Emerson FISHER 119 Series User manual

119 Series
Installation Guide
D100261X014
English –June 2018
Introduction
This installation guide provides instructions for
installation, startup and adjustment. To receive a copy of
the Instruction Manual, contact your local Sales Office or
view a copy at www.fisher.com. For further information
refer to: 119 Series Instruction Manual, D100261X012.
PED Categories
This product may be used as a safety accessory
with pressure equipment in the following Pressure
Equipment Directive categories. It may also be used
outside of the Pressure Equipment Directive using
sound engineering practice (SEP) per table below.
For information on the current PED revision see
Bulletin: D103053X012.
PRODUCT SIZE CATEGORIES FLUID TYPE
DN 20 and 25 / NPS 3/4 and 1 SEP 1
Specifications
Available Configuration
Type 119: Direct-operated valve used for on-
off or throttling control of noncorrosive or mildly
corrosive liquids and gases
Type 119EZ: Direct-operated valve with adjustable
opening speed for reliable startup operation on
gas burner systems
Type 119EZS: Type 119EZ equipped with solenoid
for valve to be operated by local control system
Body Sizes and End Connection Styles
Type 119:
BODY SIZE, NPT BODY MATERIAL
3/4 Cast Iron, WCC Steel
1
1-1/4 Cast Iron
Types 119EZ and 119EZS:
BODY SIZE, NPT BODY MATERIAL
1 Cast Iron, CF8M Stainless Steel
Maximum Inlet Pressure(1)
10.3 bar / 150 psig
Spring Ranges
0.2 to 1.0 bar / 3 to 5 psig
0.3 to 1.4 bar / 5 to 20 psig
0.3 to 2.4 bar / 5 to 35 psig
2.1 to 4.1 bar / 30 to 60 psig
Maximum Control Pressure to Diaphragm
10.3 bar / 150 psig
Maximum Pressure Drop(1)
10.3 bar / 150 psig for all port diameters
7.9 bar / 115 psig for Type 119EZS with
ASCO™ 8320 Series solenoid
Proof Test Pressure
All Pressure Retaining Components have been
proof tested per Directive
Material Temperature Capabilities(1)(2)
Type 119:
MATERIAL TEMPERATURE RANGE
Nitrile (NBR) -29 to 82°C / -20 to 180°F
Fluorocarbon (FKM)(3) -18 to 121°C / 0 to 250°F
Types 119EZ and 119EZS:
MATERIAL TEMPERATURE RANGE
Nitrile (NBR)(4) -40 to 82°C / -40 to 180°F
Fluorocarbon (FKM)(3) -18 to 121°C / 0 to 250°F
Type 119EZS Solenoid Temperature Capabilities(1)
ASCO 8320 Series Solenoid:
0 to 52°C / 32 to 125°F
ASCO 8314 Series Solenoid:
-25 to 55°C / -13 to 131°F
Installation
!
WARNING
Only qualified personnel should install
or service a valve. Valves should be
installed, operated and maintained
in accordance with international and
applicable codes and regulations, and
Emerson Process Management Regulator
Technologies Inc. instructions.
If the valve vents fluid or a leak develops
in the system, it indicates that service
is required. Failure to take the valve out
of service immediately may create a
hazardous condition.
Personal injury, equipment damage
or leakage due to escaping fluid or
bursting of pressure-containing parts
may result if this valve is overpressured
or is installed where service conditions
could exceed the limits given in the
Specifications section, or where
conditions exceed any ratings of the
adjacent piping or piping connections.
1. The pressure/temperature limits in this Installation Guide, ASCO solenoid documentation and any applicable standard or code limitation should not be exceeded.
2. Pressure and/or the body end connection may decrease these maximum temperatures.
3. Not for use with hot water or Ammonia (NH3).
4. Minimum temperature for cast iron body is -29°C / -20°F.

119 Series
2
To avoid such injury or damage, provide
pressurerelieving or pressure-limiting
devices (as required by the appropriate
code, regulation or standard) to
prevent service conditions from
exceeding limits.
Additionally, physical damage to the
valve could result in personal injury and
property damage due to escaping fluid.
To avoid such injury and damage, install
the valve in a safe location.
Clean out all pipelines before installation of the valve
and check to be sure the valve has not been damaged
or has collected foreign material during shipping. For
NPT bodies, apply pipe compound to the external pipe
threads. For flanged bodies, use suitable line gaskets
and approved piping and bolting practices. Install
the valve in any position desired, unless otherwise
specified, but be sure flow through the body is in the
direction indicated by the arrow on the body.
Note
It is important that the valve be installed
so that the vent hole in the spring case
is unobstructed at all times. For outdoor
installations, the valve should be
located away from vehicular traffic and
positioned so that water, ice and other
foreign materials cannot enter the spring
case through the vent. Avoid placing
the valve beneath eaves or downspouts
and be sure it is above the probable
snow level.
Overpressure Protection
The recommended pressure limitations are stamped
on the valve nameplate. Some type of overpressure
protection is needed if the actual inlet pressure
exceeds the maximum operating outlet pressure
rating. Overpressure protection should also be
provided if the valve inlet pressure is greater than the
safe working pressure of the downstream equipment.
Valve operation below the maximum pressure
limitations does not preclude the possibility of
damage from external sources or debris in the line.
The valve should be inspected for damage after any
overpressure condition.
Startup
The valve is factory set at approximately the midpoint
of the spring range or the pressure requested, so
an initial adjustment may be required to give the
desired results.
With proper installation completed and relief valves
properly adjusted, slowly open the upstream and
downstream shutoff valves.
Adjustment
To change the control pressure, remove the closing
cap or loosen the locknut and turn the adjusting
screw clockwise to increase control pressure or
counterclockwise to decrease pressure. Monitor
the control pressure with a test gauge during the
adjustment. Replace the closing cap or tighten the
locknut to maintain the desired setting.
Taking Out of Service (Shutdown)
!
WARNING
To avoid personal injury resulting from
sudden release of pressure, isolate
the valve from all pressure before
attempting disassembly.
Parts List
Key Description
1 Valve Body
2 Spring Case
3* Orifice
4* Disk Holder Assembly
5* Diaphragm/Stem Assembly
6 Hair Pin Clip
7 Bushing Spacer
8* O-ring
9 Bonnet
10 Internal Retaining Ring
11* Bonnet O-ring
12 Adjusting Screw
13 Locknut
14 Cap Screw
15 Cap Screw (not shown)
16 Actuator Spring
17 Upper Spring Seat
18 Type Y602-12 Vent (not shown)
19 Stem Wiper
20 Nameplate
23 Vent Screen (not shown)
24 NACE Tag
25 O-ring (Types 119EZ and 119EZS only)
26 Check Valve (Types 119EZ and 119EZS only)
27 Retaining Ring (Types 119EZ and 119EZS only)
28 Restrictor Screw (Types 119EZ and 119EZS only)
29 Solenoid Valve (Types 119EZ and 119EZS only)
30 Connector (Type 119EZS only)
31 Tubing (Type 119EZS only)
32 Tag Wire (not shown)
33 Drive Screw (not shown)
34 Flow Arrow (not shown)
35 Pipe Plug (Types 119EZ and 119EZS only)
* Recommended spare parts

119 Series
3
Figure 2. Types 119EZ and 119EZS Fuel Gas Valve Assembly
APPLY LUBRICANT(1)
1. Lubricant must be selected such that they meet the temperature requirements.
ERAA14665
TYPE 119EZ
Figure 1. Type 119 Fuel Gas Valve Assembly
37A8078-D
APPLY LUBRICANT(1)
L1 = Anti-seize compound lubricant
L2 = Silicone grease lubricant
1. Lubricants must be selected such that they meet the temperature requirements.
17
16
12
13
2
14
20
9
8
7
6
3
1
10
5
19
11
4
L1
L1
L1
L2
15
28
27
25
L
1
3
7
8
9
6
20
26
14
2
13
12
L
L
L
L
4
11
19
35
10
5
16
17
15
28
27
25
L
1
3
7
8
9
6
20
26
14
2
13
12
L
L
L
L
4
11
19
35
10
5
16
17

119 Series
Emerson Automation Solutions
Fisher.com
Americas
McKinney, Texas 75070 USA
T [phone]
[phone]
Europe
Bologna 40013, Italy
T [phone]
Asia Pacic
Singapore 128461, Singapore
T [phone]
Middle East and Africa
Dubai, United Arab Emirates
T [phone]
Figure 2. Types 119EZ and 119EZS Fuel Gas Valve Assembly (continued)
ERAA20310
TYPE 119EZS
30
TYPE 119EZ
30
31
29
For further information on the current
PED revision see Bulletin: D103053X012
or scan the QR code.
