Instruction Manual
NGA2000HardwareManualfor
MLTorCAT200Analyzerand
MLTorCAT200AnalyzerModule(combinedwith
NGA2000Platform,MLT,CAT200orTFIDAnalyzer)
10th Edition 01/2007
Instruction Manual
90002929
01/2007

NGA 2000 MLT Hardware InstructionManual
90002929
07/2006
Emerson Process Management
GmbH & Co. OHG
Industriestrasse 1
D-63594 Hasselroth
Germany
T [phone]
F [phone]
Internet: www.EmersonProcess.com
ESSENTIALINSTRUCTIONS
READ THIS PAGE BEFORE PROCEEDING!
Emerson Process Management (RosemountAnalytical) designs, manufactures and tests
itsproductsto meet manynationalandinternational standards. Becausetheseinstruments
are sophisticated technical products, you MUST properly install, use, and maintain
them to ensure they continue to operate within their normal specifications. The following
instructionsMUST be adhered to and integratedintoyoursafetyprogram when installing,
using and maintaining Emerson Process Management (RosemountAnalytical) products.
Failure to follow the proper instructions may cause any one of the following situations to
occur:Loss oflife; personalinjury; propertydamage; damageto thisinstrument; andwarranty
invalidation.
•Read all instructions prior to installing, operating, and servicing the product.
•If you do not understand any of the instructions, contact your Emerson Process
Management(Rosemount Analytical) representative for clarification.
•Followallwarnings, cautions,andinstructionsmarkedonandsuppliedwiththeproduct.
•Inform and educate your personnel in the proper installation, operation, and
maintenance of the product.
•Installyour equipmentas specifiedin the InstallationInstructions ofthe appropriate
InstructionManual and perapplicable localand nationalcodes. Connectallproducts
totheproper electricalandpressure sources.
•Toensureproperperformance,use qualifiedpersonneltoinstall,operate,update,program,
andmaintain theproduct.
•Whenreplacement partsare required,ensurethatqualifiedpeopleusereplacement parts
specifiedby EmersonProcessManagement (RosemountAnalytical). Unauthorizedparts
and procedures can affect the product’s performance, place the safe operation of your
processat risk, andVOIDYOUR WARRANTY.Look-alike substitutionsmayresultinfire,
electricalhazards, orimproperoperation.
•Ensurethatall equipmentdoorsareclosed andprotectivecovers are inplace,except
when maintenance is being performed by qualified persons, to prevent electrical
shockand personalinjury.
The information contained in this document is subject to change without notice. Misprints
reserved.
1st Edition02/1997 2nd Edition03/1997 3rd Edition 09/1997 4th Edition04/1998
5th Edition07/1999 6th Edition10/1999 7th Edition 04/2003 8th Edition08/2004
9th Edition07/2006 10thEdition 01/2007
©1997-2006by Emerson ProcessManagement

NGA 2000 MLT Hardware
CONTENTS
I
Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
01/2007
Table of Contents
PREAMBEL ....................................................................................S - 1
DEFINITIONS.................................................................................. S - 1
SAFETY INSTRUCTIONS ............................................................. S - 2
Operating and maintaining this apparatus................................... S - 3
Intended use statement .................................................................S - 4
Safety summary.............................................................................. S - 4
Authorized personnel..................................................................... S - 4
Gases and Gas Conditioning (Sample Handling) ........................ S - 6
Power Supply.................................................................................. S - 7
Instruments with External Power Supply Unit ................................... S - 7
Instruments with Internal Power Supply Unit .................................... S - 7
General operating instructions .....................................................S - 9
Additional hints for UV measurement ........................................ S - 10
Magnetically Operated Front Panel ............................................ S - 11
Electrostatic Discharge................................................................ S - 12
PREFACE........................................................................................ P - 1
a) Analyzer versions ......................................................................... P - 1
Standard General Purpose Applications........................................ P - 1
b) Analyzer versions
Installation in Hazardous Areas ..................................................... P - 2
c) Analyzer System Architecture ....................................................... P - 4
DESCRIPTION
1. Technical Description .................................................................... 1 - 1
1.1 Standard General Purpose Applications .......................................... 1 - 1
1.2 Installation in Hazardous Areas ........................................................ 1 - 1
1.3 Operating Front Panel ...................................................................... 1 - 2
1.3.1 Standard Version ........................................................................... 1 - 2
1.3.2 Magnetically Operated Touch Panel .............................................. 1 - 3
1.3.2.1 Magnetic Touch Panel Elements.................................................. 1 - 3
1.3.2.2 Accessories .................................................................................. 1 - 4
1.3.2.3 Operating the Touch Panel .......................................................... 1 - 4

NGA 2000 MLT Hardware
CONTENTS
II Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
01/2007
1.4 MLT 1 ............................................................................................... 1 - 6
1.4.1 MLT 1 1/2 19" housing ................................................................... 1 - 6
1.4.2 MLT 1 ULCO ................................................................................ 1 - 11
1.4.3 MLT 1 Housing for platform mounting .......................................... 1 - 13
1.5 MLT 2 (Field Housing) .................................................................... 1 - 17
1.6 MLT 3 ............................................................................................. 1 - 21
1.6.1 MLT 3 (Gas purity measurement) ................................................. 1 - 23
1.6.2 MLT 3HT (high temperature measurement).......................................1 - 24
1.7 MLT 4 ............................................................................................. 1 - 26
1.8 CAT 200 ......................................................................................... 1 - 28
1.9 Internal Gas Paths .......................................................................... 1 - 32
1.9.1 Gas Path Material ........................................................................ 1 - 32
1.9.2 Gas Path Layout (internal tubing)................................................. 1 - 33
1.9.3 MLT 3 (gas purity measurement) ................................................. 1 - 34
1.10 Printed Circuit Boards .................................................................... 1 - 36
1.10.1 ICB (Inter-Connection Board) ....................................................... 1 - 37
1.10.2 PSV/PIC Combination ................................................................. 1 - 37
1.10.3 DSP (alternitavely to PSV/PIC Combination) .............................. 1 - 37
1.10.4 PIC (Physics Interface Card) ........................................................ 1 - 38
1.10.5 Digital Signal Processing Card (DSP) ......................................... 1 - 39
1.10.6 ACU ............................................................................................. 1 - 40
1.10.7 SIO (Standard Inputs-/Outputs) .................................................... 1 - 41
1.10.8 DIO (Digital In-/Outputs) ............................................................... 1 - 42
1.11 Network Termination ...................................................................... 1 - 43
1.12 Specifications at the Nameplate Label ........................................... 1 - 44
1.13 MLT 2HT (high temperature measurement)...................... ................ 1 - 46
2. Measuring Principle ....................................................................... 2 - 1
2.1 IR Measurement ............................................................................... 2 - 1
2.1.1 Opto - Pneumatic Measuring Principle........................................... 2 - 3
2.1.2 Interference Filter Correlation (IFC Principle) ................................ 2 - 4
2.2 UV Measurement.............................................................................. 2 - 6
2.3 Oxygen Measurement ...................................................................... 2 - 7
2.3.1 Paramagnetic Measurement (PO2)................................................. 2 - 7
2.3.2 Electrochemical Measurement (EO2) ........................................... 2 - 11
2.3.3 Trace Electrochemical Measurement (TEO2) ............................... 2 - 13
2.4 Thermal Conductivity ..................................................................... 2 - 15
2.4.1 Sensor Design ............................................................................. 2 - 15
2.4.2 Analysis Cell ................................................................................ 2 - 15
2.4.3 Measurement Method .................................................................. 2 - 16
3. (vacant)
4. (vacant)

NGA 2000 MLT Hardware
CONTENTS
III
Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
OPERATION (START-UP)
5. Installation .................................................................................... 5 - 1
5.1 General........................................................................................... 5 - 1
5.1.1 Transfer Safety Lock of MLT 1/ULCO or MLT 2 .......................... 5 - 3
5.2 Gas Conditioning (Sample Handling) ............................................. 5 - 4
5.2.1 Fine Dust Filter (Option MLT 3) ................................................... 5 - 5
5.2.2 Gas Sampling Pump (Option MLT 3) ........................................... 5 - 5
5.2.3 Pressure Sensor (Option) ............................................................ 5 - 5
5.2.4 Gas Flow...................................................................................... 5 - 5
5.3 Gas Connections ............................................................................ 5 - 6
5.3.1 Internal Solenoid Valve Block (Option for MLT 1/CAT 200) ......... 5 - 8
5.3.2 Purge Gas Connections ............................................................... 5 - 8
5.4 Analyzer Specific Instructions......................................................... 5 - 9
5.4.1 MLT 1........................................................................................... 5 - 9
5.4.1.1 MLT 1, platform mounting only ................................................... 5 - 9
5.4.1.2 MLT 1, external installation and 1/2-19" Housing ....................... 5 - 10
5.4.2 MLT 2 (Field Housing) ................................................................. 5 - 13
5.4.2.1 Wall Mounting ............................................................................ 5 - 13
5.4.2.2 Electrical Connections................................................................ 5 - 15
a) Mains Supply ......................................................................... 5 - 16
b) optional Data Lines ................................................................ 5 - 16
c) Cable Gland Assembly Instruction for Shielded Cables ......... 5 - 19
d) Gas Connections ................................................................... 5 - 20
5.4.3 MLT 3........................................................................................... 5 - 21
5.4.3.1 MLT 3 for gas purity measurement ............................................ 5 - 22
a) Instrument with manual 4/2-way-valve ................................... 5 - 22
b) Instrument with solenoid valve block...................................... 5 - 23
c) Instrument with quick shutoff connector ................................. 5 - 23
5.4.4 MLT 4........................................................................................... 5 - 24
5.4.5 CAT 200....................................................................................... 5 - 26
5.4.5.1 Wall Mounting ............................................................................ 5 - 27
5.4.5.2 Electrical Connections................................................................ 5 - 28
5.4.5.3 Gas Connections........................................................................ 5 - 31
5.5 Wiring Signal Terminals.................................................................. 5 - 32
5.5.1 Electrical Connections in General ................................................ 5 - 32
5.5.2 Wiring Inductive Loads................................................................. 5 - 34
5.5.3 Driving Multiple Loads.................................................................. 5 - 35
5.5.4 Driving High Current Loads.......................................................... 5 - 36

NGA 2000 MLT Hardware
CONTENTS
IV Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
6. Switching On .................................................................................. 6 - 1
7. Measurement / Calibration / Switching Off .................................. 7 - 1
7.1 Measurement ................................................................................... 7 - 1
7.2 Calibration ........................................................................................ 7 - 2
7.2.1 Test Gases .................................................................................... 7 - 3
7.2.1.1 Zero Gas ...................................................................................... 7 - 3
7.2.1.2 Span Gas ..................................................................................... 7 - 3
7.3 Switching Off .................................................................................... 7 - 4
8.
- (vacant)
9.
TROUBLESHOOTING
10. Troubleshooting ........................................................................... 10 - 1
10.1 Instrument has no function (LCD display is dark) ........................... 10 - 1
10.2 No / Incorrect Measurement Screen............................................... 10 - 2
10.3 Display Messages .......................................................................... 10 - 3
10.3.1 Chopper Fail ................................................................................ 10 - 3
10.3.2 Raw Signal Too High / Low.......................................................... 10 - 3
10.3.3 Detector signal communication failed .......................................... 10 - 4
10.3.4 Light source ................................................................................. 10 - 4
10.3.5 Detector ....................................................................................... 10 - 4
10.3.6 Heater Unit Regulation................................................................. 10 - 5
10.3.7 Temperature Measurement ......................................................... 10 - 5
10.3.8 Invalid Pressure Measurement .................................................... 10 - 5
10.3.9 External Input............................................................................... 10 - 6
10.4 No or incorrect Analog Outputs / Digital I/O's ................................. 10 - 6
10.5 Calibration not possible .................................................................. 10 - 7
10.6 Fluctuating or erroneous display .................................................... 10 - 8
10.7 Response time too long (t90 time)................................................. 10 - 9

NGA 2000 MLT Hardware
CONTENTS
V
Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
11. Test Procedure / Test Points ....................................................... 11 - 1
11.1 Signal processing ........................................................................... 11 - 1
11.1.1 Internal Voltage Supply ................................................................ 11 - 2
11.1.2 IR Source ..................................................................................... 11 - 2
11.1.3 Chopper ....................................................................................... 11 - 3
11.1.4 Unamplified Measuring Signal at Detector ................................... 11 - 3
11.1.5 Signal Processing on PCB “PSV” ................................................ 11 - 4
11.1.6 Physical Zero Alignment .............................................................. 11 - 5
11.1.6.1 IR Measurement......................................................................... 11 - 5
11.1.6.2 Paramagnetic Oxygen Measurement ......................................... 11 - 5
11.1.6.3 Electrochemical Oxygen Measurement (EO2) ........................... 11 - 5
11.2 Heating Unit.................................................................................... 11 - 6
11.3 Troubleshooting Instructions for PCB DSP01 ................................ 11 - 7
11.3.1 Inspection of LEDs on component side of DSP01 ....................... 11 - 8
11.3.2 Inspection of soldering pads of DSP01 ...................................... 11 - 10
11.3.3 Evaluation .................................................................................. 11 - 11
11.3.4 Appendix .................................................................................... 11 - 12
11.3.4.1 Description of soldering pad DEF (LB3): .................................. 11 - 12
11.3.4.2 Definition of LEDs: ................................................................... 11 - 12
12. Removal / Replacement of Components .................................... 12 - 1
12.1 Removal / Replacement of PCBs (in preparation).......................... 12 - 1
12.1.1 Rear Mounting Slots (in preparation) ........................................... 12 - 1
12.1.2 Internal Slots (in preparation)....................................................... 12 - 1
12.2 Removal / Replacement of Operation Front Panel ......................... 12 - 2
12.3 Replacement of Buffer Battery on the ACU 02 ............................... 12 - 3
12.3.1 Removal of ACU 02 ..................................................................... 12 - 3
12.3.2 Replacement of Buffer Battery ..................................................... 12 - 4
12.3.3 Installation of ACU 02 .................................................................. 12 - 4
12.4 Fuses.............................................................................................. 12 - 5
12.4.1 MLT 2........................................................................................... 12 - 5
12.4.2 MLT 1 / 4...................................................................................... 12 - 6
12.5 Connect/Disconnect UV Source/Power Supply for UV Source ...... 12 - 7

NGA 2000 MLT Hardware
CONTENTS
VI Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
MAINTENANCE ............................................................................. 13 - 1
14. Leak Testing ................................................................................. 14 - 1
15. Opening the Housing ................................................................... 15 - 1
15.1 MLT 1 ............................................................................................. 15 - 2
15.1.1 MLT 1 (Platform housing) ............................................................... 15 - 2
15.1.1.1 Housing Cover ........................................................................... 15 - 2
15.1.1.2 Front Panel................................................................................. 15 - 3
15.1.2 MLT 1 (1/2 19" housing) .............................................................. 15 - 4
15.1.2.1 Housing Cover ........................................................................... 15 - 4
15.1.2.2 Front Panel................................................................................. 15 - 5
15.2 MLT 2 (Field Housing) .................................................................... 15 - 6
15.3 MLT 3/4 (1/1 19" housing) .............................................................. 15 - 8
15.3.1 Housing Cover ............................................................................. 15 - 8
15.3.2 Front Panel (MLT 4 / MLT 3 standard version) ............................ 15 - 8
15.3.3 Front Panel (MLT 3 gas purity measurement) ............................. 15 - 9
15.3.3.1 Operation Front Panel ................................................................ 15 - 9
15.3.3.2 Left Front Panel.......................................................................... 15 - 9
15.4 CAT 200 ....................................................................................... 15 - 10
15.4.1 Junction Box .............................................................................. 15 - 12
15.4.2 Dome ......................................................................................... 15 - 13
15.4.3 Magnetically Operated Front Panel ........................................... 15 - 16
15.4.3.1 Sliding the Analyzer into Position ............................................. 15 - 16
15.4.3.2 Fixing the Analyzer................................................................... 15 - 16
15.4.3.3 Completing the Adjustment ...................................................... 15 - 16
16. Fine Dust filter (MLT 3 Option) .................................................... 16 - 1
17. Replacement and Cleaning of Photometric Components ........ 17 - 1
17.1 Removal of the Photometer Assembly ........................................... 17 - 2
17.2 Light Source Replacement (IR) ...................................................... 17 - 3
17.3 Cleaning of Analysis Cells and Windows ....................................... 17 - 4
17.3.1 Removal of Analysis Cells ........................................................... 17 - 4
17.3.2 Cleaning....................................................................................... 17 - 5
17.3.3 Reinstalling of Analysis Cells ....................................................... 17 - 6
17.4 Reinstalling of the Photometer Assembly ....................................... 17 - 7
17.5 Physical Zeroing ............................................................................. 17 - 8

NGA 2000 MLT Hardware
CONTENTS
VII
Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
18. Check / Replacement of electrochemical Oxygen Sensor........ 18 - 1
18.1 EO2-Sensor .................................................................................... 18 - 2
18.2 Check of the EO2-Sensor ............................................................... 18 - 3
18.3 Replacement of the EO2-Sensor .................................................... 18 - 4
18.3.1 Removal of the EO2-Sensor ......................................................... 18 - 4
18.3.2 Replacing the EO2-Sensor ........................................................... 18 - 5
18.3.3 Reinstalling of the EO2-Sensor .................................................... 18 - 5
18.3.4 Basic conditions for the EO2-Sensor ............................................ 18 - 6
18.4 TEO2-Sensor .................................................................................. 18 - 7
19. Cleaning of Housing Outside ...................................................... 19 - 1
TECHNICAL DATA ........................................................................ 20 - 1
20.1 Housing .......................................................................................... 20 - 1
20.2 Options ........................................................................................... 20 - 2
20.3 General Specifications ................................................................... 20 - 3
20.4 Voltage supply .............................................................................. 20 - 11
20.4.1 Analyzers...................................................................................... 20 - 11
20.4.1.1 MLT 1/4 .................................................................................... 20 - 11
20.4.1.2 MLT 2/3 .................................................................................... 20 - 11
20.4.1.3 CAT 200 ................................................................................... 20 - 11
20.4.1.4 Electrical Safety ....................................................................... 20 - 11
20.4.2 Power Supplies .......................................................................... 20 - 12
20.4.2.1 UPS 01 T (Universal Power Supply) ........................................ 20 - 12
20.4.2.2 External 5A Power Supply Unit for DIN Rail Installation........... 20 - 14
20.4.2.3 External 10A Power Supply Unit for DIN Rail Installation......... 20 - 16
20.4.2.4 Tabletop Power Supply Units ................................................... 20 - 18

NGA 2000 MLT Hardware
CONTENTS
VIII Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
SUPPLEMENT
21. Pin Assignments ........................................................................ 21 - 1
21.1 24 V dc Input (MLT 1/4) ................................................................ 21 - 1
21.2 230/120 V ac Input (MLT 3) .......................................................... 21 - 1
21.3 Option SIO (Standard I/O) ............................................................ 21 - 2
21.3.1 Analog Signal Outputs ............................................................... 21 - 2
21.3.2 Relay Outputs / Serial Interfaces ............................................... 21 - 2
21.4 Option DIO (Digitale I/O) .............................................................. 21 - 3
21.5 Terminal Assignment of CAT 200 ................................................. 21 - 4
21.6 CAT 200 Increased Safety Box - Label Schematic ........................ 21 - 7
22. Calculation of Water Content from Dew-point to
Vol. -% or g/Nm³.......................................................................... 22 - 1

NGA 2000 MLT Hardware
CONTENTS
IX
Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
LIST OF FIGURES
Fig. Title Page
Fig. P-1: Analyzer Nameplate Label (example) .............................................................................P - 3
Fig. P-2: From separate analyzers to analyzer system ................................................................. P - 4
Fig. P-3: Example of NGA-cabling .................................................................................................P-5
Fig. P-4: Example/possibilities of NGA analyzer system ............................................................... P - 6
Fig. 1-1: Operation front panel, Front view .................................................................................... 1 - 2
Fig. 1-2: Magnetically Operated Touch Panel, Front view ............................................................ 1 - 3
Fig. 1-3a: Magnetic actuator ........................................................................................................... 1 - 5
Fig. 1-3b: Magnetic actuator, view at magnets................................................................................ 1 - 5
Fig. 1-4a: Symbols showing actuator alignment ............................................................................. 1 - 4
Fig. 1-4b: Horizontally aligned, activating F4 .................................................................................. 1 - 5
Fig. 1-4c: Vertically aligned, activating F5....................................................................................... 1 - 5
Fig. 1-5: Actuator stored when not in use ..................................................................................... 1 - 4
Fig. 1-6: MLT analyzer, Front view ................................................................................................ 1 - 6
Fig. 1-7: MLT 1, Front panel, Rear view ........................................................................................ 1 - 7
Fig. 1-8: MLT 1, Rear panel (standard) ......................................................................................... 1 - 7
Fig. 1-9: MLT 1, Rack/Table-top Housing, Top view (with electrochemical O2Sensor) ................ 1 - 8
Fig. 1-10: MLT 1, Rack/Table-top Housing, Top viewA(with paramagnetic O2Sensor) .................. 1 - 9
Fig. 1-11: MLT 1, Rack/Table-top Housing extended, Top view (with paramagnetic O2Sensor) . 1 - 10
Fig. 1-12: MLT 1 ULCO, Rack/Table-top Housing, Top view ........................................................ 1 - 12
Fig. 1-13: MLT 1 Analyzer module (Platform mounting), Front panel, Front view ......................... 1 - 13
Fig. 1-14: MLT 1, Platform mounting, Top view (with electrochemical O2Sensor) ....................... 1 - 14
Fig. 1-15: MLT 1, Platform mounting, Top view (with paramagnetical O2Sensor) ........................ 1 - 15
Fig. 1-16: MLT 1, Platform mounting extended, Top view (with paramagnetic O2Sensor) ........... 1 - 16
Fig. 1-17a: Front view MLT 2 (Standard housing/Standard operation front panel) ......................... 1 - 19
Fig. 1-17b: Front view MLT 2 (Dual compartment housing/Standard operation front panel)........... 1 - 19
Fig. 1-18a: MLT 2, Inside view (drawing without front panel) .......................................................... 1 - 20
Fig. 1-18b: MLT 2, Photometer sliding carriage, Top view .............................................................. 1 - 20
Fig. 1-19: MLT 3 (standard) (1/1 19" housing), front view ............................................................ 1 - 21
Fig. 1-20: MLT 3 (standard version), Rear view ........................................................................... 1 - 21
Fig. 1-21: MLT 3 (standard version), Top view ............................................................................. 1 - 22
Fig. 1-22: MLT 3 (gas purity measurement), front view................................................................. 1 - 23
Fig. 1-23: MLT 3 (gas purity measurement), Rear view ................................................................ 1 - 24
Fig. 1-24: MLT 3 (gas purity measurement), Top view.................................................................. 1 - 25
Fig. 1-25: MLT 4 (1/1 19" housing), front view .............................................................................. 1 - 26
Fig. 1-26: MLT 4, Rear view .......................................................................................................... 1 - 26
Fig. 1-27: MLT 4, Rack/Table-top Housing, Top view ................................................................... 1 - 27
Fig. 1-28: CAT 200, Exterior view ................................................................................................. 1 - 30
Fig. 1-29: CAT 200 (Dome and extender housing removed) ........................................................ 1 - 31
Fig. 1-30a: MLT 3 (gas purity measurement), gas path layout.................................................................
(3 measuring channels with solenoid valve block option) ............................................. 1 - 34
Fig. 1-30b: MLT 3 (gas purity measurement), gas path layout.................................................................
(3 measuring channels with valve block option and quick shuttoff connector option) ... 1 - 35
Fig. 1-30c: MLT 3 (gas purity measurement), gas path layout.................................................................
(2 measuring channels with manual 4/2-way-valve option) .......................................... 1 - 35
Fig. 1-31a: Cardcage MLT 1/3/4, Top View .................................................................................... 1 - 36
Fig. 1-31b: PCB arrangement MLT 2 [Inside view, detail (without front panel)] .............................. 1 - 37
LIST OF FIGURES

NGA 2000 MLT Hardware
CONTENTS
XEmerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
Fig. Title Page
Fig. 1-32: Plug pin assignment PCB PIC ...................................................................................... 1 - 38
Fig. 1-33: Plug pin assignment PCB DSP ..................................................................................... 1 - 39
Fig. 1-34: Function blocks of SIO-PCB ......................................................................................... 1 - 41
Fig. 1-35: SIO-PCB with extension cards ...................................................................................... 1 - 42
Fig. 1-36: RJ 45 network termination connector ........................................................................... 1 - 43
Fig. 1-37: Network termination (examples) ................................................................................... 1 - 43
Fig. 1-38: Analyzer Nameplate Label (example) ........................................................................... 1 - 44
Fig. 2-1: Measuring Principle for NDIR / UV Measurement........................................................... 2 - 2
Fig. 2-2: Principle Design of Gas Detector .................................................................................... 2 - 3
Fig. 2-3: Absorption Bands of Sample Gases and Transmittance of the .............................................
Interference Filters used ................................................................................................. 2 - 5
Fig. 2-4: Principle Construction of paramagnetic Analysis Cell ..................................................... 2 - 8
Fig. 2-5: Structure of electrochemical Oxygen Sensor................................................................ 2 - 11
Fig. 2-6: Reaction of galvanic cell ............................................................................................... 2 - 12
Fig. 2-7: Structure of electrochemical Trace Oxygen Sensor...................................................... 2 - 13
Fig. 2-8: Sensor block (thermal conductivity detector TCD) ........................................................ 2 - 15
Fig. 2-9: Measuring principle Thermal Conductivity Sensor (Wheatstone bridge) ...................... 2 - 16
Fig. 5-1a: Transfer safety lock MLT-ULCO (housing side view, detail sketch) ................................ 5 - 3
Fig. 5-1c: MLT 2, Photometer safety lock ....................................................................................... 5 - 3
Fig. 5-1b: MLT 1, Rear panel (holder for safety lock) ...................................................................... 5 - 3
Fig. 5-2: MLT, Bypass installation ................................................................................................. 5 - 7
Fig. 5-3: MLT 1 analysis module (platform mounting), front panel, front view ............................... 5 - 9
Fig. 5-4: MLT 1, standard gas connections ................................................................................. 5 - 11
Fig. 5-5: MLT 1, gas connections with solenoid valve option ...................................................... 5 - 12
Fig. 5-6a: Dimensional sketch / Drill drawing MLT 2 Standard version ......................................... 5 - 14
Fig. 5-6b: Dimensional sketch / Drill drawing MLT 2 Dual housing version .................................. 5 - 14
Fig. 5-8: MLT 2, Data line connections Inside view from front (detail, without front door) ........... 5 - 17
Fig. 5-9: MLT 2, Connection data lines / mains line (inside view, left side panel) ....................... 5 - 18
Fig. 5-10: Cable Gland Assembly Instruction for Shielded Cables................................................ 5 - 19
Fig. 5-11: Cable gland sealing plug / Cable gland allen screw sealing plug ................................. 5 - 19
Fig. 5-12a: MLT 2, gas connections ................................................................................................ 5 - 20
Fig. 5-12b: MLT 2, Gas fittings at analyzer’s bottom side ............................................................... 5 - 20
Fig. 5-13: MLT 3 (standard version), gas connections and voltage supply ................................... 5 - 21
Fig. 5-14: MLT 3 (gas purity measurement), Rear view ................................................................ 5 - 22
Fig. 5-15: Solenoid valve block MLT 3 (gas purity measurement) (side view) .............................. 5 - 23
Fig. 5-16: MLT 3 (gas purity measurement), front view................................................................. 5 - 23
Fig. 5-17: MLT 4, Voltage supply .................................................................................................. 5 - 24
Fig. 5-18: MLT 4, gas connections ................................................................................................ 5 - 25
Fig. 5-19: Drill drawing CAT 200 [all dimensions in mm (Inch)]..................................................... 5 - 27
Fig. 5-20: CAT 200, Junction box, interior view............................................................................. 5 - 30
Fig. 5-21: CAT 200, Analyzer’s bottom view at gas fittings ........................................................... 5 - 30
Fig. 5-22: Shielded Signal Cable, shield connected at both ends ................................................. 5 - 32
Fig. 5-23: Shielded Signal Cable, shield connected at one end .................................................... 5 - 32
Fig. 5-24: Double-shielded Signal Cable, shields connected at both sides................................... 5 - 33
Fig. 5-25: Suppressor Diode for Inductive Loads .......................................................................... 5 - 34
Fig. 5-26: ”Serial” Wiring ............................................................................................................... 5 - 35
Fig. 5-27: Running Supply Lines "Parallel” .................................................................................... 5 - 35
Fig. 5-28: Driving High Current Loads ........................................................................................... 5 - 36
LIST OF FIGURES

NGA 2000 MLT Hardware
CONTENTS
XI
Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
Fig. Title Page
Fig. 11-1: Principle signal processing with PCB "PSV" ................................................................. 11 - 1
Fig. 11-2: PCB "VVS" .................................................................................................................... 11 - 2
Fig. 11-3: PCB "MOP” (partial view).............................................................................................. 11 - 3
Fig. 11-4: PCB "BHZ” (position of signal LED's / heating transistors) ........................................... 11 - 6
Fig. 11-5: PCB "DSP01” ................................................................................................................ 11 - 7
Fig. 11-6: LEDs on component side of PCB "DSP01” ................................................................... 11 - 8
Fig. 11-6a: LEDs “V7” and “V9” (PCB "DSP01”) ............................................................................. 11 - 8
Fig. 11-6b: LEDs “V3” and “V4” (PCB "DSP01”) ............................................................................. 11 - 9
Fig. 11-6c: LEDs “V12” to “V17”, Jumper “P40” (PCB "DSP01”) .................................................... 11 - 9
Fig. 11-7: Soldering pads on soldering side of PCB "DSP01” ..................................................... 11 - 10
Fig. 11-7a: Soldering pad “LB1” and “LB2 (PCB "DSP01”) ........................................................... 11 - 10
Fig. 11-7b: Soldering pad “LB18” (PCB "DSP01”) ........................................................................ 11 - 10
Fig. 11-8: Schematic diagram of inspection of PCB "DSP01” ..................................................... 11 - 11
Fig. 11-9: Soldering pad “DEF/LB3” (PCB "DSP01”) .................................................................. 11 - 12
Fig. 12-1: Controller Board ACU (partial view, component side)................................................... 12 - 3
Fig. 12-2: Fuses MLT 2 (partial inside view, drawing without front panel)..................................... 12 - 5
Fig. 12-3a: Fuses PCB LEM 01 (component side) .......................................................................... 12 - 6
Fig. 12-3a: Fuses PCB LEM 01 (component side) .......................................................................... 12 - 6
Fig. 12-4a: Power Supply for UV Source (front view, front panel disassembled) ............................ 12 - 8
Fig. 12-4b: UV Source and PCB ESP10 (top view, housing cover disassembled) ......................... 12 - 9
Fig. 14-1: Leak Testing with an U - Tube - Manometer ................................................................. 14 - 1
Fig. 15-1: MLT 1 (Plattform housing) Fastening screws housing cover ........................................ 15 - 2
Fig. 15-2: MLT 1 (Plattform housing) Fastening screws front panel.............................................. 15 - 3
Fig. 15-3: MLT 1 (1/2 19" housing) Fastening screws housing cover ........................................... 15 - 4
Fig. 15-4: MLT 1 (1/2 19" housing) Fastening screws front panel ................................................. 15 - 5
Fig. 15-5: MLT 2 (Field housing) fastener for front panel .............................................................. 15 - 7
Fig. 15-6: MLT 2, photometer carriage slide ................................................................................. 15 - 7
Fig. 15-7: MLT3 (standard version) / MLT 4 (1/1 19" housing) Fastening screws front panel ....... 15 - 8
Fig. 15-8: MLT3 (gas purity measurement) (1/1 19" housing) Fastening screws front panel ........ 15 - 9
Fig. 15-9: Cat 200 Enclosure Assembly ...................................................................................... 15 - 11
Fig. 15-10: Cat 200 Junction box .................................................................................................. 15 - 12
Fig. 15-11: CAT 200 Dome, fixing screws ..................................................................................... 15 - 13
Fig. 15-12: View at analyzer module ............................................................................................. 15 - 14
Fig. 15-13: Plate with detents........................................................................................................ 15 - 14
Fig. 15-14: CAT 200, Cast Iron housing, Interior View .................................................................. 15 - 15
Fig. 17-1: Photometer Assembly, example (Top view, detail) ....................................................... 17 - 2
Fig. 17-2: Chopper Housing with IR light sources ......................................................................... 17 - 3
Fig. 17-3: Photometer Assembly (1 mm to 10 mm analysisi cells) ................................................ 17 - 4
Fig. 17-4: Photometer Assembly (30 mm to 200 mm analysisi cells) ............................................ 17 - 4
Fig. 18-1: PCB “OXS”, assembled, horizontal projection .............................................................. 18 - 3
Fig. 18-2: MLT 1, front panel, rear view ........................................................................................ 18 - 4
Fig. 18-3: PCB “OXS”, assembled, horizontal projection .............................................................. 18 - 6
LIST OF FIGURES

NGA 2000 MLT Hardware
CONTENTS
XII Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
Fig. Title Page
Fig. 20- 1: Dimensional sketch MLT 1 [all dimensions in mm] ........................................................ 20 - 6
Fig. 20- 2: Dimensional sketch / Drill drawing MLT 2 Standard version ........................................... 20 - 7
Fig. 20- 3: Dimensional sketch / Drill drawing MLT 2 Dual housing version ..................................... 20 - 7
Fig. 20- 4: Dimensional sketch MLT 2 for Ex Zone 2 in standard housing ....................................... 20 - 8
Fig. 20- 5: Dimensional sketch MLT 2 for Ex Zone 1 in standard housing ....................................... 20 - 8
Fig. 20- 6: Dimensional sketch MLT 2 for Ex Zones with “Z Purge” (MLT 2-NF) .......................................
or “Continuous purge” in standard housing ................................................................... 20 - 9
Fig. 20- 7: Dimensional sketch MLT 3/4 ......................................................................................... 20 - 9
Fig. 20- 8: Dimensional sketch / Drill drawing CAT 200 ............................................................... 20 - 10
Fig. 20- 9: Dimensional sketch UPS 01 T (Universal Power Supply), table-top version .............. 20 - 13
Fig.20-10a: IEC mains input plug (UPS 01 T) ................................................................................ 20 - 13
Fig. 20-10b: 24 V DC output socket, Pin assignment (UPS 01 T) ................................................... 20 - 13
Fig. 20-11: Power Supply SL5, Dimensions .................................................................................. 20 - 15
Fig. 20-12: Power Supply SL 10, Dimensions ............................................................................... 20 - 17
Fig. 20-13: 10 A Tabletop Power Supply, Dimensions .................................................................. 20 - 18
Fig. 21- 1: Pin assignments 24 V dc Input (MLT 1/4) ..................................................................... 21 - 1
Fig. 21- 2: Pin assignments 230/120 V ac Input (MLT 3) ............................................................... 21 - 1
Fig. 21- 3: Pin assignments Socket Analog Signal Outputs (Option SIO) ...................................... 21 - 2
Fig. 21-4a: Pin assignments Socket Relay Outputs / RS 232 Serial Interface (Option SIO) ........... 21 - 2
Fig. 21-4b: Pin assignments Socket Relay Outputs / RS 485 Serial Interface (Option SIO) ........... 21 - 2
Fig. 21- 5: Pin assignments Socket Digital Inputs/Outputs (Option DIO) ........................................ 21 - 3
Fig. 21- 6: CAT 200, Junction box, interior view .............................................................................. 21 - 4
LIST OF TABLES
Table Title Page
Table P-1: Possibilities of NGA 2000 MLT I/O combinations ........................................................... P - 7
Table 1-1: Possible internal tubings (examples with 3 measuring channels) ................................... 1 - 33
Table 2-1: Solvent Resistant Sensor: Approved solvents ................................................................. 2 - 9
Table 2-2: Medium affected Materials within Paramagnetic Oxygen Sensor .................................... 2 - 9
Table 2-3: Paramagnetic Oxygen Measurement, cross interference by accompanying gases ........ 2 - 10
Table 5-1: CAT 200, Assignment of gas fittings ............................................................................. 5 - 30
Table 11-1: Definition of LEDs/Default configuration of soldering pads (PCB "DSP01”) .................. 11 - 12
Table 11-2: Definition of LEDs/Normal configuration of soldering pads (PCB "DSP01”) .................. 11 - 13
Table 20-1: Specifications of MLT .................................................................................................... 20 - 4
Table 20-2: Altered NDIR/VIS/UV-Specifications of MLT-ULCO compared to table 1 ...................... 20 - 5
Table 21-1: CAT 200 Power Connections Terminal Assignments ..................................................... 21 - 5
Table 21-2: CAT 200 Analog Signal Outputs Terminal Assignments (Option SIO) ............................ 21 - 5
Table 21-3: CAT 200 Relay Outputs Terminal Assignments (Option SIO) ........................................ 21 - 5
Table 21-4: CAT 200 Field Bus Terminal Assignments (Option) ....................................................... 21 - 5
Table 21-5: CAT 200 RS 232 / RS 485 Serial Interface Terminal Assignments (Option SIO) ............ 21 - 6
Table 21-6: CAT 200 Digital Inputs/Outputs Terminal Assignments (Option DIO) ............................. 21 - 6
Table 21-7: CAT 200 Terminal Assignments - Bottom (Lower) Contacts........................................... 21 - 8
Table 21-8: CAT 200 Terminal Assignments - Top (Upper) Contacts ................................................ 21 - 8
Table 22-2: Calculation of Water Content from Dew-point to Vol. -% or g/Nm³ .................................. 22 - 1
LIST OF FIGURES/LIST OF TABLES

NGA 2000 MLT Hardware
SAFETYINSTRUCTIONS
S - 1
Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
Preambel
ThisinstructionmanualprovidesinformationaboutMLTandCAT200seriesgasanalyzers/analyzer
modules concerning subassemblies, functions, procedures, installation, operation and mainte-
nance.
This instruction manual covers several MLT and CAT200 series gas analyzers /analyzer modules
variations and therefore may describe configurations and/or options not part of your specific
analyzer.
Installation and operation of instruments intended to be installed and operated in HAZARDOUS
AREAS is NOT COVERED by this instruction manual, but part of the specific instruction manual
shippedtogetherwithsuchanalyzersbecauseofthespecialrequirementsforworkinginhazardous
environments!
Definitions
The following definitions apply to WARNINGS, CAUTIONS and NOTES found throughout this
publication.
Highlights an operation or
maintenance procedure,
practice, condition, state-
ment, etc.
If not strictly observed, could
result in injury, death, or long-
term health hazards of
personnel.
Highlights an operation or
maintenance procedure,
practice, condition, state-
ment, etc.
If not strictly observed, could
result in damage to or
destruction of equipment, or
loss of effectiveness.
PREAMBEL / DEFINITIONS
NOTE
Highlights an essential operating
procedure, condition or statement.

NGA 2000 MLT Hardware
SAFETYINSTRUCTIONS
S - 2 Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
GENERAL
IMPORTANT
SAFETY INSTRUCTIONS
WIRING AND INSTALLATION OF THIS APPARATUS
The following safety instructions apply specifically to all EU member states. They should be
strictly adhered to in order to assure compliance with the Low Voltage Directive. Non-EU
states should also comply with the following unless superseded by local or National
Standards.
1. Adequate earth connections should be made to all earthing points, internal and external,
where provided.
2. After installation or troubleshooting, all safety covers and safety grounds must be replaced.
The integrity of all earth terminals must be maintained at all times.
3. To ensure safe operation of this equipment, connection to the mains supply should only
be made through a circuit breaker which will disconnect all circuits carrying conductors
during a fault situation. The circuit breaker may also include a mechanically operated
isolating switch. Circuit breakers or switches must comply with a recognized standard
such as IEC947. All wiring must conform with any local standards.
4. Where equipment or covers are marked with the symbol to the right,
hazardous voltages are likely to be present beneath.These covers should
only be removed when power is removed from the equipment — and then
by trained service personnel only.
5. Where equipment or covers are marked with the symbol to the right, there
is a danger from hot surfaces beneath. These covers should only be
removed by trained service personnel when power is removed from the
equipment. Certain surfaces may remain hot to the touch.
6. Where equipment or covers are marked with the symbol to the right, refer
to the Instruction Manual for instructions.
7. Further graphical symbols used in this product:
All graphical symbols used in this product are from one or more of the following standards:
EN61010-1, IEC417, and ISO3864.
Explosion Hazard!
Harmful (to Health)!
Elektrostatic discharge (ESD)
Toxic!
Heavy Instrument!
Disconnect from Mains!

NGA 2000 MLT Hardware
SAFETYINSTRUCTIONS
S - 3
Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006 OPERATING AND MAINTAINING THIS APPARATUS
Operating and maintaining this apparatus
This instrument has left the factory in compliance with all applicable safety regulations.
To maintain this operating condition, the user must strictly follow the instructions and consider
the warnings in this manual or provided on the instrument.
Before switching on the instrument, verify that the electrical supply voltage matches the
instrument´s operating voltage as set in the factory.
Any interruption in the instrument´s ground line, whether inside or outside the instrument, or
removal or interruption of its ground line connection, could result in hazardous operating
conditions. Intentionally interrupting the instrument´s protective ground is strictly prohibited.
Opening cover panels could expose voltage-carrying components. Connectors may also be
under voltage. The instrument must be disconnected from all electrical supplies before
attempting any calibrations, maintenance operations, repairs or component replacements
requiring opening of the instrument. Any calibrations, maintenance operations, or repairs that
need the instrument to be opened while connected to electrical supplies should be subject to
qualified technicians familiar with the hazards involved only!
Use only fuses of the correct type and current ratings as replacements. Using repaired fuses
and short circuiting of fuse holders is prohibited.
Observe all applicable regulations when operating the instrument from an auto-transformer
or variac.
Substances hazardous to health may emerge from the instrument‘s exhaust.
Please pay attention to the safety of your operation personnel. Protective measures must be
taken, if required.

NGA 2000 MLT Hardware
SAFETYINSTRUCTIONS
S - 4 Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
INTENDED USE STATEMENT / SAFETY SUMMARY / AUTHORIZED PERSONNEL
Intended use statement
MLT and CAT200 series gas analyzers/analyzer modules are intended to be used as
analyzers for industrial purposes.They must not be used in medical, diagnostic or life
support applications, and no independent agency certifications or approvals are to be
implied as covering such applications!
Safety summary
If this equipment is used in a manner not specified in these instructions, protective
systems may be impaired.
Authorized personnel
To avoid loss of life, personal injury and damage to this equipment and on-site property,
do not operate or service this instrument before reading and understanding this
instruction manual and receiving appropriate training. Save these instructions.
ELECTRICAL SHOCK HAZARD !
Do not operate without covers secure. Do not open while energized. Installation requires
access to live parts which can cause death or serious injury.
For safety and proper performace this instrument must be connected to a properly
grounded three-wire source of power.
TOXIC GASES !
This unit’s exhaust may contain toxic gases such as sulfur dioxide.
These gases can cause serious injuries.
Aviod inhalation of the exhaust gases at the exhaust fitting.
Connect exhaust outlet to a safe vent. Check vent line and connections for leakage.
Keep all fittings tight to avoid leaks. See section 14 for leak test information.

NGA 2000 MLT Hardware
SAFETYINSTRUCTIONS
S - 5
Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
EXPLOSION HAZARD !
Do not operate nor install these instruments in hazardous areas without
additional measures!
MLT 2 and CAT 200 -- HEAVY INSTRUMENTS !
The analyzer variations MLT 2 and CAT 200 intended to be wall
mounted and/or outdoor installed weigh up to 35 kg resp. 70 kg, depending
on included options!
Use two person and/or suitable tools for transportation and lifting these
instruments!
Take care to use anchors and bolts specified to be used for the weight of
the units!
Take care the wall or stand the unit is intended to be installed at is solid
and stable to hold the units!
HIGH TEMPERATURES !
While working at photometers and/or thermostated components inside the
analyzers hot components may be accessible!
The electrochemical O2-sensor contains electrolyte which is caustic and
can cause serious burns to skin. Do not ingest contents of sensor !
CAUSTIC !
Tampering with or unauthorized substitution of components may adversely affect the
safety of this instrument. Use only factory approved components for repair.
Because of the danger of introducing additional hazards, do not perform any unauthorized
modification to this instrument!

NGA 2000 MLT Hardware
SAFETYINSTRUCTIONS
S - 6 Emerson Process Management GmbH & Co. OHG
Instruction Manual
90002929
07/2006
Gases and Gas Conditioning (Sample Handling)
GASES AND GAS CONDITIONING (SAMPLE HANDLING)
Supplying explosive gases is not permitted !
EXPLOSION HAZARD !
Supplying flammable gases of concentrations above 25 % of lower
explosion limit (LEL) we recommend to utilize one or more of the following
measures:
•Purging the housing with inert gas
• Internal tubing with stainless steel
• Flame arrestors at gas input and output fittings
• Intrinsically safe paramagnetical or thermal conductivity sensors
• Purge gas must be conditioned:
Take care for purge gas temperature: Purge gas should have the same temperature as
ambient temperature of the analyzer but NOT below 20 °C and above 35 °C! Otherwise
it must be cooled or warmed up before let in into the instrument!
Purge gas should be instrumental / synthetic air (free of oil, no corrosive, toxic or flammable
gas componets) or nitrogen depending on application.
Take care of the safety instructions applicable for the gases (sample
gases and test gases) and for the gas bottles containing these gases!
Before opening gas paths they must be purged with ambient air or
neutral gas (N2) to avoid hazards caused by toxic, flammable,
explosive or harmful to health sample gas components!
Flammable gases must not supplied without additional protective
measures!
It is prohibited to supply explosive gases!
