ELMO EDR–X116 Rack Mount Chassis
Series
FEATURES
! 16 video channel inputs @ 120 fps
! Simultaneous recording, playback, & remote access
! Digital watermark with verification software
! Call (spot) monitor output @ 30 fps
! LAN, WAN and dial-up connectivity (via TCP/IP) software provided
! P.O.S. and ATM ready (optional)
! Browser based monitoring
! Event log file function
! Backup remotely via static IP, LAN, or CD Burner
! Multiplexed output
! Remote software provided for infinite users
! PAN/TILT Zoom Control
! Intelli Guard/control output/email/dial up
! Health Checking Function

ELMO EDR - X116 Rack Mount Chassis
Model Specifications
EDR-X116 - 16 video inputs 120 FPS
Video Input & Image Quality
Video input 1VPP, 75 OHM typical
Connector for BNC
Proprietary compression
Resolutions 160x120, 320x240, 640x480
Maximum display 16 cameras 120 fps
Maximum recording 1-4 cameras120fps, 8 cameras
120fps, and 16 cameras 112fps
Video Output
Main monitor VGA (1024x768)
Connector type DB-15 HD (SVGA)
Call (spot) monitor 1Vpp, 75 OHM
Multiplexed output on monitor
Audio
Recording and playback 1 channel (line mic and line out)
Connectors are 1/8” mini phone jacks
Alarm Inputs and Outputs
Number of inputs & outputs: 16 (non isolated for dry
contact sensors)
Connectors screw less & terminal blocks
Connectivity
LAN / WAN 10/100 Ethernet card
Modem
Connector (dial-up) DB-9 or telephone jack RJ-12
Transmission Speed LAN: 120 Frame/Sec, PSTN: 1~5
Frame/Sec, ISDN: 3~10 Frame/Sec
Hardware
PC based, Windows 2000™
Internal 180 GB hard disk drive (upgradeable to a total of
6 HD-with upgrade in Power Supply and IDE Card)
CDRW & 1.44 MB floppy drive
Pentium IV up to 1.8GHz or higher, 256 MB RAM, 64 MB
Graphic Card
Electrical
Power source 115-120 VAC; 50-60 HZ switchable,
maximum 350W
Mechanical
Rack mount design
Steel case
Environmental
Dimensions: 440mm wide x 452 mm deep x 175 mm
high or (17.32"x17.8 "x6.89")
Approx. weight: 40lbs or 18.18 kg
Operating Temperature: 5º to 40ºC, 41º to 104ºF
Operating Humidity below 90% RH
Warranty
Coverage provided is 3 years for parts & labor and 1 year
parts & labor for hard drive
Shipping not included
Video Standards
NTSC/EIA is standard, while PAL CCIR is available upon
request
Key Features and Benefits
! 1-16 video channel inputs
! Simultaneous recording and
playback
! Digital watermark
! Printer hardcopy/JPEG/BMP to
diskette
! Call (spot) monitor output
! LAN, WAN and dial-up connectivity
(via TCP/IP)
! P.O.S. and ATM ready (optional)
! Web security ready (Browser
Access)
! Event log file function
! 'Video Loss' or 'No Video Alarm'
when camera(s) off will control the
relay output
! Drop/drag pictures on the remote
! Backup remotely via static IP or
LAN & CD Burner
! PAN/TILT Zoom Control
! Intelli Guard/control
output/email/dial up/voice
command
! I.P.C.O.
