
Tolerance:
Pressure gauge:
Tolerance:
Communication
Protocol:
Transmitter frequency:
Range in open space:
Transmission power (max.):
Other parameters
Working temperature:
Storage temperature:
Operating position:
Mounting:
Protection degree:
Dimension:
Weight:
1x 3.6V LS 14500 Li-SOCl2AA
0.4 years
2.1 years
8.5 years
9.9 years
With a message from the server
programming cable
message to the server
only when the battery is powered by a message on the server
button SET
Tamper
Temperature, humidity, atmospheric pressure
-40 .. +85 °C
± 1.5 °C
0-100 % RH
± 3% RH
300 - 1250 hPa
± 1.7 hPa
Sigfox
RCZ1 868 MHz
Approx. 50 km**
25 mW / 14 dBm
-30…+60°C (Pay attention to the operating
temperature of batteries)
-30…+70°C
sensor down
glue / screws
IP65
189 x 62 x 34 mm
122 g (Without battery)
The company ELKO EP, as the manufacturer, is entitled to make technical modications to the
product, in the technical specication and product manual, without prior notication.
* Values are calculated under ideal conditions
** Depending on network coverage
Other Elko Measuring Instrument manuals
Popular Measuring Instrument manuals by other brands

Unipro
Unipro UniStop V2 user guide

Leviton
Leviton VerifEye 6000 Series installation manual

Hofmann
Hofmann MC10 HS Operator's manual

PASCO
PASCO PASPort PS-2128 quick start

Thermo Scientific
Thermo Scientific Orion 8030cX instruction manual

Observator Instruments
Observator Instruments NEP-9500 Series user manual

LaserLiner
LaserLiner ActiveFinder One manual

GANN
GANN HYDROMETTE BL COMPACT TF 3 Operating instruction

Bently Nevada
Bently Nevada 3300/15 Operation manual

Seikom Electronic
Seikom Electronic NLSW 45-4 user manual

Hanna Instruments
Hanna Instruments HI 93711 user manual

International Light Technologies
International Light Technologies ILT1000 Application notes
