Emerson EASYHEAT MSA-1 Installation instructions

GENERAL
The MSA‑1 sensor detects falling or blowing snow coming
in contact with the sensor grid, then sends a signal to the
MSC‑1 to energize heating equipment (snow melting or de‑
icing cables, etc.).
The sensor operates on low voltage supplied by the MSC‑1
control unit and has a built in 1/2" NPT conduit connection
and includes 10´ of wire for connection back to the MSC‑1.
The MSA‑1 is well suited for mast mounting and custom
positioning. Rounded features and neutral colour allows
the sensor to discreetly blend into almost any environment.
The MSA‑1 connection wire may be extended up to 500´
with an appropriately rated 18‑20 AWG 3 wire unshielded
stranded cable.
The main components of them MSA‑1 are shown in Fig.1.
WARNINGS
1. Thisisnota“do-it-your-self”product.Aqualied
electrician must install the MSA‑1.
2. If after carefully reading these instructions you still
have questions regarding installation, operation or
maintenance of this product, call the numbers listed for
assistance.
3. Prior to installation, check the MSA‑1 body enclosure
or wires for possible shipping damages. Do not install a
damaged MSA‑1 sensor.
4. All heating equipment, controls & associated systems
must be installed in compliance with the latest editions
of all applicable electrical codes and ordinances.
5. The MSA‑1 has been designed for the sole purpose
of connection to an EasyHeat MSC‑1 Control Panel.
TheriskofreorelectricshockexistsiftheMSA-1is
connected to any device other than an MSC‑1 Control
Panel.
6. These instructions must be saved and made available
to owners or users of this product and/or transferred to
future owners.
8. Secure the MSA‑1 in an area free of obstructions such
as trees, shrubs, etc. to prevent any damages to the
snow sensor.
9. Avoid excessive shock or vibration.
10. Do not install an MSA‑1 Sensor when the ambient
temperature is colder than 32°F (0°C). Installing the
sensor below this temperature will damage the
connectionwireandresultintheriskofreor
electrical shock.
©2009 Easy Heat www.easyheat.com 14068-001 Rev. 3
MSA-1 Aerial Moisture Sensor for Connection to MSC‑1 Panel for Snow & Ice
Melting Installations Installation & Operation Instructions
Figure 1 Moisture Sensor
10´ Connection
Wire
MSA
Housing
Mounting
Connector
(1 /2" NPT)

INSTALLATION INSTRUCTIONS
1. Mount the MSA‑1 securely in upright position in an open space, in direct contact with snowfall pattern with a ½” NPT
mounting connector. The unit is water‑resistant, but it is not designed to be submerged or immersed in water. Ensure that
the mounting location is close (less than 10 feet) to the MSC‑1 Control Panel or a suitable connection box. See Fig.2
2. Ensure that all pipe connections are sealed to prevent any penetration of water inside of conduit or
electrical junction box.
3. The MSA‑1 connection wire may be extended up to 500’ with an appropriately rated 18‑20AWG 3 wire unshielded cable.
Ensure that all electrical connections within connection boxes are sealed to prevent any penetration of water.
4. The MSA‑1 is wired directly to the appropriate zone sensor terminal block on the MSC‑1 control panel.
Figure 2 — MSA-1 connection to MSC-1
MSA‑1 Installations & Operation Instructions
2" min
indoor location
Access
Cover
Extend to
500´ max;
18 – 20 AWG,
3 conductor
unshielded
stranded cable
1/2" Tubing
Gutter
Electrical
Junction Box MSC‑1 Control
Panel
©2009 Easy Heat www.easyheat.com 14068-001 Rev. 3

ELECTRICAL SPECIFICATIONS
Environmental
Working / Storage temperature ‑40°C (‑40°F) to 70°C (160°F)
Humidity environment 0 to 100 %
Supply requirements
Power supply voltage 24VAC
Maximum amperage 500mA
Mounting connector 1/2" NPT
Connection Leads length 10 feet
OPERATION INSTRUCTIONS
The MSA‑1 snow melting control is designed to send a signal to the MSC‑1 control panel indicating when snow or ice
conditions exist. The MSC‑1 control panel uses this information, along with temperature data from the TS‑1 to determine
when snow‑melting equipment should be energized.
The MSA‑1 may be tested for functionality if outside temperature is below 3°C (38°F), Apply a small amount of moisture onto
the surface of the moisture sensor, the MSC‑1 should energise the heating equipment in the associated zone. After this test,
dry the sensor, the heating equipment in the associated zone should de‑energize after the pre‑set hold time.
Every year, in the fall the MSA‑1 must be inspected for physical damage and to clean up the snow sensor surface. To clean
the snow sensor surface:
1. Disconnect MSA‑1 from the power supply.
2. With a clean wet swab clean up the surface of the snow sensor.
3. Reconnect MSA‑1 to the power supply.
