Fisher™EWD, EWS, and EWT Valves
through NPS 12x8
Contents
Introduction 1...................................
Scope of Manual 1.............................
Description 3.................................
Specifications 3...............................
Educational Services 4.........................
Installation 4
....................................
Inverted Globe Valve Applications
(Actuator below valve) 6.....................
Maintenance 7
..................................
Packing Lubrication 8..........................
Packing Maintenance 10........................
Replacing Packing 11.......................
Trim Maintenance 14..........................
Trim Removal 15..........................
Lapping Metal Seats 16.....................
Valve Plug Maintenance 17..................
Trim Replacement 19......................
Retrofit: Installing C‐seal Trim 20................
Replacement of Installed C‐seal Trim 24...........
Trim Removal (C‐seal Constructions) 24.......
Lapping Metal Seats (C‐seal Constructions) 25..
Remachining Metal Seats
(C‐seal Constructions) 25.................
Trim Replacement (C‐seal Constructions) 26...
ENVIRO‐SEALtBellows Seal Bonnet 27...........
Parts Ordering 32
................................
Parts Kits 33.....................................
Parts List 36.....................................
Figure 1. Fisher NPS 12x6 EW Series Valve With
667 Actuator
W2777‐2*
Introduction
Scope of Manual
This instruction manual includes installation, maintenance, and parts information for Fisher NPS 4x2 through 12x8
EWD, EWS, and EWT valves (figure 1). Refer to separate manuals for instructions covering the actuator and
accessories.
Do not install, operate, or maintain an EW valve without being fully trained and qualified in valve, actuator, and
accessory installation, operation, and maintenance. To avoid personal injury or property damage, it is important to
carefully read, understand, and follow all the contents of this manual, including all safety cautions and warnings. If you
have any questions about these instructions, contact your Emerson sales office or Local Business Partner before
proceeding.
Instruction Manual
D100399X012
EW Valve
July 2017

Instruction Manual
D100399X012
EW Valve
July 2017
2
Table 1. Specifications
End Connection Styles
Flanged Ends: CL300, CL600, or CL900 Raised‐face or
ring‐type joint flanges per ASME B16.5
Buttwelding Ends: Styles per ASME B16.25 schedules
consistent with ASME B16.34 are: Schedules J40 or
J80 for all CL300 and CL600 valves, Schedule J80
or JXXS for NPS 8x6 CL900 valves, or Schedule
J80, J100, or J120 for NPS 12x8 CL900 valves.
Maximum Inlet Pressures, Temperatures, and
Pressure Drops(1)
Consistent with applicable JCL300, JCL600(2), or
JCL900(3) pressure/temperature ratings per ASME
B16.34, but do not exceed the pressure,
temperature, and pressure drop conditions specified
when the valve was ordered. Also see the Installation
section.
Also see Bulletin 80.3:010 WhisperFlotAerodynamic
Attenuation Trims, D102362X012
Shutoff Classifications
See table 2
C‐seal trim: High‐temperature, Class V per ANSI/FCI
70‐2 and IEC 60534‐4
See table 3
WhisperFlo Trim:
JClass IV per ANSI/FCI 70‐2 and IEC 60534‐4
JOthers per application
Flow Characteristics
Standard Cages: JLinear, Jquick opening, or
Jequal percentage
Whisper Trimtand CavitroltCages: Linear
WhisperFlo Trim: Linear (restricted linear cages and
special, characterized cages are available--consult
your Emerson sales office or Local Business Partner)
Flow Directions
EWS and Standard Cage: Normally up
EWD or EWT with Standard Cage: Normally down
Whisper Trim Cages: Always up
Cavitrol Cages: Always down
WhisperFlo Trim: Flow up (standard)—through the
seat ring and out through the cage orifices
Approximate Weights
See table 4
WhisperFlo Trim Material and Selection
J410 Stainless Steel
JOthers per application
See appropriate valve body bulletin
WhisperFlo Pressure/Temperature Capability
J-29 to 427_C (-20 to 800_F)
JOthers per application
See appropriate valve body bulletin for
complementary information
WhisperFlo Aerodynamic Trim Pressure Ratings(1,2)
Up to 1500 psi drop
WhisperFlo Velocity Limits
WhisperFlo trim is designed for 0.3 MACH as an
inherent outlet velocity limit. Variations higher and
lower may be applied per special applications
WhisperFlo Rangeability
100:1
WhisperFlo Noise Attenuation
Approximately -40 dBA maximum depending on the
nP/P1ratio per IEC 534‐8‐3 calculation procedure
See Fisher Specification Manager
Additional Specifications
For specifications such as materials, port diameters,
valve plug travels, yoke boss diameters, and stem
diameters, refer to the Parts List
1. The pressure or temperature limits in this manual and any applicable standard limitations should not be exceeded.
2. Certain bonnet bolting material selections may require a CL600 easy‐e valve assembly to be derated. Contact your Emerson sales office.
3. There are two different CL900 NPS 8x6 valve bodies, one for use only with Cavitrol III cages and the other for use with all other constructions. A CL900 valve with Cavitrol III cage can take full
CL900 pressure drops. For information on other NPS 8x6 constructions that can take full CL900 pressure drops, contact your Emerson sales office. All other trim constructions are limited to
CL600 pressure/temperature limits even though installed in a CL900 valve.

Instruction Manual
D100399X012
EW Valve
July 2017
3
Figure 2. Cutaway Detail of the Fisher WhisperFlo Trim, Valve Body Typical
W6825‐1
Description
These single‐port globe‐style valves have cage guiding, clamped seat rings, and push‐down‐to‐close valve plug action.
Valve configurations are as follows:
EWD: Balanced valve plug with metal‐to‐metal seating for all general applications over a wide range of pressure drops
and temperatures.
C‐seal trim is available for EWD valves, CL300 and CL600, in sizes NPS 6x4x2‐1/2, 6x4, 8x4, 8x6, 12x6, 10x8, and 12x8.
With C‐seal trim, a balanced valve can achieve high‐temperature, Class V shutoff. Because the C‐seal plug seal is
formed from metal (N07718 nickel alloy) rather than an elastomer, a valve equipped with the C‐seal trim can be
applied in processes with a fluid temperature of up to 593_C (1100_F), provided other material limits are not
exceeded.
EWS: Unbalanced valve plug with metal‐to‐metal or optional metal‐to‐PTFE seating for all general applications
requiring better shutoff capabilities than can be obtained with the EWD valve.
EWT: Balanced valve plug with either metal‐to‐PTFE seating (standard for all except Cavitrol III cages) for stringent
shutoff requirements or metal‐to‐metal seating (standard for Cavitrol III cages, optional for all others) for higher
temperatures.
Control valves with WhisperFlo cages (figure 2) provide additional attenuation for aerodynamic noise in very
demanding vapor or gas applications with high‐pressure drops. A WhisperFlo cage with an appropriately sized valve
body is designed to reduce the noise level up to -40 dBA. For special applications, -50 dBA attenuation can be
achieved.
Specifications
Typical specifications for these valves are shown in table 1.

Instruction Manual
D100399X012
EW Valve
July 2017
4
Table 2. Shutoff Classification Per ANSI/FCI 70‐2 and IEC 60534‐4
Valve Seating Shutoff Class
EWD Metal II (standard)
III (optional for NPS 6x4 through 12x6 valves with optional single graphite piston ring or for
NPS 10x8 and 12x8 valves with optional double piston rings)
IV (optional for NPS 6x4 through 12x8 valves with optional multiple graphite piston rings)
EWS Metal IV (standard)
V (optional, consult your Emerson sales office or Local Business Partner)
EWS PTFE VI
EWT with all except
Cavitrol III cages
PTFE Standard Air Test (maximum leakage is 0.05 mL/min/psid/inch port diameter)
V (optional)
Metal IV (standard)
Metal V (optional)(1)
EWT with
1‐stage Cavitrol III cage
Metal IV (standard)
V (optional)
EWT with 2‐stage Cavitrol III cage Metal V
1. Class V shutoff for EWT requires spring loaded seal ring, radius‐seat plug, wide‐bevel seat ring, and seat lapping. Not available with 8‐inch port, quick‐opening cage. Not available with
S31600 (316 SST) valve plug and seat ring.
Table 3. Additional Shutoff Classification for C‐seal Trim Per ANSI/FCI 70‐2 and IEC 60534‐4
Valve Valve Size, NPS Port Diameter, Inches Cage Style Leakage Class
EWD
(CL300, CL600)
6x4x2‐1/2 2.875 Equal Percentage, Linear, Whisper I,
Cavitrol III (2‐stage)
V (for port
diameters from 2.875
through 8‐inch with
optional C‐seal trim)
6x4
8x4 4.375 Equal Percentage, Linear, Whisper I, Cavitrol III (1‐stage)
8x6 and 12x6 5.375 Whisper III (A3, B3, D3, D3), Cavitrol III (2‐stage)
8x6
12x6 7Equal Percentage, Linear, Whisper I, Cavitrol III (1‐stage)
10x8
12x8 8Equal Percentage, Linear, Whisper I, Cavitrol III (1‐stage)
Educational Services
For information on available courses for the Fisher EW valve, as well as a variety of other products, contact:
Emerson Automation Solutions
Educational Services - Registration
Phone: [phone] or 1-800-338-8158
E-mail: [email protected]
emerson.com/fishervalvetraining
Installation
WARNING
Always wear protective gloves, clothing, and eyewear when performing any installation operations to avoid personal
injury.
Personal injury or equipment damage caused by sudden release of pressure or bursting of parts may result if the valve
assembly is installed where service conditions could exceed the limits given in table 1 or on the appropriate nameplates. To
avoid such injury or damage, provide a relief valve for overpressure protection as required by government or accepted
industry codes and good engineering practices.

Instruction Manual
D100399X012
EW Valve
July 2017
5
Check with your process or safety engineer for any additional measures that must be taken to protect against process
media.
If installing into an existing application, also refer to the WARNING at the beginning of the Maintenance section in this
instruction manual.
CAUTION
When ordered, the valve configuration and construction materials were selected to meet particular pressure, temperature,
pressure drop and controlled fluid conditions. Responsibility for the safety of process media and compatibility of valve
materials with process media rests solely with the purchaser and end‐user. Since some body/trim material combinations
are limited in their pressure drop and temperature ranges, do not apply any other conditions to the valve without first
contacting your Emerson sales office or Local Business Partner.
Before installing the valve, inspect the valve and pipelines for any damage and any foreign material which may cause
product damage.
Table 4. Approximate Weights
END CONNECTION
VALVE SIZE, NPS
4X2 6X4 8X4 8X6 10X8 12X6 12X8
Kg Lb Kg Lb Kg Lb Kg Lb Kg Lb Kg Lb Kg Lb
CL300 (flanged only) 84 185 150 330 234 515 284 625 567 1250 500 1102 653 1440
CL600 Flanged 100 220 195 430 272 600 308 680 744 1640 721 1590 857 1890
Buttwelding 61 135 122 270 177 390 272 600 512 1130 526 1160 658 1450
CL900 Flanged ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ 612 1350 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ 1361 3000
Buttwelding ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ 454 1000 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ 1293 2850
CAUTION
If hoisting the valve, use a nylon sling to protect the surfaces. Carefully position the sling to prevent damage to the actuator
tubing and any accessories. Also, take care to prevent people from being injured in case the hoist or rigging slips
unexpectedly. Refer to table 4 for valve assembly weights. Be sure to use adequately sized hoists and chains or slings to
handle the valve.
1. Before installing the valve, inspect the valve body cavity and associated equipment for any damage and any foreign
material.
2. Make certain the valve body interior is clean, that pipelines are free of foreign material, and that the valve is
oriented so that pipeline flow is in the same direction as the arrow on the side of the valve.
3. Install the control valve assembly in any orientation unless limited by seismic criteria. However, the normal method
is with the actuator vertical above the valve. Other positions may result in uneven valve plug and cage wear and in
improper operation. With some valves, the actuator may also need to be supported when it is not vertical. For more
information, consult your Emerson sales office or Local Business Partner.
Note
If installing a valve with small internal flow passages, such as with WhisperFlo, Whisper Trim, or Cavitrol cages, consider installing
an upstream strainer to prevent the lodging of particles in these passages. This is especially important if the pipeline cannot be
thoroughly cleaned or if the flowing medium is not clean.

Instruction Manual
D100399X012
EW Valve
July 2017
6
4. Use accepted piping and welding practices when installing the valve in the line. For flanged valve bodies, use a
suitable gasket between the valve body and pipeline flanges.
CAUTION
Depending on valve body materials used, post weld heat treating may be required. If so, damage to internal elastomeric
and plastic parts, as well as internal metal parts is possible. Shrink‐fit pieces and threaded connections may also loosen. In
general, if post weld heat treating is to be performed, remove all trim parts. Contact your Emerson sales office or Local
Business Partner for additional information.
5. With a leak‐off bonnet construction, remove the pipe plugs (keys 14 and 16, figure 21) from the bonnet to hook up
the leak‐off piping. If continuous operation is required during inspection or maintenance, install a three‐valve
bypass around the control valve assembly.
6. If the actuator and valve are shipped separately, refer to the actuator mounting procedure in the appropriate
actuator instruction manual.
WARNING
Personal injury could result from packing leakage. Valve packing was tightened before shipment; however, the packing
might require some readjustment to meet specific service conditions. Check with your process or safety engineer for any
additional measures that must be taken to protect against process media.
Valves with ENVIRO‐SEAL live‐loaded packing or HIGH‐SEAL live‐loaded packing will not require this initial
re‐adjustment. See Fisher instruction manuals, ENVIRO‐SEAL Packing System for Sliding‐Stem Valves, D101642X012,
or HIGH‐SEAL Live‐Loaded Packing System, D101453X012, (as appropriate), for packing instructions. If you wish to
convert your present packing arrangement to ENVIRO‐SEAL packing, refer to the retrofit kits listed in the parts kit
sub‐section near the end of this manual.
Inverted Globe Valve Applications (Actuator below valve)
Due to space restrictions in your application, you may be required to mount the valve/actuator assembly in an inverted
orientation, with the actuator positioned below the valve. If so, the following procedures will help you with
disassembly and assembly techniques.
WARNING
Avoid personal injury or property damage caused by components dropping.
With the valve/actuator upside down, components may drop during disassembly or assembly. Be careful not to position
yourself below the valve in the path of falling parts.
As the bonnet/plug/cage is lowered from the valve body, the center of gravity will be above the lifting points. Take care to
prevent the assembly from tipping over as it is lowered. Either leave the actuator attached to the plug and bonnet, attach
straps to the stem, or provide other means to prevent tipping.
Disassembly
1. Provide adequate support to the actuator while removing it from the bonnet.

Instruction Manual
D100399X012
EW Valve
July 2017
7
2. Provide adequate support to the bonnet while removing the bonnet nuts.
3. Be aware that the bonnet/plug/cage may tip over as they are lowered from the valve body. Make provision to
prevent tipping.
4. Be aware that the cage and seat ring may not come out with the bonnet and plug/stem assembly. If this occurs,
make provision to support these parts, as they may fall out unexpectedly.
Assembly
1. Start this assembly procedure with the plug/stem assembly already installed in the bonnet.
2. Put the gaskets and cage onto the bonnet and plug.
3. Place the seat ring with the seat ring gasket onto the cage, if applicable with the valve design.
4. Raise this bonnet/plug/cage assembly up into the valve body. Make provision to prevent tipping of these parts as
they are being raised into the valve body.
5. Torque the bonnet nuts.
6. Mount the actuator.
Maintenance
Valve parts are subject to normal wear and must be inspected and replaced as necessary. Inspection and maintenance
frequency depends on the severity of service conditions. This section includes instructions for packing lubrication,
packing maintenance, trim maintenance, lapping metal seats, and ENVIRO‐SEAL bellows seal bonnet replacement. All
maintenance operations may be performed with the valve in the line.
WARNING
Avoid personal injury or property damage from sudden release of process pressure. Before performing any maintenance
operations:
D Do not remove the actuator from the valve while the valve is still pressurized.
D Always wear protective gloves, clothing, and eyewear when performing any maintenance operations to avoid personal
injury.
D Disconnect any operating lines providing air pressure, electric power, or a control signal to the actuator. Be sure the
actuator cannot suddenly open or close the valve.
D Use bypass valves or completely shut off the process to isolate the valve from process pressure. Relieve process pressure
on both sides of the valve. Drain the process media from both sides of the valve.
D Vent the pneumatic actuator loading pressure and relieve any actuator spring precompression.
D Use lock‐out procedures to be sure that the above measures stay in effect while you work on the equipment.
D The valve packing box may contain process fluids that are pressurized, even when the valve has been removed from the
pipeline. Process fluids may spray out under pressure when removing the packing hardware or packing rings, or when
loosening the packing box pipe plug.
D Check with your process or safety engineer for any additional measures that must be taken to protect against process
media.
CAUTION
Follow instructions carefully to avoid damaging the product surfaces, which could result in damage to the product.

Instruction Manual
D100399X012
EW Valve
July 2017
8
Note
Whenever a gasket seal is disturbed by removing or shifting gasketed parts, install a new gasket upon reassembly. This is necessary
to ensure a good gasket seal because the used gasket may not seal properly.
Figure 3. Lubricator and Lubricator/Isolating Valve (optional)
LUBRICATOR
LUBRICATOR/ISOLATING VALVE
10A9421‐A
AJ5428‐D
A0832‐2
Packing Lubrication
CAUTION
Do not lubricate graphite packing. Graphite packing is self-lubricated. Additional lubrication may result in slip-stick
movement of the valve.
Note
ENVIRO‐SEAL or HIGH‐SEAL packing does not require lubrication.
WARNING
To avoid personal injury or property damage resulting from fire or explosion, do not lubricate packing used in oxygen
service or in processes with temperatures over 260_C (500_F).
If a lubricator or lubricator/isolating valve (figure 3) is provided for PTFE/composition or other packings that require
lubrication, it will be installed in place of the pipe plug (key 14, figure 21). Use a good quality silicon‐base lubricant. Do
not lubricate packing used in oxygen service or in processes with temperatures over 260_C (500_F). To operate the
lubricator, simply turn the cap screw clockwise to force the lubricant into the packing box. The lubricator/isolating
valve operates the same way, except open the isolating valve before turning the cap screw and then close the isolating
valve after lubrication is completed.

Instruction Manual
D100399X012
EW Valve
July 2017
9
Figure 4. PTFE V‐Ring Packing Arrangements
UPPER WIPER
(KEY 12)
PACKING
FOLLOWER
(KEY 13)
WASHER
(KEY 10)
SPRING
(KEY 8)
PACKING BOX
RING (KEY 11)
FEMALE
ADAPTOR
PACKING RING
MALE
ADAPTOR
LOWER WIPER
FEMALE
ADAPTOR
PACKING RING
MALE
ADAPTOR
LOWER WIPER
UPPER WIPER
(KEY 12)
PACKING
FOLLOWER
(KEY 13)
SPACER
(KEY 8)
PACKING BOX
RING (KEY 11)
1
1
FOR S31600 (316 SST) OR
S17400 (17‐4PH SST)
METAL PACKING BOX PARTS
FOR ALL OTHER METAL PACKING
BOX PART MATERIALS
SINGLE ARRANGEMENTS
NOTE:
PACKING SET (KEY 6) (2 REQ'D FOR DOUBLE ARRANGEMENTS).
12A7837−A/IL
B2398
1
1
1
1
1
1
1
UPPER WIPER
(KEY 12)
PACKING
FOLLOWER (KEY 13)
LANTERN RING
(KEY 8)
PACKING BOX
RING (KEY 11)
MALE ADAPTOR
PACKING RING
FEMALE ADAPTOR
LOWER WIPER
ASSEMBLY 1
(POSITIVE
PRESSURES)
ASSEMBLY 2
(VACUUM) ASSEMBLY 3 (POSITIVE
PRESSURES
& VACUUM)
ASSEMBLY 1
(POSITIVE
PRESSURES)
ASSEMBLY 2
(VACUUM) ASSEMBLY 3 (POSITIVE
PRESSURES
& VACUUM)
ASSEMBLY 1
(POSITIVE
PRESSURES)
ASSEMBLY 2
(VACUUM) ASSEMBLY 3 (POSITIVE
PRESSURES
& VACUUM)
9.5 mm (3/8 INCH) STEM 12.7 mm (1/2 INCH) STEM 19.1, 25.4, OR 31.8 mm
(3/4, 1, OR 1‐1/4 INCH) STEM
DOUBLE ARRANGEMENTS
12A8187-C 12A7814-C 12A7839-A
B1428‐2

Instruction Manual
D100399X012
EW Valve
July 2017
10
Packing Maintenance
Note
For valves with ENVIRO‐SEAL live‐loaded packing, see the Fisher instruction manual, ENVIRO‐SEAL Packing System for Sliding‐Stem
Valves, D101642X012, for packing instructions. For valves with HIGH‐SEAL live‐loaded packing, see the Fisher instruction manual,
HIGH‐SEAL Live‐Loaded Packing System, D101453X012, for packing instructions.
Key numbers refer to figure 4 for PTFE V‐ring packing and to figure 5 for PTFE/composition packing, unless otherwise
indicated.
For spring‐loaded single PTFE V‐ring packing, the spring (key 8, figure 4) maintains a sealing force on the packing. If
leakage is noted around the packing follower (key 13, figure 4), check to be sure the shoulder on the packing follower
is touching the bonnet. If the shoulder is not touching the bonnet, tighten the packing flange nuts (key 5, figure 21)
until the shoulder is against the bonnet. If leakage cannot be stopped in this manner, go to the Replacing Packing
procedure.
Figure 5. Detail of PTFE/Composition Packing Arrangements
UPPER WIPER
(KEY 12)
PACKING
FOLLOWER
(KEY 13)
LANTERN RING
(KEY 8)
PACKING BOX
RING (KEY 11)
PACKING RING
(KEY 7)
9.5 mm
(3/8 INCH)
STEM
12.7 mm
(1/2 INCH)
STEM
19.1, 25.4, OR
31.8 mm
(3/4, 1, OR
1‐1/4 INCH) STEM
TYPICAL (DOUBLE) ARRANGEMENTS
12A8188‐A
12A7815‐A
12A8173‐A
A2619‐1
If there is undesirable packing leakage with other than spring‐loaded packing, first try to limit the leakage and
establish a stem seal by tightening the packing flange nuts.
If the packing is relatively new and tight on the stem and if tightening the packing flange nuts does not stop the
leakage, the valve stem may be worn or nicked so that a seal cannot be made. The surface finish of a new valve stem is
critical for making a good packing seal. If the leakage comes from the outside diameter of the packing, the leakage
may be caused by nicks or scratches around the packing box wall. If performing any of the following procedures,
inspect the valve stem and packing box wall for nicks and scratches.
Replacing Packing
WARNING
Avoid personal injury or property damage from sudden release of process pressure. Before performing any maintenance
operations:

Instruction Manual
D100399X012
EW Valve
July 2017
11
D Do not remove the actuator from the valve while the valve is still pressurized.
D Always wear protective gloves, clothing, and eyewear when performing any maintenance operations to avoid personal
injury.
D Disconnect any operating lines providing air pressure, electric power, or a control signal to the actuator. Be sure the
actuator cannot suddenly open or close the valve.
D Use bypass valves or completely shut off the process to isolate the valve from process pressure. Relieve process pressure
on both sides of the valve. Drain the process media from both sides of the valve.
D Vent the pneumatic actuator loading pressure and relieve any actuator spring precompression.
D Use lock‐out procedures to be sure that the above measures stay in effect while you work on the equipment.
D The valve packing box may contain process fluids that are pressurized, even when the valve has been removed from the
pipeline. Process fluids may spray out under pressure when removing the packing hardware or packing rings, or when
loosening the packing box pipe plug.
D Check with your process or safety engineer for any additional measures that must be taken to protect against process
media.
1. Isolate the control valve from the line pressure, release pressure from both sides of the valve, and drain the process
media from both sides of the valve. If using a power actuator, also shut‐off all pressure lines to the power actuator
and release all pressure from the actuator. Use lock‐out procedures to be sure that the above measures stay in
effect while you work on the equipment.
2. Disconnect the operating lines from the actuator and any leak‐off piping from the bonnet. Disconnect the stem
connector, and then remove the actuator from the valve by unscrewing the yoke locknut (key 15, figure 21) or the
hex nuts (key 26, figure 21).
3. Loosen the packing flange nuts (key 5, figure 21) so that the packing is not tight on the valve stem. Remove any
travel indicator parts and stem locknuts from the valve stem threads.
WARNING
To avoid personal injury or property damage caused by uncontrolled movement of the bonnet, loosen the bonnet by
following the instructions in the next step. Do not remove a stuck bonnet by pulling on it with equipment that can stretch
or store energy in any other manner. The sudden release of stored energy can cause uncontrolled movement of the bonnet.
Note
The following step also helps to provide additional assurance that the valve body fluid pressure has been relieved.
4. Hex nuts (key 16, figure 22, 23 or 24) attach the bonnet (key 1, figure 21) to the valve body (key 1, figure 22, 23 or
24). Loosen these nuts approximately 3 mm (1/8 inch). Then loosen the body‐to‐bonnet gasketed joint by either
rocking the bonnet or prying between the bonnet and valve body. Work the prying tool around the bonnet until the
bonnet loosens. If no fluid leaks from the joint, proceed with bonnet removal as described in the following steps.
CAUTION
To avoid damage to the seating surface caused by the valve plug and stem assembly dropping from the bonnet after being
lifted part way out, temporarily install a valve stem locknut on the valve stem when lifting the bonnet. The locknut
prevents the valve plug and stem assembly from dropping out of the bonnet.
5. Completely remove the hex nuts (key 16) and carefully lift the bonnet off the valve body.

Instruction Manual
D100399X012
EW Valve
July 2017
12
6. Remove the locknut and separate the valve plug and stem from the bonnet. Set the parts on a protective surface to
prevent damage to gasket or seating surfaces.
7. Remove the bonnet gasket (key 10, figure 22 through 24), and cover the opening in the valve body to protect the
gasket surface and prevent foreign material from getting into the valve body cavity.
8. Remove the packing flange nuts, packing flange, upper wiper, and packing follower (keys 5, 3, 12, and 13, figure
21). Carefully push out all the remaining packing parts from the valve side of the bonnet using a rounded rod or
other tool that will not scratch the packing box wall. Clean the packing box and the metal packing parts.
9. Inspect the valve stem threads and packing box surfaces for any sharp edges that might cut the packing. Scratches
or burrs could cause packing box leakage or damage to the new packing. If the surface condition cannot be
improved by light sanding, replace the damaged parts by following the appropriate steps in the Trim Maintenance
procedure.
10. Remove the covering protecting the valve cavity and install a new bonnet gasket (key 10, figure 22 through 24),
making sure the gasket seating surfaces are clean and smooth. Place the stem and valve plug into the valve body
and slide the bonnet over the stem and onto the stud bolts (key 15, figure 22, 23, or 24).
Figure 6. Detail of Graphite Ribbon/Filament Packing
NOTES:
0.102 mm (0.004 INCH) THICK SACRIFICIAL ZINC WASHERS;
USE ONLY ONE BELOW EACH GRAPHITE RIBBON RING.
PACKING
FOLLOWER
(KEY 13)
LANTERN
RING (KEY 8)
PACKING BOX
RING (KEY 11)
1
12.7 mm
(1/2 INCH)
STEM
SINGLE ARRANGEMENTS
A6067
GRAPHITE
RIBBON
PACKING RING
(KEY 7)
GRAPHITE
FILAMENT
PACKING RING
(KEY 7)
1
19.1, 25.4, & 31.8 mm
(3/4, 1 & 1‐1/4 INCH)
STEM
13A9775-B 13A9776-B
PACKING
FOLLOWER
(KEY 13)
LANTERN
RING (KEY 8)
PACKING BOX
RING (KEY 11)
1
12.7 mm
(1/2 INCH)
STEM
DOUBLE ARRANGEMENTS
GRAPHITE
RIBBON
PACKING RING
(KEY 7)
GRAPHITE
RIBBON
PACKING RING
(KEY 7)
GRAPHITE
FILAMENT
PACKING RING
(KEY 7)
1
19.1, 25.4, & 31.8 mm
(3/4, 1 & 1‐1/4 INCH)
STEM
14A1849-B 14A1780-B
1
1

Instruction Manual
D100399X012
EW Valve
July 2017
13
Note
Proper performance of the tightening procedures in step 11 compresses the spiral wound gasket (key 12, figure 22 through 23) or
load ring (key 26, figure 24) enough to both load and seal the seat ring gasket (key 13, figure 22, 23 or 24). It also compresses the
outer edge of the bonnet gasket (key 10, figure 22 through 24) enough to seal the body‐to‐bonnet joint.
The proper bolting procedures in step 11 include‐‐but are not limited to‐‐ensuring that bolting threads are clean, and evenly
tightening the nuts onto the studs in a criss‐cross pattern. Because of the bolt‐up characteristics of spiral wound gaskets,
tightening one nut may loosen an adjacent nut. Repeat the criss‐cross tightening pattern several times until each nut is tight and
the body‐to‐bonnet seal is made. When the operating temperature has been reached, perform this torquing procedure once
again.
Note
Stud(s) and nut(s) should be installed such that the manufacturer's trademark and material grade marking is visible, allowing easy
comparison to the materials selected and documented in the Emerson/Fisher serial card provided with this product.
WARNING
Personal injury or damage to equipment could occur if improper stud and nut materials or parts are used. Do not operate or
assemble this product with stud(s) and nut(s) that are not approved by Emerson/Fisher engineering and/or listed on the
serial card provided with this product. Use of unapproved materials and parts could lead to stresses exceeding the design
or code limits intended for this particular service. Install studs with the material grade and manufacturer's identification
mark visible. Contact your Emerson Automation Solutions representative immediately if a discrepancy between actual
parts and approved parts is suspected.
11. Lubricate the bolting (not necessary if factory pre‐lubricated stud bolt nuts are used) and install it, using proper
bolting procedures during tightening so that the body‐to‐bonnet joint will withstand test pressures and application
service conditions. Use the bolt torques in table 5 as guidelines.
12. Install new packing and the metal packing box parts according to the appropriate arrangement in figure 4, 5, or 6.
Place a smooth‐edged pipe over the valve stem and gently tap each soft packing part into the packing box.
13. Slide the packing follower, upper wiper, and packing flange (keys 13, 12, and 3, figure 21) into position. Lubricate
the packing flange studs (key 4, figure 21) and the faces of the packing flange nuts (key 5, figure 21). Install the
packing flange nuts.
14. For spring‐loaded PTFE V‐ring packing, tighten the packing flange nuts until the shoulder on the packing follower
(key 13, figure 21) contacts the bonnet.
For graphite packing, tighten the packing flange nuts to the maximum recommended torque shown in table 6. Then,
loosen the packing flange nuts, and retighten them to the recommended minimum torque shown in table 6.
For ENVIRO‐SEAL or HIGH‐SEAL live‐loaded packing, refer to the note at the beginning of the Packing Maintenance
section.
For other packing types, tighten the packing flange nuts alternately in small equal increments until one of the nuts
reaches the minimum recommended torque shown in table. Then, tighten the remaining flange nuts until the packing
flange is level and at a 90‐degree angle to the valve stem.
15. Mount the actuator on the valve assembly, and reconnect the actuator and valve stem according to the procedure
in the appropriate actuator instruction manual.

Instruction Manual
D100399X012
EW Valve
July 2017
14
Trim Maintenance
WARNING
Avoid personal injury or property damage from sudden release of process pressure. Before performing any maintenance
operations:
D Do not remove the actuator from the valve while the valve is still pressurized.
D Always wear protective gloves, clothing, and eyewear when performing any maintenance operations to avoid personal
injury.
D Disconnect any operating lines providing air pressure, electric power, or a control signal to the actuator. Be sure the
actuator cannot suddenly open or close the valve.
D Use bypass valves or completely shut off the process to isolate the valve from process pressure. Relieve process pressure
on both sides of the valve. Drain the process media from both sides of the valve.
D Vent the pneumatic actuator loading pressure and relieve any actuator spring precompression.
D Use lock‐out procedures to be sure that the above measures stay in effect while you work on the equipment.
D The valve packing box may contain process fluids that are pressurized, even when the valve has been removed from the
pipeline. Process fluids may spray out under pressure when removing the packing hardware or packing rings, or when
loosening the packing box pipe plug.
D Check with your process or safety engineer for any additional measures that must be taken to protect against process
media.
Table 5. Body‐to‐Bonnet Bolt Torque Guidelines
VALVE SIZE, NPS BOLT TORQUES(1, 2)
NSm LbfSft
4x2 102 75
6x4 or 8x4 259 191
8x6 CL300 or CL600 548 404
CL900 1315 970
10x8 745 550
12x6 548 404
12x8 CL300 or CL600 732 540
CL900 2712 2000
1. Determined from laboratory tests.
2. For other materials, contact your Emerson sales office or Local Business Partner for torques.
Table 6. Recommended Torque for Packing Flange Nuts
VALVE STEM
DIAMETER PRESSURE
RATING
GRAPHITE TYPE PACKING PTFE TYPE PACKING
Minimum Torque Maximum Torque Minimum Torque Maximum Torque
mm Inches NSm LbfSIn NSm LbfSIn NSm LbfSIn NSm LbfSIn
12.7 1/2 CL300 7 59 10 88 3 28 5 42
12.7 CL600 9 81 14 122 4 39 7 58
19.1 3/4 CL300 15 133 23 199 7 64 11 95
19.1 CL600 21 182 31 274 10 87 15 131
25.4 1CL300 26 226 38 339 12 108 18 162
25.4 CL600 35 310 53 466 17 149 25 223
31.8 1‐1/4 CL300 36 318 54 477 17 152 26 228
31.8 CL600 49 437 74 655 24 209 36 314

Instruction Manual
D100399X012
EW Valve
July 2017
15
CAUTION
In the following applicable procedures, to avoid damaging parts, do not grip the bellows shroud or other parts of the
stem/bellows assembly. Grip only the flat areas on the stem where it extends out of the top of the bellows shroud.
For C‐seal construction, see the appropriate C‐seal sections in this instruction manual.
Except where indicated, key numbers in this section are referenced in figure 22 for EWD constructions, figure 22 for
restricted trim detail, figure 23 for EWS constructions, and figure 24 for EWT constructions. Refer to figures 26 and 27
for Cavitrol III, figure 27 for Whisper Trim III, and figure 29 for WhisperFlo construction.
Trim Removal
1. Remove the actuator and the bonnet according to steps 1 through 5 of the Replacing Packing procedure.
WARNING
Avoid personal injury or property damage from valve or packing leakage.
When lifting the valve plug stem (key 7) and attached valve plug (key 2) out of the valve, be certain that the cage (key 3)
remains in the valve (key 1). This will prevent cage damage that might be caused by the cage dropping back into the valve
after being lifted part way out.
Use care to avoid damaging gasket sealing surfaces.
Each graphite piston ring (key 6) in an EWD valve is brittle and in two pieces. Use care to avoid damage to the piston ring(s)
caused by dropping or rough handling.
Any damage to the gasket sealing surfaces could cause the valve to leak. The surface finish of the valve stem (key 7) is
critical for making a good packing seal. The inside surface of the cage or cage/baffle assembly (key 3) or cage retainer (key
31) is critical for smooth operation of the valve plug and for making a seal with the piston ring (key 6) or seal ring (key 28).
The seating surfaces of the valve plug (key 2) and the seat ring (key 9) on a metal‐seat construction are critical for tight
shutoff. Protect these parts accordingly while disassembling the trim.
2. Remove the packing flange nuts, packing flange, upper wiper, and packing follower (keys 5, 3, 24, and 25, figure
21). Carefully push out all the remaining packing parts from the valve side of the bonnet using a rounded rod or
other tool that will not scratch the packing box wall. Clean the packing box and the metal packing parts.
3. Inspect the valve stem threads and packing box surfaces for any sharp edges which might cut the packing.
Scratches or burrs could cause packing box leakage or damage to the new packing. If the surface condition cannot
be improved by light sanding, replace the damaged parts.
4. Remove the load ring (key 26) from an NPS 10x8 or 12x8 valve or the cage adaptor (key 4) from any restricted‐trim
valve through NPS 8x4, and wrap it for protection.
5. On a 102 mm (4‐inch) travel valve with Whisper Trim I cage or on any NPS 8x6 or 12x6 valve with Whisper Trim III
cage, remove the bonnet spacer (key 32) and bonnet gasket (key 10) on top of the spacer. Then on any
construction with a cage retainer (key 31), remove the cage retainer and its associated gaskets. A Whisper Trim III
cage retainer has two 3/8‐inch ‐ 16 UNC tappings in which screws or bolts can be installed for lifting.
6. Remove the cage or cage/baffle assembly (key 3) and the associated gaskets (keys 10, 11, and 12). With
full‐capacity constructions that have FGM gasket sets, a shim (key 53) is used instead of the cage gasket (key 11). If
the cage is stuck in the valve, use a rubber mallet to strike the exposed portion of the cage at several points around
its circumference.

Instruction Manual
D100399X012
EW Valve
July 2017
16
Figure 7. TSO (Tight Shutoff Trim), Detail of Protected Soft Seat
INNER PLUG
OUTER PLUG
CAGE
SEAT RING
PROTECTED SOFT SEAT
A7088
7. For constructions other than TSO (tight shutoff trim), remove the seat ring (key 9) or disk seat (key 22), seat ring
gasket (key 13), and the seat ring adaptor (key 5) and adaptor gasket (key 14) where used in a restricted‐capacity
construction. EWS and EWT PTFE‐seat constructions use a disk (key 23) sandwiched between the disk seat and disk
retainer (key 21). A CL900 NPS 8x6 EWT construction with Cavitrol III cage has its spiral wound gasket (key 12) on
the side of the seat ring opposite the seat ring gasket.
8. For TSO (tight shutoff trim) constructions, perform the following steps (refer to figures 7 and 8):
D Remove the piston ring, anti‐extrusion rings, backup ring, and retainer.
D Remove the set screws that lock the outer plug to the inner plug.
D Using a strap wrench or similar tool, unscrew the outer plug from the inner plug. Do not damage the outer plug
guide surfaces.
D Remove the protected soft seat seal.
D Inspect the parts for damage and replace if needed.
9. For all constructions, inspect parts for wear or damage that would prevent proper operation of the valve. Replace or
repair trim parts according to the following procedures for lapping metal seats or other valve plug maintenance
procedures, as appropriate.
Lapping Metal Seats
CAUTION
To avoid damaging the ENVIRO‐SEAL bellows seal bonnet assembly, do not attempt to lap the metal seating surfaces. The
design of the assembly prevents rotation of the stem and any forced rotation will damage internal components of the
ENVIRO‐SEAL bellows seal bonnet.

Instruction Manual
D100399X012
EW Valve
July 2017
17
Figure 8. Typical Balanced TSO Trim
VALVE PLUG
SEAL
PROTECTED
SOFT SEAT
A7096
Except with respect to the ENVIRO‐SEAL Bellows Seal Bonnet assembly, with metal seat constructions, seating surfaces
of the valve plug and seat ring (keys 2 and 9, figures 24 through 26) can be lapped for improved shutoff. (Deep nicks
should be machined out rather than ground out.) Use a good quality lapping compound of a mixture of 280 to
600‐grit. Apply the compound to the bottom of the valve plug.
Assemble the valve to the extent that the cage (and cage retainer and bonnet spacer, if used) is in place and the
bonnet is bolted to the valve. A simple handle can be made from a piece of strap iron locked to the valve plug stem
with nuts. Rotate the handle alternately in each direction to lap the seats. After lapping, remove the bonnet, and clean
the seat surfaces. Completely assemble the valve as described in the Trim Replacement portion of the Trim
Maintenance section, and test the valve for shutoff. Repeat the lapping procedure if leakage is still excessive.
Valve Plug Maintenance
Except where indicated, key numbers in this section are referenced in figure 22 for EWD valve plugs, figure 23 for EWS
valve plugs, and figure 24 for EWT valve plugs.
CAUTION
If replacing the piston ring (key 6) or seal ring (key 28), be careful not to scratch the surfaces of the ring groove in the valve
plug or any of the surfaces of the replacement ring, or the replacement ring may not seal properly.
1. With the valve plug (key 2) removed, according to the Trim Removal section, proceed as appropriate:

Instruction Manual
D100399X012
EW Valve
July 2017
18
For the EWD carbon‐filled PTFE piston ring, the ring is split in one place. If there is visible damage, spread the ring
slightly, and remove it from the groove in the valve plug. To install a carbon‐filled PTFE piston ring, spread the ring
apart slightly at the split, and install it over the stem and into the groove in the valve plug. The open side must face
along the stem, depending on flow direction, as shown in figure 22.
For each EWD graphite piston ring, the ring can be easily removed since it is in two pieces. A new graphite piston ring is
furnished as a complete ring. Use a vise with smooth or taped jaws to break this replacement ring into halves. Place the
new ring in the vise so that the jaws will compress the ring into an oval. Slowly compress the ring until it snaps on both
sides. If one side snaps first, do not try to tear or cut the other side. Instead, keep compressing the ring until the other
side snaps. Be sure to match the broken ends when installing the ring in the valve plug groove.
For the EWT two‐piece seal ring, the ring cannot be reused as it is a closed ring, which must be pried and/or cut from
the groove. Then the elastomeric backup ring (key 29) can be spread slightly and removed.
To install a new two‐piece seal ring, apply a general purpose silicone‐base lubricant to both the backup ring and seal
ring (keys 29 and 28). Place the backup ring over the stem (key 7) and into the groove. Place the seal ring over the top
edge of the valve plug (key 2) so that it enters the groove on one side of the valve plug. Slowly and gently stretch the
seal ring, and work it over the top edge of the valve plug. The PTFE material in the seal ring must be permitted time to
cold‐flow during the stretching procedure; so avoid jerking sharply on this ring. Stretching the seal ring over the valve
plug may make it seem unduly loose when in the groove, but it will contract to its original size after insertion into the
cage.
For the EWT spring‐loaded seal ring, the ring used on a valve plug having a 136.5 mm (5.375 inch) or less port
diameter may be removed undamaged by first working the retaining ring (key 27) off with a screwdriver. Then
carefully slide the metal backup ring (key 29) and seal ring (key 28) off the valve plug (key 2). The spring‐loaded seal
ring used on a valve plug having a 178 mm (7‐inch) or greater port diameter must be carefully pried and/or cut from its
groove. Therefore, it cannot be reused.
A spring‐loaded seal ring must be installed so that its open side faces toward either the top or the bottom of the valve
plug, depending on flow direction, as shown in view A of figure 24. To install a spring‐loaded seal ring on a valve plug
with a 136.5 mm (5.375 inch) or less port diameter, slide the seal ring (key 28) onto the valve plug followed by the
metal backup ring (key 29). Then install the retaining ring (key 27) by inserting one end in the groove and, while
turning the plug, press the ring into the groove. Again, be careful not to scratch any surfaces of the ring or plug.
To install the seal ring on a valve plug with 178 mm (7‐inch) or greater port diameter, lubricate it with a general
purpose silicone‐base lubricant. Then gently stretch the seal ring, and work it over the top edge of the valve plug. The
PTFE material in the seal ring must be permitted time to cold‐flow during the stretching procedure; so avoid jerking
sharply on the ring. Stretching the seal ring over the valve plug may make it seem unduly loose when in the groove,
but it will contract to its original size after insertion into the cage.
CAUTION
Never reuse an old stem or adaptor with a new valve plug. Using an old stem or adaptor with a new plug requires drilling a
new pin hole in the stem (or adaptor in case an ENVIRO‐SEAL bellows seal bonnet is being used). This drilling weakens the
stem or adaptor and may cause failure in service. However, a used valve plug may be reused with a new stem or adaptor
except with Cavitrol III trim.
Note
The valve plug and valve plug stem for Cavitrol III trim are a matched set and must be ordered together. If the Cavitrol III valve plug
or valve plug stem is damaged, replace the entire assembly (key 2, figure 26 and 27).
2. To replace the valve stem (key 7), drive out the pin (key 8). Unscrew the valve plug from the stem or adaptor.

Instruction Manual
D100399X012
EW Valve
July 2017
19
3. To replace the adaptor (key 24, figure 21) on ENVIRO‐SEAL bellows seal bonnets, place the plug stem assembly and
valve plug in a soft‐jaw chuck or other type of vise so that the jaws grip a portion of the valve plug that is not a
seating surface. Drive out the pin (key 36, figure 21). Reverse the plug stem assembly and valve plug in the soft‐jaw
chuck or vise. Grip the flat areas on the valve stem just below the threads for the actuator/stem connection.
Unscrew the valve plug/adaptor assembly (key 24, figure 21) from the valve stem assembly (key 20, figure 21).
4. Screw the new stem or adaptor into the valve plug. Tighten to the torque value given in table 7. Refer to table 7 to
select the proper drill size. Drill through the stem or adaptor, using the hole in the valve plug as a guide. Remove
any chips or burrs, and drive in a new pin to lock the assembly.
5. For ENVIRO‐SEAL bellows seal bonnets, grip the flats of the stem extending out of the top of the bellows shroud
with a soft‐jaw chuck or other type of vise. Screw the valve plug/adaptor assembly onto the valve stem. Tighten as
necessary to align the pin hole in the stem with one of the holes in the adaptor. Secure the adaptor to the stem with
a new pin.
Trim Replacement
Except where indicated, key numbers in this section are referenced in figure 22 for EWD constructions, figure 22 for
restricted trim detail, figure 23 for EWS construction, and figure 24 for EWT constructions. Refer to figures 26 and 27
for Cavitrol III, figure 28 for Whisper Trim III, and figure 29 for WhisperFlo constructions.
1. With a restricted‐trim seat ring construction, install the adaptor gasket (key 14) and seat ring adaptor (key 5).
2. Install the seat‐ring gasket (key 13), seat ring (key 9), or disk seat (key 22). With a PTFE‐seat construction install the
disk and disk retainer (keys 21 and 23). With an NPS 8x6 CL900 EWT valve with Cavitrol III cage, install the spiral
wound gasket (key 12) on the seat ring.
3. Install the cage or cage/baffle assembly (key 3). Any rotational orientation of the cage or assembly with respect to
the valve is acceptable. A Whisper Trim III cage designated by level A3, B3, or C3 may be installed with either end
up. The level D3 cage/baffle assembly or Cavitrol III cage assembly, however, must be installed with the hole pattern
end next to the seat ring. If a cage retainer (key 31) is to be used, place it on top of the cage.
4. For constructions other than TSO (tight shutoff trim), slide the valve plug (key 2) and stem assembly or valve plug
and ENVIRO‐SEAL bellows seal assembly into the cage. Make sure the piston ring or seal ring (key 6 or 28) is evenly
engaged in the entrance chamfer at the top of the cage (key 3) or cage retainer (key 31) to avoid damaging the ring.
5. For TSO (tight shutoff) trim constructions, perform the following steps (refer to figures 7 and 8).
D Thread the outer plug onto the inner plug until the parts seat metal to metal, using a strap wrench or similar tool
that will not damage the outer plug guide surfaces.
D Mark the top of the inner plug and outer plug with alignment marks in the assembled position.
Table 7. Valve Stem to Plug Torque and Pin Replacement Data
VALVE STEM DIAMETER STEM TORQUE, MINIMUM TO MAXIMUM DRILL SIZE, INCHES
mm Inch NSm LbfSft
12.7 1/2 81 to 115 60 to 85 1/8
19.1 3/4 237 to 339 175 to 250 3/16
25.4 1 420 to 481 310 to 355 1/4
31.8 1‐1/4 827 to 908 610 to 670 1/4
D Disassemble the outer plug from the inner plug and install the seal over the inner plug, so that the seal rests below
the threaded area.
D Thread the outer plug onto the inner plug and tighten with a strap wrench or similar tool until the alignment marks
line up. This will ensure that the plug parts are metal to metal and the seal is compressed properly. Do not damage
the outer plug guide surfaces.
D Install set screws centering the inner plug in the outer plug and torque to 11 NSm (8 lbfSft).

Instruction Manual
D100399X012
EW Valve
July 2017
20
D Assemble the piston ring, anti‐extrusion rings, backup ring, and retainer.
6. For all constructions, place the gaskets (keys 12, 11 or 14 if used, and 10) and the shim, if used (key 53), on top of
the cage or cage retainer. If there is a cage adaptor (key 4) or a bonnet spacer (key 32), set it on the cage or cage
retainer gaskets and place another flat sheet gasket (key 10) on top of the adapter or spacer. If there is only a cage
retainer or bonnet spacer, place another flat sheet gasket on the retainer or spacer.
7. With an NPS 10x8 or 12x8 valve, install the load ring (key 26).
8. Mount the bonnet on the valve, and complete assembly according to steps 11 through 15 of the Replacing Packing
section. Be sure to observe the note prior to step 11.
Retrofit: Installing C‐seal Trim
Note
Additional actuator thrust is required for a valve with C‐seal trim. When installing C‐seal trim in an existing valve, contact your
Emerson sales office or Local Business Partner for assistance in determining new actuator thrust requirements.
Assemble the new valve plug/retainer assembly (with C‐seal plug seal) using the following instructions:
CAUTION
To avoid leakage when the valve is returned to service, use appropriate methods and materials to protect all sealing
surfaces of the new trim parts while assembling the individual parts and during installation in the valve body.
1. Apply a suitable high‐temperature lubricant to the inside diameter of the C‐seal plug seal. Also, lubricate the
outside diameter of the valve plug where the C‐seal plug seal must be pressed into the proper sealing position
(figure 9).
2. Orient the C‐seal plug seal for correct sealing action based on the process fluid flow direction through the valve.
D The open interior of the C‐seal plug seal must face up in a valve with flow‐up construction (figure 9).
D The open interior of the C‐seal plug seal must face down in a valve with flow‐down construction (figure 9).
Note
An installation tool must be used to properly position the C‐seal plug seal on the valve plug. A tool is available as a spare part from
Emerson or a tool could be manufactured following the dimensions given in figure 10.
3. Place the C‐seal plug seal over the top of the valve plug and press the C‐seal plug seal onto the plug using the C‐seal
installation tool. Carefully press the C‐seal plug seal onto the plug until the installation tool contacts the horizontal
reference surface of the valve plug (figure 11).
4. Apply a suitable high‐temperature lubricant to the threads on the plug. Then, place the C‐seal retainer onto the
plug and tighten the retainer using an appropriate tool such as a strap wrench.
5. Using an appropriate tool such as a center punch, stake the threads on top of the plug in one place (figure 12) to
secure the C‐seal retainer.
