Elmo Huddle Space HS-G1 User manual

ELMO Huddle Space
HS-G1/HS-G2/HS-G3
取扱説明書
Please read this instruction manual carefully before using this product.

2
■IMPORTANT SAFEGUARDS
■Read Instructions
All the safety and operating instructions should be read before the appliance is operated.
■Retain Instructions
The safety and operating instructions should be retained for future reference.
■Heed Warnings
All warnings on the product and in the operating instructions should be adhered to.
■Follow Instructions
All operating and use instructions should be followed.
■Cleaning
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a damp cloth for cleaning.
■Attachments
Do not use attachments not recommended by the product manufacturer as they may cause
hazards.
■Water and Moisture
Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink,
or laundry tub, in a wet basement, or near a swimming pool, and the like.
The connector of this unit and the USB cable into the water or foreign matter, or not wet.
This could cause a fire or electric shock.
■Placement
Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product
may fall, causing serious injury to a child or adult, and serious damage to the product. Use
only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold
with the product. Any mounting of the product should follow the manufacturer’s instructions,
and should use a mounting accessory recommended by the manufacturer.
■Ventilation
Slots and openings in the cabinet are provided for ventilation and to ensure reliable
operation of the product and to protect it from overheating, and these openings must not be
blocked or covered. The openings should never be blocked by placing the product on a bed,
sofa, rug, or other similar surface. This product should not be placed in a built-in installation
such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s
instructions have been adhered to.
■Power Sources
This product should be operated only from the type of power source indicated on the marking
label. If you are not sure of the type of power supply to your home consult your appliance
dealer or local power company. For products intended to operate from battery power, or other
sources, refer to the operating instructions.

3
■Grounding or Polarization
This product may be equipped with either a polarized 2-wire AC line plug (a plug having
one blade wider than the other) or a 3-wire grounding type plug, a plug having a third
(grounding) pin. The 2-wire polarized plug will outlet, try reversing the plug. If the plug still
fails to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug. The 3-wire grounding type plug will fit into a grounding type
power outlet. This is a safety feature. If you are unable to insert the plug into the outlet,
contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of
the grounding type plug.
■Power-Cord Protection
Power-supply cords should be routed so that they are not likely to be walked on or pinched
by items placed upon or against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the product.
■Lightning
For added protection for this product during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage to the product due to lightning and
power-line surges.
■Overloading
Do not overload wall outlets, extension cords, or integral convenience receptacles as this
can result in a risk of fire or electric shock.
■A product and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the product and cart
combination to overturn.
■Object and Liquid Entry
Never push objects of any kind into this product through openings as they may touch
dangerous voltage points or short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
■Servicing
Do not attempt to service this product yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all servicing to qualified service
personnel.
■Damage Requiring Service
Unplug this product from the wall outlet and refer servicing to qualified service personnel
under the following conditions:
• When the power-supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into the product.
• If the product has been exposed to rain or water.
• If the product does not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will often require extensive work
by a qualified technician to restore the product to its normal operation.

4
• If the product has been dropped or damaged in any way
• When the product exhibits a distinct change in performance - this indicates a need for
service.
■Replacement Parts
When replacement parts are required, be sure the service technician has used replacement
parts specified by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
■Safety Check
Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks to determine that the product is in proper operating condition.
■Heat
The product should be situated away from heat sources such as radiators, heat registers,
stoves, or other products (including amplifiers) that produce heat.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the product.
SA 1966
SA 1965

5
FOR UNITED STATES USERS:
INFORMATION
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classeA est conforme à la norme NMB-003 du Canada.
This symbol [crossed-out wheeled bin WEEE Annex IV] indicates
separate collection of waste electrical and electronic equipment in
the EU countries.
Please do not throw the equipment into the domestic refuse.
Please use the return and collection systems available in your
country for the disposal of this product.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
The connection of a non-shielded equipment interface cable to this equipment will invalidate the
FCC Certification or Declaration of this device and may cause interference levels which exceed the
limits established by the FCC for this equipment. It is the responsibility of the user to obtain and use
a shielded equipment interface cable with this device. If this equipment has more than one interface
connector, do not leave cables connected to unused interfaces. Changes or modifications not
expressly approved by the manufacturer could void the user’s authority to operate the equipment.
This symbol [crossed-out wheeled bin Directive 2006/66/ECAnnex
II] indicates separate collection of waste batteries in the EU
countries.
Please do not throw the batteries into the domestic refuse.
Please use the return and collection systems available in your
country for the disposal of the waste batteries.
WARNING:
Handling the cord on this product or cords associated with accessories sold with this product,
will expose you to lead, a chemical known to the State of California to cause birth defects or
other reproductive harm.
Wash hands after handling.
THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT THIS PRODUCT MAY CAUSE
RADIO INTERFERENCE IN WHICH CASE THE USER MAY BE REQUIRED TO TAKE
ADEQUATE MEASURES.

6
BEFORE YOU USE
Power Supply
■Be sure to use the power cable and AC adapter that come with the product.
■The power cable and AC adapter that come with the product are for the product only. Do
not use them with another product.
■Be sure to use the AC adapter applicable to your local power specifications. If the product
was sold in Japan, use the AC adapter sold with the product with 100 VAC and 50 or 60
Hz.
Installation
■Do not place this product in any humid, dusty, salt bearing wind, or vibrating locations.
Use it under the following environmental conditions:
Temperature: 0°C - 40°C
Humidity: 30% - 85% (No condensation)
■Follow the guidelines below to prevent the unit from dropping or overturning.
• Use the product on a stable base, desk, or table. Do not place the product on an
unstable base or slanted location.
• Place or wire the product to prevent the cables such as power cable and AC adapter
cable from pulling.
Storage and Maintenance
■Make sure to turn off the power of the product before cleaning. Use a soft, dry cloth for
cleaning.
Do not use any volatile solvent such as thinner or benzene.
■When storing the product, do not leave it under direct sunlight or by heaters.
It may be discolored, deformed, or damaged.
Battery
■Remove the battery from the remote control when not in use for an extended period of
time.
■Do not use a rechargeable battery.
■Do not charge or short-circuit the battery.
■Follow the regulations of the city or town when disposing of the battery.
■Pay attention to the polarity (+ / - ) of the battery.
■Children may ingest small batteries; always keep batteries safe and out of reach.
If a battery is swallowed, consult a doctor immediately as this could result in asphyxiation
or be an obstacle to digestion, etc.
■If any liquid from a battery leaks onto your skin or clothes, flush the area with clean water
immediately. If it gets into your eye, flush immediately with clean water and then contact a
doctor.
■A battery is used for the internal clock. When you need to replace the battery, contact the
dealer from whom you purchased this product.

7
Other Precautions
■Do not open the cover of the product or disassemble the product. Doing so may cause
malfunction.
■Carry the product by holding the lower part of the main unit in both hands.
■Do not wrap the cable tightly during use, otherwise the cable may be broken.
■Save a backup copy before switching HDMI devices. Malfunction of the product may
occur due to a problem while switching the devices.
■If the product is used for longer than the warranty period, its performance and quality may
deteriorate due to the lifetime of its parts. For parts replacement (on chargeable basis),
consult the dealer from whom you purchased the product or our branch/office near your
location.
■ELMO shall not be liable for any loss of data or program occurred during the use of the
product.
■This product is designed to be used with the normal HDMI devices. It is not designed to be
used for the applications which require high-level reliability and security.
■There may be unexpected compatibility problems when different devices of different
manufacturers are connected to the product. Also, the full performance of the devices may
not be obtained when multiple devices are connected.
■About features
Functions and features may vary depending on the models. Some setting items or
functions are not available with some models.
■Copyright
Unless used for personal use, it is prohibited strictly under copyright law to use any data
recorded using the product without the prior consent of the copyright holder. Even if using
for personal use, be careful that there could be a situation where recording is restricted or
illegal.
■The contents of this document are subject to change without notice.
The latest version can be obtained from the following official website:
http://www.elmousa.com/
http://www.elmoeurope.com/
■It is prohibited under copyright law to use or copy any part or the whole of this document
without our prior written consent.
■ELMO shall not be liable for any claim for damage or loss of earnings or any claim raised
by a third person due to the use, malfunction or repair of this product.
■Recording / Playback
• We recommend that you make a test recording and playback before the actual
recording to ensure the normal video and audio recording operations.
• When the recording time becomes too long, the video file may be divided into multiple
files.
■Microphone
Connecting a microphone other than an electret condenser microphone (a microphone for
a computer) may cause malfunction.

8
■TABLE OF CONTENTS
■IMPORTANT SAFEGUARDS ·························································································································· 2
BEFORE YOU USE ···················································································································································· 6
■TABLE OF CONTENTS····································································································································· 8
➊PACKAGE CONTENTS ····································································································································· 9
➋FEATURE COMPARISON BY MODEL ······································································································· 10
■INTERFACE AND FUNCTIONS ··········································································· 10
■LED············································································································· 11
➌THE NAME OF EACH PART··························································································································· 12
➍BASIC OPERATIONS········································································································································· 16
■CONNECTING THE INPUT CABLE TO THE PRODUCT············································· 16
■CONNECTING THE OUTPUT CABLE TO THE PRODUCT ········································· 16
■TURNING ON/OFF THE POWER········································································· 16
➎SWITCHING THE DISPLAYED IMAGE ······································································································· 17
■SWITCHING THE INPUT SOURCE ······································································· 17
■REMOTE CONTROL ························································································ 17
➏RECORDING FEATURE ···································································································································· 19
■RECORDING TO THE SD CARD ········································································· 19
■RECORDING PROCEDURES ·············································································· 20
➐OTHER FEATURES············································································································································· 21
■REAL TIME CLOCK FUNCTION ·········································································· 21
■VIEWING FILES IN THE SD CARD ON A COMPUTER··············································· 21
■CONNECTING A COMMERCIALLY AVAILABLE HDBaseT DEVICE ······························ 22
■BATTERY FOR THE HUDDLE SPACE（OPTION）···················································· 22
➑TROUBLE SHOOTING······································································································································· 23
■SYMPTOMS AND SOLUTIONS··········································································· 23
➒SPECIFICATIONS················································································································································ 25
■GENERAL ····································································································· 25
■RESOLUTION / FRAMERATE ············································································ 26
■TRADEMARKS AND LICENSES ·········································································· 27

9
➊PACKAGE CONTENTS
The items below are included with the product. If any item is missing, contact the dealer from
whom you purchased this product.
The items included vary depending on the model. Note in advance that some items may not
be included depending on the model.
AC power cable（black）
AC adapter
⑩
Battery CR2025
(for remote control)
※For HS-G2/HS-G3 only
Huddle Space
USB cable（gray）
※For HS-G2/HS-G3 only
①
②
⑥
④
Warranty Card
(For Japan/ North America
only）
Quick Start Guide
⑤
HDMI cable
(TYPE A-micro) （1ｍ）
2pcs
Quick
Start
Guide
Warranty
Card
IR wireless remote control
※For HS-G2/HS-G3 only
③
※By destination shape is different
HDMI cable
(TYPE A-TYPE A) （1ｍ）
2pcs
⑨
⑧
⑦

10
➋FEATURE COMPARISON BY MODEL
Ports (input/output) and features vary depending on the models (HS-G1/ HS-G2/ HS-G3).
Refer to the below table for details.
■INTERFACE AND FUNCTIONS
INTERFACE
HS-G1
HS-G2
HS-G3
INPUT
MIC IN
-
○
○
HDMI IN（8 terminals）
○
○
○
Built-in microphone
○
○
○
DC IN 12V
○
○
○
OUTPUT
HDMI OUT
○
○
○
HDBaseT OUT
-
-
○
DC OUT 5V
○
○
○
RGB OUT
○
○
○
AUDIO OUT
-
○
○
USB
-
○
○
SD card slot
○
○
○
RECORDING
HS-G1
HS-G2
HS-G3
Still image recording
-
○
○
Video recording
○
○
○
AUDIO
HS-G1
HS-G2
HS-G3
INPUT
Built-in microphone
Possible to record to the SD card.
※Not possible to output the audio.
※The audio from the built-in microphone will not
be recorded when an external microphone is
connected.
External microphone
Audio of the
connected HDMI
device
Possible to output the audio.
※Not possible to record the audio.
OUTPUT
AUDIO OUT
The audio of the connected HDMI device is output
from this port.
※Available only when the output mode is set to
RGB.
※This feature is not available with the HS-G1.
※HDCP protected signal is not output.
Recording with audio
The audio from the built-in microphone or external
microphone will be recorded.
※The audio from the built-in microphone will not
be recorded when an external microphone is
connected.
※The audio of the connected HDMI device will
not be recorded.

11
■LED
※1．When the SD card cannot be recognized or when there is insufficient capacity on the
SD card or when the product is connected to a computer via the USB cable.
※2．When an input device is not connected or when HDCP signal (copy-protected signal) is
input.
FUNCTION
HS-G1
HS-G2
HS-G3
Playback
Use a media player on your computer to play the recorded files.
Operation with the remote
control
-
○
○
Mass storage mode
-
○
○
Clock function
○
○
○
Use with the Battery for
the Huddle Space (sold
separately)
○
○
○
LED COLOR
LED STATUS
Power LED
Standby
Red
ON
Power ON
Blue
ON
Channel LED
When selected
Green
ON
MIC MUTE LED
When MUTE is on
Green
ON
REC LED
When recording
Green
ON
When recording is not
possible ※1
Green
Quickly flashes 3 times
and then goes off
When there are
recording limitations ※2
Green
Flashing (Continuously)

12
➌THE NAME OF EACH PART
A．OPERATING PANEL
Name
Function
①
Power button
To turn ON/OFF the power.
Power ON ：LED lights up blue
Power OFF ：LED lights up red (Standby)
②
MIC MUTE
button
To mute or cancel mute of the microphone during recording.
③
REC button
To start or stop recording.
（The recorded video file and audio will be saved in the SD card.）
※The LED lights up during recording.
④
Channel buttons
（8ch）
Switch the channel of the image to be input to the product.
⑤
Built-in
microphone
To record surrounding voice and sound during video recording.
Remote control sensor
①
B. INPUT TERMINALS
B. INPUT TERMINALS
B. INPUT TERMINALS
C. REAR PANEL
②
③
④
④
⑤

13
B．INPUT TERMINALS
Matrix of HDMI input connectors and HDMI devices
HDMI device
Windows PC / Chromebook
HDMI input connector
HDCP non-compliant
(Channel 1,3,5,7)
HDCP compliant
(Channel 2,4,6,8)
Input image
Normal image
(Not protected)
protected by
HDCP
Normal image
(Not protected)
protected by
HDCP
HDMI OUT
HDBaseT OUT
〇
×
〇
〇
RGB OUT,AUDIO
OUT
Video recording,
Still-image recording
〇
×
〇
×
Name
Function
①
MIC IN port
To connect an external microphone (electret condenser
microphone) to input audio from the external microphone.
※When the external microphone is connected, the built-in
microphone is disabled.
②
SD card slot
To insert the SD card (commercially available).
To remove, push in again, then pull out.
③
HDMI input ports
（HDCP
non-compliant）
（Channel 1,3,5,7）
To switch among the input devices with the Channel buttons.
Connect a device such as Windows PC or Chromebook to HDCP
compliant connectors (channel 2,4,6,8). Devices such as DVD
player or Android device can be connected to HDCP compliant
connectors (channel 2,4,6,8) to display images. (The recording
cannot be performed.)
Connect an Apple device such as iPhone, iPad, or MacBook to
HDCP non-compliant connectors (channel 1,3,5,7).
Refer to “Matrix of HDMI input connectors and HDMI devices” for
details.
④
HDMI input ports
（HDCP
compliant）
（Channel 2,4,6,8）
①
②
④
③

14
HDMI device
Blu-ray player / DVD player / Android device
HDMI input connector
HDCP non-compliant
(Channel 1,3,5,7)
HDCP compliant
(Channel 2,4,6,8)
Input image
Normal image
(Not protected)
protected by
HDCP
Normal image
(Not protected)
protected by
HDCP
HDMI OUT
HDBaseT OUT
×
×
〇
〇
RGB OUT,AUDIO
OUT
Video recording,
Still-image recording
×
×
×
×
HDMI device
iPad / iPhone / MacBook
HDMI input connector
HDCP non-compliant
(Channel 1,3,5,7)
HDCP compliant
(Channel 2,4,6,8)
Input image
Normal image
(Not protected)
protected by
HDCP
Input image
Normal image
(Not protected)
HDMI OUT
HDBaseT OUT
〇
×
〇
〇
RGB OUT,AUDIO
OUT
Video recording,
Still-image recording
〇
×
×
×
CAUTION
・We do not guarantee the compatibility with all the commercially available HDMI devices
(including HDMI conversion tools).
・The above matrix shows only examples.
Be sure to verify the compatibility with the HDMI device to be connected before actually
using it with the Huddle Space.

15
C．REAR PANEL
Name
Function
①
Output mode
selection switch
To set the output video mode of the selected channel.
（RGB／HDBaseT／HDMI）
※The HDBaseT mode is for HS-G3 only.
②
DC IN 12V port
To connect the DC plug of the supplied AC adapter.
③
USB port
To connect to a computer via the supplied USB cable to play video
files or audio files on the SD card.
Use a media player on your computer to play the recorded files.
（※The USB cable is not included in the HS-G1.）
④
AUDIO OUT
port
To output audio. (The audio cable is not included in the product.)
※This function is available only when the analog RGB output is
selected.
※HDCP protected signal is not output.
⑤
RGB OUT port
To output analog RGB images.
(The RGB cable is not included in the product.)
※HDCP protected signal is not output.
⑥
DC OUT 5V port
To supply DC5V power to an external WHDI module (commercially
available).
※WHDI module only, please use.
⑦
HDBaseT OUT
port
To connect to a projector or monitor which has an HDBaseT port, or
to the Receiver Box (commercially available) via a commercially
available Ethernet cable (Cat5e or higher).
⑧
HDMI OUT port
To output digital images and sound.
(The HDMI cable is included in the product.）
マークの画を
もらう
⑦
⑥
⑤
④
③
②
①
⑧

16
➍BASIC OPERATIONS
■CONNECTING THE INPUT CABLE TO THE
PRODUCT
After connecting the HDMI cable to the device, connect it to the HDMI input port of the product.
Repeat the same when multiple devices are connected.
■CONNECTING THE OUTPUT CABLE TO THE
PRODUCT
Connect the output port in the rear panel of the product and the input port of the output device
(such as a monitor or projector) with an appropriate cable.
■TURNING ON/OFF THE POWER
TURNING ON THE POWER
①Connect the product and the supplied AC adapter. Connect the AC adapter to an AC outlet.
②Connect each HDMI device to the product with the HDMI cable.
③Connect a video cable corresponding to an image display device to the product.
④Press the Power button to turn on the power.
TURNING OFF THE POWER
①Press the Power button for long to turn off the power.
②Remove the video cable from the product. Disconnect the AC adapter from the AC outlet.

17
The supplied remote control uses a coin cell battery, type “CR2025”.
➎SWITCHING THE DISPLAYED IMAGE
■SWITCHING THE INPUT SOURCE
The HDMI device to input can be selected by the following methods:
※Make sure that the Output mode selection switch is set correctly.
＜Switching with the Channel buttons on the Operating panel＞
Select the desired port by pressing the Channel button（①～⑧）on the Operating panel.
The video of the HDMI device connected to the selected port appears.
＜Switching with the remote control＞
Select the desired port by pressing the Channel button（①～⑧）on the remote control.
The video of the HDMI device connected to the selected port appears.
【CAUTION】
The time it takes to change the channel may differ depending on the connected device.
■REMOTE CONTROL
The input source can also be switched from the remote control.
PREPARATION OF THE REMOTE CONTROL
Remove the cover in the back of the remote control and insert the supplied battery.
REMOTE CONTROL OPERATIONS
Button
Name
Function
①～⑧
Channel buttons
To select the HDMI input for CH.
REC button
To start/stop recording.
（The recorded video file will be saved
in the SD card）
Capture button
To capture still images.
（The captured image will be saved in
the SD card.）
MIC MUTE
button
To mute the microphone during
recording.
マークの画を
もらう
NOTE

18
The receivable range may be reduced when the product is placed in direct sunlight or near
an inverter fluorescent light.
Depending on the surrounding environment, the receivable range may be shorter or the
sensor may fail to receive any infrared light. In such cases, relocate the product or shield
the light source.
【CAUTION】
●About Recording
There are cases where recording is not possible.
In that case, LED of the REC button flashes.
For details, refer to “➏RECORDING FEATURS”.
RECEIVING SIGNAL FROM THE REMOTE CONTROL
Point the transmitter of the remote control at the receiver of the product. Then press the
desired button.
PAIRING OF THE REMOTE CONTROL
By pairing the remote control with the product, the remote control works as a dedicated
remote control for the product.
HOW TO DO THE PAIRING
①While the product is powered off, press the Power button of the product for long. Then press
the Channel button ①of the remote control three times.
②Check that the pairing is successfully completed. (The Channel LED of the 8 Channel
buttons of the product will flash 2 times.)
HOW TO CANCEL THE PAIRING
①While the product is powered off, press the Power button of the product for long. Then press
the Capture button of the remote control three times.
②Check that the pairing is cancelled. (The MIC MUTE LED and REC LED will flash 2 times.)
NOTE
Remote control sensor

19
・It may take some time to recognize the SD card after inserting it or to save images to
the SD card.
・Do not remove the SD card when it is in read/write operation.
・If you want to turn off the power during recording, press the REC button to stop
recording and then long press the Power button to turn off the power.
➏RECORDING FEATURE
■RECORDING TO THE SD CARD
You can record still images and videos of the device connected to the product via the HDMI
cable as well as the audio from the built-in microphone or external microphone to the SD card.
※Before you begin, insert a commercially available SD card into the SD card slot under the
Operating panel.
※The product records a displayed image as well as the audio from the built-in microphone
or external microphone.
※When an external microphone is connected, only the audio from the external microphone
will be recorded.
※The audio of the connected HDMI device will not be recorded.
The product is not equipped with a playback feature.
Remove the SD card from the product and insert into your computer or connect the product
and your computer with the supplied USB cable in the Mass Storage mode to playback the
recorded still images or videos.
※The Mass Storage feature is not available with the HS-G1.
Recording limitations
The recording is not possible in the following cases:
①The product is connected to a computer with the USB cable.
②The HDCP protected signal is input to the selected channel.
③An HDMI cable is not connected to the selected channel.
※The REC LED flashes when the recording (still image/ video) is not possible.
※The REC LED starts to flash when ②or ③occurs during video recording. (Only the
audio from the built-in microphone will be recorded in this case.)
④The SD card does not have enough capacity.
マークの画を
もらう
NOTE
CAUTION
・Depending on the type of the SD card being used, it may not be used with the product.
・Transfer the data from the SD card onto a device such as a computer to save a
backup copy.
・When inserting the SD card, pay attention to its direction.
･Supported SD cards: SD, SDHC,
SDXC （64 GB or less: Using the SD card class 6 or higher is
recommended.）

20
or
■RECORDING PROCEDURES
This section explains how to record still images and videos of the device connected to the
product via the HDMI cable as well as the audio from the built-in microphone or external
microphone to the SD card.
Video （MP4 file / Image size：1080p/30fps）
①Select the desired channel from 8 HDMI input channels.
Press the Channel button to perform the recording.
②Confirm that the image of the selected device is
displayed on the monitor.
③Press the REC button of the remote control or the
product.
④The REC LED turns during the recording.
Press the REC button again to stop the recording.
【CAUTION】
・Do not remove the SD card while the LED is on.
・The REC LED flashes when the recording is not possible due to the recording limitations.
・The product records the audio from the built-in microphone when an external microphone is
not connected. When an external microphone is connected, only the audio from the external
microphone will be recorded.
Still image （JPEG file / Image size：1920×1080）
①Select the desired channel from 8 HDMI input channels.
Press the Channel button to perform the still image capturing.
②Confirm that the image of the selected device is displayed on the monitor.
③Press the Capture button on the remote control.
The still image of the selected channel will be captured.
④The REC LED turns for a few seconds. It will go off when the saving
of data is completed.
【CAUTION】
・Do not remove the SD card while the LED is on.
・The REC LED flashes when the still image capturing is not possible.
・The REC LED flashes once when a still image capturing is performed during recording.
マークの画を
もらう
CAUTION
・We recommend that you make a test recording and playback before the actual recording
to ensure the normal video and audio recording operations.
・When the recording time becomes too long, the video file may be divided into multiple
files.
・Unless used for personal use, it is prohibited strictly under copyright law or international
treaty to use any photo files or movie files without the prior consent of the copyright
holder. Even if using for personal use, be careful that there could be a situation where
video or audio recording is restricted or illegal.
