USER MANUAL
Elo Touch Solutions
ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
UM600504 Rev A

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
2
Copyright © 2020 Elo Touch Solutions, Inc. All Rights Reserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or
by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission of Elo Touch Solutions, Inc.
Disclaimer
The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its Affiliates (collectively “Elo”) make no representations or warranties
with respect to the contents herein, and specifically disclaim any implied warranties of merchantability or fitness for a particular purpose. Elo reserves the right to revise
this publication and to make changes from time to time in the content hereof without obligation of Elo to notify any person of such revisions or changes.
Trademark Acknowledgments
Elo, Elo (logo), Elo Touch,Elo Touch Solutions and TouchPro are trademarks of Elo and its Affiliates. Windows is a trademark of Microsoft Corporation.

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
3
Table of Contents
Section 1: Introduction ............................................................................................................................................................................................................................... 4
Section 2: Installation................................................................................................................................................................................................................................. 5
Section 3: Mounting ................................................................................................................................................................................................................................... 8
Section 4: Operation ................................................................................................................................................................................................................................ 14
Section 5: Technical Support................................................................................................................................................................................................................... 15
Section 6: Safety & Maintenance............................................................................................................................................................................................................. 17
Section 7: Regulatory Information............................................................................................................................................................................................................ 18
Section 8: Warranty Information............................................................................................................................................................................................................... 26

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
4
Section 1: Introduction
Product Description
Your new touch monitor combines the latest developments in touch technology and display design with reliability for use in high-traffic environments.
This touch monitor incorporates a 24-bit color, active matrix thin-film-transistor LCD panel to provide high-quality display performance. The 03 Series
includes full sizes from 19 to 27 inches and supports resolutions from 1280 x 1024 to full HD 1920 x 1080. Its LED backlight significantly reduces power
consumption and eliminates the need for mercury (compared to CCFL-backlit panels). Other features that enhance this LCD monitor’s performance are
Plug & Play compatibility, remote on-screen display (OSD) controls and flexible mounting options.
This monitor is DICOM 14 compliant and follows AAPM-TG18 secondary medical display criteria (less than 20% variance in contrast). The monitor can
be used in a variety of non-diagnostic healthcare applications and environments including: self check-in/registration or point-of-information in hospitals
and clinics, EHR review, various kinds of modality where image reconstruction, reprocessing, or post-processing is required, clinical image review, ER,
and surgical applications. The monitor is powered by an externally recognized AC/DC adaptor.
Precautions
Follow all warnings, precautions and maintenance as recommended in this user manual to maximize the life of your unit and prevent risks to user safety.
See the Safety & Maintenance Section for more information.
This manual contains information that is important for the proper setup and maintenance of the unit. Before setting up and powering on your new touch
monitor, read through this manual, especially the Installation, Mounting, and Operation Sections.

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
5
Section 2: Installation
Unpacking the Touch Monitor
Open the carton and verify that the following items are present:
• Touch monitor with stand
• Quick Install Guide
• VGA cable
• HDMI cable
• USB cable
• Audio cable
• Power brick
• Europe power cord
• North America power cord
• 3 x tie wraps
• EEI Label
• 2 x cable cover screws
• DICOM calibration sheet

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
6
Connector Panel
Note: Cable tie-down points can be used to tie down the cables with tie wraps. Simply loop the tie wraps through the cable tie-down points and around
the cable to secure cable connections.
Touch Monitor Connections
1. Connect one end of the HDMI or VGA video cable to the monitor’s HDMI/VGA input connector and the other end to yourHDMI/VGA video source. (Tighten the
video cable’s screws on the VGAconnector for best performance.)
2. Connect the USB touch cable between the monitor’s USB connector and your PC’s USB port. (Optional RS232 serial touch connection via option Y-cable
E810917, this Y-cable can also connect as the VGA video source)
3. Connect the audio cable between the monitor’s Audio Out and your audio source.
4. Connect the power adaptor’s input connector to the power source. Connect the power adaptor’s DC output connector to the monitor’s input power jack.
5. The touch monitor ships in an OFF state. Press the power button to turn it on.

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
7
Installing the Touch Technology Software Drivers
No additional drivers are required for your projected-capacitive touch monitor with Windows 7 or 10 operating systems, as it will use the Windows HID
drivers.
If the monitor is used with the Windows XP operating system or you want to use RS232 touch (touch via COM port), follow the steps below to install the
Windows XP touch driver.
To download the latest touch drivers:
1. Visitwww.elotouch.com/Support/Downloads/Driver/DriverDownload/Default.aspx
2. Select the operating system from the Operating System drop-down menu.
3. Select the technology from the Technologies drop-downmenu.
4. Download the driver version required for your touch monitor. (later than 7.0 for RS232 touch)
For RS232 touch, please check with and Elo sales rep or Elo support team to purchase the Elo Y-cable (Elo P/N: E810917) separately.

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
8
Section 3: Mounting
Rear VESA Mount
A four-hole 100 x 100 mm mounting interface for M4 screws is provided on the rear of the monitor. Remove the stand using a Phillips screwdriver to
access the mounting interface. The VESA FDMI-compliant counting is coded VESA MIS-B, 75, C and VESA MIS-D, 100, C.

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
9
Base Mount
The VESA FDMI-compliant counting is coded VESA MIS-E, C.
ET1903LM & ET2203LM base mounting options are shown below.

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
10
ET2403LM & ET2703LM base mounting options shown below.

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
11
Magnetic Stripe Reader (MSR) Installation (Optional)
Your monitor comes with four pheripheral ports, located at the top, bottom, left and right sides of the monitor. To mount an MSR, remove one of the
pheripheral port covers with your finger tips and install the MSR as shown below. Please refer to the MSR Quick Install Guide (QIG) for set-up details.

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
12
Wall Mount
Mount the wall bracket to the wall using six fasteners appropriate for the type of wall material and following all applicable building code standards.
Ensure the unit is mounted to a solid structure and surface, such as a support beam or wall.
Attach the other bracket to the monitor using the four M4 screws included in the kit.
Hang the monitor on the wall bracket and secure using two M3 screws included with the kit on the left and right side of the bracket.

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
13
Handles Installation (Optional)
Optional handles can be installed on 03 Series monitors, as shown below. Please note that it is not recommended to use handles to carry the touch
monitor. Damage to the touch monitor will occur if the touch monitor is lifted by the handles. Use handles only to adjust the tilt angle.

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
14
Section 4: Operation
Power
To turn the touch monitor on or off, press the touch monitor’s power button once.
The Power Status LED on the bottom of the touch monitor functions as follows:
Touch Monitor Status
LED Status
OFF
OFF
SLEEP
PULSING (Orange)
ON
ON ( Green)
The system consumes low power when in SLEEP or OFF modes. For detailed power-consumption specifications, refer to the technical
specifications on the Elo website http://www.elotouch.com
Touching the screen will bring the attached host PC out of SLEEP mode (similar to moving the mouse or pressing a keyboard key).
To improve reliability and reduce wasteful power consumption, disconnect the AC power cable from the monitor when long periods of disuse are planned.
Touch
No calibration is required for projected capacitive touch technology. Your touch monitor can support up to 10 touches (2 touches for RS232 touch) at
once.
Note: When using a privacy filter with your monitor, it is important to update the touch configuration file of you monitor to support touch.
For 2 touches with 3mm cover glass support, simply go to the OSD menu and enable the touch-through function (Recommendpower cycle). Do not forget to
disable the touch-through function when using the monitor without a privacy screen.
Touch Technology & Capacity
TouchPro® PCAP - up to 10 touches with palm rejection and touch through capability.
Direct Touch
Support 10 touches with direct finger, capacitive stylus, privacy filter, and/or latex gloves (2 layers).
Touch Through
Support up to 3mm glass with up to 2 touches. Limited power palm support.

User Manual –ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
10
Projected Capacitive Touch Technology
When connected to Windows 7 or 10 computers, the touch monitor can detect 10 simultaneous touches. When connected to Windows XP computers, the
touch monitor detects only single touches.
No additional drivers are required for this technology to work with Windows 7 or 10, as it uses Windows HID drivers.
Refer to Section 2, “Installing the Touch Technology Software Drivers,” for instructions on downloading touch drivers for Windows XP or RS232 touch.
No calibration is required for this technology.

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
11
Gesture Support
TouchPro PCAP technology enables several gestures that support single and multiple touches. Refer to the Microsoft website at
http://msdn.microsoft.com/en-us/library/dd940543 on the various gestures that are supported in Windows 7, 8, 10 and later OS versions.
Video
A display’s native resolution is its width and height measured in pixels. Generally, for best performance, an image displayed on this monitor will look best
when your computer’s output resolution matches this monitor’s native resolution, which is 1280 x 1024 for the 1903L and 1920 x 1080 for the 2203L, 2403L
and 2703L monitors
For computer output at non-native resolutions, the monitor will scale the video to its panel’s native resolution. This involves stretching or compressing the
input image as needed in the X and Y dimensions to fit the display’s native resolution. An unavoidable byproduct of the scaling algorithms is a loss of
fidelity when the computer’s output video image is scaled by the monitor to fit the display. This loss of fidelity is most apparent when viewing feature-rich
images at close distances (e.g., images containing small-font text).
Your touch monitor will likely not require video adjustments. However, for analog VGA video, variations in video graphic card outputs may require user
adjustments through the OSD to optimize the quality of the touch monitor’s displayed image. These adjustments are stored by the touch monitor. Also, to
reduce the need for adjustments for different video mode timings, the monitor correctly scales and displays some of the video industry’s most common
video timing modes. Refer to the technical specifications for this monitor at http://www.elotouch.com for a list of these Preset Video Modes.
On-Screen Display (OSD)
Five OSD buttons are located on the rear of the monitor. These can be used
to adjust various parameters. The buttons and their functionalities are:
Button
Function when OSD is not displayed
Function when OSD is displayed
Menu
Display OSD Main menu
Return to previous OSD menu
Display OSD Contrast submenu
Decreasevalueof selectedparameter/selectpreviousmenuitem
Display OSD Brightness submenu
Increase value of selected parameter/select next menu item
Select
Display Video Priority submenu
Select parameter for adjustment/select submenu to enter
Power key
Power on/off display

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
12
The OSD buttons control an on-screen graphical user interface that overlays your input video, allowing the following adjustments:
Parameter
Available Adjustment
Brightness
Increases/decreases monitorbrightness.
Default:maximum
Contrast
Increases/decreases monitorcontrast.
Default:bestgray-shadeperformance
Clock
Allows fine adjustments of the panel’s pixel dot clock.
Applicable for VGA input video only.
Phase
Allows fine adjustments of the panel’s pixel dot clock phase.
Applicable for VGA input video only.
Auto Adjust
Automatically adjuststhe system clockto the input analog VGA videosignal, affectingthe H-position,V-position, Clock, and Phasemenuitems.
Applicable for VGA input video only.
H-position
Movestheimagehorizontallyon the displayin single-pixelincrements.
Default:centered
Applicable for VGA input video only.
V-position
Movestheimageverticallyon thedisplayin single-pixelincrements.
Default:centered
applicable for VGA input video only.
Aspect Ratio
SwitchesthescalingmethodbetweenFullScalingandMaintainAspectRatio.Default:
FullScaling
Full Scaling: Scales the X and Y dimensions of the input video (up or down as needed) to the display’s native resolution.
Fillto Aspect Ratio:Assuminga landscapeorientationand an inputvideowithaspectratiosmallerthan16:9, scalestheYdimensionof theinputvideo(upordown
asneeded)tothedisplay’s Yresolution,scalestheX-dimensiontomaintaintheinputvideo’s aspectratio,andfillstherestofthedisplaywithequalblackbarsonthe
leftandright.
Other touchscreen technologies may need recalibration when switching between Aspect Ratio options.
Sharpness
Adjusts sharpnessof thedisplayedimages.
Default:no sharpnessadjustment
Applicable at non-native input video resolutions only.
Color Temperature
Selectsthedisplay’s color temperature.Theavailablecolortemperaturesare 9300K,7500K,6500K,5500KandUserDefined. If the UserDefinedoptionis
selected,theusercanchangethecolortemperaturebychangingindividualR,G,andBgainsonascalefrom0to100.Default:UserDefinedwithR,G,andB
allsetto100.

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
13
Parameter
Available Adjustment
OSD H-Position
Adjusts the horizontallocationof the OSDmenuson the display. Default:centered
OSD V-Position
AdjuststheverticallocationoftheOSDmenusonthedisplay.Default:centered
OSD Timeout
AdjustshowlongthetouchmonitorwillwaitwithoutOSDbuttonactivitybeforeclosingtheOSD.Theadjustablerangeisbetween5and60seconds.
Default: 15 seconds
OSD Language
Selectsthe OSD’s display language. Theavailablelanguagesare:English,French,Italian,German,Spanish,SimplifiedChinese,TraditionalChinese,andJapanese.
Default: English
Recall Defaults
Restores allfactorydefaultsettingsfor OSD-adjustable parameters (except OSD Language) and for Preset VideoModetimings.
Video Priority
The monitor continually scans for active video on the VGA and HDMI connectors.
Thisadjustmentselectswhichof thoseinputportsshouldbegiventhepriorityfordisplay. Theoptionsare:VGAPriority,HDMIPriority.
Default: HDMI Priority
Audio
Audio menu enables users to switch between audio sources. When HDMI is plugged in, internal speakers can be used by changing the audio source
to HDMI. This menu includes the headphone feature as well, which will allow users to plug in an external audio source when using HDMI. When using
the VGA Line in option, it can be used to enable internal speakers.
Power LED
OptiontoturnthepowerLEDON/OFF.
Default:On
Touch Through
Enablestouchcapabilitieswhenusing2touches with 3mmcoverglass.Recommendpower cycle.
DICOM mode
SelectDICOMwillmakecontrastresponsefollow AAPM-TG18(20%).
All touch monitor adjustments made through the OSD are automatically memorized as soon as they are modified.
This feature prevents having to reenter the settings every time the touch monitor is unplugged or powered off.
In case of a power failure, the touch monitor settings will not default to the factory specifications.

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
14
OSD and Power Lockouts
Press and hold the “Menu” and “ ” buttons simultaneously for two seconds to enable/disable the OSD Locking feature. When OSD Locking is enabled,
pressing any of the Menu, Up, Down or Select keys will have no effect.
Press and hold the “Menu” and “ ” buttons simultaneously for two seconds to enable/disable the Power Locking feature. When Power Locking is
enabled, pressing the power switch will have no effect.

User Manual ET1903LM, ET2203LM, ET2403LM, ET2703LM REVB
15
Section 5: Technical Support
If you are experiencing trouble with your touch monitor, refer to the following suggestions.
If the problem persists, please contact your local dealer or contact Elo Touch Solutions Customer Service. Worldwide technical support phone numbers
are available on the last page of this user manual.
Solutions to Common Problems
Problem
Suggested Troubleshooting
The touchmonitor does not respondwhenturning on
the system.
Checkthatthe DC poweradaptoris properlyconnected.Verifythe
DC poweradaptoris functioning
Monitor display is dim.
Use theOSD to increasethe brightness.
Use theOSD to increasethe contrast.
Monitor display is blank.
IfthePowerStatusLEDisblinking,themonitororComputerModulemaybeinSLEEPmode.Press
any key/movethe mouse/touchthe touchscreento seeif the image reappears.Checkthatthesignal
sourcedeviceisturnedon.
Check that that there are no loose cable connections.
Monitor displaysthe “Out of Range” message.
Adjustyourcomputer’s resolution/timing modeto be withinthe allowabletimingranges
specifiedfor your touchmonitor(see websitefor specifications).
Monitor display image looks strange.
Adjustyourcomputer’s resolution/timing modeto be withinthe allowabletimingranges
specifiedfor your touchmonitor(see websitefor specifications).
Use the Auto Adjust function in the OSD.
Touch functionality doesn’t work.
Verify your PC has the latest Elo drivers installed.
Perform the calibration routine provided with the latest Elo drivers.
Neither the OSDnor powerbuttons
respondswhen pressed.
Check to see if the OSD lock or power lock functions are on.
No touch, or touch is not accurate when using
privacy filters.
Check if the touch-through mode is enabled for 19”/22” monitors.
Monitor turns off by itself.
If the monitor turns off by itself, it could be due to a voltage drop (to below 10 V) in the building. The
monitor will turn itself back on once it receives minimum 11 V of power.
